English

LT-32HG20E

50185104

ENGLISH

English - 1 -

Information for Users on Disposal of Old Equipment and Batteries

[European Union]

These symbols indicate that the electrical and electronic equipment and the battery with this

symbol should not be disposed of as general household waste at its end-of-life. Instead,

the products should be handed over to the applicable collection points for the recycling of

electrical and electronic equipment as well as batteries for proper treatment, recovery and

recycling in accordance with your national legislation and the Directive 2002/96/EC and

2006/66/EC.

By disposing of these products correctly, you will help to conserve natural resources and will

help to prevent potential negative effects on the environment and human health which could

otherwise be caused by inappropriate waste handling of these products.

For more information about collection points and recycling of these products, please contact

your local municipal ofﬁ ce, your household waste disposal service or the shop where you

purchased the product.

Penalties may be applicable for incorrect disposal of this waste, in accordance with national

legislation.

[Business users]

If you wish to dispose of this product, please contact your supplier and check the terms

and conditions of the purchase contract.

[Other Countries outside the European Union]

These symbols are only valid in the European Union.

If you wish to dispose of these items, please do so in accordance with applicable national

legislation or other rules in your country for the treatment of old electrical and electronic

equipment and batteries.

Dear Customer,

This apparatus is in conformance with the valid European directives and standards regarding electromagnetic

compatibility and electrical safety.

European representative of Victor Company of Japan, Limited is:

JVC Technical Services Europe GmbH

Postfach 10 05 04

61145 Friedberg

Germany

Logo & License

HDMI, the HDMI Logo, and High-Deﬁ nition Multimedia Interface are trademarks or registered trademarks of

HDMI Licensing LLC in the United States and other countries.

DVB is a registered trademark of the DVB Project

LICENSE NOTICE

Manufactured under license from Dolby Laboratories.

TRADEMARK ACKNOWLEDGMENT

“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

Battery

Products

Notice:

The sign Pb below

the symbol for

batteries indicates

that this battery

contains lead.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 1A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 1 07.03.2011 17:51:1307.03.2011 17:51:13

English - 2 -

Contents

Logo & License ....................................................... 1

Features ................................................................. 3

Introduction ............................................................. 3

Package Contents .................................................. 3

Preparation ............................................................. 4

Safety Precautions ................................................. 4

Waste Disposal ................................................... 4

LCD Screen ........................................................ 5

Warning .............................................................. 5

Connection to a Television Distribution

System (Cable TV etc.) from Tuner .................... 5

Environmental Information ..................................... 5

Overview of the Remote Control ............................ 6

Inserting Batteries in the Remote Control............... 7

Operating Range for the Remote Control ............... 7

Switching the TV On/Off ......................................... 7

Using the Cable Holder .......................................... 7

LCD TV and Operating Buttons .............................. 8

Viewing the Back side Connections ....................... 8

Viewing the Connections - Side Connectors .......... 9

Power Connection ................................................ 10

Aerial Connection ............................................. 10

Using Digital Multimedia Connectors.................... 10

USB Memory Connection ................................. 10

Side HDMI Connection ......................................... 10

Connecting the LCD TV to a PC ........................... 10

Connecting to a DVD Player..................................11

Using Side AV Connectors ....................................11

Using Other Connectors ........................................11

Input Selection ...................................................... 12

Operation with the Buttons on the TV ............... 12

Volume Setting .............................................. 12

Programme Selection ................................... 12

Viewing Main Menu ....................................... 12

AV Mode ....................................................... 12

Operation with the Remote Control .................. 12

Volume Setting .............................................. 12

Programme Selection

(Previous or Next Programme) ..................... 12

Programme Selection (Direct Access) .......... 12

Digital Teletext (** for UK only) ............................. 12

Analogue Teletext ............................................. 12

Viewing Electronic Programme Guide (EPG) ....... 13

First Time Installation............................................ 14

Auto Tuning .......................................................... 15

Auto Channel Scan Menu Operation ................ 15

Manual Tuning ..................................................... 15

Digital Manual Search....................................... 15

Analogue Manual Search ................................. 15

Analog Fine Tune.............................................. 15

Managing Stations: Channel List .......................... 16

Operating the Channel List ............................... 16

Moving a Channel ............................................. 16

Deleting a Channel ........................................... 16

Renaming a Channel ........................................ 16

Locking a Channel ............................................ 16

Managing Stations: Favourites ............................. 17

Button Functions ............................................... 17

Managing Stations: Sorting Channel List ............. 17

On-Screen Information ......................................... 17

Media Playback Using Media Browser ................. 17

Changing Image Size: Picture Formats ................ 19

Conﬁ guring Picture Settings ................................. 20

Operating Picture Settings Menu Items ............ 20

Picture Settings Menu Items ............................. 20

PC Picture Settings........................................... 21

Conﬁ guring Sound Settings .................................. 21

Operating Sound Settings Menu Items ............. 21

Sound Settings Menu Items.............................. 21

Conﬁ guring Your TV’s Settings ............................. 22

Operating Settings Menu Items ........................ 22

Settings Menu Items ......................................... 22

Using a Conditional Access Module ..................... 22

Viewing Conditional Access Menu (*) ............... 22

Conﬁ guring Language Preferences ...................... 23

Parental Control.................................................... 23

Parental Settings Menu Operation (*) ............... 23

Timers ................................................................... 24

Conﬁ guring Date/Time Settings ............................ 24

Conﬁ guring Source Settings ................................. 25

Conﬁ guring Other Settings ................................... 25

Operation .......................................................... 25

Other Features ..................................................... 26

Teletext ................................................................. 26

Tips ....................................................................... 27

Appendix A: PC Input Typical Display Modes ....... 28

Appendix B: AV and HDMI Signal

Compatibility (Input Signal Types) ........................ 28

Appendix C: Supported DVI Resolutions.............. 29

Appendix D: Supported File Formats

for USB Mode ....................................................... 29

Appendix D: Software Upgrade ............................ 30

Speciﬁ cations ....................................................... 31

Digital Reception (DVB-T) .................................... 31

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 2A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 2 07.03.2011 17:51:1507.03.2011 17:51:15

English - 3 -

Features

Full HD 1080p LCD TV.•

Fully integrated Terrestrial digital TV (DVB-T - • MPEG2) (DVB-T - MPEG4).

HDMI connectors for digital video and audio. This • connection is also designed to accept high deﬁ nition

signals.

USB input.•

1000 programmes (analogue+digital).•

OSD menu system.•

SCART socket for external devices (such as video, • video games, audio set, etc.).

Stereo sound system. (German+Nicam)•

Teletext, fastext, TOP text.•

Headphone connection.•

Automatic programming system.•

Forward or backward manual tuning.•

Sleep timer / Child lock.•

Automatic sound muting when no transmission.•

NTSC playback. •

AVL (Automatic Volume Limiting).•

Auto power down.•

PLL (Frequency Search).•

PC input. •

Plug&Play for Windows 98, ME, 2000, XP, Vista, • Windows 7.

Game Mode •

Introduction

Please read the corresponding instructions of this

handbook prior to the ﬁ rst usage of the device, even

when the usage of electronic devices is familiar

to you. Notice especially the chapter SAFETY

PRECAUTIONS. Carefully keep the handbook as

future reference. When selling the device or giving it

away, absolutely give these direction for use.

Thank you for choosing this product. This manual will

guide you for the proper operation of your TV.

Before operating the TV, please read this

manual thoroughly. Please do keep this

manual in a safe place for future references.

This device is intended to receive and display TV

programs. The different connection options make

an additional expansion of the reception and display

sources possible (receiver, DVD player, DVD

recorder,

VCR, PC etc.). This device is only suitable for the

operation in dry interiors. This appliance is intended

solely for private domestic use and may not be used

for industrial and commercial purposes. We exclude

liability in principle, if the device is not used as

intended, or unauthorized modiﬁ cations have been

made. To operate your LCD TV in extreme ambient

conditions may cause the damage of the device.

Package Contents

Remote Controller

Batteries: 2 X AAA

Instruction Book

Quick Guide

Cable Holder

Note: You should check the accessories after

purchasing. Make sure that each accessory is

included.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 3A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 3 07.03.2011 17:51:1507.03.2011 17:51:15

English - 4 -

Preparation

For ventilation, leave a free space of at least 10 cm

all around the set. To prevent any fault and unsafe

situations, please do not place any objects on top of

the set. Use this device in moderate climates.

10 cm

Safety Precautions

Read the following recommended safety

precautions carefully for your safety.

Power Source

The TV set should be operated only from a 220 V - 240

V AC, 50 Hz outlet. Ensure that you select the correct

voltage setting for your convenience.

