It’s common knowledge that the performance of even the best automotive amplier can only be as good as its
installation and setup. That’s why the new GTO line of ampliers is designed to take the guesswork out of this
process. Large, clearly marked knobs and color-coded LEDs, along with the included setup CD, make dialing
in perfect sound easy. For upgrading a factory system, the GTO ampliers make signal connection simple. No
additional signal converters, adapters or plugs are necessary because everything is included in the box. The
complete line of GTO ampliers includes chassis sizes, output-power capabilities and congurations sure to t
any car, any system and nearly any budget, and all are backed by the JBL® reputation for top quality.
Top performance made easy: a new line of car amps makes
great sound easy with simple setup built right in
JBL® GTO AmpLifiers
TECHNICAL SPECIFICATIONS
GTO-504EZ
• Bridgeable 4-channel amplier
• Power output (CEA 2006A): 50W RMS x 4 channels at
4 ohms, 14.4V DC, <1.0% THD; 75W RMS x 4 channels
at 2 ohms, 14.4V DC, <1.0% THD; 150W RMS x 2 channels
bridged at 4 ohms, 14.4V DC, <1.0% THD
• Max power: 640W (160W x 4 at 2 ohms), 15.5V DC,
10% THD, one channel driven at a time
• Dimensions (D x H x W): 8-3/8" x 2-9/16" x 9-11/16"
(213mm x 66mm x 246mm)
• Weight: 6.4 lb (2.9kg)
GTO-804EZ
• Bridgeable 4-channel amplier
• Power output (CEA 2006A): 80W RMS x 4 channels at
4 ohms, 14.4V DC, <1.0% THD; 100W RMS x 4 channels
at 2 ohms, 14.4V DC, <1.0% THD; 200W RMS x 2 channels
bridged at 4 ohms, 14.4V DC, <1.0% THD
• Max power: 940W (235W x 4 at 2 ohms), 15.5V DC,
10% THD, one channel driven at a time
• Dimensions (D x H x W): 11-15/16" x 2-9/16" x 9-11/16"
(302mm x 66mm x 246mm)
• Weight: 8.4 lb (3.8kg)
GTO-3EZ
• 3-channel system amplier
• Power output (CEA 2006A): 50W RMS x 2 channels at
4 ohms + 350W RMS x 1 channel at 4 ohms, 14.4V DC,
<1.0% THD; 75W RMS x 2 channels at 2 ohms + 500W
RMS x 1 channel at 2 ohms, 14.4V DC, <1.0% THD;
150W RMS x 1 channel bridged at 4 ohms + 500W
RMS x 1 channel at 2 ohms, 14.4V DC, <1.0% THD
• Max power: 1370W (1050W x 1 at 2 ohms + 160W x 2 at
2 ohms), 15.5V DC, 10% THD, one channel driven at a time
• Dimensions (D x H x W): 11-15/16" x 2-9/16" x 9-11/16"
(302mm x 66mm x 246mm)
• Weight: 9.0 lb (4.1kg)
GTO-5EZ
• 5-channel system amplier
• Power output (CEA 2006A): 50W RMS x 4 channels at
4 ohms + 350W RMS x 1 channel at 4 ohms, 14.4V DC,
<1.0% THD; 75W RMS x 4 channels at 2 ohms + 500W
RMS x 1 channel at 2 ohms, 14.4V DC, <1.0% THD;
150W RMS x 2 channels bridged at 4 ohms + 500W
RMS x 1 channel at 2 ohms, 14.4V DC, <1.0% THD
• Max power: 1935W (1075W x 1 at 2 ohms + 215W x 4 at
2 ohms), 15.5V DC, 10% THD, one channel driven at a time
• Dimensions (D x H x W): 14-11/16" x 2-9/16" x 9-11/16"
(373mm x 66mm x 246mm)
• Weight: 11.2 lb (5.1kg)
HARMAN Consumer, Inc.
