AM7315 & AM7200
High-Powered 3-Way & Mid-high loudspeakers
AL7115
Low-Frequency Module
AM7212 & AM7215
Medium- Powered Two - Way Full - Range Loudspeakers
AM5212 & AM5215
Medium-Power 2-Way Full-Range Loudspeakers
ASB
High- Powered Subwoofers
AE SERIES
application engin eered
ASB6112 ASB6115 ASB6125 ASB7118 ASB7128
System Type:
Driver:
Power Rating:
(2 hrs. Continuous Pink Noise)
Sensitivity (1w / 1m):
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Dimensions (H x W x D):
Weight:
Ultra - Compact High Power
12" Subwoofer
2263H 12" Woofer
1000 W
96 dB SPL
35 Hz – 1 kHz
43 Hz – 1 kHz
406 x 369 x 483 mm
16 x 14.5 x 19 in
16.3 kg (36 lb)
Compact High Power
15" Subwoofer
2265H-1 15" Woofer
800 W
97 dB SPL
32 Hz – 1 kHz
42 Hz – 1 kHz
483 x 419 x 597 mm
19 x 16.5 x 23.5 in
20.6 kg (45.5 lb)
High Power
Dual 15" Subwoofer
2 x 2265H-1 15" Woofers
1600 W
100 dB SPL
32 Hz – 1 kHz
38 Hz – 1 kHz
965 x 419 x 597 mm
38 x 16.5 x 23.5 in
36.7 kg (81 lb)
Ultra High Power
18" Subwoofer
2269H 18" Woofer
2000 W
96 dB SPL
22 Hz – 1 kHz
34 Hz – 1 kHz
546 x 560 x 815 mm
21.5 x 22 x 32.1 in
42.9 kg (94.5 lb)
Ultra High Power
Dual 18" Subwoofer
2 x 2269H 18" Woofers
4000 W
99 dB SPL
20 Hz – 1 kHz
25 Hz – 1 kHz
1092 x 560 x 815 mm
43 x 22 x 32.1 in
71.9 kg (158.5 lb)
Patented technology In Every Model
JBL’s Patented Differential Drive® dual-coil and dual-magnetic-gap
lightweight woofers are at the core of all new ASB models providing high
power, low distortion, extended response and excursion.
The 2269H 18" Driver utilized in the ASB7118 and ASB7128 models features 2000
Watts of continuous pink noise power handling, dual 4" voice coils and dual magnetic
gaps with Vented Gap Cooling™ and a maximum excursion of 3.5".
Application Engineered Series
Using the most advanced JBL transducer technology the AE Series
was designed with one goal in mind, deliver performance and features
system designers need and listeners demand. With a wide selection
of models, high performance capabilities, reliability, and a systems
approach, AE Series has a loudspeaker for just about any application.
HIGH-POWERED
SUBWOOFERS
ASB MODELS
www.jblpro.com
CAT AE 08/2010-25 © 2010 JBL Professional
8500 Balboa Blvd.
Northridge, CA 91329 USA
AM7315 & AM7200
High-Powered 3-Way & Mid-high loudspeakers
AM7115
Low-Frequency Module
AM7212 & AM7215
Medium- Powered Two - Way Full - Range Loudspeakers
AM5212 & AM5215
Medium-Power 2-Way Full-Range Loudspeakers
ASB
High- Powered Subwoofers
AE SERIES
application engin eered
ASB6112 ASB6115 ASB6125 ASB7118 ASB7128
System Type:
Driver:
Power Rating:
(2 hrs. Continuous Pink Noise)
Sensitivity (1w / 1m):
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Dimensions (H x W x D):
Weight:
Ultra - Compact High Power
12" Subwoofer
2263H 12" Woofer
1000 W
96 dB SPL
35 Hz – 1 kHz
43 Hz – 1 kHz
406 x 369 x 483 mm
16 x 14.5 x 19 in
16.3 kg (36 lb)
Compact High Power
15" Subwoofer
2265H-1 15" Woofer
800 W
97 dB SPL
32 Hz – 1 kHz
42 Hz – 1 kHz
483 x 419 x 597 mm
19 x 16.5 x 23.5 in
20.6 kg (45.5 lb)
High Power
Dual 15" Subwoofer
2 x 2265H-1 15" Woofers
1600 W
100 dB SPL
32 Hz – 1 kHz
38 Hz – 1 kHz
965 x 419 x 597 mm
38 x 16.5 x 23.5 in
36.7 kg (81 lb)
Ultra High Power
18" Subwoofer
2269H 18" Woofer
2000 W
96 dB SPL
22 Hz – 1 kHz
34 Hz – 1 kHz
546 x 560 x 815 mm
21.5 x 22 x 32.1 in
42.9 kg (94.5 lb)
Ultra High Power
Dual 18" Subwoofer
2 x 2269H 18" Woofers
4000 W
99 dB SPL
20 Hz – 1 kHz
25 Hz – 1 kHz
1092 x 560 x 815 mm
43 x 22 x 32.1 in
71.9 kg (158.5 lb)
Patented technology In Every Model
JBL’s Patented Differential Drive® dual-coil and dual-magnetic-gap
lightweight woofers are at the core of all new ASB models providing high
power, low distortion, extended response and excursion.
