SPECS
VTX B18 VT | Vertical Transporter
• Vertical transport cart for 4 x VTX B18 enclosures
• Truck-friendly dimensions
• Built-in stacking features for easy storage
• Lightweight design
• Heavy-duty casters
The VTX B18 VT vertical transporter is a robust, lightweight cart solution for vertically transporting up to 4 x VTX B18 enclosures. The
VTX B18 VT is constructed out of aluminum and steel parts and measures 32” (813mm) wide and 30” (762mm) deep. When transported
in blocks of 2, 3 or 4, B18 cabinets can be configured in either front-firing or cardioid mode. The VTX B18 VT CVR, a reinforced protective
cover, is available and supplied separately. Front-face dolly and cover is available for individual B18 transportation (VTX B18 ACC). For
more information about the Vertical Transporter and use cases, refer to the VTX B18 Rigging Manual.
• 1 x VTX B18 VT Vertical Transporter Cart
INCLUDED
HIGHLIGHTS
DESCRIPTION
SPECS
VTX B18 VT | Vertical Transporter
762.00mm (30.00”)
DIMENSIONS
TECHNICAL SPECIFICATIONS
Construction: High-grade steel with anti-corrosion coating
Finish: Black Powder Coat
Mechanical Limits
Maximum:
4 x VTX B18
Dimensions (H x W x D)1:250.00 mm x 812.80 mm x 762.00 mm
(9.85 in x 32.00 in x 30.00 in)
Net Weight2:22 kg (49 lbs)
Footnotes:
1: Refer to the 2D and 3D Customer Drawings for more detailed dimensions
2: Shackles and other rigging parts not included
JBL continually engages in research related to product improvement. Some materials, production methods and design refinements are introduced into existing products without notice as a routine expression of that philos-
ophy. For this reason, any current JBL product may differ in some respect from its published description, but will always equal or exceed the original design specifications unless otherwise stated.
© 2018 Harman International Industries, Incorporated | 8500 Balboa Blvd. Northridge, CA 91329 USA | www.jblpro.com | Part Number: 5108379-00 | Version: A
812.80mm
(32.00”)
250.00mm
(9.85”)