Power Cord

Do not place the set, a piece of furniture, etc. on the

power cord (mains lead) or pinch the cord. Handle the

power cord by the plug. Do not unplug the appliance by

pulling from the power cord and never touch the power

cord with wet hands as this could cause a short circuit or

electric shock. Never make a knot in the cord or tie it with

other cords. The power cords should be placed in such a

way that they are not likely to be stepped on. A damaged

power cord can cause ﬁ re or give you an electric shock.

When it is damaged and needs to be replaced, it should

be done by qualiﬁ ed personnel.

Moisture and Water

Do not use this device in a humid and

damp place (avoid the bathroom, the

sink in the kitchen, and near the washing

machine). Do not expose this device to

rain or water, as this may be dangerous

and do not place objects filled with

liquids, such as ﬂ ower vases, on top.

Avoid from dripping or splashing.

If any solid object or liquid falls into the cabinet, unplug

the TV and have it checked by qualiﬁ ed personnel

before operating it any further.

Cleaning

Before cleaning, unplug the TV set

from the wall outlet. Do not use liquid

or aerosol cleaners. Use soft and dry

cloth.

Ventilation

The slots and openings on the TV set are intended for

ventilation and to ensure reliable operation. To prevent

overheating, these openings must not be blocked or

covered in anyway.

Heat and Flames

The set should not be placed near to

open ﬂ ames and sources of intense heat

such as an electric heater. Ensure that

no open ﬂ ame sources, such as lighted

candles, are placed on top of the TV. Batteries should

not be exposed to excessive heat such as sunshine,

ﬁ re or the like.

Lightning

In case of storm and lightning or when

going on holiday, disconnect the power

cord from the wall outlet.

Replacement Parts

When replacement parts are required, make sure that

the service technician has used replacement parts,

which are speciﬁ ed by the manufacturer or have the

same speciﬁ cations as the original one. Unauthorized

substitutions may result in ﬁ re, electrical shock or

other hazards.

Servicing

Please refer all servicing to qualiﬁ ed

personnel. Do not remove the cover

yourself as this may result in an electric

shock.

Waste Disposal

Instructions for waste disposal:•

Packaging and packaging aids are recyclable and • should principally be recycled. Packaging materials,

such as foil bag, must be kept away from children.

Batteries, including those which are heavy metal-• free, should not be disposed of with household

waste. Please dispose of used battery in an

environment friendly manner. Find out about the

legal regulations which apply in your area. Don’t try

to recharge batteries. Danger of explosion. Replace

batteries only with the same or equivalent type.

Cold cathode fluorescent lamp in LCD PANEL • contains a small amount of mercury; please follow

the local laws or regulations for disposal.

Disconnecting the Device

The mains plug is used to disconnect TV set from

the mains and therefore it must remain readily

operable.

Headphone Volume

Excessive sound pressure from earphones

and headphones can cause hearing loss.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 4A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 4 07.03.2011 17:51:1607.03.2011 17:51:16

English - 5 -

Installation

To prevent injury, this device must be securely

attached to the wall in accordance with the installation

instructions when mounted to the wall (if the option

is available).

LCD Screen

The LCD panel is a very high technology product with

about a million thin ﬁ lm transistors, giving you ﬁ ne

picture details. Occasionally, a few non-active pixels

may appear on the screen as a ﬁ xed blue, green or

red point. Please note that this does not affect the

performance of your product.

Warning

Do not leave your TV in standby or operating mode

when you leave your house.

The Standby / On button doesn´t separate this • device completely from mains. Moreover the device

consumes power in the standby operation. In order

to separate the device completely from mains, the

mains plug has to be pulled from the mains socket.

Because of that the device should be set up in a

way, that an unobstructed access to mains socket

is guaranteed, so that in case of emergency the

mains plug can be pulled immediately. To exclude

the danger of ﬁ re, the power cord should principally

be separated from the mains socket prior to a longer

period of non-usage, i.e. during vacations.

Electrical device not in the hands of children

Never let children use electrical device unsupervised.

Children can´t always recognize properly the

possible dangers. Batteries / accumulators can be

life threatening when swallowed. Store batteries

unreachable for small children. In case of swallowing

a battery medical aid has to be sought immediately.

Also keep the packaging foils away from children.

There is danger of suffocation.

Connection to a Television Distribution

System (Cable TV etc.) from Tuner

Device connected to the protective earthing of the

building installation through the mains connection or

through other apparatus with a connection to protective

earthing-and to a television distribution system using

coaxial cable, may in some circumstances create a

ﬁ re hazard.

Connection to a cable distribution system has

therefore to be provided through a device providing

electrical isolation below a certain frequency range

(galvanic isolator, see EN 60728-11).

WARNING

To prevent ﬁ re, never place

any type of candle or open

ﬂ ame on the top or near

the TV set.

Environmental Information

This television is designed to consume less energy • to save environment.

You not only help to save the environment but also

you can save money by reducing electricity bills

thanks to the energy efﬁ ciency feauture of this TV.

To reduce energy consumption, you should take the

following steps:

You can use Power Save Mode setting, located in • the Feature menu. If you set Power Save Mode

as On, the TV will switch to energy-saving mode

and luminance level of TV set will be decreased to

optimum level. Note that some picture settings will

be unavailable to be changed when the TV is in

Power Save Mode.

When the TV is not in use, please switch off or • disconnect the TV from the mains plug. This will

also reduce energy consumption.

Disconnect power when going away for longer • time.

Note that annually, using the TV set in Power Save • Mode has more power efﬁ ciency than disconnecting

the TV from the mains plug instead of keeping

stand-by mode. Therefore disconnect the TV from

the mains plug to save energy when you do not

use. However it is highly recommended to activate

Power Save Mode setting to reduce your annual

power consumption.

Please helps us to save environment by following • these steps.

Repair Information

Please refer all servicing to qualiﬁ ed personnel. Only

qualiﬁ ed personnel must repair the TV. Please contact

your local dealer, where you have purchased this TV

for further information.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 5A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 5 07.03.2011 17:51:1707.03.2011 17:51:17

English - 6 -

Overview of the Remote Control

TV/DTV: TV – Digital TV

OK: OK / Conﬁ rm / Channel list

: Cursor left

MENU: Menu on-off

ZOOM: Image size

RED: Function in menu help bar

GREEN: Function in menu help bar

AV: Source selection

/ : Programme up / down

: Info

: Index Page (in TXT mode)

: Favourite mode (in DTV mode)

: Hold (in TXT mode)

TV/RADIO: Switches between TV and radio

broadcasts.(in DTV mode)

: Standby

GUIDE: Programme guide

: Cursor up

: Cursor right

BACK: Return

: Cursor down

: Jump to now (in EPG mode) /

Surround Sound on/off

BLUE: Function in menu help bar

YELLOW: Function in menu help bar

/ : Volume up / down

: Muting

0,1...8,9: Numeric buttons.

: Teletext on / PAT (Picture-and-text) /

Teletext off

: Reveal

: Sleep timer on/off

: Subtitle on-off

: Mono-stereo / Dual I-II / Current

Language (in DTV mode)

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 6A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 6 07.03.2011 17:51:1707.03.2011 17:51:17

English - 7 -

Inserting Batteries in the

Remote Control

Remove the battery cover located on the back of • the handset by gently pulling backwards from the

indicated part.

Insert two • AAA/R3 or equivalent type batteries

inside. Place the batteries in the right directions and

replace the battery cover.

Note: Remove the battery from remote control

handset when it is not to be used for a long period.

Otherwise it can be damaged due to any leakage of

batteries.

Batteries should not be exposed to excessive heat • such as sunshine, ﬁ re or the like.

Operating Range for the Remote

Control

Point the top of the remote control toward the LCD • TV’s remote sensor LED while pressing a button.

Remote range is approximately 7m/23ft.•

Switching the TV On/Off

To Switch the TV On

Connect the power cord to the 220 V - 240 V AC, • 50 Hz.

Switch the “• ” button to position “|” so the TV will

switch on, LED will blink during switch on.

To switch on the TV from standby mode either:

Press the “• ” button, / or a numeric button

on the remote control.

Press the • P/CH- or P/CH+ button on the TV.

The TV will then switch on and the Power LED lights

up.

Note: If you switch on your TV via PROGRAMME

UP/DOWN buttons on the remote control or on the

TV set, the programme that you were watching last

will be reselected.

To Switch the TV Off

Switch the “• ” button to position 2 as illustrated,

() so the TV will switch OFF.

To power down the TV completely, unplug the power • cord from the mains socket.

Note: When the TV is switched to standby mode,

Power LED can blink to indicate that features such

as Standby Search, Over Air Download or Timer is

active.

