JVC KENWOOD Corporation UHF Digital Base-Repeater NXR 5700 5800
Users Manual
B5A-0713-00 (K,K3,K5)
NXR-5700
VHF DIGITAL BASE-REPEATER/ UHF DIGITAL BASE-REPEATER
INSTRUCTION MANUAL
BASE-RELAIS NUMÉRIQUE VHF/ BASE-RELAIS NUMÉRIQUE UHF
MODE D’EMPLOI
BASE-REPETIDOR DIGITAL VHF/ BASE-REPETIDOR DIGITAL UHF
MANUAL DE INSTRUCCIONES
NXR-5800
1
◆ This repeater is intended for use as a fi xed base station with
the antenna located outdoors on the rooftop or on an antenna
tower.
◆ This repeater is designed for a 13.6 V DC power source!
Never use a 24 V DC or higher source to power the repeater.
◆ Use only the supplied DC cord.
◆ Do not remove the ferrite core attached to the DC cord. Doing
so may cause interference with radio communications.
UNPACKING AND CHECKING EQUIPMENT
Note: The following unpacking information is for use by your
KENWOOD dealer, an authorized KENWOOD service center, or the
factory.
Carefully unpack the repeater. We recommend that you identify
the items listed in the following table before discarding the
packing material. If any items are missing or have been damaged
during shipment, fi le a claim with the carrier immediately.
Item Part Number Quantity
Front glass B10-2781-XX 1
Dressed screw N08-0563-XX 1
Bracket J29-0725-XX 2
Flat head machine screw N32-4008-XX 4
Handle K01-0421-XX 1
DC cord E30-3427-XX 1
Lead wire with connector (15 pin) E31-3228-XX 1
Fuse (15 A) F52-0042-XX 1
SYNC Cable E30-7701-XX 1
Instruction Manual B5A-0713-XX 1
INSTALLATION
To install the handles onto the front panel of the repeater, align
the handles with the holes on the front panel, then secure the
handles using the supplied screws.
Please consult your dealer for installing the repeater and
antenna.
MICROPHONE
Connect an optional KMC-30, KMC-35, KMC-9C, or KMC-53
KENWOOD microphone to the MICROPHONE jack on the front
panel.
OCXO UNIT (KXK-3):Option
The OCXO unit (KXK-3) is an Oven Controlled Crystal Oscillator
(OCXO) unit.
NOTICES TO THE USER
◆ Government law prohibits the operation of unlicensed radio
transmitters within the territories under government control.
◆ Illegal operation is punishable by fi ne and/or imprisonment.
◆ Refer service to qualifi ed technicians only.
One or more of the following statements may be applicable:
FCC WARNING
This equipment generates or uses radio frequency energy. Changes
or modifi cations to this equipment may cause harmful interference
unless the modifi cations are expressly approved by the party
responsible/JVC KENWOOD. The user could lose the authority to
operate this equipment if an unauthorized change or modifi cation is
made.
INFORMATION TO THE DIGITAL DEVICE USER REQUIRED BY
THE FCC
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can generate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer for technical assistance.
THANK YOU!
We are grateful you purchased this KENWOOD repeater. We
believe this easy-to-program repeater will be highly effective in
your communications system, and will keep personnel operating
at peak effi ciency.
KENWOOD incorporates the latest in advanced technology into
all of our products. As a result, we feel strongly that you will be
pleased with the quality and features of this product.
PRECAUTIONS
• Do not expose the unit to rain or moisture; to prevent fi re or
electric shock.
• Do not open the unit under any circumstances; to avoid risk
of electric shock.
• Do not expose the unit to long periods of direct sunlight, nor
place it close to heating appliances.
• Do not place the unit in excessively dusty and/or humid
areas, nor on unstable surfaces.
• Do not put the plastic bag used for packing of this equipment
on the place which reaches a small child's hand. It will
become a cause of suffocation if it wears fl atly.
• Always switch the transceiver power off before installing
optional accessories.
• If you detect an abnormal odor or smoke coming from the
unit, disconnect the power from the unit immediately. Contact
your KENWOOD service center or dealer.
NXR-5700 / NXR-5800 INSTRUCTION MANUAL
VHF DIGITAL BASE-REPEATER / UHF DIGITAL BASE-REPEATER
Firmware Copyrights
The title to and ownership of copyrights for fi rmware embedded in
KENWOOD product memories are reserved for JVC KENWOOD
Corporation.
