JBL Bass Pro Hub Spec Sheet English
JBL_BassPro_Hub_Spec_Sheet_English JBL BassPro Hub | 11 (279mm) Spare tire subwoofer with built-in 200W RMS amplifier with remote control.
User Manual: JBL JBL BassPro Hub | 11 (279mm) Spare tire subwoofer with built-in 200W RMS amplifier with remote control.
Open the PDF directly: View PDF
.
Page Count: 2
Features
Fiberglass Woofer Cone with Rubber
Surround
Built-in Class D 200W RMS amplifier
Wired Remote with User Interface
Controls
Line-level Inputs and Speaker-level Inputs
Harman Standard Reliability Testing
JBL at an Affordable Price
JBL’s BassPro Hub Subwoofer Rattles Your Rear View Mirror.
The new JBL BassPro Hub subwoofer delivers show & shine performance without crowding
your passengers or sacrificing cargo area. This all-in-one powered subwoofer system fits
into the hub of your spare tire for a super easy installation and out of sight sound solution.
The built-in Class D amplifier delivers 200W RMS and is designed to work with the BassPro
Hub subwoofer and enclosure as a system. The 11" (279mm) feather-light fiberglass
woofer cone with rubber surround delivers the signature kick and punch of JBL bass. And
with over temperature protection (OTP) and over current protection (OCP) you can count
on reliability at peak volume levels. The included remote control enables adjustment of
crossover point, gain, phase—and a bass boost of 12dB when you’re in the mood and on
the move. Whether you’re cruising or competing, the JBL BassPro leaves the competition
behind without missing a beat.
11" (279mm) Spare tire subwoofer with built-in 200W RMS amplifier with remote control
BassPro Hub
HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
www.jbl.com
© 2018 HARMAN International Industries, Incorporated. All rights reserved. JBL is a trademark of HARMAN
International Industries, Incorporated, registered in the United States and/or other countries. Features, specifications
and appearance are subject to change without notice.
What’s in the box:
BassPro Hub Subwoofer
Safety sheet
Quick Start Guide (full manual online)
Hardware for attachment to vehicle
Wiring harness
Remote controller with 5 meters cable
Technical Specifications
Amplifier Power: 200W RMS (2 ohms)
Frequency Response: 30Hz – 150Hz
Fuse: 30A
Maximum Current Draw: 30A
Quiescent Current Draw: <1.2A
Crossover Frequency: 50Hz – 150Hz
Crossover Slope: 24dB/Octave
Bass Boost: 0 – 12dB Variable @ Fix 50 Hz
Line level input sensitivity: 0.2 V – 4V
Speaker level input sensitivity: 0.5V – 10V
Dimensions (D x H): 14-3/16" x 6-1/2"
(D360mm x H165mm)
Features and Benefits
Fiberglass Woofer Cone with Rubber Surround
The 11" (279mm) woofer cone is engineered to deliver fast and tight, deep bass with low distortion
and unwanted second and third order anomalies.
Built-in Class D 200W RMS amplifier
The JBL subwoofer system’s built-in amplifier is optimized to work as a system with the woofer. Its
Class D design runs cooler and draws less current from your vehicles electrical system making it the
perfect concealed subwoofer solution.
Wired Remote with User Interface Controls
Gain control adjusts the volume level right from the drivers seat. Phase switch changes the input
phase to inverted or noninverted. (This can sometimes be helpful for troubleshooting.) Crossover
frequency control adjusts the crossover frequency to any point between 50Hz and 150Hz. Bass EQ
control provides 12dB of boost.
Line-level Inputs and Speaker-level Inputs
The JBL BassPro Hub has line level inputs and speaker inputs that allow you to connect to any
car audio system making it a great upgrade to your factory system or the bass foundation of the
aftermarket system of your dreams.
Harman Standard Reliability Testing
JBL speakers have to undergo a testing process that would destroy lesser speakers. JBL freezes
them, bakes them, shakes them, blasts them with ultraviolet light and drives them at full power for
days at a time.
JBL at an Affordable Price
This is JBL—the legendary speaker and sound company that has excited audio enthusiasts for over
seventy years. There’s nothing better than riding with JBL.
11" (279mm) Spare tire subwoofer with built-in 200W RMS amplifier with remote control
BassPro Hub