Using the Cable Holder

You can use the supplied cable holder as the

following:

Place the cable holder into the cable holder hole • located on the rear side of the TV as illustrated

above.

Place cables into the cable holder after all necessary • connections are made.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 7A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 7 07.03.2011 17:51:2207.03.2011 17:51:22

English - 8 -

LCD TV and Operating Buttons

FRONT and REAR VIEW FRONT VIEW Control Buttons

Standby button

TV/AV button

Programme Up/Down

buttons

Volume Up/Down buttons

Note: Press and

buttons at the same time to view

main menu.

Viewing the Back side Connections

HDMI 3

SCART 2 inputs or outputs for external devices.

Note: Slow switching* can only be possible in EXT-2. *TV will turn on from standby if EXT-2 is

activated. TV will goes to standby after EXT-2 deactivation.

SCART 1 input or output for external devices. Connect the SCART cable between SCART socket on

TV and SCART socket on your external device (such as a decoder, a VCR or a DVD player).

Note: If an external device is connected via the SCART socket, the TV will automatically switch to AV

mode.

Note: To connect external device, please use to supplied SCART connection cable .

Component Video Inputs (YPbPr) are used for connecting component video.

You can connect the component video and audio sockets with a device that has component output.

Connect the component video cables between the COMPONENT VIDEO INPUTS on on the TV and

the component video outputs of your device. While connecting, be sure that the letters on your TV, “Y”,

“Pb”, “Pr” correspond with your device’s connectors.

Power LED

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 8A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 8 07.03.2011 17:51:2407.03.2011 17:51:24

English - 9 -

PC/YPbPr Audio Inputs are used for connecting audio signals of a PC or a device that connects to the

TV via YPbPr. Connect the PC audio cable between the AUDIO INPUTS on the TV and audio output

of your PC to enable PC audio. Connect the audio cable between AUDIO INPUTS on the TV and audio

outputs of your device to enable component audio.

S/PDIF Coaxial Out outputs digital audio signals of the currently watched source.

Use an SPDIF coaxial cable to trasfer audio signals to a device that has S/PDIF input

RF Input connects to an aerial antenna system.

Note that if you use a decoder or a media recorder, you should connect the aerial cable through the device

to the television with an appropriate antenna cable, as shown in the illustration in the following pages.

PC Input is for connecting a personal computer to the TV set.

Connect the PC cable between the PC INPUT on the TV and the PC output on your PC

HDMI 1: HDMI Input

HDMI Inputs are for connecting a device that has an HDMI socket. Your LCD TV is capable of

displaying High Deﬁ nition pictures from devices such as a High Deﬁ nition Satellite Receiver or DVD

Player. These devices must be connected via the HDMI sockets or Component Socket. These sockets

can accept either 720p or 1080p signals. No sound connection is needed for an HDMI to HDMI

connection.

HDMI 2: HDMI Input

HDMI 3: HDMI Input

Viewing the Connections - Side Connectors

CI Slot is used for inserting a CI card. A CI card allows you to view all the

channels that you subscribe to. For more information, see “Conditional

Access” section.

Side USB.

Side HDMI Input is for connecting a device that has an HDMI socket.

Headphone jack is used for connecting an external headphone to the

system. Connect to the HEADPHONE jack to listen to the TV from

headphones (optional).

Video Input (SIDE AV) is used for connecting video signals of external

devices.Connect the video cable between the VIDEO IN socket on the TV

and the VIDEO OUT jack on your device.

Audio Inputs (SIDE AV) are used for connecting audio signals of external

devices. Connect the audio cable between the AUDIO INPUTS on the TV

and the AUDIO OUTPUT jacks on your device.

Standby switch is used for turning the TV on or off.

Note: If you connect a device to the TV via the VIDEO INPUT, you should also

connect your device with an audio cable to the AUDIO INPUTS of the TV to

enable audio.

INPUT AV

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 9A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 9 07.03.2011 17:51:2507.03.2011 17:51:25

English - 10 -

Power Connection

IMPORTANT: The TV set is designed to operate on

220 V - 240 V AC, 50 Hz.

After unpacking, allow the TV set to reach the • ambient room temperature before you connect the

set to the mains. Plug the power cable to the mains

socket outlet.

Aerial Connection

Connect the aerial or cable TV plug to the AERIAL • INPUT socket located at the rear of the TV.

HDMI 3

Using Digital Multimedia

Connectors

You can connect USB devices to your TV by using • the USB inputs of the TV. This feature allows you

to display/play JPG, MP3 and video ﬁ les stored in

a USB stick.

It is possible that certain types of USB devices (e.g. • MP3 Players) may not be compatible with this TV.

You may back up your ﬁ les before making any • connections to the TV set in order to avoid any

possible data loss. Note that manufacturer will not

be responsible for any ﬁ le damage or data loss.

Do not pull out USB module while playing a ﬁ le.•

CAUTION: Quickly plugging and unplugging USB

devices, is a very hazardous operation. Especially,

do not repeatedly quickly plug and unplug the

drive. This may cause physical damage to the USB

player and especially the USB device itself.

SIDE VIEW USB MEMORY

USB Memory Connection

IMPORTANT: The TV should be switched off while

plugging or unplugging a USB device. Plug your

USB device to the USB inputs of the TV. You can

connect two usb device to your TV by using the USB

inputs of the TV at the same time.

Note: It is possible certain types of hard disk drives

are not supported.

Side HDMI Connection

You can use side HDMI input to connect a device that

has an HDMI connector to your TV. Use an appropriate

HDMI cable to make such a connection. Note that you

should switch to the HDMI source to view the content

from the connected device. Power off both the TV and

the device before making any connections. Side HDMI

Input supports connections between HDMI devices

such as DVD players. You can use side HDMI input

of the TV to connect to an external HDMI device. Use

an HDMI cable to connect.

HDMI DEVICE SIDE VIEW

Connecting the LCD TV to a PC

For displaying your computer’s screen image on your

LCD TV, you can connect your computer to the TV set.

Power off both computer and display before making

any connections. Use 15-pin D-sub display cable to

connect a PC to the LCD TV. When the connection

is made, switch to PC source. See “Input selection”

section. Set the resolution that suits your viewing

requirements. Resolution information can be found

in the appendix parts.

PC audio cable

(not supplied)

PC VGA cable

(not supplied)

Audio inputs of the TV

PC input of the TV

Audio output of the PC Monitor output of the PC

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 10A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 10 07.03.2011 17:51:2807.03.2011 17:51:28

English - 11 -

Using Side AV Connectors

You can connect a range of optional equipment to

your LCD TV.

For connecting a camcorder, connect to the VIDEO • IN socket and the AUDIO SOCKETS. Do not connect

the camcoder to VIDEO IN socket at the same time

since it can cause noise in the picture. For selecting

the related source, see the section “Input selection”

in the following parts.

To listen the TV sound from headphones, connect •

to the HEADPHONE jack of theTV.

Using Other Connectors

You can connect a range of optional equipment

to your LCD TV. Possible connections are shown

below. Note that cables shown in the illustration are

not supplied.

For connecting a to a device that has SPDIF support, • use an appropriate SPDIF cable to enable sound

connection.

External Speakers

A device that

supports

SPDIF signal.

Connecting to a DVD Player

If you want to connect a DVD player to your LCD

TV, you can use connectors of the TV set. DVD

players may have different connectors. Please refer

to your DVD player’s instruction book for additional

information. Power off both the TV and the device

before making any connections.

Note: Cables shown in the illustration are not

supplied.

If your DVD player has an HDMI socket, you can • connect via HDMI. When you connect to DVD player

as illustrated below, switch to HDMI source. See,

“Input Selection” section.

Most DVD players are connected through • COMPONENT SOCKETS. Use a component video

cable to connect video input. For enabling audio,

use a component audio cable as illustrated below.

When the connection is made, switch to YPbPr

source. See, “Input selection” section.

You may also connect through the SCART 1 or • SCART 2. Use a SCART cable as shown below.

Note: These three methods of connection perform the

same function but in different levels of quality. It is not

necessary to connect by all three methods.

HDMI

inputs

Scart sockets

Component

video

inputs

Component

audio

inputs

DVD Player

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 11A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 11 07.03.2011 17:51:3007.03.2011 17:51:30

English - 12 -

Input Selection

Once you have connected external systems to your

TV, you can switch to different input sources. Press

“AV” button on your remote control consecutively for

directly changing sources.

You can operate your TV using both the remote control

and onset buttons.

Operation with the Buttons on the TV

Volume Setting

Press “• ” button to decrease volume or

button to increase volume, so a volume level scale

(slider) will be displayed on the screen.