The 2269H 18" Driver utilized in the ASB7118 and ASB7128 models features 2000
Watts of continuous pink noise power handling, dual 4" voice coils and dual magnetic
gaps with Vented Gap Cooling™ and a maximum excursion of 3.5".
Application Engineered Series
Using the most advanced JBL transducer technology the AE Series
was designed with one goal in mind, deliver performance and features
system designers need and listeners demand. With a wide selection
of models, high performance capabilities, reliability, and a systems
approach, AE Series has a loudspeaker for just about any application.
HIGH-POWERED
SUBWOOFERS
ASB MODELS
www.jblpro.com
CAT AE 08/2010-25 © 2010 JBL Professional
8500 Balboa Blvd.
Northridge, CA 91329 USA
AM7315, AM7200 & AL7115 adds more fl exibility to your loudspeaker system design capabilities. The AM7315/64 and AM7315/95
are three-way full-range models that can be either bi-amplifi ed or tri-amplifi ed. The AM7200/64 and AM7200/95 are two-way
mid-high models that can be bi-amplifi ed or operate as a full passive system. The AL7115 is a single 15" low-frequency module
designed to work with the AM7200 models in a low-profi le array application where a full-range three-way system is desired.
AE Series three-way and mid-high models utilize the latest in transducer technology. All low-frequency drivers are JBL’s patented
Differential Drive ®, dual 3" voice coil – dual magnetic gap transducers. Three-way and mid-high models utilize JBL’s CMCD ™,
Cone Midrange Compression Driver technology. In addition to providing
increased output and lower distortion, this cone-based true compression driver
design extends bandwidth ( both up and down in frequency ) to cover the entire
vocal range seamlessly. All three-way and mid-high models utilize injection
molded rotatable Progressive Transition
™ waveguides. Like the high-power
two-way AE Series models, all three-way and mid-high models utilize the 2432H
1.5" exit, 3" diaphragm compression driver.
Complementing the AM7200/64 and AM7200/95 is the AL7115 15" low-frequency module. The AL7115, utilizing the PAF-3K planar
array frame kit, can be fi tted between two AM7200 mid-high loudspeakers to form a low-profi le three-wide array. The AL7115 is
equipped with the 2265 HPL Differential Drive 15" transducer.
System Type:
LF Driver:
HF Driver:
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Sensitivity (1w / 1m):
Rated Maximum SPL (1m):
System Nominal Impedance:
Power Rating (2 hr Continuous Pink Noise)
Long-Term System Power Rating (IEC 100 hrs)
:
(Continuous / Program / Peak)
Dimensions (H x W x D):
Weight:
Coverage:
AM5212 | Five AM5212 Horn Coverage Patterns AM5215 | Four AM5215 Horn Coverage Patterns
12" Two - Way, Medium Power, Full - Range
262H - 1
2408H - 1
37 Hz - 20 kHz
43 Hz - 18 kHz
Passive Mode: 96 dB
121 dB
8
400 W
300 / 600 / 1200 W
711 x 369 x 458 mm / 28 x 14.5 x 18 in
20.2 kg (45 lb)
AM5212/64: 60° x 40° horn, AM5212/66: 60° x 60° horn,
AM5212/95:90° x 50° horn, AM5212/00: 100 °x 100° horn,
AM5212/26: 120° x 60° horn
15" Two - Way, Medium Power, Full - Range
265H - 1
2408H - 1
35 Hz - 20 kHz
41 Hz - 18 kHz
Passive Mode: 99 dB
124 dB
8
500 W
350 / 700 / 1400 W
781 x 420 x 503 mm / 30.8 x 16.5 x 19.8 in
25.0 kg (55 lb)
AM5215/64: 60° x 40° horn, AM5215/66: 60° x 60° horn,
AM5215/95: 90° x 50° horn, AM5215/26: 120° x 60° horn
AE SERIES
application engin eered
System Type:
LF Driver:
HF Driver:
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Sensitivity (1w / 1m):
Rated Maximum SPL (1m):
System Nominal Impedance:
Power Rating (2 hr Continuous Pink Noise)
Long-Term System Power Rating (IEC 100 hrs)
