ACTIVERSEMONITOR‐10.1STD

ATM1010AA0

ActiveRearSeatEntertainment

System

OwnersManual

ATM1010AA0OwnersManual

English

2012AtomEnterprises,Inc.Allrights

reserved.Thismanual,oranyportionthereof,

maynotbereproducedwithouttheexpress

writtenconsentofAtomEnterprises,Inc.

Foranyquestions,pleasecallcustomer

service(855)574‐2866

www.atomenterprisesinc.com

ATM1010AA0OwnersManual

TableofContents

English

Generalinformation4

Safetyinstructions4

GeneralCharacteristics4

Cleaningandcare4

Supportedmedia5

Countrycodes5

Openingandclosingdisplay6

Frontpanelcontrolbuttons7

Inputs/outputs8

Remotecontrol9‐10

WirelessIRheadphones11

Operation

Playingadisc12

PlayingmediaviaA/Vinput12

PlayingmediaviaUSB12

PlayingmediaviaHDMI/MHLinput12

FMTransmitterfunction12

Sharingmediabetweenmonitors13

Setup

Systemsetupmenu13

DVDsetupmenu13

Troubleshooting14

Complianceinformation14‐16

Specifications16

English

GeneralInformation

Pleasereadthisinstructionmanual

carefully.

Poorroadconditionscancause

problemswithsomemediaplayback.

Incoldenvironments,thescreenmay

sometimesdisplaydistortion.Thisis

normal.

SafetyInformation

Forsafetyreasons,itisrecommended

thatmediaisonlychangedwhen

vehicleisstationary.Childrenshould

notbepermittedtounfastentheir

seatbelttofunctionthe

system/changemedia.Systemcanbe

functionedusingtheremotecontrol

withseatbeltsfastened.

Theuseofheadphonesathighvolume

cancausepermanentdamageto

hearing.Toavoidhearingdamage,set

thevolumetolowbeforeusingthem.

Itisunlawful,inmostjurisdictions,

andunsafetodriveamotorvehicle

whichisequippedwithavideodisplay

thatisvisible,directlyorindirectly,by

thedriverwhilemoving.Thissystem

shouldneverbeinstalledwherevisible

bythedriver.

GeneralCharacteristics

•10.1” LEDLCDdisplay

•1024x600Resolution

•SlotloadDVDplayer

•Frontsensorkeypadcontrols

•SupportIRheadphones/remote

control

•AnalogA/Vinput‐1/8” Jack

•USB2.0/1ampcharging

•SDcardslot

•Stereoheadphoneoutput‐1/8” Jack

•FMTransmitter(88.3‐107.7MHZ)

Caution

Donotoperatethesystemwithout

thevehiclerunning,asitmaycause

thebatterytodrain.Pleasemakesure

thesystemisturnedoffwhenthe

vehicleisnotrunning.

CleaningandCare

Cleanyourrearseatentertainment

systemwithasoft,drycloth.For

stubborndeposits,amildcleaning

agentmaybeused.Wipeoffand

finishwithadrycloth.

Pleasenotethatstrongcleaning

agents,suchasalcohol,thinners,

benzene,insecticides,maycause

damagetothesystemandshould

neverbeused.

English

SupportedMedia

Supporteddiscmedia

Beforeinsertingmedia,ensurethatit

iscompatiblewiththesystem.Please

notethatthefollowingdatamediais

NOTcompatiblewiththesystem:

•Opticaldatamedia(CD‐1,CD‐ROM,

DVD‐ROM)

•Minidisc

Disctypesthatare

compatible

SupportedUSB/SD

mediafiles

MP3,WMA,OGG,MPE,MPG,MPEG,AVI,

DIV,VID,VOB,JPG,JPEG, AAC,M1V,

M2V,OGM.

SupportedHDMI/MHL

input

•HDMImediafromanyHDMIoutput

Device

•HDMImediafromMHLcompatible

device(ie:MHLcompatible

smartphone,MHLcompatibletablet,

etc)NOTE:onlycertaindevicesare

MHLcompatibleandmayrequire

specialcables/adapters(pleasecheck

withthedevicemanufacturer)

Symbol DiscType

VideoDVD

AudioCD(ie:CD‐

RwithMP3,

MPEG,WMA,or

JPGfiles)

VideoCD

Region Countriesinthis

region

1 Canada,USA,USterritories

2 Japan,Europe,SouthAfrica,

MiddleEast(includingEgypt)

3SouthEastAsia,EastAsia

(includingHongKong)

4 Australia,NewZealand,

PacificIslands,Central

America,Mexico,South

America,Carribean

5FormerSovietUnion,(also

NorthKorea,Mongolia),

Indiansubcontinent,Africa

6 China

Countrycoderestrictions

IfthecountrycodeonaDVDdiscdoes

notmatchthesystemcountrycode,

theDVDcannotbeplayed.