Programme Selection

Press “• P/CH +” button to select the next programme or

“P/CH -” button to select the previous programme.

Viewing Main Menu

Press the “• ” / “ ” button at the same time

to view main menu. In the Main menu select sub-

menu using “AV” button and set the sub-menu using

“” or “ ” buttons. To learn the usage of

the menus, refer to the menu system sections.

AV Mode

Press the “• TV/AV” button in the control panel on the

TV to switch between AV modes.

Operation with the Remote Control

The remote control of your TV is designed to control • all the functions of the model you selected. The

functions will be described in accordance with the

menu system of your TV.

Volume Setting

Press “• ” button to increase the volume. Press

“” button to decrease the volume. A volume

level scale (slider) will be displayed on the screen.

Programme Selection (Previous or Next

Programme)

Press “• ” button to select the previous programme.

Press “• ” button to select the next programme.

Programme Selection (Direct Access)

Press numeric buttons on the remote control to select • programmes between 0 and 9. The TV will switch

to the selected programme. To select programmes

between, press the numeric buttons consecutively.

When the pressing time is due for the second

numeric button, only the ﬁ rst digit programme will

be displayed. Press directly the programme number

to reselect single digit programmes.

Digital Teletext (** for UK only)

Press the “• ” button.

The digital teletext information appears.•

Operate it with the coloured buttons, cursor buttons • and OK button.

The operation method may differ depending on the

contents of the digital teletext.

Follow the instructions displayed on digital teletext

screen.

When Press “• OK” button or similar message appears

on the screen, press the OK button.

When the “• ” button is pressed, the TV returns to

television broadcasting.

With digital terrestrial broadcasting (DVB-T), in • addition to digital teletext broadcasting together with

the normal broadcasting, there are also channels

with just digital teletext broadcasting.

The aspect ratio (picture shape) when watching • a channel with just digital teletext broadcasting is

the same as the aspect ratio of the picture viewed

previously.

When you press the “• ” button again, the digital

teletext screen will be displayed.

Analogue Teletext

Use of teletext and its functions are identical to

the analogue text system. Please do refer to the

“TELETEXT” explanations.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 12A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 12 07.03.2011 17:51:3007.03.2011 17:51:30

English - 13 -

Viewing Electronic Programme

Guide (EPG)

You can view the electronic programme guide (EPG)

to view information about available programmes.To

view the EPG menu please press GUIDE button on

the remote control.

Press “• / / / ” buttons to navigate through

channels and programme list.

EPG menu displays available information on all • channels.

Please note that event information is updated • automatically. If there are no event information

data available for channels, EPG will be displayed

with blanks.

OK (Options): Displays programme options including

“Select Channel” option.

(INFO) (Event Details): Displays the programmes

in detail.

Green button: Programme schedule will be listed

Yellow button: Display EPG data in accordane with

timeline schedule

Blue button (Filter): Views ﬁ ltering options.

Red button (Prev Time Slice): Displays the

programmes of previous time slice.

Green button (Next Time Slice): Displays the

programmes of the next time slice.

Yellow button (Prev Day): Displays the programmes

of previous day.

Blue button (Next day): Displays the programmes

of the next day.

Numeric buttons (Jump): Jumps to the preferred

channel directly via numeric buttons.

OK (Options): Displays programme options including

“Select Channel” option.

Text button (Filter): Views ﬁ ltering options.

(INFO): Displays the programmes in detail.

Red button (Prev Day): Displays the programmes of

previous day.

Green button (Next day): Displays the programmes

of the next day.

Yellow button (Zoom): Expands programme information.

Blue button (Filter): Views ﬁ ltering options.

(INFO): Displays the programmes in detail.

Numeric buttons (Jump): Jumps to the preferred

channel directly via numeric buttons.

OK (Options): Displays programme options including

“Select Channel” option.

Text (Search): Displays “Guide Search” menu.

: Press button to view Select Genre menu.

Using this feature, you can search the programme guide

database in accordance with the genre. Info available

in the programme guide will be searched and results

matching your criteria will be listed.

(Now) : Shows the current programme.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 13A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 13 07.03.2011 17:51:3107.03.2011 17:51:31

English - 14 -

First Time Installation

IMPORTANT: Ensure that the aerial is connected

before switching on the TV for the first time

installation.

When the TV is operated for the ﬁ rst time, installation • wizard will guide you through the process. First,

language selection screen will be displayed:

Use “• ” or “ ” buttons to select your language

and press OK button to set selected language and

continue.

After selecting the language, “• Welcome!” screen will

be displayed, requiring you to set Country,Teletext

Language and Scan Encrypted options.

By pressing “• ” or “ ” button, select the country

you want to set and press “ ” button to highlight

Teletext Language option. Use “ ” or “ ” button

to select desired Teletext Language.

Press “• ” button after setting Teletext Language

option. Scan Encrypted will be then highlighted.

You can set Scan Encrypted as Yes if you want to

scan coded stations.Afterwards select the desired

Teletext Language.

Press • OK button on the remote control to continue

and the following message will be displayed on the

screen:

To select the “Yes” or “No” option, highlight the item by

using “ ” or “ ” buttons and press OK button.

Afterwards, the following OSD will be displayed on the

screen and the digital television will search for digital

terrestrial TV broadcasts

Note: You can press “MENU” button to cancel.

After all the available stations are stored, Channel • List will be displayed on the screen. If you like the

sort channels, according to the LCN, please select

“Yes” and than press “OK”.

Press • OK button to quit channel list and watch TV.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 14A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 14 07.03.2011 17:51:3107.03.2011 17:51:31

English - 15 -

Auto Tuning

HINT: Auto tuning feature will help you to retune the TV

set in order to store new services or stations.

Press “MENU” button on the remote control and

select Installation by using “ ” or “ ” button. Press

OK button and the following menu screen will be

displayed.

Select Automatic Channel Scan by using “”/“ ”

button and press OK button. Automatic Channel Scan

options will be displayed. You can select Digital Aerial,

Analog or Digital Aerial-Analogue tuning using “ ”/“

” and OK buttons.

Auto Channel Scan Menu Operation

Digital: Searches and stores aerial DVB stations.

Analogue: Searches and stores analog stations.

Full: Searches and stores both analog and aerial

DVB stations.

Whenever you select an automatic search type and • press OK button, a conﬁ rmation screen will appear

on the screen. To start installation process, select

Yes, to cancel select No by using .“ ” or “ ” and

OK button.

After auto channel scan type is set and selected • and conﬁ rmed, installation process will start and

progress bar will move along. Press “MENU” button

to cancel process. In such a case, located channels

are not stored.

Manual Tuning

HINT: This feature can be used for direct broadcast

entry.

Select • Manual Channel Scan from the Installation

menu by using “ ”/“ ” and OK buttons. Manual

Scan options screen will be displayed.

Select the desired • Search Type using “ ” or “

” button. Manual search options will change

accordingly. Use “ ”/“ ” button to highlight an item

and then press “ ” or “ ” button to set an option.

You can press “MENU” button to cancel.

Digital Manual Search

In manual channel scan, the number of the multiplex

or frequency are entered manually and only that

multiplex or frequency are searched for the channels.

After selecting search type as Digital, you can enter

the multiplex or frequency number using the numeric

buttons and press OK button to search.

Also you can change Network channel scan as

enabled or disabled. While Network channel scan is

enabled and if channels that have network search

info are found, automatic search process will end by

locating those channels.

Analogue Manual Search

After selecting search type as analogue, you can use

“ ”/“ ” button to highlight an item and then press “

” or “ ” button to set an option.

Enter the channel number or frequency using the

numeric buttons. You can then press OK button

to search. When the channel is located, any new

channels that are not on the list will be stored.

Analog Fine Tune

Select • Analog Fine Tune from the Installation menu

by using “ ” or “ ” and OK buttons. Analog ﬁ ne tune

screen will be displayed. Analog Fine Tune feature

will not be available if there are no analog channels,

digital channels and external sources stored.

Press • OK button to proceed. Use “ ” or “ ” button

to set Fine Tune. When ﬁ nished, press OK button

again.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 15A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 15 07.03.2011 17:51:3207.03.2011 17:51:32

English - 16 -

Managing Stations: Channel List

The TV sorts all stored stations in the Channel List.

You can edit this channel list, set favourites or set

active stations to be listed by using the Channel List

options.

Press • “MENU” button to view main menu. Select

Channel List item by using “ ” or “ ” button. Press

OK to view menu contents.

Select Edit Channel List to manage all stored

channels. Use “ ” or “ ” and OK buttons to select

Edit Channel List.

Operating the Channel List

Press “• ” or “ ” button to select the channel that

will be processed. Press “ ” or “ ” button to select

a function on Channel List menu.

