JETOP IHCTB627CW WIRELESS HOME MUSIC SYSTEM User Manual Users manual

JETOP INDUSTRIAL LIMITED WIRELESS HOME MUSIC SYSTEM Users manual

Users manual

Wireless Home Music System
User’s Guide for Model IHCTB627CW v1831-01
IHCTB627CW-IB -Lab.indd 1 1/18/2017 10:02:58 AM
2
Safety Instructions & Warnings
WARNING: To reduce the risk of electric
shock, do not remove cover (or back). No
user-serviceable parts inside. Refer servicing
to qualied service personnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of un-insulated
“dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude
to constitute a risk of electric shock to persons.
This product utilizes a Class 1 laser to read
Compact Discs. This laser Compact Disc
Player is equipped with safety switches to
avoid exposure when the CD door is open and
the safety interlocks are defeated. Invisible
laser radiation is present when the CD Player’s
lid is open and the system’s interlock has failed
or been defeated. It is very important that you
avoid direct exposure to the laser beam at
all times. Please do not attempt to defeat or
bypass the safety switches.
IHCTB627CW-IB -Lab.indd 2 1/18/2017 10:02:59 AM
3
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers)
that produce heat.
• Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. When the provided
plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories specied by the
manufacturer.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• Use only with a cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is
used, use caution when moving the cart/
apparatus combination to avoid injury from
tip-over.
FCC Warnings
Warning: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC Notice:
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierent
fromthattowhichthereceiverisconnected.
• Consultthedealeroranexperiencedradio/TVtechnician
forhelp.
Battery Warnings
• WARNING: Do not ingest the battery, Chemical Burn
Hazard.
• The remote control supplied with this product contains a
coin/button cell battery.
• If the coin/button cell battery is swallowed, it can cause
severe internal burns in just 2 hours and can lead to death.
• Keep new and used batteries away from children. Iff the
battery compartment does not close securely, stop using the
product and keep it away from children.
• If you think batteries might have been swallowed or
placed inside and part of the body, seek immediate medical
attention.
• CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
• WARNING: There is a danger of explosion if you attempt
to charge standard Alkaline batteries in the unit. Only use
rechargeable NiMH batteries.
• Battery shall not be exposed to excessive heat such as
sunshine, re or the like.
• Do not mix old and new batteries.
• Completely replace all old batteries with new ones.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable
(ni-cad, ni-mh, etc) batteries.
• Batteries should be recycled or disposed of as per state and
local guidelines.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
• Mains plug is used as disconnect device and it should remain
readily operable during intended use. In order to disconnect
the apparatus from the mains completely, the mains plug
should be disconnected from the mains socket outlet
completely.
• CAUTION: Use of controls or adjustments or performance
of procedures other than those specied may result in
hazardous radiation exposure.
• WARNING: Changes or modications not expressly
approved by the party responsible for compliance could void
the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference. (2) This device
must accept any interference received, including interference
that may cause undesired operation.
• WARNING: Use of this unit near uorescent lighting may
cause interference regarding use of the remote. If the unit is
displaying erratic behavior move away from any uorescent
lighting, as it may be the cause.
• WARNING: Shock hazard - Do Not Open.
• Caution and marking information is located at the rear or
bottom of the apparatus.
• WARNING: To reduce the risk of re or electric shock,
do not expose this apparatus to rain, moisture, dripping, or
splashing.
• Objects lled with liquids, such as vases, shall not be placed
on the apparatus.
• WARNING: This product may contain chemicals known
to the State of California to cause birth defects, or other
reproductive harm (California Prop 65). Wash hands after
handling.
• This product meets and complies with all Federal regulations.
IHCTB627CW-IB -Lab.indd 3 1/18/2017 10:02:59 AM
4
Table of Contents
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Includes
Power
Speakers
Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Features & Controls
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Functions
Batteries
Connecting External Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Pairing Bluetooth and Playing Audio Wirelessly
Using the Aux In (3.5mm Audio Input)
RCA Audio Output
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Playing a Record
Loading and Playing a CD
Programming a CD
Playing the AM/FM Radio
Programming Radio Station Presets
Playing a Cassette Tape
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Contact Information
Warranty
International Support
IHCTB627CW-IB -Lab.indd 4 1/18/2017 10:02:59 AM
5
Setup
L
R
AUDIO OUTPUT
L
R
AUDIO OUTPUT
Includes
• Remote control with CR2025 battery
• 45 rpm adapter
• User's Guide
Power
Plug the built in AC power cord into a standard wall
outlet.