:
(Continuous / Program / Peak)
Dimensions (H x W x D):
Weight:
Coverage:
System Type:
LF Driver:
MF Driver:
HF Driver:
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Sensitivity (1w / 1m):
Rated Maximum SPL (1m):
System Nominal Impedance:
Power Rating (2 hr Continuous Pink Noise)
Long-Term System Power Rating (IEC 100 hrs):
Dimensions (H x W x D):
Weight:
AM7212 | Five AM7212 Horn Coverage Patterns
AM7315 AM7215 | Four AM7215 Horn Coverage Patterns
AM7200 AL7115
12" Two - Way, High Power, Full - Range
2262H
2432H
36 Hz - 20 kHz
42 Hz - 18 kHz
Passive Mode: 95 dB
123 dB
8
700 W
600 / 1200 / 2400 W
711 x 369 x 458 mm / 28 x 14.5 x 18 in
23.1 kg (51 lb)
AM7212/64: 60° x 40° horn, AM7212/66: 60° x 60° horn,
AM7212/95:90° x 50° horn, AM7212/00: 100 °x 100° horn,
AM7212/26: 120° x 60° horn
15" Three - Way High Power, Full Range
2265HPL
CMCD-82H
2432H
38Hz - 20 kHz w/ recommended active tuning
45Hz - 18 kHz w/ recommended active tuning
LF 97 dB; MF 108 dB; HF 113 dB; MHF Passive 108 dB
LF 126/132 dB; MF 133/139 dB; HF 133/139 dB; MHF Passive
133/139 dB (Continuous / Peak)
8 ohms all bandpasses
LF 1000 W; MF 350 W; HF 100 W
LF 600/1200/2400 W; MHF Passive 200/400/800 W
(Continuous / Program / Peak)
967 x 561 x 657 mm (38.1 x 22.1 x 25.9 in)
45.8 kg (101 lb)
Two - Way High Power, Mid - High
CMCD-82H
2432H
260Hz - 20 kHz w/ recommended active tuning
330Hz - 18 kHz w/ recommended active tuning
MF 108 dB; HF 113 dB; MHF Passive 108 dB
MF 133/139 dB; HF 133/139 dB; MHF Passive 133/139 dB
(Continuous / Peak)
8 ohms all bandpasses
MF 350W; HF 100W
MHF Passive 200/400/800W
(Continuous / Program / Peak)
548 x 561 x 657 mm (21.6 x 22.1 x 25.9 in)
27.2 kg (60 lb)
High Power, Low - Frequency
2265HPL
40 Hz - 4.2 kHz w/out processing
47 Hz - 3.0 kHz w/out processing
97dB
126/132 dB
(Continuous / Peak)
8 ohms
1000 W
600/1200/2400 W
(Continuous / Program / Peak)
548 x 561 x 657 mm (21.6 x 22.1 x 25.9 in)
25.9 kg (57 lb)
15" Two - Way, High Power, Full - Range
2265H
2432H
34 Hz - 20 kHz
42 Hz - 18 kHz
Passive Mode: 96 dB
124 dB
8
750 W
600 / 1200 / 2400 W
781 x 420 x 503 mm / 30.8 x 16.5 x 19.8 in
27.2 kg (60 lb)
AM7215/64: 60° x 40° horn, AM7215/66: 60° x 60° horn,
AM7215/95: 90° x 50° horn, AM7215/26: 120° x 60° horn
The AM7212 and AM7215 models are designed to give you
unlimited fl exibility. The line consists of nine high-power two-way,
full-range models featuring two additional horn coverage patterns
of 60° x 60° and 120° x 60°. All models utilize JBL’s patented
Differential Drive
® dual 3" voice coil and dual gap woofers.
The high-frequency section utilizes the new 1.5" exit, 3" diaphragm 2432H
compression driver. All models utilize large mouth rotatable Progressive
Transition™ Waveguides for precise directivity control. These rotatable
waveguides allow the loudspeaker to be used in either the vertical or
horizontal orientation maintaining the intended horn coverage pattern.
The AM5000 Series consists of AM5212 and AM5215
which offer nine medium-power two-way, full-range models
featuring the same horn coverage patterns as the high-
power AM7000 Series models.
The AM5000 Series utilizes Differential Drive® 2" dual voice
coil dual gap woofers with 1.5" voice coil 2408H-1
compression drivers. All AE Series models are designed
specifi cally to fi t the needs of any discerning system designer
for permanent installation applications.
Differential Drive
®
JBL’s exclusive dual voice coil dual gap cone
transducers featuring a unique design with heat
sinks integrated into the cast aluminum frame
is at the core of all new AM7000 and AM5000
Series loudspeakers.
