JTECH an HME IQ2008 GUEST PAGING SYSTEM User Manual MANUAL
HME WIRELESS, INC. GUEST PAGING SYSTEM MANUAL
Contents
- 1. USERS MANUAL
- 2. Users Manual
USERS MANUAL
IQ RECEIVER
IQ-2008
INSTRUCTIONAL MANUAL
LEE TECHNOLOGY KOREA CO., LTD.
INSTRUCTION for IQ Pager
※
When the pager is removed from the charger base, it will be vibrating and flashing for 5 or
10 seconds.
Programming the Alert Mode
A) Capcode 1 (Group Message)
Message Alert Description Alert Time & Remark
9292 Vibrating Only Alert time can be selected at
8, 15, 30, 60, 120, 180 sec, Continue
9393 Out of Range “OFF”
9494 Out of Range “ON” (Melody & Voice) The pager will melody,
when it is out of range.
9595 Beeping, Flashing and Voicing Alert time can be selected at
8, 15, 30, 60, 120, 180 sec, Continue
9696 Vibrating and Flashing Alert time can be selected at
8, 15, 30, 60, 120, 180 sec, Continue
9797 Flashing Only Alert time can be selected at
8, 15, 30, 60, 120, 180 sec, Continue
9898 Beeping, Vibrating, Flashing, Voicing Alert time can be selected at
8, 15, 30, 60, 120, 180 sec, Continue
99 Sleep Mode
8281 Beeping once and Vibrating Alert Time : 5 Sec
(when the pager is removed from the
charger base)
8282 Beeping once and Vibrating
Alert Time : 10 Sec
(when the pager is removed from the
charger base)
8381 Volume 1 (LOW) Speaker Volume Range Setting
8382 Volume 2 (MID) Speaker Volume Range Setting
8383 Volume 3 (HIGH) Speaker Volume Range Setting
8882 Beeping once and Vibrating Beeping & Flashing for 3 min
(when it receives the Group Call)
8883 Beeping once and Vibrating The last message will be activated
(when it receives the Group Call)
9090 Beeping once and Vibrating Alert Time : 8 sec
9091 Beeping once and Vibrating Alert Time : 15 sec
9092 Beeping once and Vibrating Alert Time : 30 sec
9093 Beeping once and Vibrating Alert Time : 60 sec
9094 Beeping once and Vibrating Alert Time : 120 sec
9095 Beeping once and Vibrating Alert Time : 180 sec
9099 Beeping once and Vibrating Alerting continuously
B) Capcode 2 (Individual Message)
Message Alert Description Alert Time & Remark
No Message The last message will be activated Alert time can be selected at
8, 15, 30, 60, 120, 180 sec, Continue
C) Capcode 4 (Group Call)
Message Alert Description Alert Time & Remark
No Message
Melody (Voice) and all LED will be
activated (8882)
The last message will be activated
(8883)
8882
(10 min)
8883
(8, 15, 30, 60, 120, 180 sec, Continue)
9*7*8(Base Id) This function changes the Base Id,
when the pager is in the charger base Ex) Base Id: 070,
9*7*8070
※ When the “Out of Range” is activated, display will show “---“ with a melody.
※ When the pager receives the individual message (CAP2), the pager number flashes.
※ When the pager receives the group message (CAP4), display will show the pager number
continuously.
※ When the pager is in the charger base, display will show the pager number continuously.
※ When the batter needs to be charged, display will show “LO”.
LEE TECHNOLOGY KOREA CO., LTD.
