If the only thing stopping you from installing a built-in home entertainment system is sound quality, then nothing is
stopping you. The SoundPoint® SP8CII in-ceiling loudspeaker features a 100-watt, 8-inch (200mm) titanium-laminate
woofer and fast titanium-laminate dome tweeter in a swivel mount that together deliver the kind of high-output,
high-impact sound for which JBL® systems have long been famous, with clear, distinct highs and plenty of satisfying,
low-distortion bass. As the primary speakers in a stereo or whole-house music system, or as surround speakers in a
multichannel home theatre, SP8CIIs perform brilliantly, install easily, virtually disappear in your listening area and free up
a few cubic metres of living space in the bargain.
A high-impact, two-channel in-ceiling loudspeaker
TECHNICAL SPECIFICATIONS
SoundPoint SP8CII Speaker System:
Low-frequency transducer: 8" (200mm) titanium-laminate cone with rubber surround
High-frequency transducer: 1" (25mm) titanium-laminate dome with swivel mount
Maximum recommended power: 100 watts
Impedance: 8 ohms nominal
Frequency response: 32Hz – 20kHz (–10dB)
Sensitivity: 89dB (2.83V/1m)
Crossover frequency: 2.4kHz
Plate size (diametre): 10-7/8" (275mm)
Mounting cutout size (diametre): 9-1/2" (240mm)
Mounting depth: 4-1/4" (108mm)
Weight: 5.6 lb (2.5kg) per speaker
JBL® SOUNDPOINT®
SP8CII
JBL SOUNDPOINT
SP8CII
A high-impact, two-channel in-ceiling loudspeaker
HARMAN Consumer, Inc.
8500 Balboa Boulevard, Northridge, CA 91329 USA
www.jbl.com
© 2010 HARMAN International Industries, Incorporated. All rights reserved.
JBL and SoundPoint are trademarks of HARMAN International Industries, Incorporated, registered in the United States
and/or other countries.
Features, benefits and appearance are subject to change without notice.
HIGHLIGHTS
8" (200mm) low-frequency transducer
The stiff titanium-laminate cone delivers clean, rich bass with lower distortion at high output levels
than lesser cone materials
The rubber surround improves performance and durability for longer speaker life
An extended polepiece increases power handling for higher overall bass output
1" (25mm) titanium-laminate dome tweeter
Titanium laminate offers greater strength and heat absorption than other commonly used dome
materials for better power handling and higher output
The swivel tweeter mount allows the speaker to aim high-frequency sound toward the primary
listening area, increasing speaker placement options
FEATURES
• Available rough-in frame for easy installation in new construction
• Integral dog-ear brackets simplify installation in existing homes
• Paintable frame and grille allow speakers to disappear into your room’s décor