English

Openingandclosingthedisplay

Displayisheldclosedwith2flexibletabsthatsnapintothesidesofthedisplay.

Pullonthetabsoutwardtodisengagethetabsbeforeopeningthedisplay.The

displaycanthenbeopenedandviewingangleadjustedbyrotatingitintothe

uprightposition(seebelow)

Caution:

Pleasemakesuretabsaresnappedfullyintothedisplaywhenin theclosed

positiontomakesurethedisplayissecuredsafely.

Displayclosed

Displayopen

Closuretabs

PanelControlButtons/Discslot

English

12345

1. Powerbutton‐turnssystempoweron/off.

2. Sourcebutton‐selectmediasourceforplayingmedia(ie:DVD,AV

input,MHL/HDMI,USB,SD)

3. Play‐startsplayingmediasourceselected.

4. Pause‐pausesmediathatisplaying.

5. Stop‐stopsmediathatisplaying.

6. Eject‐ejectsdisc(displayMUSTbeinclosedpositiontoinsert/eject

disc)

7. Discslot(ONLYACCESSIBLEWHENDISPLAYISCLOSED)

8. Monitoridentification‐“A” OR“B”.

English

Inputs/Outputs

5

4

3

2

1

1. HDMIinput(MHLcompatible)

2. USB2.0input(1ampcharging)

3. Headphonejackoutput(wired)

4. A/Vinputjack(analog3.5MM)

5. SDcardslot

RemoteControl

Buttons/Functions

TocontrolmonitorA,presstheAbuttonfirst.

TocontrolmonitorB,presstheBbuttonfirst.

1.POWER‐turnspoweron/off

2.UP ‐navigateselectionup

3.LEFT ‐navigateselectionleft

4.ENTER ‐acceptsselection

5.FM ‐turnsFMtransmitteron/off

(stationcanalsobechangedwhen

buttonisdepressed)**Functionisfor

MonitorAonly.

6.PLAY ‐selecttoplaymedia

7.REVERSE ‐reversesplay(fast)

8.PREVIOUS ‐selectsprevioustrack

9.STOP ‐stopsmediafromplaying

10.A‐depresstocontrolAmonitor

11.SOURCE ‐selectssourcetoplay

media(DVD,USB,SD,AUX,MHL/HDMI)

12.SYSOSD‐displayssystemmenu

13.EJECT ‐ejectsdisc(onlywhen

displayisinCLOSEDposition)

14.RIGHT ‐navigateselectionright

15.DOWN ‐navigateselectiondown

16.DVDMENU‐displaysDVD“ROOT

MENU”

17.FORWARD ‐playsmediafast

forward

18.PAUSE ‐pausesmediabeingplayed

19.NEXT ‐selectsnexttrack

20.B‐depresstocontrolBmonitor

21.DVDOSD‐displaysDVDsetup

22.OUTPUTSOURCE‐displayslistof

outputsources(formonitorAonly)

RemoteControlBattery

Installation/Operation

English

TAB

1. Removebatterycoverby

depressingtab(indirection

ofarrow)thenliftingcover.

2. Insert2AAAbatteries(make

surebatteriesareinstalled

withcorrectpolarity(+/‐)

3. Reinstallbatterycover

!NOTE:Thereisriskoffireif

batteriesarenothandled

correctly.DoNOTrecharge

batteries.DoNOTintermix

differentbatterytypes,or

batteriesnotchargedthe

sameamount.

Pleasedisposeofbatteriesper

locallaws.

Pleasekeepbatteriesoutofreach

ofchildren.

Operation

TocontrolmonitorA,presstheAbuttonfirst.TocontrolmonitorB,press

theBbuttonfirst.

Remotecontrolhasaninfraredbeam,whichmustbeaimedtowards the

topofthedisplaymonitorbeingcontrolled.

Monitorwillnotreceiveremotesignalifbeamisblocked.

WirelessHeadphones

Headphonesaredualchannel(AandBchannel)infraredwireless.

Channelmustbeselectedtomatchthedisplaymonitorbeingviewed(see

below)

Headphonesmustbeinlineofsightofdisplaymonitortoreceiveaudiosignal

Headphonesrequire(2)AAAbatteries.

