PRX515
Features:
䉴
Differential Drive®woofer
䉴
1.5" annual polymer diaphragm
compression driver
䉴
Class-D, Crown®digital amplifier
䉴
DSP input section with crossover, dynamic
limiting, component optimization,
selectable system EQ
䉴
Professional XLR line and ¼"
Mic/Instrument inputs, with loop through
䉴
Illuminated logo for clear Power-On status
䉴
Integrated pole mount socket
䉴
DuraFlex™ coated plywood construction
䉴
Polypropylene end-caps enhance durability
䉴
Wrap around heavy duty steel grille
provides protection without obstructing
performance.
䉴
Large die-cast aluminum handle bar with a
fine tuned ergonomic rubber grip for
maximum comfort
Application:
The 2-way 15"; the most recognizable form
of portable PA loudspeakers, the perfect
balance between size and performance. The
PRX515 truly is an exception; it’s smaller and
lighter without compromising on
performance. For applications requiring full
bandwidth sound reproduction, using only a
pair of speakers, the PRX515 delivers the
optimum balance. For live music, recorded
music playback and speech the user has the
option of tailoring the EQ, ‘flat’ for speech
intelligibility, and ‘boost’ for enhanced bass
and crisp highs in recorded music playback.
A microphone can be directly connected to
the speaker input for quick on-the-fly PA
applications.
The PRX515 is a self-powered, lightweight
two-way loudspeaker system capable of
delivering a very high level of performance.
The PRX515 is comprised of a 380 mm (15
in) 265F Differential Drive®woofer, a 2408H
37.5 mm (1.5 in) annular polymer diaphragm,
neodymium compression driver mounted to a
70° by 70° horn, all driven by a multi-channel
Crown International Class-D digital power
amplifier. A propriety DSP chip is at the core
of a fully featured input section, providing
user selectable system EQ, protection, input
sensitivity selection, cross-over functionality,
dynamic limiting and discrete component
optimization.
The enclosure is constructed of quality
plywood and coated in JBL’s rugged
DuraFlex™ finish. Durable polypropylene
end-caps add extra protection for the cabinet.
An integrated pole mount on the bottom end-
cap enables easy deployment. The CNC-
machined steel grille wraps around the sides
of the enclosure so there are no protruding
lips on the front of the box to create
acoustical interference. The grille is also lined
with an acoustically transparent foam to
provide additional driver protection.
The amplifier input panel offers XLR or ¼
inch jack compatibility and a sensitivity
switch provides extra flexibility, making it
possible to connect literally any sound source
without using a mixer. Signal present and
overload lights indicate the system status and
assist in setting the optimum level, via the
level control knob.
Preliminary Specifications:
System Type: Self powered 15", two-way, bass-reflex,
Frequency Range (-10 dB): 45 Hz – 20 kHz (EQ in flat position)
Frequency Response (±3 dB): 52 Hz – 20 kHz (EQ in flat position)
Coverage Pattern: 70° x 70° nominal
Directivity Index (DI): 10.3 dB
Directivity Factor (Q): 10.8
Crossover Modes: DSP controlled 48 dB filter slope
Crossover Frequency: 1.6 KHz
System Power Rating: 500 W continuous, 1000 W peak
LF Power amp: Class-D, 400 Watt (continuous) at driver impedance
HF Power amp: Class-D, 100 Watt (continuous) at driver impedance
Distortion: Less than 0.1% at rated power
Maximum SPL1: 133 dB SPL peak
Signal indicators: Overload: Red LED indicates input overload condition
Signal: Green LED indicates signal presents
Input sensitivity: Mic position: –25 dBu to 0 dBu
Line position: +28 dBu to +10 dBu
Input Impedance: 64 K Ohms (balanced), 32 K Ohms (unbalanced)
EQ: Presets for Flat or Boost
LF Driver: 1 x JBL 265F 380 mm (15 in) Differential Drive®woofer
HF Driver: 1 x JBL 2408H 37.5 mm (1.5 in) annular polymer diaphragm,
neodymium compression driver
Enclosure: Trapezoidal, 18 mm, plywood with polypropylene end caps
Suspension / Mounting: 36 mm pole socket
Transport: 2 x die-cast handles with backing cup
Finish: Anthracite DuraFlex™ finish
Grille: Powder coated, Anthracite black, 18 gauge perforated steel
with acoustically transparent black foam backing.
Input Connectors: Balanced XLR / ¼inch combo jack with XLR loop through,
Dimensions (H x W x D): 815 mm x 440 mm x 465 mm
(32 in x 17.25 in x 18.25 in)
Net Weight: 26 kg (57 lb)
1. Maximum Peak output measured with IEC pink noise at 1 meter in front of speaker baffle under free space
conditions. Measurement instrument set to peak hold. Speaker muted and released at full power, recording maximum
peak level.
JBL continually engages in research related to product improvement. Some materials, production methods and design
refinements are introduced into existing products without notice as a routine expression of that philosophy. For this
reason, any current JBL product may differ in some respect from its published description, but will always equal or
exceed the original design specifications unless otherwise stated.
15" 2-Way Self-Powered
Sound Reinforcement
System
74323_JBL_PRX515 1/10/07 9:58 AM Page 1
JBL Professional
8500 Balboa Boulevard, P.O. Box 2200
Northridge, California 91329 U.S.A.
© Copyright 2007 JBL Professional
A Harman International Company
SS PRX515
CRP 5M
01/07
䉴PRX515 15" 2-Way Self-Powered Sound Reinforcement System
PRX515
MIC
LINE
FLAT
BOOST
AMPLIFIER ONLY
Block Diagram
PRX515 Input Panel
dBSPL
50
60
70
80
90
20 Hz 50 100 200 500 1K 2K 5K 10K 20K
100
Frequency Response
Level
Si
g
nal Presen
t
DSP
Overload
Inpu
t
Hi
g
h
Low
Sensitivity Power Amplifiers
Output EQ Selec
t