Dual Voice Coil and Dual Gap Technology
The dual voice coil and dual gap places the
neodymium magnets inside the dual voice coil
assembly, completing the magnetic circuit
without the heavy surrounding steel structure
of conventional drivers.
Progressive Transition™ Waveguides
Provide excellent coverage control and
are rotatable so the loudspeaker system
can be used in either the vertical or
horizontal orientation.
As technology gets more complex, our purpose is to ensure quality and maximum usability
Conceived, Tuned and Balanced to provide peak performance
Compression Driver
All nine AM 7000 Series models utilize
the 1.5" exit, 3" diaphragm 2432H
compression driver.
CMCD
™ | Cone Midrange Compression Driver Selectable Crossover Mode
All AE Series speakers (except single driver
subwoofers ) offer selectable crossover modes.
Two-Way speakers operate in either bi-amp or
passive mode. Dual-driver subwoofer cabinets
offer selection between parallel and discrete
driver access.
Connectors
All models include both Speakon® and CE-
approved covered barrier strip input connectors.
HIGH-POWER TWO-WAY
FULL-RANGE LOUDSPEAKERS
HIGH-POWER THREE-WAY &
MID-HIGH LOUDSPEAKERS
LOW-FREQUENCY MODULE
MEDIUM-POWER TWO-WAY
FULL-RANGE LOUDSPEAKERS
AM7212 & AM7215AM7315 & AM7200
AL7115
AM5212 & AM5215
AM7315, AM7200 & AL7115 adds more fl exibility to your loudspeaker system design capabilities. The AM7315/64 and AM7315/95
are three-way full-range models that can be either bi-amplifi ed or tri-amplifi ed. The AM7200/64 and AM7200/95 are two-way
mid-high models that can be bi-amplifi ed or operate as a full passive system. The AL7115 is a single 15" low-frequency module
designed to work with the AM7200 models in a low-profi le array application where a full-range three-way system is desired.
AE Series three-way and mid-high models utilize the latest in transducer technology. All low-frequency drivers are JBL’s patented
Differential Drive ®, dual 3" voice coil – dual magnetic gap transducers. Three-way and mid-high models utilize JBL’s CMCD ™,
Cone Midrange Compression Driver technology. In addition to providing
increased output and lower distortion, this cone-based true compression driver
design extends bandwidth ( both up and down in frequency ) to cover the entire
vocal range seamlessly. All three-way and mid-high models utilize injection
molded rotatable Progressive Transition
™ waveguides. Like the high-power
two-way AE Series models, all three-way and mid-high models utilize the 2432H
1.5" exit, 3" diaphragm compression driver.
Complementing the AM7200/64 and AM7200/95 is the AL7115 15" low-frequency module. The AL7115, utilizing the PAF-3K planar
array frame kit, can be fi tted between two AM7200 mid-high loudspeakers to form a low-profi le three-wide array. The AL7115 is
equipped with the 2265 HPL Differential Drive 15" transducer.
System Type:
LF Driver:
HF Driver:
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Sensitivity (1w / 1m):
Rated Maximum SPL (1m):
System Nominal Impedance:
Power Rating (2 hr Continuous Pink Noise)
Long-Term System Power Rating (IEC 100 hrs)
:
(Continuous / Program / Peak)
Dimensions (H x W x D):
Weight:
Coverage:
AM5212 | Five AM5212 Horn Coverage Patterns AM5215 | Four AM5215 Horn Coverage Patterns
12" Two - Way, Medium Power, Full - Range
262H - 1
2408H - 1
37 Hz - 20 kHz
43 Hz - 18 kHz
Passive Mode: 96 dB
121 dB
8
400 W
300 / 600 / 1200 W
711 x 369 x 458 mm / 28 x 14.5 x 18 in
20.2 kg (45 lb)
AM5212/64: 60° x 40° horn, AM5212/66: 60° x 60° horn,
AM5212/95:90° x 50° horn, AM5212/00: 100 °x 100° horn,
AM5212/26: 120° x 60° horn
15" Two - Way, Medium Power, Full - Range
265H - 1
2408H - 1
35 Hz - 20 kHz
41 Hz - 18 kHz
Passive Mode: 99 dB
124 dB
8
500 W
350 / 700 / 1400 W
781 x 420 x 503 mm / 30.8 x 16.5 x 19.8 in
25.0 kg (55 lb)
AM5215/64: 60° x 40° horn, AM5215/66: 60° x 60° horn,
AM5215/95: 90° x 50° horn, AM5215/26: 120° x 60° horn