NOTE:Pleasemakesurevolumecontrolissettolowforthesafetyofthenext

user(excessivevolumecancausepermanentdamage)

Pleasenote:headphoneswillpoweroffautomaticallyifnoaudio isplayedfor

morethan3minutes.Thisissothebatteriesaren’tdrained.Intheeventthis

happens,justturntheswitchoffthenon.

Volumecontrol

Poweron/offswitch

ChannelA/Bselectionswitch

Batterycover(depressandslidedowntoremove)

Monitor“A/B”

identification

location

Operating

Instructions

Turningpoweron

Turnvehicleignition“ON/ACC”.

PresspowerbuttononRSEfrontpanel

orremotecontrol.

PlayingaDisc

Closedisplayandinsertdisc(labelside

facingtowardsyou)

Opendisplay(AFTERDISCISFULLY

INSERTED)

MakesureDVD–Discistheselected

source.

Pressplaytostartmedia.

NOTE:disccanonlybeejectedwhen

displayisinclosedposition.

PlayingmediafromUSB

InsertUSBdeviceintoUSBslotonleft

sideofunit.

MakesureDVD‐USBistheselected

source.

Usenavigationbuttonsonremoteto

controlmediafiles

PlayingmediafromSD

card

InsertSDcardintoSDcardsloton

rightsideofunit.

MakesureDVD‐SDistheselected

source.

Usenavigationbuttonsonremoteto

controlmediafiles.

PlayingmediafromAUX

input

PlugsmallmaleendofAVcableinto

3.5mmAVinputonrightsideofunit

Plugotherjackends(RCAtype)into

devicetobeplayed.

MakesureAUXistheselectedsource.

Playdeviceperdeviceinstructions.

Playingmediafrom

HDMI/MHLinput

PlugHDMIcableconnectorintoHDMI

jackonleftsideofunit.

Plugotherendofcableintodeviceto

beplayed.

MakesureMHL/HDMIisselected

source.

Playdeviceperdeviceinstructions.

NOTE:onlydeviceswithMHLor

HDMIoutputcapabilitycanbeused.

Playingaudiothrough

vehicleradiosystem

DepressFMontheremotecontrol(if

FMbuttonisdepressedagain,itwill

turnofftheFMtransmitted)

Usetheleft/rightnavigationbuttons

toselectdesiredradiostationtoplay

audio(88.3MHZ~107.7MHZ)

Tunevehicleradiotostationselected

onunit.

NOTE:Qualityofaudiomaybe

affectedbystationselected.Certain

radiostationsmaynotbeclearly

audiblewhenFMtransmitteris

turnedon.

Sharingmediaon

monitorBfrommonitor

1.Pressoutputsourcebuttonon

monitorA.

2.Usetheup/downnavigation

buttonsoroutputsourcebuttonto

scrollthroughsources(DVD‐disc,DVD‐

SD,etc)

3.Selectsourcedesiredtobeviewed

onmonitorB.

4.Pressthesourcebuttononmonitor

B.

5.Usetheup/downnavigation

buttonsorsourcebuttontoscroll

throughthesourcesavailableuntil

monitorAishighlighted.

6.SelectmonitorA.

NOTE:mediacanonlybesharedfrom

monitorAtomonitorB.media

cannotbesharedfrommonitorBto

monitorA.MHL/HDMIcannotbe

sharedfromtheAmonitortotheB

monitor.Thisisnormal.

English

Troubleshooting

Unitwillnotpoweron

1.Besurevehicleisturnedon

Remotecontrolnot

working

1.Checkbatteriesforcorrect

installationandmakesuretheyhave

plentyofchargeleft.

2.Makesurecorrectmonitoris

selectedontheremoteforthe

monitordesiredtobecontrolled

(monitorA/B)

3.Besureremoteisaimeddirectly

towardstopofmonitorbeing

controlledwithnoobstructions.

Nopicture

1.Ensurecorrectsourceisselected(ie:

DVD‐Disc,DVD‐SD,etc)

2.Ensureanyexternaldevicesare

correctlyconnected(ie:cable/sfor

AUXinput,USB,SD,etc)

NosoundthroughIR

headphones

1.Checkbatteriesforcorrect

installationandmakesuretheyhave

plentyofchargeleft.

2.Checktomakesurechannel

selectedonheadphonesmatchesthe

monitorbeingwatched(AorB)

3.Besureheadphonesareinlineof

sightofdisplaymonitorbeingwatched

withnoobstructions.

