Highlights

• Equippedwithoriginal

JBL®GT5-12subwoofers

• Dual-stackedmagnetsand

ventedmotorstructure

• ProprietarySlipstreamtechno-

logytoeliminateportnoise

• Increasedpowerhandling

GT5

Subwoofer enclosures

Key Specifications

GT5-1204BR GT5-1204BP GT5-2402BR

Size: 300mm 300mm 2x300mm

Type of System: Bass-reflex Band-pass Dualbass-reflex

Impedance: 4Ohms 4Ohms 2Ohms

Power Handling, RMS: 275W 275W 550W

Power Handling, Peak: 1100W 1100W 1600W

Sensitivity (@ 2,83V, 1m): 92dB 90dB 95dB

Frequency Response: 45Hz–150Hz 35Hz–100Hz 40Hz–200Hz

Dimensions (W x H x D): 570x369x305mm 602x420x342mm 889x393x318mm

HarmanConsumerGroup,Inc.

8500BalboaBoulevard,Northridge,CA91329,USA

www.jbl.com

©2008HarmanInternationalIndustries,Incorporated.Allrightsreserved.JBLisatrademarkofHarmanInternationalIndustries,Incorporated,

registeredintheUnitedStatesand/orothercountries.

Features,specificationsandappearancearesubjecttochangewithoutnotice.

FE AT URES

Proprietary Slipstream port technology

• Thedouble-flaredshapeoftheoversizedportispreciselycalculated,efficientlyeliminatingportnoise.Evenathigh

SPL,airflowthroughtheportwillremainuniform,offeringbetterlow-frequencyextensionandwooferprotection.

Significantly improved power-handling capabilities

• ThenewGT5enclosuregenerationhandles10percentmorepowerthanpreviousCSandoffersnearly20percent

moreXmaxforhigherSPL.

Increased reliability

• Theventedpolepiecesandmotorstructureprovideadditionalcooling.Incombinationwiththerubber-coatedtinselleads,

thisresultsinmuchbetterlong-termreliability.

Dual-stacked oversized magnets

• Theincreasedmagneticfluxresultsinhigherefficiencyandbetterwoofercontrol.

Oversized protection bars

• Theportedmodels(GT5-1204BRandGT5-2402BR)comewithmassivemetal-bargrillesforabeefylookandperfect

woofer-coneprotection.

Optimized band-pass tuning

• Unlikemanyinexpensiveband-passsubwoofers,theGT5-1204BPisabletoreproduceeventhelowestbassfrequencies

thankstoacarefullytunedenclosure.

Proprietary terminals

• ThelargeterminalsaredesignedexclusivelyforJBLproductsandacceptheavy-dutyspeakerwires.
