Product Overview
The devices Mini PCI-e adapter cards contain an Atheros chip for Wireless LAN
applications. The mini PCI-e adapter cards support key security features like Wi-Fi
Protected Access (WPA), WPA2, WEP and 802.1x.
Typical application of the card is integration into other wireless products such as AP/ Router
which is used distance 20 cm away human body.
Packaging Contents
The mini PCI-e card package contains the following item(s):
1 x Wireless Mini PCI-e Adapter
Installation guide
Shut down the power of the platform
Align the Mini PCI-e adapter with the Mini PCI-e socket on the platform
Adjust and push down the Mini PCI-e adapter gently until the metal locking levers on the
Mini PCI-e socket is latched. (Please take note that the Mini PCI-e adapter can only fit in
one direction due to the keyed notch. Wrong orientation will cause improper installation
and may damage the Mini PCI-e socket)
Connect the antenna(s) on the mini PCI-e module
Reboot on the platform
Install drivers if necessary
Frequency
2412 ~ 2462 MHz
5180 ~ 5240MHz, 5745 ~ 5825MHz
Connector: Reverse U.FL PLUG
jjPlus CORP.
13F-3, No.120, Qiaohe Rd., Zhonghe Dist., New Taipei City 235, Taiwan
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
-
Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
FCC Caution
For product available in the USA/Canada market, only channel 1~11 can be operated.
Selection of other channels is not possible.
jjPlus CORP.
13F-3, No.120, Qiaohe Rd., Zhonghe Dist., New Taipei City 235, Taiwan
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20
cm between the radiator & your body.
This device is intended only for OEM integrators under the following conditions:
1)
The antenna must be installed such that 20 cm is maintained between the
antenna and users, and the maximum antenna gain allowed for use with this
device is 2dBi.
2)
The transmitter module may not be co-located with any other transmitter or
antenna.
As long as 2 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed
Important Notes
In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no
longer considered valid and the FCC ID can not be used on the final product. In these
circumstances, the OEM integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate FCC authorization.
Label for end product must include
This transmitter module is authorized only for use in device where the antenna may be
installed such that 20 cm may be maintained between the antenna and users. The final
end product must be labeled in a visible area with the following: “Contains FCC ID: W23-
JWX5556”. The grantee's FCC ID can be used only when all FCC compliance
requirements are met.
jjPlus CORP.
13F-3, No.120, Qiaohe Rd., Zhonghe Dist., New Taipei City 235, Taiwan
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding
how to install or remove this RF module in the user’s manual of the end product which
integrates this module.
The end user manual shall include all required regulatory information/warning as show in
this manual.
Appendix
The antenna information for certification is listed as below;
Frequency : 2400 ~ 2500 MHz, 5150 ~ 5850 MHz
Gain : 2 dBi
VSWR :
≦
2.0
Type : Omni-directional
Impedance : 50 Ohm
Connector Type : SMA Male Reverse
jjPlus CORP.
13F-3, No.120, Qiaohe Rd., Zhonghe Dist., New Taipei City 235, Taiwan
CE Mark Warning
This device complies with Directive 2014/53/EU issued by the Commission of the European
Community.
A minimum separation distance of 20 cm must be maintained between the user’s body and
the device, including the antenna during body-worn operation to comply with the RF
exposure requirements in Europe.
Frequency bands and Powers
a.
Frequency :
2412 ~ 2462 MHz
5180 ~ 5240MHz, 5745 ~ 5825MHz
b.
Maximum output power
JWX6082/JWX6083: 19 dBm @ 1 ~ 11Mbps
JWX6052/JWX6053: 18 dBm @ 1 ~ 11Mbps
JWX6055/JWX6056: 20 dBm @ 1 ~ 11Mbps
Components and accessories
The module is delivered without an antenna, the suggest antenna information is listed as
below:
Frequency : 2400 ~ 2500 MHz, 5150 ~ 5850 MHz
Type : Omni, Directional
Impedance : 50 Ohm
Connector Type : SMA Male Reverse
The module must be installed at host device and installed with proper driver before to use it
jjPlus CORP.
13F-3, No.120, Qiaohe Rd., Zhonghe Dist., New Taipei City 235, Taiwan
Operating temperature
Temperature Range -20℃ ~ +70℃ -40℃ ~ +85℃
Model name JWX6083, JWX6052,
JWX6055
JWX6082, JWX6053,
JWX6056
Warning:
The over temperature could let module stop functioning or function abnormally.
Safety Information
Don’t power on module without antenna installed
Don’t disassemble the product, or make repairs yourself. You run the risk of electric
shock and voiding the limited warranty
Avoid water and wet locations
Simplified DoC
Hereby, jjPlus CORP. declares that the radio equipment is in compliance with Directive 2014/53/EU
The full text of the EU declaration of conformity is available at the following internet address:
http://www.jjplus.com/?page_id=3320
Importer Information
Requirements
inAT/BE/BG/CZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/
SK/TR/FI/SE/CH/UK/HR.5150MHz~5350MHz is for indoor use only.