Speakers
Connect the speaker wires to the speaker inputs on
the turntable. Be sure to match the positive (red) and
negative (black) wires to their corresponding inputs.
120V~60Hz
RL
SPEAKER OUTPUT
FM ANT.
L
R
AUDIO OUTPUT
IHCTB627CW-IB -Lab.indd 5 1/18/2017 10:03:01 AM
6
Orientation
Speakers
Features & Controls
120V~60Hz
RL
SPEAKER OUTPUT
FM ANT.
L
R
AUDIO OUTPUT
VOLUME
MIN MAX
–
TUNE / SKIP
+
OPEN / CLOSE
REPEAT 1 / ALL
POWER
CD PLAYER /
AUX IN
SOURCE
FM Antenna
Cassette
Player
Dust Cover
Speaker Output
Connect included
speakers here.
Power
Display Volume
CD Player
Remote
Receiver
Open/Close
Play/Pause/Pair
Bluetooth
Stop
Tune/Skip Track
Repeat 1/All
Source
Audio Output
Connect to send
audio signal to an
external source.
Aux In (3.5mm
Audio Input)
IHCTB627CW-IB -Lab.indd 6 1/18/2017 10:03:02 AM
7
Tone Arm
& Stylus
Record Speed
Choose 33, 45, or
78, depending on
the type of record
to be played.
Auto Stop
Select ON or OFF.
Tone Arm
Lock
Turntable
Tone Arm
Lift Switch
45 rpm Record Adapter
IHCTB627CW-IB -Lab.indd 7 1/18/2017 10:03:03 AM
8
Remote Control
POWER
SOURCE
PROG MUTE
TUNE +
TUNE –
REPEAT 1
/ ALL
VOLUME
OPEN Open
Press to open the CD player.
Stop
Press to stop audio track.
Play/Pause/Pair
Press to play or pause an
audio track.
In Bluetooth mode, press
and hold to pair.
Volume
Press to adjust volume.
Mute
Press to mute volume.
Power
Press to power the
system ON or OFF.
Source
Press to set the media source.
Repeat 1/All
Press to repeat 1 audio track or
all audio tracks on a loaded CD.
Stop
Press to stop and audio track.
Skip/Tune
Press to skip and audio track.
In FM radio mode, press
to adjust the tuning.
Prog
Press to program tracks to
play in a specific order.
Batteries
Requires 1 CR2025 battery (included).
Functions
IHCTB627CW-IB -Lab.indd 8 1/18/2017 10:03:03 AM
9
RCA Audio Output
Requires RCA audio cables (red/white, not included). Use to
connect the turntable to an external stereo system.
1. Connect RCA audio cables to the Audio Output on
the back of the turntable, and to the audio input of
an external stereo system.
2. If need be, adjust the external stereo system to
accept input from the turntable.
3. Audio played through the turntable should now be
heard through the connected stereo system.
Note : The Audio Output sends a fixed audio volume level to any connected audio device. To adjust the volume, you
must change it from the connected device.
Using the Aux In (3.5mm Audio Input)
Requires 3.5 mm audio input cable (not included).
1. Plug a 3.5 mm audio input cable into the Aux In on
the unit and the headphone jack on an MP3 Player or
other audio source.
2. Set the Source to Aux and use the controls on your
connected music player to select and play audio.
3. Audio played through the connected device should
now be heard through the speakers.
L
R
AUDIO OUTPUT
L
R
AUDIO OUTPUT
VOLUME
MIN MAX
–
TUNE / SKIP
+
OPEN / CLOSE
REPEAT 1 / ALL
POWER
CD PLAYER /
AUX IN
SOURCE
VOLUME
MIN MAX
–
TUNE / SKIP
+
OPEN / CLOSE
REPEAT 1 / ALL
POWER
CD PLAYER /
AUX IN
SOURCE
Connecting External Devices
Pairing Bluetooth and Playing Audio Wirelessly
1. Set the Source to BT and press and hold the Play/Pause/Pair button. The pairing indicator will begin quickly
flashing blue. When pairing, remain within 3 feet of the unit.
2. Using the controls on your Bluetooth device, search for and select IHCTB627 in your Bluetooth settings to pair. If
your device requests a password, enter the default password 0 0 0 0 . If need be, refer to the user’s manual for your
specific device for instructions on pairing and connecting Bluetooth devices.