Use • P+/P- buttons to move page up or down.

Press • BLUE button to view ﬁ ltering options.

Press • “MENU” button to exit.

Moving a Channel

First select the desired channel. Select Move option • in the channel list and press OK button.

Edit Number screen will be displayed. Enter the • desired channel number by using the numeric

buttons on the remote control. If there is a previously

stored channel on that number, a warning screen

will be displayed. Select Yes if you want to move the

channel and press OK.

Press • OK button to process. Selected channel is

now moved.

Deleting a Channel

You can press GREEN button to tag/untag all

channels; YELLOW button to tag/untag channel.

Select the channel that you want to delete and select • Delete option. Press OK button to continue.

A warning screen will appear. Select • YES to delete,

select No to cancel. Press OK button to continue.

Renaming a Channel

Select the channel that you want to rename and • select Edit Name option. Press OK button to

continue.

Pressing “• ” or “ ” button moves to the previous/

next character. Pressing “ ” or “ ” button toggles

the current character, i.e., ‘b’ character becomes ‘a’

by “ ” and ‘c’ by “ ”. Pressing the numeric buttons

‘0...9’ replaces the highlighted character with the

characters printed above the button one by one as

the button is pressed.

When ﬁ nished, press • OK button to save. Press

“MENU” to cancel.

Locking a Channel

You can press GREEN button to tag/untag all

channels; YELLOW button to tag/untag a single

channel.

Select the channel that you want to lock and select • Lock option. Press OK button to continue.

You will be asked to enter parental control PIN. • Default PIN is set as 0000. Enter the PIN number.

Press • OK button when the desired channel is

highlighted to lock/unlock the channel. Lock symbol

will be displayed next to the selected channel.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 16A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 16 07.03.2011 17:51:3307.03.2011 17:51:33

English - 17 -

Managing Stations: Favourites

You can create a list of favourite programmes.

Press • “MENU” button to view main menu. Select

Channel List item by using “ ” or “ ” button. Press

OK to view menu contents.

Select • Favourites to manage favourite list. Use “

”/“ ” and OK buttons to select Favourites.

You can set various channels as favourites so that • only the favourite channels are navigated.

Select a channel by using “• ” or “ ” button. Press

OK button to add selected channel to favourites list.

Press OK button again to remove.

Button Functions

OK• : Add/remove a station.

YELLOW• : Tag/untag a channel.

GREEN• : Tag/untag all channels.

BLUE• : Displays ﬁ ltering options.

Managing Stations: Sorting

Channel List

You can select broadcasts to be listed in the channel

list. To display speciﬁ c types of broadcast, you should

use Active channel list setting.

Select Active channel list from the Channel list

menu by using “ ” or “ ” button. Press OK button

to continue.

You can select a broadcast type option from the list

by using “ ” /“ ” and OK buttons.

On-Screen Information

You can press “ (INFO)” button to display on-

screen information. Details of the station and current

programme will be displayed on the information

banner.

The information banner gives information on the

channel selected and the programmes on it. The name

of the channel is displayed, along with its channel

list number.

Hint: Not all channels broadcast the programme

data. If the name and time of the programme are not

available, then information banner will be displayed

with blanks.

If the selected channel is locked, you must enter the

correct four-digit numeric code to view the channel

(default code is 0000). “Enter PIN” will be displayed

on the screen in such a case:

Media Playback Using Media

Browser

If the USB stick is not recognized after power off/on

or First Time Installation, ﬁ rst, plug the USB device

out and power off/on the TV set. Plug the USB device

in again.

To display Media Browser window, press either

“MENU” button on the remote control and then select

Media Browser by pressing “ ” or “ ” button. Press

OK button to continue. Media Browser menu options

will be displayed.

Also, when you plug USB devices, media browser

screen will be displayed automatically:

You can play music, picture and video ﬁ les from the

connected USB memory stick. Use “ ” or “ ” button

to select Videos, Photos, Music or Settings.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 17A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 17 07.03.2011 17:51:3407.03.2011 17:51:34

English - 18 -

Viewing Videos via USB

When you select Videos from the main options,

available video ﬁ les will be ﬁ ltered and listed on this

screen. You can use “ ” or “ ” button to select a video

ﬁ le and press OK button to play a video. If you select

a subtitle ﬁ le and press OK button, you can select or

deselect that subtitle ﬁ le. The following menu will be

displayed while playing a video ﬁ le:

Jump (Numeric buttons): The TV will jump to the

ﬁ le starting with the letter you input via the numeric

buttons on your remote control.

button: Preview a video ﬁ le.

Loop/Shufﬂ e (BLUE button): Press once to enable

Loop. Press again to enable both Loop and Shufﬂ e.

Press once more to enable only Shufﬂ e. Press again

to disable all. You can follow the disabled functions

with the change of the icons.

(INFO): Changes ﬁ lter options.

AV: Sorts ﬁ les by date.

Play (RED button): Starts the video playback.

Stop (BLUE button): Stops the video playback.

Pause (OK button): Pause the video playback.

Rewind ( button): Goes backward.

Forward ( button): Goes forward.

Subtitle/Audio ( button): Sets subtitle/Audio.

Yellow button: Opens subtitle time correction menu

Jump (GREEN button): Jumps to time. Use numeric

buttons to type the desired time and press GREEN

button again to proceed.

Press BACK button to switch back to previous

menu.

Viewing Photos via USB

When you select Photos from the main options,

available image ﬁ les will be ﬁ ltered and listed on this

screen.

Jump (Numeric buttons): Jump to selected ﬁ le using

the numeric buttons.

OK: Views the selected picture in full screen.

Slideshow (GREEN button): Starts the slideshow

using all images.

Loop/Shufﬂ e (BLUE button): Press once to enable

Loop. Press again to enable both Loop and Shufﬂ e.

Press once more to enable only Shufﬂ e. Press again

to disable all. You can follow the disabled functions

with the change of the icons.

AV: Sorts ﬁ les by date.

button: Views images in thumbnails.

(INFO): Changes ﬁ lter options.

Slideshow Options

RED button: Selected, the picture zooms.

Pause (YELLOW button): Pauses the slideshow.

Continue (GREEN button): Continues the slideshow.

Previous/Next (Left/Right buttons): Jumps to

previous or next ﬁ le on slideshow.

Rotate (Up/Down buttons): Rotates the image using

up/down buttons.

Loop/Shufﬂ e (BLUE button): Press once to enable

Loop. Press again to enable both Loop and Shufﬂ e.

Press once more to enable only Shufﬂ e. Press again

to disable all. You can follow the disabled functions

with the change of the icons.

BACK: Back to ﬁ le list.

(INFO): Displays help screen.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 18A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 18 07.03.2011 17:51:3407.03.2011 17:51:34

English - 19 -

Playing Music via USB

When you select Music from the main options,

available audio ﬁ les will be ﬁ ltered and listed on this

screen.

Jump (Numeric buttons): The TV will jump to the

ﬁ le starting with the letter you input via the numeric

buttons on your remote control.

Play This (OK button): Plays the selected ﬁ le.

Play (GREEN button): Plays all media ﬁ les starting

with the selected one.

Stop (RED button): Stops playback.

Pause (YELLOW button): Pauses the selected

playback.

Previous/Next (Left/Right buttons): Jumps to

previous or next ﬁ le to play.

AV: Sorts ﬁ les by Title,Artist or Album..

(INFO): Changes ﬁ lter options.

Loop/Shufﬂ e (BLUE button): Press once to enable

Loop. Press again to enable both Loop and Shufﬂ e.

Press once more to enable only Shufﬂ e. Press again

to disable all. You can follow the disabled functions

with the change of the icons.

Media Browser Settings

You can set your Media Browser preferences by

using the Settings dialog. Press “ ” or “ ” button to

highlight an item and use “ ” or “ ” button to set.

View Style: Sets default browsing mode.

Slideshow Interval: Sets slide show interval time.

Show Subtitle: Sets subtitle enabling preference.

Subtitle Language: Sets supported subtitle

language.

Subtitle Position: Sets subtitle position as up or

down.

Subtitle Font Size: Sets subtitle font size (max.

54pt).

Changing Image Size: Picture

Formats

Programmes can be watched in different picture • formats, depending on the transmission received.

You can change the aspect ratio (image size) of • the TV for viewing the picture in different zoom

modes.

Press • ZOOM button repeatedly to change the image

size. Available zoom modes are listed below.

Auto

When a WSS (Wide Screen Signalling) signal, which

shows the aspect ratio of the picture, is included in

the broadcast signal or the signal from an external

device, the TV automatically changes the ZOOM

mode according to the WSS signal.