AE SERIES
application engin eered
System Type:
LF Driver:
HF Driver:
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Sensitivity (1w / 1m):
Rated Maximum SPL (1m):
System Nominal Impedance:
Power Rating (2 hr Continuous Pink Noise)
Long-Term System Power Rating (IEC 100 hrs)
:
(Continuous / Program / Peak)
Dimensions (H x W x D):
Weight:
Coverage:
System Type:
LF Driver:
MF Driver:
HF Driver:
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Sensitivity (1w / 1m):
Rated Maximum SPL (1m):
System Nominal Impedance:
Power Rating (2 hr Continuous Pink Noise)
Long-Term System Power Rating (IEC 100 hrs):
Dimensions (H x W x D):
Weight:
AM7212 | Five AM7212 Horn Coverage Patterns
AM7315 AM7215 | Four AM7215 Horn Coverage Patterns
AM7200 AL7115
12" Two - Way, High Power, Full - Range
2262H
2432H
36 Hz - 20 kHz
42 Hz - 18 kHz
Passive Mode: 95 dB
123 dB
8
700 W
600 / 1200 / 2400 W
711 x 369 x 458 mm / 28 x 14.5 x 18 in
23.1 kg (51 lb)
AM7212/64: 60° x 40° horn, AM7212/66: 60° x 60° horn,
AM7212/95:90° x 50° horn, AM7212/00: 100 °x 100° horn,
AM7212/26: 120° x 60° horn
15" Three - Way High Power, Full Range
2265HPL
CMCD-82H
2432H
38Hz - 20 kHz w/ recommended active tuning
45Hz - 18 kHz w/ recommended active tuning
LF 97 dB; MF 108 dB; HF 113 dB; MHF Passive 108 dB
LF 126/132 dB; MF 133/139 dB; HF 133/139 dB; MHF Passive
133/139 dB (Continuous / Peak)
8 ohms all bandpasses
LF 1000 W; MF 350 W; HF 100 W
LF 600/1200/2400 W; MHF Passive 200/400/800 W
(Continuous / Program / Peak)
967 x 561 x 657 mm (38.1 x 22.1 x 25.9 in)
45.8 kg (101 lb)
Two - Way High Power, Mid - High
CMCD-82H
2432H
260Hz - 20 kHz w/ recommended active tuning
330Hz - 18 kHz w/ recommended active tuning
MF 108 dB; HF 113 dB; MHF Passive 108 dB
MF 133/139 dB; HF 133/139 dB; MHF Passive 133/139 dB
(Continuous / Peak)
8 ohms all bandpasses
MF 350W; HF 100W
MHF Passive 200/400/800W
(Continuous / Program / Peak)
548 x 561 x 657 mm (21.6 x 22.1 x 25.9 in)
27.2 kg (60 lb)
High Power, Low - Frequency
2265HPL
40 Hz - 4.2 kHz w/out processing
47 Hz - 3.0 kHz w/out processing
97dB
126/132 dB
(Continuous / Peak)
8 ohms
1000 W
600/1200/2400 W
(Continuous / Program / Peak)
548 x 561 x 657 mm (21.6 x 22.1 x 25.9 in)
25.9 kg (57 lb)
15" Two - Way, High Power, Full - Range
2265H
2432H
34 Hz - 20 kHz
42 Hz - 18 kHz
Passive Mode: 96 dB
124 dB
8
750 W
600 / 1200 / 2400 W
781 x 420 x 503 mm / 30.8 x 16.5 x 19.8 in
27.2 kg (60 lb)
AM7215/64: 60° x 40° horn, AM7215/66: 60° x 60° horn,
AM7215/95: 90° x 50° horn, AM7215/26: 120° x 60° horn
The AM7212 and AM7215 models are designed to give you
unlimited fl exibility. The line consists of nine high-power two-way,
full-range models featuring two additional horn coverage patterns
of 60° x 60° and 120° x 60°. All models utilize JBL’s patented
Differential Drive
® dual 3" voice coil and dual gap woofers.
The high-frequency section utilizes the new 1.5" exit, 3" diaphragm 2432H
compression driver. All models utilize large mouth rotatable Progressive
Transition™ Waveguides for precise directivity control. These rotatable
waveguides allow the loudspeaker to be used in either the vertical or
horizontal orientation maintaining the intended horn coverage pattern.
The AM5000 Series consists of AM5212 and AM5215
which offer nine medium-power two-way, full-range models
featuring the same horn coverage patterns as the high-
power AM7000 Series models.
The AM5000 Series utilizes Differential Drive® 2" dual voice
coil dual gap woofers with 1.5" voice coil 2408H-1
compression drivers. All AE Series models are designed
specifi cally to fi t the needs of any discerning system designer
for permanent installation applications.
Differential Drive
®
JBL’s exclusive dual voice coil dual gap cone
transducers featuring a unique design with heat
sinks integrated into the cast aluminum frame
is at the core of all new AM7000 and AM5000
Series loudspeakers.
