JULONG EDUCATIONAL TECHNOLOGY JL-TB2015 WIRELESS TABLET User Manual
JULONG EDUCATIONAL TECHNOLOGY CO., LTD. WIRELESS TABLET
USERS MANUAL
1
MANUAL
ⅠINTRODUCTION
Important note
z Only can be written on with Julong’s specialized electronic pens.
z Make sure the driver is installed correctly. Make sure the battery
electricity is sufficient.
z While using the tablet, make sure the switch is on, and launch the
driver.
1 BRIEF INTRODUCTION
IPTablet is a pc-based interactive input device, with the wireless tablet and driver.
The writing position information of an electronic pen can be detected by the wireless
tablet and transmitted to PC (driver installed) through RF signal receiver, then displayed
on the interactive whiteboard through projector. Besides, it can work with the interactive
whiteboard software. IPtablet enables users to control the computer, write, note, draw
geometric graphics, print and store. IPtablet and IPBOARD make an integrated interactive
presentation system.
IPtablet frees the user to control the computer from anywhere in the classroom and it
is the perfect device for promoting maximum interactivity and mobility for engaging, truly
interactive presentation and lessons.
2. FUNCTION
IPBOARD Tablet enables users to operate IPBOARD software. The function keys are the
same as IPBOARD’s. That means users can operate IPBOARD with IPTablet. Better
demonstration, higher interaction.
After installing correctly, there is a text of "Online Help" in the software which
introduced particularly the functions.
2
3 SPECIFICATIONS
Working Principle Wireless Electromagnetic Induction
Hardware Platform Normal PC, Laptop
System Windows 2000/XP/Vista
Transmission
Interface
2.4 G RF wireless Transmission
Wireless
Transmission Work
5mA ~ 55mA
Data Transmission
Range
20 meters
Data-Signaling Rate 19200 baud rate
Working Electricity 50mA ~ 100mA
Reading Speed Maximum 100 points/sec.
Pair ≥30 Pairs
Orientation Defaulted Orientation
Writing Pen Small whiteboard pen ( can be used in the whiteboard)
Type of Battery Rechargeable battery
Charge Time ≥ 6hrs
Working Voltage 4.8V
Capacity 600mA
Battery Durability 6 hrs
Writing Area 204mmX 154mm
Dimension 256mmX250mmX30mm
Working Temperature -20℃ ～ +55℃
Weight (including
battery)
500g
3
4 FAQ
1 What kind of accessories should be used together with the tablet?
Tablet, electronic pen or electronic pen of whiteboard, signal receiver, PC, attached
software
2 What should be done if the cursor on the screen doesn’t have any response or any writing
on the tablet can not be seen on the screen when the user writes on the running tablet?
Check the color of indicator light. The red light of indicator means the wireless
connection is not connected yet.
¾ Check to ensure the driving programme of the receiver is installed completely
¾ Check to ensure that the driving programme of tablet is installed completely and
is run
¾ Check to see whether the battery of the electronic pen has sufficient power, if not,
the battery should be changed in time.
¾ Check to see whether the battery has sufficient power. If not, the battery should
be replaced in time.
3 Can the tablet be used without interactive whiteboard?
YES
4 Can normal alkaline battery be used in the tablet?
No, because normal alkaline battery does not have sufficient power to support the running
of tablet, and the attached rechargeable battery should be used particularly.
5 What should be done when it reminds that a whiteboard software is already running by
clicking the driver icon of tablet?
Close the running programme of the whiteboard in the taskbar area, and then run the
programme of the tablet
6What’s the problem if there is signal be transmitted (the indicator light become
green),but the cursor did not moved at all when the electronic pen touched the running
tablet?
This problem is caused by the disorder of running the tablet programme first and turning
on the tablet later. The users have to turn on the table first and then run the tablet
programme later.
FCC NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED
BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE
USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
4
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: 1. This device may not cause harmful interference, and 2. This device
must accept any interference received, including interference that may cause undesired
operation