3. When successfully paired and connected, an audible chime will sound and the pairing indicator will turn solid.
After initial pairing, the unit will stay paired unless unpaired manually by the user or erased due to a reset of the
device. If your device should become unpaired or you find it is unable to connect, repeat these steps.
4. Use the controls on your connected Bluetooth Device to select and begin playing audio. Play, pause or skip a
selected track using the controls on the connected Bluetooth Device or the controls on the turntable.
IHCTB627CW-IB -Lab.indd 9 1/18/2017 10:03:06 AM
10
Operation
Playing a Record
It is recommended that you use extreme care when manipulating the tone arm, stylus, and other components of this
turntable. These parts are very sensitive and can easily break or become damaged if they are carelessly handled.
1. Set the Source to Phono.
2. Lift open the turntable cover and place the record on the turntable. If you are playing a 45 rpm record, use the
included 45 rpm adapter and place it between the turntable and the record.
3. Remove the shroud that protects the stylus and release the lock that holds the Tone Arm in place.
4. Use the Tone Arm Lift Switch to raise the Tone Arm from its catch.
5. Using your hand, gently swing the Tone Arm into the desired location over the record. The turntable will start
spinning as the Tone Arm is moved into position.
6. Use the Tone Arm Lift Switch to safely lower the stylus onto the record.
Using the Lift Switch instead of your hand will reduce the chance of accidentally damaging the record or the stylus.
7. Slide the Auto Stop Switch to ON to enable the Auto Stop feature. When the record is finished playing, it will
automatically stop the turntable. Use the Lift Switch to raise the stylus off of the record, and gently return the
Tone Arm to the catch by hand.
Note: Some records place their Auto Stop area outside of the range of this unit. In these cases, the record will stop
playing before the last track is reached. Set the Auto Stop Switch to OFF and use the Tone Arm Lift Switch to safely
raise the stylus off the record when the end of the record has been reached.
8. When not in use, secure and lock the Tone Arm in its resting position and replace the protective shroud over the
stylus. This will minimize the risk of accidental damage to these sensitive parts.
Lock Unlock
IHCTB627CW-IB -Lab.indd 10 1/18/2017 10:03:06 AM
11
Playing the AM/FM Radio
Adjust the position of the antenna to improve AM/FM radio reception.
1. Set the Source to Tune mode.
2. Use the Tuning buttons to tune to a desired frequency band.
Loading and Playing a CD
1. Press the Open/Close button to open the CD tray.
2. Place a CD in the tray, label side facing up, and close the CD tray.
3. Set the Source to CD mode.
4. Use the controls on the unit to begin play, pause, stop and skip audio on the loaded disc.
Programming a CD
1. Press the Stop button to stop a loaded CD.
2. Press the Prog button on the remote. “01” will blink on the display.
3. Press the Skip Fwd/Rev buttons to select a track.
4. Press the Prog button to add the selected track to the program. Repeat this process to program up to 20 tracks
to play in a specified order.
5. Press the Stop button to cancel a program.
PLAY
F. FWD
PLAY
F. FWD
F. FWDF. FWD
Playing a Cassette Tape
1. Set the Source to Tape.
2. Insert a cassette tape in the Cassette Door on the side of the unit.
3. Use the control button on the side of the unit to play, fast forward and eject the cassette.
Play EjectFast Forward
Programming Radio Station Presets
1. With the radio on, tune to a desired frequency and press & hold the Prog button on the remote or the unit.
2. Press the Tune+/- buttons on the remote to select a preset number. Up to 20 stations may be preset.
3. Once you have selected the preset number you wish to program, press the Prog button again to save the
current station to that preset.
IHCTB627CW-IB -Lab.indd 11 1/18/2017 10:03:07 AM
12
Protect for Today
Sustain for Tomorrow
Made
Green
International Support
To download this User’s Guide in English, Spanish, and French, or to get answers to frequently asked questions, visit
the support section at: www.iliveelectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes,
visite la sección de apoyo en: www.iliveelectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des
questions fréquemment posées, consultez la rubrique d’assistance sur: www.iliveelectronics.com
Contact Information
Website: www.iliveelectronics.com
Email Support: prodinfo@dpiinc.com
Email Parts: partsinfo@dpiinc.com
Phone Support: 1-888-999-4215
Customer Support
Copyright © 2017 Digital Products International (DPI, Inc.). All other trademarks appearing herein are the property of
their respective owners. Specifications are subject to change without notice.
IHCTB627CW-IB -Lab.indd 12 1/18/2017 10:03:07 AM

Navigation menu