When the • AUTO mode does not function correctly

due to poor WSS signal quality or when you want to

change the ZOOM mode, change to another ZOOM

mode manually.

16:9

This uniformly stretches the left and right sides of a

normal picture (4:3 aspect ratio) to ﬁ ll the wide TV

screen.

For 16:9 aspect ratio pictures that have been • squeezed into a normal picture (4:3 aspect ratio),

use the 16:9 mode to restore the picture to its

original shape.

Subtitle

This zooms up the wide picture (16:9 aspect ratio)

with subtitles to the full screen.

Note: You can shift to screen up or down by pressing

“” / “ ” buttons while picture zoom is selected as

panaromic, 14:9 Zoom, Cinema or Subtitle.

14:9

This zooms up the wide picture (14:9 aspect ratio) to

the upper and lower limits of the screen.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 19A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 19 07.03.2011 17:51:3507.03.2011 17:51:35

English - 20 -

14:9 Zoom

This option zooms to the 14:9 picture.

4:3

Use to view a normal picture (4:3 aspect ratio) as this

is its original size.

Panoramic

This stretches the left and right sides of a normal

picture (4:3 aspect ratio) to ﬁ ll the screen, without

making the picture appear unnatural.

The top and bottom of the picture are slightly cut off.

Cinema

This zooms up the wide picture (16:9 aspect ratio) to

the full screen.

Conﬁ guring Picture Settings

You can use different picture settings in detail.

Press “MENU” button and select the Picture icon

by using “ ” or “ ” button. Press OK button to view

Picture Settings menu.

Operating Picture Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

Use “• ” or “ ” button to set an item.

Press • “MENU” button to exit.

Picture Settings Menu Items

Mode: For your viewing requirements, you can set

the related mode option. Picture mode can be set

to one of these options: Cinema,Game,Dynamic

and Natural.

Contrast: Sets the lightness and darkness values

of the screen.

Brightness: Sets the brightness value for the

screen.

Sharpness: Sets the sharpness value for the objects

displayed on the screen.

Colour: Sets the colour value, adjusting the colors.

Colour Shift: Adjust the desired colour tone.

Colour Temp: Sets the desired colour tone.

Setting Cool option gives white colours a slight blue

stress.

For normal colours, select Normal option.

Setting Warm option gives white colours a slight red

stress.

Noise Reduction: If the broadcast signal is weak and

the picture is noisy, use Noise Reduction setting to

reduce the noise amount. Noise Reduction can be set

to one of these options: Low, Medium, High or Off.

Picture Zoom:Sets the picture size to Auto,16:9,

Subtitle,14:9, 14:9 Zoom, 4:3, Panoramic or Cinema.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 20A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 20 07.03.2011 17:51:3507.03.2011 17:51:35

English - 21 -

Reset: Resets the picture settings to factory default

settings.

While in VGA (PC) mode, some items in Picture menu

will be unavailable. Instead, VGA mode settings will be

added to the Picture Settings while in PC mode.

PC Picture Settings

For adjusting PC picture items, do the following:

Press “ ” or “ ” button to select Picture icon. Picture

menu appears on the screen.

Contrast, Brightness, Colour, Colour Temp and

Picture Zoom settings in this menu are identical

to settings deﬁ ned in TV picture menu under “Main

Menu System”.

Sound,Settings and Source settings are identical to the

settings explained in main menu system.

PC Position: Select this to display PC position menu

items.

Autoposition: Automatically optimizes the display.

Press OK to optimize.

H Position: This item shifts the image horizontally to

right hand side or left hand side of the screen.

V Position: This item shifts the image vertically

towards the top or bottom of the screen.

Dot Clock: Dot Clock adjustments correct the

interference that appear as vertical banding in

dot intensive presentations like spreadsheets or

paragraphs or text in smaller fonts.

Phase: Depending on the resolution and scan

frequency that you input to the TV set, you may see

a hazy or noisy picture on the screen. In such a case

you can use this item to get a clear picture by trial

and error method.

Conﬁ guring Sound Settings

Sound settings can be conﬁ gured according to your

personal preferences.

Press “MENU” button and select the ﬁ rst icon by

using “ ” or “ ” button. Press OK button to view

Sound Settings menu.

Operating Sound Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

Use “• ” or “ ” button to set an item.

Press • “MENU” button to exit.

Sound Settings Menu Items

Volume: Adjusts volume level.

Equalizer: Press OK button to view equalizer sub-

menu.

In equalizer menu, the preset can be changed to

Music, Movie, Speech, Flat, Classic and User.

Press the “MENU” button to return to the previous

menu.

Note: Equalizer menu settings can be changed

manually only when the Equalizer Mode is in User.

Balance: This setting is used for emphasizing left or

right speaker balance.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 21A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 21 07.03.2011 17:51:3607.03.2011 17:51:36

English - 22 -

Headphone: Sets headphone volume.

AVL: Automatic Volume Limiting (AVL) function sets the

sound to obtain ﬁ xed output level between programmes

(For instance, volume level of advertisements tend to

be louder than programmes).

Dynamic Bass: Dynamic Bass is used to increase

bass effect of the TV set.

Surround Mode: Surround mode can be change as

On or Off.

Digital Out: Sets digital out audio type.

Conﬁ guring Your TV’s Settings

Detailed settings can be configured to suit your

personal preferences.

Press “MENU” button and select Settings ikon by

using “ ” or “ ” button. Press OK button to view

Settings menu.

Operating Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

Press • OK button to select an item.

Press • “MENU” button to exit.

Settings Menu Items

Conditional Access: Controls conditional access

modules when available.

Language: Conﬁ gures language settings.

Parental: Conﬁ gures parental settings.

Timers: Sets timers for selected programmes.

Date/Time: Sets date and time.

Sources: Enables or disables selected source

options.

Other Settings: Displays other setting options of

the TV set.

Using a Conditional Access

Module

IMPORTANT: Insert or remove the CI module only

when the TV is SWITCHED OFF.

In order to watch certain digital channels, a • conditional access module (CAM) can be necessary.

This module must be inserted in the CI slot of your

TV.

Obtain the Conditional Access Module (CAM) and • the viewing card by subscribing to a pay channel

company, then insert those to the TV using the

following procedure.

Insert the CAM and then the viewing card to the • slot that is located in the terminal cover at the rear

side of the TV.

The CAM should be correctly inserted, it is • impossible to insert fully if reversed. The CAM or

the TV terminal may be damaged if the CAM is

forcefully inserted.

Connect the TV to the mains supply, switch on

and then wait for few moments until the card is

activated.

When no module is inserted, “• No Common

Interface module detected” message appears on

the screen.

Refer to the module instruction manual for details • of the settings.

Viewing Conditional Access Menu (*)

(*) These menu settings may change depending on

the service provider.

Press “MENU” button and select the icon by using

“” or “ ” button. Press OK button to view Settings

menu. Use “ ” or “ ” button to highlight Conditional

Access and press OK to view menu items.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 22A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 22 07.03.2011 17:51:3707.03.2011 17:51:37

English - 23 -

Conﬁ guring Language

Preferences

You can operate the TV’s language settings using

this menu.

Press “MENU” button and select the ﬁ fth icon by using

“” or “ ” button. Press OK button to view Settings

menu. Use “ ” or “ ” button to highlight Language

and press OK to continue:

Use “” or “ ” button to set an item. Settings are

stored automatically.

Menu: displays the system language.

Preferred

These settings will be used if available. Otherwise the

current settings will be used.

Audio• : Sets the preferred audio language.

Subtitle• : Sets the subtitle language. Selected

language will be seen in subtitles.

Teletext• : Sets teletext language.

Guide• : Sets the preferred Guide language.

Current (*)

(*) These settings can be changed if only the

broadcaster supports. Otherwise, settings will not be

available to be changed.

Audio: Changes the audio language for the current

channel.

Subtitle• : Sets the subtitle language for the current

channel.

Parental Control

To prohibit viewing of certain programmes, channels

and menus can be locked by using the parental

control system.

This function enables or disables the menu protection

system and allows the PIN code to be changed.

Press “MENU” button and select the icon by using

“” or “ ” button. Press OK button to view Settings

menu. Use “ ” or “ ” button to highlight Parental

and press OK to continue:

To display parental lock menu options, PIN number

should be entered. Factory default PIN number is

0000. After coding the correct PIN number, parental

settings menu will be displayed:

Parental Settings Menu Operation (*)

Select an item by using “• ” or “ ” button.

Use “• ” or “ ” button to set an item.

Press• OK button to view more options.

(*) If you set Country option as UK in the ﬁ rst time

installation, Maturity Lock and Child Lock options

will not be visible. This setting is available only for

EU countries.