Dual Voice Coil and Dual Gap Technology
The dual voice coil and dual gap places the
neodymium magnets inside the dual voice coil
assembly, completing the magnetic circuit
without the heavy surrounding steel structure
of conventional drivers.
Progressive Transition™ Waveguides
Provide excellent coverage control and
are rotatable so the loudspeaker system
can be used in either the vertical or
horizontal orientation.
As technology gets more complex, our purpose is to ensure quality and maximum usability
Conceived, Tuned and Balanced to provide peak performance
Compression Driver
All nine AM 7000 Series models utilize
the 1.5" exit, 3" diaphragm 2432H
compression driver.
CMCD
™ | Cone Midrange Compression Driver Selectable Crossover Mode
All AE Series speakers (except single driver
subwoofers ) offer selectable crossover modes.
Two-Way speakers operate in either bi-amp or
passive mode. Dual-driver subwoofer cabinets
offer selection between parallel and discrete
driver access.
Connectors
All models include both Speakon® and CE-
approved covered barrier strip input connectors.
HIGH-POWER TWO-WAY
FULL-RANGE LOUDSPEAKERS
HIGH-POWER THREE-WAY &
MID-HIGH LOUDSPEAKERS
LOW-FREQUENCY MODULE
MEDIUM-POWER TWO-WAY
FULL-RANGE LOUDSPEAKERS
AM7212 & AM7215AM7315 & AM7200
AL7115
AM5212 & AM5215
AM7315, AM7200 & AL7115 adds more fl exibility to your loudspeaker system design capabilities. The AM7315/64 and AM7315/95
are three-way full-range models that can be either bi-amplifi ed or tri-amplifi ed. The AM7200/64 and AM7200/95 are two-way
mid-high models that can be bi-amplifi ed or operate as a full passive system. The AL7115 is a single 15" low-frequency module
designed to work with the AM7200 models in a low-profi le array application where a full-range three-way system is desired.
AE Series three-way and mid-high models utilize the latest in transducer technology. All low-frequency drivers are JBL’s patented
Differential Drive ®, dual 3" voice coil – dual magnetic gap transducers. Three-way and mid-high models utilize JBL’s CMCD ™,
Cone Midrange Compression Driver technology. In addition to providing
increased output and lower distortion, this cone-based true compression driver
design extends bandwidth ( both up and down in frequency ) to cover the entire
vocal range seamlessly. All three-way and mid-high models utilize injection
molded rotatable Progressive Transition
™ waveguides. Like the high-power
two-way AE Series models, all three-way and mid-high models utilize the 2432H
1.5" exit, 3" diaphragm compression driver.
Complementing the AM7200/64 and AM7200/95 is the AL7115 15" low-frequency module. The AL7115, utilizing the PAF-3K planar
array frame kit, can be fi tted between two AM7200 mid-high loudspeakers to form a low-profi le three-wide array. The AL7115 is
equipped with the 2265 HPL Differential Drive 15" transducer.
System Type:
LF Driver:
HF Driver:
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Sensitivity (1w / 1m):
Rated Maximum SPL (1m):
System Nominal Impedance:
Power Rating (2 hr Continuous Pink Noise)
Long-Term System Power Rating (IEC 100 hrs)
:
(Continuous / Program / Peak)
Dimensions (H x W x D):
Weight:
Coverage:
AM5212 | Five AM5212 Horn Coverage Patterns AM5215 | Four AM5215 Horn Coverage Patterns
12" Two - Way, Medium Power, Full - Range
262H - 1
2408H - 1
37 Hz - 20 kHz
43 Hz - 18 kHz
Passive Mode: 96 dB
121 dB
8
400 W
300 / 600 / 1200 W
711 x 369 x 458 mm / 28 x 14.5 x 18 in
20.2 kg (45 lb)
AM5212/64: 60° x 40° horn, AM5212/66: 60° x 60° horn,
AM5212/95:90° x 50° horn, AM5212/00: 100 °x 100° horn,
AM5212/26: 120° x 60° horn
15" Two - Way, Medium Power, Full - Range
265H - 1
2408H - 1
35 Hz - 20 kHz
41 Hz - 18 kHz
Passive Mode: 99 dB
124 dB
8
500 W
350 / 700 / 1400 W
781 x 420 x 503 mm / 30.8 x 16.5 x 19.8 in
