User Manual
Power
Press and hold to power
ON or OFF
Wireless Headphones
User’s Guide for Model SAHB48 v1978-01
LED
MIC
Volume +/-
Press to adjust volume.
Play / Pause / Speakerphone
Press to play or pause audio.
Press to answer incoming phone call.
Pair Bluetooth
Press and hold for 9 seconds to
pair Bluetooth.
Features
• Bluetooth Wireless: range - 33 ft.
• Built-in microphone
• Aux in (3.5mm audio input)
• Folding adjustable headband
• On-ear controls
• Voice prompts announce headphone operations
• Built-in rechargeable lithium ion battery: life - approx. 8 hrs
• Micro-USB port for battery recharge
Includes
• 3.5mm audio cable
• Micro-USB to USB charging cable
DC Power Input
Microphone
Indicator LED
Aux In
Battery Charging
Initial charge time is approximately 2 hours. Charge fully before
use. The low battery indicator will ash for 1 minute, then the
unit will automatically power OFF.
1. Using a Micro-USB to USB cable (included), connect to
the USB port of a powered on computer or USB power
adaptor (not included) to charge the unit.
LED
MIC
STATUS INDICATOR
Power On Flashing blue light
Charging Solid red light
Charging Complete Light OFF
Pairing Flashing red / blue light
Pairing Complete Solid blue light
SAHB48-1978-01-IB.indd 1 21/7/2017 10:37:03
Speakerphone
1. To accept a call, press the button, or use the
controls on the connected phone.
2. To end a call, press the button, or use the controls
on the connected phone.
3. To re-dial the last dialed number, press the
button twice.
Pairing Bluetooth & Playing Audio
After initial pairing to a Bluetooth device, the headphones will
stay paired unless unpaired manually by the user, or erased due
to a reset of the device. If your device should become unpaired
or you nd it is unable to connect, repeat these steps.
1. Press and hold the Power button to power on the unit.
2. Press and hold the Pair button for 7-9 seconds to begin
pairing. The LED indicator will begin quickly ashing
blue and red. When pairing, remain within 3 ft. of the unit.
3. From your smartphone or other Bluetooth device, access
Bluetooth Settings and search for nearby devices. Select
SAHB48 when it is discovered.
4. When successfully paired, the LED indicator will
turn solid blue and a voice will announce “Bluetooth
connected”.
5. Audio played through the connected Bluetooth device
will now be heard through the headphones. Use the
controls on the connected device to select and begin
playing audio.
6. Use the controls on the connected device or the earbuds
to play, pause, skip, or change volume.
Customer Support
Customer Service:
1-888-999-4215
| Email Support:
prodinfo@
dpiinc.com
| Email Parts:
partsinfo@dpiinc.com
For Warranty Information and the most up-to-date version of
this User’s Guide, go to
www.iLiveElectronics.com
To download this User’s Guide in English, Spanish, or French, or
to get answers to frequently asked questions, visit the support
section at:
www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y
francés, o para obtener respuestas a preguntas frecuentes,
visite la sección de apoyo en:
www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol
ou français, ou pour obtenir des réponses à des questions
fréquemment posées, consultez la rubrique d’assistance sur:
www.iLiveElectronics.com
Copyright © 2017 Digital Products International (DPI, Inc.).
All other trademarks appearing herein are the property of their
respective owners.
Specications are subject to change without notice.
Aux In
Aux In mode will function even if the headphones are not
powered on. To conserve battery power, keep them powered
o when using Aux In.
Requires a 3.5mm audio cable (included).
1. Connect a 3.5mm audio cable to the Aux In on the
headphones and the audio output on an audio device.
2. Use the controls on the connected device to select and
play audio.
LED
MIC
SAHB48-1978-01-IB.indd 2 21/7/2017 10:37:03
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved
by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
FCC warning