Menu Lock: Menu lock setting enables or disables

the menu access. You can disable access to the

installation menu or the whole menu system.

Maturity Lock: When set, this option gets the maturity

information from the broadcast and if this maturity level

is disabled, disables access to the broadcast.

Child Lock: When Child Lock is set, the TV can only

be controlled by the remote control. In this case the

control panel buttons will not work, except for the

Standby/On button. When Child Lock is activated

you are able to switch the TV into Standby mode with

the Standby/On button. To switch the TV on again,

you need the remote control. Hence, if one of those

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 23A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 23 07.03.2011 17:51:3707.03.2011 17:51:37

English - 24 -

buttons is pressed, Child Lock Is On will be displayed

on the screen when the menu screen is not visible.

Set PIN: Deﬁ nes a new PIN number. Use numeric

buttons to enter a new pin number. You will need

to code your new pin a second time for veriﬁ cation

purposes.

IMPORTANT: The factory default pin number is 0000,

if you change the pin number make sure you write it

down and keep it safe.

Timers

To view Timers menu, press “MENU” button and

select Channel List icon by using “ ” or “ ” button.

Press OK button to view Channel List menu. Use “

” or “ ” button to highlight Timers and press OK

to continue:

Setting Sleep Timer

This setting is used for setting the TV to turn off after

a certain time.

Highlight Sleep Timer by using “• ” or “ ” button.

Use “• ” or “ ” button to set. The timer can be

programmed between Off and 2.00 hours (120

minutes) in steps of 30 minutes.

Setting Programme Timers

You can set programme timers for a particular

programme using this feature.

Press “ ” button to set timers on an event. Programme

timer function buttons will be displayed on the

screen.

Adding a Timer

Press • YELLOW button on the remote control to

add a timer. The following menu appears on the

screen:

Channel: Changes channel by using “ ” or “ ”.

Timer Type: This feature is unavailable to be set.

Date: Enter a date using the numeric buttons.

Start: Enter a starting time using the numeric

buttons.

End: Enter an ending time using the numeric

buttons.

Duration: Displays duration between the starting and

ending time.

Repeat: Sets a timer to be repeated as Once, Daily or

Weekly. Use “ ” or “ ” buttons to select an option.

Press • GREEN button to save the timer. Press RED

button to cancel.

Change/Delete:Controls parental settings on timers.

Editing a Timer

Select the timer you want to edit by pressing “• ”

or “ ” button.

Press • GREEN button. Edit Timer menu screen will

be displayed.

When ﬁ nished with editing, press • GREEN button to

save. You can press “MENU” button to cancel.

Deleting a Timer

Select the timer you want to delete by pressing “• ” or “ ” button.

Press • RED button.

Select • YES by using “ ” or “ ” buttons to delete the

timer. Select NO to cancel.

Conﬁ guring Date/Time Settings

Select Date/Time in the Settings menu to conﬁ gure

Date/Time settings. Press OK button.

Use “• ” or “ ” buttons to highlight Date/Time.

Date,Time,Time Settings Mode and Time Zone Setting

will be available.

Use “ ” or “ ” buttons to highlight the Time Settings

Mode. Time Settings Mode is set using “ ” or “ ”

buttons. It can be set to AUTO or MANUAL.

When AUTO is selected, Date/Time and Time Zone

options will not be available to be set. If MANUAL

option is selected as the Time Zone can be altered:

• By pressing “ ” or “ ” buttons select Time Zone.

Use “ ” or “ ” buttons to change the Time Zone

between GMT-12 or GMT+12. Date/Time on the top

of the menu list will then change according to the

selected Time Zone.

Changes are automatically stored. Press • “MENU”

to exit.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 24A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 24 07.03.2011 17:51:3807.03.2011 17:51:38

English - 25 -

Conﬁ guring Source Settings

You can enables or disable selected source options.

The TV will not switch to the disabled source options

when “AV” button is pressed.

Select • Sources in the Settings menu and press

OK button.

Press“• ” or “ ” buttons to select a source.

Use “• ” or “ ” button to enable or disable the

selected source. Changes are automatically

stored.

Conﬁ guring Other Settings

To view general conﬁ guration preferences, select

Other Settings in the Settings menu and press OK

button.

Operation

Press “• ” or “ ” buttons to select an item.

Use “• ” or “ ” button to set an option.

Press• OK button to view a sub-menu.

Menu Timeout: Changes timeout duration for menu

screens.

Scan Encrypted: When this setting is on, search

process will locate the encrypted channels as well. If

it is set as Off, encrypted channels will not be located

in automatic search or manual search.

Backlight (optional): This setting controls the

backlight level and it can be set to Maximum,

Minimum, Medium and Eco Mode.

Power Save Mode: Use “ ” or “ ” button to select

Power Save Mode. Press “ ” or “ ” button to set

Power Save Mode as On or Off. See the section,

“Environmental Information” in this manual for further

information on Power Save Mode.

Note: Backlight function will be invisible if Power Save

Mode is set to on.

Blue Background: Activates or deactivates blue

background system when the signal is weak or

absent.

Software Upgrade: To ensure that your TV always

has the most update information, you can use this

setting. In order for the proper operation, please

ensure that the TV is set to standby mode.

You can enable or disable automatic upgrade by

setting Automatic Scanning option.

You can manually search for new software by

selecting Scan for upgrade.

Hard of Hearing: If the broadcaster enables any

special signal concerning the audio, you can set this

setting as On to receive such signals.

Audio Description: Audio description refers to

an additional narration track for blind and visually

impaired viewers of visual media, including television

and movies. The description narrator talks through

the presentation, describing what is happening on the

screen during the natural pauses in the audio (and

sometimes during dialogue, if deemed necessary).

You can use this feature, only if the broadcaster

supports that additional narration track.

Auto TV Off: You can set the timeout value of auto off

feature.After the timeout value is reached and the Tv is

not operated for selected time , the TV will go off.

Standby Search (optional): Use “ ” or “ ” button

to select Standby Search and then press “ ” or “

” button to set this setting as On or Off. If you

change Standby Search to Off, this function will be

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 25A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 25 07.03.2011 17:51:3907.03.2011 17:51:39

English - 26 -

unavailable.To use Standby search please make sure

that you select Standby Search as On.

Other Features

Displaying TV Information: Programme Number,

Programme Name, Sound Indicator, time, teletext,

channel type and resolution information is displayed

on the screen when a new programme is entered or

“ (INFO)” button is pressed.

Muting Function: Press “ ” button to disable

sound. Muting indicator will be displayed in the upper

side of the screen. To cancel Muting, there are two

alternatives; the ﬁ rst one is pressing the “ ” button

and the second one is increasing the volume level.

Displaying Subtitles: You can enable subtitles by

pressing the button of the remote control. Press

button again to disable subtitle function.

If “Subtitle” is On, pressing the “ ” button causes the

following warning message display on the screen (**

for UK only)

Teletext

Teletext system transmits information such as news,

sports and weather on your TV. Note that is the signal

degrades, for example in poor/adverse weather

conditions, some text errors may occur or the teletext

mode may be aborted.

Teletext function buttons are listed below:

“” Teletext / Mix: Activates teletext mode when

pressed once. Press again to place the teletext screen

over the programme (mix).Pressing again will quit the

teletext mode.

“” Index

Selects the teletext index page.

“” Expand

No function

“” Reveal

Shows hidden information (e.g. solutions of games).

“” Hold

Holds a text page when convenient. Press again to

resume.

“ ” No fuction

/ and numbers (0-9)

Press to select a page.

Note: Most TV stations use code 100 for their index

pages.

Coloured Buttons

(RED/GREEN/YELLOW/BLUE)

Your TV supports both FASTEXT and TOP text

systems. When these systems are available, the

pages are divided into groups or topics.

When FASTEXT system is available, sections in a

teletext page will become colour-coded and can be

selected by pressing the coloured buttons. Press

a coloured button that corresponds to with your

needs.

The coloured writings will appear, showing you which

coloured buttons to use when TOP text transmission

is present. Pressing or commands will request

the next or previous page respec tively.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 26A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 26 07.03.2011 17:51:4007.03.2011 17:51:40

English - 27 -

Tips

Screen Care: Clean the screen with a slightly damp,

soft cloth. Do not use abrasive solvents as they may

damage the coating layer of the TV screen. For your

safety, unplug the mains plug when cleaning the

set. When moving the TV, hold it properly from the

bottom part.

Image Persistence: Please note that ghosting may

occur while displaying a persistent image.LCD TVs’

image persistence may disappear after a short time.

Try turning off the TV for a while.

To avoid this, do not leave the screen in still picture

for extended periods.

No Power: If your TV system has no power, please

check the main power cable and connection to the

mains socket outlet.