25.0 kg (55 lb)
AM5215/64: 60° x 40° horn, AM5215/66: 60° x 60° horn,
AM5215/95: 90° x 50° horn, AM5215/26: 120° x 60° horn
AE SERIES
application engin eered
System Type:
LF Driver:
HF Driver:
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Sensitivity (1w / 1m):
Rated Maximum SPL (1m):
System Nominal Impedance:
Power Rating (2 hr Continuous Pink Noise)
Long-Term System Power Rating (IEC 100 hrs)
:
(Continuous / Program / Peak)
Dimensions (H x W x D):
Weight:
Coverage:
System Type:
LF Driver:
MF Driver:
HF Driver:
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Sensitivity (1w / 1m):
Rated Maximum SPL (1m):
System Nominal Impedance:
Power Rating (2 hr Continuous Pink Noise)
Long-Term System Power Rating (IEC 100 hrs):
Dimensions (H x W x D):
Weight:
AM7212 | Five AM7212 Horn Coverage Patterns
AM7315 AM7215 | Four AM7215 Horn Coverage Patterns
AM7200 AL7115
12" Two - Way, High Power, Full - Range
2262H
2432H
36 Hz - 20 kHz
42 Hz - 18 kHz
Passive Mode: 95 dB
123 dB
8
700 W
600 / 1200 / 2400 W
711 x 369 x 458 mm / 28 x 14.5 x 18 in
23.1 kg (51 lb)
AM7212/64: 60° x 40° horn, AM7212/66: 60° x 60° horn,
AM7212/95:90° x 50° horn, AM7212/00: 100 °x 100° horn,
AM7212/26: 120° x 60° horn
15" Three - Way High Power, Full Range
2265HPL
CMCD-82H
2432H
38Hz - 20 kHz w/ recommended active tuning
45Hz - 18 kHz w/ recommended active tuning
LF 97 dB; MF 108 dB; HF 113 dB; MHF Passive 108 dB
LF 126/132 dB; MF 133/139 dB; HF 133/139 dB; MHF Passive
133/139 dB (Continuous / Peak)
8 ohms all bandpasses
LF 1000 W; MF 350 W; HF 100 W
LF 600/1200/2400 W; MHF Passive 200/400/800 W
(Continuous / Program / Peak)
967 x 561 x 657 mm (38.1 x 22.1 x 25.9 in)
45.8 kg (101 lb)
Two - Way High Power, Mid - High
CMCD-82H
2432H
260Hz - 20 kHz w/ recommended active tuning
330Hz - 18 kHz w/ recommended active tuning
MF 108 dB; HF 113 dB; MHF Passive 108 dB
MF 133/139 dB; HF 133/139 dB; MHF Passive 133/139 dB
(Continuous / Peak)
8 ohms all bandpasses
MF 350W; HF 100W
MHF Passive 200/400/800W
(Continuous / Program / Peak)
548 x 561 x 657 mm (21.6 x 22.1 x 25.9 in)
27.2 kg (60 lb)
High Power, Low - Frequency
2265HPL
40 Hz - 4.2 kHz w/out processing
47 Hz - 3.0 kHz w/out processing
97dB
126/132 dB
(Continuous / Peak)
8 ohms
1000 W
600/1200/2400 W
(Continuous / Program / Peak)
548 x 561 x 657 mm (21.6 x 22.1 x 25.9 in)
25.9 kg (57 lb)
15" Two - Way, High Power, Full - Range
2265H
2432H
34 Hz - 20 kHz
42 Hz - 18 kHz
Passive Mode: 96 dB
124 dB
8
750 W
600 / 1200 / 2400 W
781 x 420 x 503 mm / 30.8 x 16.5 x 19.8 in
27.2 kg (60 lb)
AM7215/64: 60° x 40° horn, AM7215/66: 60° x 60° horn,
AM7215/95: 90° x 50° horn, AM7215/26: 120° x 60° horn
The AM7212 and AM7215 models are designed to give you
unlimited fl exibility. The line consists of nine high-power two-way,
full-range models featuring two additional horn coverage patterns
of 60° x 60° and 120° x 60°. All models utilize JBL’s patented
Differential Drive
® dual 3" voice coil and dual gap woofers.
The high-frequency section utilizes the new 1.5" exit, 3" diaphragm 2432H
compression driver. All models utilize large mouth rotatable Progressive
Transition™ Waveguides for precise directivity control. These rotatable
waveguides allow the loudspeaker to be used in either the vertical or
horizontal orientation maintaining the intended horn coverage pattern.
The AM5000 Series consists of AM5212 and AM5215
which offer nine medium-power two-way, full-range models
featuring the same horn coverage patterns as the high-
power AM7000 Series models.
The AM5000 Series utilizes Differential Drive® 2" dual voice
coil dual gap woofers with 1.5" voice coil 2408H-1
compression drivers. All AE Series models are designed
specifi cally to fi t the needs of any discerning system designer
for permanent installation applications.