8500 Balboa Boulevard, Northridge, CA 91329 USA
© 2012 HARMAN International Industries, Incorporated. All rights reserved.
JBL is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or other countries.
Features, specifications and appearance are subject to change without notice.
www.jbl.com
Top performance made easy: a new line of car amps makes
great sound easy with simple setup built right in
JBL® GTO AmpLifiers
GTO-501EZ
• Class D mono subwoofer amplier
• Power output (CEA 2006A): 350W RMS x 1 channel at
4 ohms, 14.14V DC, <1.0% THD; 500W RMS x 1 channel at
2 ohms, 14.4V DC, <1.0% THD
• Max power: 770W at 2 ohms, 15.5V DC, 10% THD
• Dimensions (D x H x W): 8-3/8" x 2-9/16" x 9-11/16"
(213mm x 66mm x 246mm)
• Weight: 6.4 lb (2.9kg)
GTO-751EZ
• Class D mono subwoofer amplier
• Power output (CEA 2006A): 500W RMS x 1 channel at
4 ohms, 14.4V DC, <1.0% THD; 750W RMS x 1 channel
at 2 ohms, 14.4V DC, <1.0% THD
• Max power: 1200W at 2 ohms, 15.5V DC, 10% THD
• Dimensions (D x H x W): 11-15/16" x 2-9/16" x 9-11/16"
(302mm x 66mm x 246mm)
• Weight: 9.0 lb (4.1kg)
GTO-1001EZ
• Class D mono subwoofer amplier
• Power output (CEA 2006A): 650W RMS x 1 channel at
4 ohms, 14.4V DC, <1.0% THD; 1000W RMS x 1 channel
at 2 ohms, 14.4V DC, <1.0% THD
• Max power: 1450W at 2 ohms, 15.5V DC, 10% THD
• Dimensions (D x H x W): 14-11/16" x 2-9/16" x 9-11/16"
(373mm x 66mm x 246mm)
• Weight: 11.2 lb (5.1kg)
TECHNICAL SPECIFICATIONS, continued
FEATURES ADVANTAGES BENEFITS
Easy to connect RCA-to-bare-wire adapters for audio inputs allow the
amp to handle both speaker-level and line-level signals
on the same RCA inputs
Faster installation time
Eliminates confusion and installation mistakes
Works with OEM or aftermarket systems
Easy to set up Special setup CD, large gain knobs and multicolor
LEDs make setup in any existing system not only easy
but also precise
Helps the installer precisely optimize the
balance between system noise and output
power easily and quickly
Expensive test equipment is not needed
Maximum output power free of noise
Built-in variable crossover 50Hz – 280Hz variable electronic crossover Allows optimal system tuning based on speaker
type and conguration
Built-in variable bass boost 0dB – 12dB @ 45Hz variable bass boost on subwoofer
amps and subwoofer channel of multichannel models
Allows adjustment of the level and “character”
of the bass
Audio-sense circuitry Can set amp to power up whenever it detects an
audio signal; feature is defeatable with switch on
bottom of amp
Works with many factory systems for an easy
upgrade from stock – even those that don’t
include a remote trigger wire
High-powered subwoofer
channels in GTO-3EZ and
GTO-5EZ system ampliers
GTO-3EZ and GTO-5EZ ampliers include a 500W
subwoofer channel with remote volume control
(sold separately)
Plenty of power to drive any subwoofer
No need for separate subwoofer amp
High-efciency Class-D
subwoofer channels
Subwoofer amps and subwoofer channels within
multichannel amps use Class D circuitry for high power
with lower current draw and lower heat generation
Less taxing on vehicle’s electrical system
Lower system heat can enhance long-term
reliability and allows smaller amplier chassis
Bridgeable channels Full-range channels of four-channel amps and
multichannel amps are bridgeable
Increases system design and installation
exibility
Thermal overload protection Includes built-in protection from high heat and
unsuitable loads
Superior long-term reliability