FCCdeclaration

ThissystemcomplieswithFCC

directive,section15.Systemissubject

tothefollowing2conditions:

1.Thissystemmustnotcauseany

harmfulinterference

2.Thissystemmaybesubjectto

interferencewhichmaycause

unwantedoperation.

FCCwarning

1.InordertoensureongoingFCC

compliance,thesystemmustbe

connectedandoperatedwiththe

suppliedcablesonly.

2.Unauthorizedmodificationsor

alterationstothesystemmayvoidthis

operatingpermit.

FCCnotice

Notice:Thechangesormodifications

notexpresslyapprovedbytheparty

responsibleforcompliancecouldvoid

theuser’sauthoritytooperatethe

equipment.

TocomplywiththeFCCRFexposure

compliancerequirements,nochange

totheantennaorthedeviceis

permitted.Anychangetotheantenna

orthedevicecouldresultinthedevice

exceedingtheRFexposure

requirementsandvoiduser’s

authoritytooperatethedevice.

English

CanadaIC

ThisClassBdigitalapparatus

complieswithCanadianICES‐003.

ThisdevicecomplieswithIndustry

Canadalicense‐exemptRSS

standard(s).Operationissubjectto

thefollowingtwoconditions:(1)this

devicemaynotcauseinterference,

and(2)thisdevicemustacceptany

interference,includinginterference

thatmaycauseundesiredoperationof

thedevice.

Thisdeviceanditsantenna(s)must

notbeco‐locatedoroperationin

conjunctionwithanyotherantennaor

transmitter.

UnderIndustryCanadaregulations,

thisradiotransmittermayonly

operateusinganantennaofatype

andmaximum(orlesser)gain

approvedforthetransmitterby

IndustryCanada.Toreducepotential

radiointerferencetootherusers,the

antennatypeanditsgainshouldbeso

chosenthattheequivalent

isotropically radiatedpower(e.i.r.p.)is

notmorethanthatnecessaryfor

successfulcommunication.

Macrovision

Thisproductcontainscopyprotection

technologyprotectedbyUS

patentsandotherintellectual

propertyrights.Theuseofthis

copyprotectiontechnology

requiresthepermissionof

macrovision andisintended

withoutexpressfurtherapproval

frommacrovision onlyfor

domesticuseandotherlimited

applications.Reverseengineering

ordismantlingareforbidden.

English

WEEEdirective

Disposalofoldelectricaland

electronicequipment(applicablein

theEuropeanUnionandother

Europeancountrieswithseparate

collectionsystems)

Thissymbolontheproductorit’s

packagingindicatesthatthedevice

mustnotbetreatedashousehold

waste.Instead,itmustbehanded

overattherelevantcollectionpoint

fortherecyclingofoldelectricaland

electronicequipment.Withcorrect

disposalofthedevice,youarehelping

toavoidanynegativeeffectsonthe

environmentandhumanhealthwhich

mightotherwisebecausedbythe

incorrectdisposalandtreatmentof

waste.Therecyclingofmaterialshelps

preservenaturalresources.Youcan

obtainmoreinformationabout

recyclingthisdevicefromyourcity

council,yourdisposalcompanyfor

householdwaste,orfromthestorein

whichyouboughtit.Applicable

accessories:remotecontrol,

headphones.

Specifications

Panelsize 10.1”

Resolution 1024x600

Backlight LED

Ratio 16:9

Luminance 500NIT(typ.)

Expected

backlightlife

20khoursMin.

Operation

temperature

‐20~70degreesC

Storage

temperature

‐30~80degreesC

Videodisplay

system

NTSC

Inputvoltage 10‐16VDC

I/Oports USB2.0,HDMI,SD,

3.5mmAV,3.5mm

earphone

IRChannels Amonitor:2.3/2.8mhz

Bmonitor:

3.2/3.8mhz

Supported

formats

MP3,WMA,OGG,MPE,

MPG,MPEG,AVI,

DIV,VID,VOB,JPG,JPEG

AAC,M1V,M2V,OGM

ATM1010AA0OwnersManual

Spanish

ATM1010AA0OwnersManual

French

JET OPTOELECTRONICS ATM1010AA0 ACTIVE RSE MONITOR-10.1 STD User Manual Microsoft PowerPoint

JET OPTOELECTRONICS CO.,LTD. ACTIVE RSE MONITOR-10.1 STD Microsoft PowerPoint

User manual

Navigation menu

Namespaces

Views

Navigation