Differential Drive
®
JBL’s exclusive dual voice coil dual gap cone
transducers featuring a unique design with heat
sinks integrated into the cast aluminum frame
is at the core of all new AM7000 and AM5000
Series loudspeakers.
Dual Voice Coil and Dual Gap Technology
The dual voice coil and dual gap places the
neodymium magnets inside the dual voice coil
assembly, completing the magnetic circuit
without the heavy surrounding steel structure
of conventional drivers.
Progressive Transition™ Waveguides
Provide excellent coverage control and
are rotatable so the loudspeaker system
can be used in either the vertical or
horizontal orientation.
As technology gets more complex, our purpose is to ensure quality and maximum usability
Conceived, Tuned and Balanced to provide peak performance
Compression Driver
All nine AM 7000 Series models utilize
the 1.5" exit, 3" diaphragm 2432H
compression driver.
CMCD
™ | Cone Midrange Compression Driver Selectable Crossover Mode
All AE Series speakers (except single driver
subwoofers ) offer selectable crossover modes.
Two-Way speakers operate in either bi-amp or
passive mode. Dual-driver subwoofer cabinets
offer selection between parallel and discrete
driver access.
Connectors
All models include both Speakon® and CE-
approved covered barrier strip input connectors.
HIGH-POWER TWO-WAY
FULL-RANGE LOUDSPEAKERS
HIGH-POWER THREE-WAY &
MID-HIGH LOUDSPEAKERS
LOW-FREQUENCY MODULE
MEDIUM-POWER TWO-WAY
FULL-RANGE LOUDSPEAKERS
AM7212 & AM7215AM7315 & AM7200
AL7115
AM5212 & AM5215
AM7315 & AM7200
High-Powered 3-Way & Mid-high loudspeakers
AM7115
Low-Frequency Module
AM7212 & AM7215
Medium- Powered Two - Way Full - Range Loudspeakers
AM5212 & AM5215
Medium-Power 2-Way Full-Range Loudspeakers
ASB
High- Powered Subwoofers
AE SERIES
application engin eered
ASB6112 ASB6115 ASB6125 ASB7118 ASB7128
System Type:
Driver:
Power Rating:
(2 hrs. Continuous Pink Noise)
Sensitivity (1w / 1m):
Frequency Range ( –10 dB):
Frequency Response ( ± 3 dB):
Dimensions (H x W x D):
Weight:
Ultra - Compact High Power
12" Subwoofer
2263H 12" Woofer
1000 W
96 dB SPL
35 Hz – 1 kHz
43 Hz – 1 kHz
406 x 369 x 483 mm
16 x 14.5 x 19 in
16.3 kg (36 lb)
Compact High Power
15" Subwoofer
2265H-1 15" Woofer
800 W
97 dB SPL
32 Hz – 1 kHz
42 Hz – 1 kHz
483 x 419 x 597 mm
19 x 16.5 x 23.5 in
20.6 kg (45.5 lb)
High Power
Dual 15" Subwoofer
2 x 2265H-1 15" Woofers
1600 W
100 dB SPL
32 Hz – 1 kHz
38 Hz – 1 kHz
965 x 419 x 597 mm
38 x 16.5 x 23.5 in
36.7 kg (81 lb)
Ultra High Power
18" Subwoofer
2269H 18" Woofer
2000 W
96 dB SPL
22 Hz – 1 kHz
34 Hz – 1 kHz
546 x 560 x 815 mm
21.5 x 22 x 32.1 in
42.9 kg (94.5 lb)
Ultra High Power
Dual 18" Subwoofer
2 x 2269H 18" Woofers
4000 W
99 dB SPL
20 Hz – 1 kHz
25 Hz – 1 kHz
1092 x 560 x 815 mm
43 x 22 x 32.1 in
71.9 kg (158.5 lb)
Patented technology In Every Model
JBL’s Patented Differential Drive® dual-coil and dual-magnetic-gap
lightweight woofers are at the core of all new ASB models providing high
power, low distortion, extended response and excursion.
The 2269H 18" Driver utilized in the ASB7118 and ASB7128 models features 2000
Watts of continuous pink noise power handling, dual 4" voice coils and dual magnetic
gaps with Vented Gap Cooling™ and a maximum excursion of 3.5".
Application Engineered Series
Using the most advanced JBL transducer technology the AE Series
was designed with one goal in mind, deliver performance and features
system designers need and listeners demand. With a wide selection
of models, high performance capabilities, reliability, and a systems
approach, AE Series has a loudspeaker for just about any application.
HIGH-POWERED
SUBWOOFERS
ASB MODELS
www.jblpro.com
CAT AE 08/2010-25 © 2010 JBL Professional
8500 Balboa Blvd.
Northridge, CA 91329 USA
