Users Manual

DRAFT

OWNER’S MANUAL

FOOT SWITCH FOR USE WITH POWER-POLE® SYSTEMS

WITH C-MONSTER™

Installation Operation

CAUTION: Read this owner’s manual carefully. Become

familiar with the controls, and know how to operate the

Power-Pole shallow water anchor system safely.

DRAFT

Questions? We’re here to help.

Call our technical support staff. [(813) 689-9932 option 2]

Installation

A.Locateasuitableareawithaflatsurfacetomountthefootswitch.

B.Removethefootswitchfromitsrubberpad,andholditinthedesiredlocation.Useafinepoint

markertoinscribetheintendedmountingscrewlocations.

WARNING–Beforedrillingpilotholesforthefootswitchmountingscrews,inspecttheareabeneath

themountingsurfaceinordertoensurethatthedrillbitwillnotcauseanydamage.

C.Usingthe7/64”drillbit,carefullydrillholesinthepreviouslyinscribedlocation.

D.Placethefootswitchbackintoitsrubberpad,andfastenboththeswitchandpadtothevesselusing

a#2Phillips‐headscrewdriverandthe(3)#6x3/4”panheadscrews.

Programming

A.Locatethe“program”buttononthetopoftheHPU,anddepressandholditfor3secondsuntilthe

LEDsteadilyilluminatesgreenincolor.Theunitisnowreadytobeprogrammedwithafootswitch.

‐Note:WhendualPower‐Poleshallowwateranchorsareinstalled,thisprocedureneedonlybe

performedononeHPU.

B.Next,depressandreleaseeitherthe“up”orthe“down”buttononthefootswitch1time.Thegreen

LEDwillinitiallyturnoff,andthenitwillflashsteadilyindicatingthattheprogramminghasbeen

completed.

C.Thefootswitchisnowprogrammed.Testitsfunctionalitywithboththe“up”andthe“down”buttons

toensurethattheprogrammingprocedurewascompletedsuccessfully.

Operation

A.Thefootswitchhasthreespeedsettings(slow,medium,&fast).Depressingandreleasingthe

“speed”buttononthefootswitchwilltogglethroughthethreesettings.

B.TheLEDonthefootswitchwillflashataspeedcorrespondingtoeitheraslow,medium,orfast

setting.

C.WithdualPower‐Poleshallowwateranchorsinstalled,thefootswitchcanalsobeusedtotoggle

betweenindependentorsimultaneouscontroloftheanchors.Depressingandreleasingthe

“directional”buttononthefootswitchwilltogglethroughthethreesettings(portsideonly,starboard

sideonly,orsimultaneouscontol).

DRAFT

D.TheLEDwillflasheitherportsideonly,starboardsideonly,oronbothsidestoindicatethecurrent

controlsettings

E.ToraiseorlowerthePower‐Poleshallowwateranchor,pressandholdeitherthe“up”or“down”

buttononthefootswitch.Theanchorwillonlycontinuetomovesolongasyoukeepthebutton

depressed.

F.Alternately,thefootswitchcanbeusedtoenabletheautomode.Doubletapping(depressingand

releasing2timeswithin1second)eitherthe“up”orthe“down”buttononthefootswitchwillcause

theanchortoretractordeployautomatically.ThePower‐Poleshallowwateranchorwillcontinueto

moveinsaiddirectionuntiliteitherretractscompletelyorsensesasolidbottomsurface.

ChangingBattery



A.Removethe(3)#6x3/4”panheadscrewswitha#2Phillips‐headscrewdriver,andremovethefoot

switchanditsrubberbasefromthevessel’ssurface.

B.Takethefootswitchanditsbasetoadrylocation,andseparatethefootswitchandrubberbase.

C.Thoroughlydrythefootswitchandthenremovethe(7)screwsonitsundersidewitha#1Phillips‐

headscrewdriver.

D.Withthescrewsremoved,lifethecoveroffoftheswitch,andcarefullyremovethecircuitboard.

E.ReplacethebatteryonthecircuitboardwithagenuinereplacementbatteryfromJLMarineSystems,

andsettheboardinasafe,drylocation.

F.Inspecttheinsideofthefootswitchcasethoroughlyforsignsofmoistureaswellasdamagetothe

rubberseals.Iftherubbersealsappeartobedamaged,orofasubstantialamountofmoistureisfound,

pleasecontactamemberofourtechnicalsupportstaff.[(813)689‐9932option2]

‐Note:Ifneeded,ahairdryermaybeusedtodryresidualmoistureinthefootswitchcase.

G.Assembleandinstallthefootswitchinthereverseorder.

Precautions

- Prior to use, read this instruction manual carefully. Become familiar with the controls and how

to operate your Power-Pole shallow water anchor properly.

- The devices listed in this installation manual comply with part 15 of the FCC rules. Operation

is subject to the following two conditions: (1) The devices may not cause harmful interference,

and (2) This device must accept any interference received, including interference that may

cause undesired operation.

DRAFT

NOTE: The manufacturer is not responsible for any radio or TV interference caused by

unauthorized modifications to this equipment. Such modifications could void the user’s

authority to operate the equipment.