Poor Picture: Have you selected the correct TV

system? Is your TV set or house aerial located too close

to a non-earthed audio equipment or neon lights, etc.?

Mountains or high buildings can cause double pictures

or ghost images. Sometimes you can improve the

picture quality by changing the direction of the aerial.

Is the picture or teletext unrecognisable? Check if you

have entered the correct frequency. Please retune the

channels. The picture quality may degrade when two

peripherals are connected to the TV at the same time.

In such a case, disconnect one of the peripherals.

No Picture: Is the aerial connected properly? Are the

plugs connected tightly to the aerial socket? Is the

aerial cable damaged? Are suitable plugs used to

connect the aerial? If you are in doubt, consult your

dealer. No Picture means that your TV is not receiving

a transmission. Have you selected the correct button

on the remote control? Try once more. Also make sure

the correct input source has been selected.

Sound: You can not hear any sound. Did you perhaps

interrupt the sound, pressing the button? Sound is

coming from only one of the speakers. Is the balance

set to one extreme? See Sound Menu.

Remote Control: Your TV no longer responds to the

remote control. Perhaps the batteries are exhausted.

If so you can still use the local buttons on the TV.

Input Sources: If you cannot select an input source,

it is possible that no device is connected. Check

the AV cables and connections if you have tried to

connect a device.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 27A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 27 07.03.2011 17:51:4007.03.2011 17:51:40

English - 28 -

Appendix A: PC Input Typical

Display Modes

The display has a maximum resolution of 1360 x 768.

The following table is an illustration of some of the

typical video display modes. Your TV may not support

different resolutions. Supported resolution modes are

listed below. If you switch your PC to an unsupported

mode, a warning OSD will appear on the screen.

Index Resolution Frequency

1640x400 70 Hz

2640x480 60 Hz

3640x480 75 Hz

4800x600 60 Hz

5800x600 75 Hz

61024x768 60 Hz

71024x768 70 Hz

81024x768 75 Hz

91152x864 75 Hz

10 1280x768 60 Hz

11 1280x1024 60 Hz

12 1360x768 60 Hz

Appendix B: AV and HDMI Signal

Compatibility (Input Signal Types)

Source Supported Signals Available

EXT-1

(SCART-1)

PAL 50/60 O

NTSC 60 O

RGB 50 O

RGB 60 O

EXT-2

(SCART-2)

PAL 50/60 O

NTSC 60 O

RGB 50 X

RGB 60 X

SIDE AV PAL 50/60 O

NTSC 60 O

YPbPr

480I 60Hz O

480P 60Hz O

576I 50Hz O

576P 50Hz O

720P 50Hz O

720P 60Hz O

1080I 50Hz O

1080I 60Hz O

1080P 50Hz O

1080P 60Hz O

HDMI1

HDMI2

HDMI3

HDMI4

480I 60Hz O

480P 60Hz O

576I 50Hz O

576P 50Hz O

720P 50Hz O

720P 60Hz O

1080I 50Hz O

1080I 60Hz O

1080P 50Hz O

1080P 60Hz O

1080P 24Hz O

(X: Not Available, O: Available)

In some cases a signal on the LCD TV may not be displayed

properly. The problem may be an inconsistency with standards

from the source equipment (DVD, Set-top box, etc. ). If you

do experience such a problem please contact your dealer and

also the manufacturer of the source equipment.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 28A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 28 07.03.2011 17:51:4007.03.2011 17:51:40

English - 29 -

Appendix C: Supported DVI Resolutions

When connecting devices to your TV’s connectors by using DVI converter cables (not supplied), you can refer

to the following resolution information.

24Hz 25Hz 30Hz 50Hz 60Hz

480i ;

480p ;

576i ;

576p ;

720p ;;

1080i ;;

1080p ;;; ; ;

Appendix D: Supported File Formats for USB Mode

Supported Players

Player Stream Video Decoder (MSVD) Audio Decoder (MSAD)

Audio MP3 None MP3

Audio WAV/AIFF None-- LPCM

Windows Media

(optional) WMA / ASF VC1 WMA

MPEG1 Program

Stream MPEG-1 MPEG1 MP3, AC-3 and PCM

MPEG2 Program

Stream MPEG-2 MPEG2 MP3, AC-3 and PCM

MPEG4 MPEG-4/H264 in

MP4 container H264 and MPEG4 AAC

AVI (Xvid) XVID MPEG4 MP3, AC-3 and PCM

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 29A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 29 07.03.2011 17:51:4007.03.2011 17:51:40

English - 30 -

Appendix D: Software Upgrade

• Your TV is capable of ﬁ nding and updating new software upgrades over broadcast channels.

• For broadcast channels search, TV looks the available channels stored in your settings. So before software

upgrade search, it is advised to auto search and update all available channels.

1) Software upgrade search via user interface

• It is possible manually to check if there is a new software upgrade for your TV set.

• Simply navigate on your main menu. Choose Settings and select Other Settings menu. In Other Settings

menu navigate on to the Software Upgrade item and press OK button to open Upgrade Options menu.

• In Upgrade Options menu select Scan for upgrade and press OK button.

• If a new upgrade is found, it starts to download the upgrade. A progress bar indicates the remaining download

progress. When download completes with success a message is displayed for reboot to activate new software.

Press OK to continue with the reboot operation.

2) 3.AM search and upgrade mode

• If Automatic scanning in Upgrade Options menu is enabled, TV wakes up at 03:00 and searches broadcast

channels for new software upgrade. If new software is found and downloaded successfully, with next power

up TV opens with new software version.

Note on reboot operation: Reboot is the last step in software upgrade operation if download of new software is

ﬁ nished successfully. During reboot TV makes ﬁ nal initializations. In reboot sequence panel power is closed and

front led indicates the activity with blinking. Around 5 minutes later TV restarts with new software activated.

• If your TV fails to restart in 10 minutes, unplug power for 10 minutes and re-plug again. TV should open with

new software safely. If you still can not get TV working, please kindly repeat unplug and plug sequence a few

times more. If your set still can not operate, please call the service personnel to ﬁ x the problem for you.

Caution: While led is blinking during reboot do not unplug your TV’s power. Doing this may cause

your TV not to re-open again and can only be ﬁ xed by service personnel.

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 30A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 30 07.03.2011 17:51:4107.03.2011 17:51:41

English - 31 -

Speciﬁ cations

TV BROADCASTING

PAL/SECAM B/G D/K K’ I/I’ L/L’

RECEIVING CHANNELS

VHF (BAND I/III)

UHF (BAND U)

HYPERBAND

NUMBER OF PRESET CHANNELS

1000

CHANNEL INDICATOR

On Screen Display

RF AERIAL INPUT

75 Ohm (unbalanced)

OPERATING VOLTAGE

220 V - 240 V AC, 50 Hz.

AUDIO

German + Nicam Stereo

AUDIO OUTPUT POWER (WRMS.) (10% THD)

2 x 6

POWER CONSUMPTION

150 W (max)

< 1 W (Standby)

PANEL

32” Wide Screen

DIMENSIONS (mm)

WxHxD (With stand): 794 x 556 x 212

Weight (kg): 12.30

WxHxD (Without stand): 794 x 520 x 97

Weight (kg): 11.60

Digital Reception (DVB-T)

Transmission Standards:

DVB-T, MPEG2,DVB-T, MPEG4 HD

I. DEMODULATION

Symbol rate: COFDM with 2K/8K FFT mode.•

Modulation: 16-QAM - 64-QAM FEC for all DVB • modes (automatically found)

MHEG-5 ENGINE compliant with ISO/IEC 13522-5 • UK engine Proﬁ le

Object carousel support compliant with ISO/IEC • 135818-6 and UK DTT proﬁ le

Frequency range: 474 MHz - 850 MHz•

II. VIDEO

H.264 (MPEG-4 part 10) main and high proﬁ le level • 4.1/MPEG-2 MP@HL video decoder.

HD display multi format capable (1080i, 720p, • 576p)

CVBS analogue output. (In HD channels, this will • not be available

III. AUDIO

MPEG-1 layer I/II, MPEG-2 layer II, AAC, HEAAC, • AC3, E-AC3

Sampling frequencies supported are 32 kHz, 44.1 • kHz and 48 kHz

A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 31A00_[GB]_MB61_RM-C2503-1C_IDTV-MPEG4_GOLD10_32841W_10069206_50185104.indd 31 07.03.2011 17:51:4107.03.2011 17:51:41

INSTRUCTIONS

WIDE LCD PANEL TV

LT-32HG20E

50185104

ENGLISH

JVC LT 32HG20E User Manual 50185104

Navigation menu

Versions of this User Manual:

Views

Navigation