The AMBE+2
TM
voice coding Technology embodied in this product
is protected by intellectual property rights including patent rights,
copyrights and trade secrets of Digital Voice Systems, Inc. This
voice coding Technology is licensed solely for use within this
Communications Equipment. The user of this Technology is
explicitly prohibited from attempting to extract, remove, decompile,
reverse engineer, or disassemble the Object Code, or in any other
way convert the Object Code into a human-readable form. U.S.
Patent Nos. #6,199,037, #6,912,495, #8,200,497, #7,970,606, and
#8,359,197.
◆ Do not install the repeater in explosive atmospheres
(infl ammable gas, dust particles, metallic powders, grain
powders, etc.).
2
REPEATER OPERATION
Note: Please consult your dealer for programming the repeater.
Due to the frequency stability on the 6.25 kHz bandwidth channel,
when operating the repeater using an optional OCXO unit, allow
the unit to warm up after turning the power on. Refer to the KXK-3
instruction manual concerning the warm up duration.
After turning on the power, wait for approximately 10 seconds for
the VCXO or 5 minutes for the OCXO (when mounting) to warm up.
During this time, the CH/STATUS Display will blink. The keys will
function when they are pressed.
When power is applied to the unit, the POWER indicator lights
green. Turn the VOLUME control clockwise until a click sounds, to
unmute the audio. Rotate to adjust the audio. Turn the VOLUME
control counterclockwise fully to mute the audio.
The BUSY indicator lights green while receiving a signal and the
TX indicator lights red while transmitting.
■ Rear Panel
a RX IN jack
Connect an RX antenna or a duplexer to this BNC
receptacle.
b TEST/SPKR jack
Test input/output jack. Connect an external speaker to
this jack.
c CONTROL I/O jack
Connect a repeater controller or a remote panel to this
DB-25 interface.
d SYNC 1 / 2 jack
Connect to another repeater to use synchronous frame
signaling for digital trunking.
e LAN jack
Connect to Ethernet.
CONTROLS AND FUNCTIONS
■ Front Panel abd
efg
hi
c
abde f g
c
MICROPHONE
VOLUME
OFF/
POWERCTRL OCXO BUSY TX
12
MON
TAKE
OVER
RPT
DISABLE
ABC
345678
STATUS
TEST/SPKR
RX TX
CONTROL I/O SYNC
12 LAN REF OUT REF IN
FUSE
15A
DC 13.6V
f REF OUT jack
Connect to another repeater within the site to supply a
reference signal.
g REF IN jack
Connect from another repeater within the site to receive a
reference signal.
h FUSE
Insert 15 A blade fuse into this fuse holder.
i DC 13.6V jack
Connect a 13.6 V DC power supply to this jack.
j TX OUT jack
Connect a TX antenna or a duplexer to this BNC receptacle.
hij
TRANSCEIVER OPERATION
■ Receive
Adjust the volume to your desired level. You may need to
readjust the volume if you are having interference while
receiving a message from your dispatcher or another member
in your fl eet.
The BUSY indicator lights green while a signal is being
received.
■ Transmit
1 Listen to the channel before transmitting, to make sure it
is not being used.
2 Press the microphone PTT switch, then speak in your
normal speaking voice.
The TX indicator lights red while transmitting.
3 When you fi nish speaking, release the PTT switch.
a Speaker
b CH/STATUS Display
Two 17-segment digits display the channel number, name,
or status.
c STATUS indicator
Indicates the status of the repeater. (NXDN mode)
d Programmable Function keys
Press these keys to activate their programmable functions.
e USB jack (B-Type)
Connect to the PC using a USB cable.
f VOLUME control
Turn clockwise until a click sounds, to unmute the audio.
Rotate to adjust the audio. Turn counterclockwise fully to
mute the audio.
g MICROPHONE jack
Connect a microphone to this 8-pin modular jack.
h POWER indicator
Lights green when power is supplied to the DC 13.6V jack.
Blinks red when an abnormal voltage is present. While
blinking, the repeater cannot be used.
i TX indicator
Lights red while transmitting.
j BUSY indicator
Lights green while a signal is being received.
k OCXO indicator
The OCXO indicator shows the state of the reference
10 MHz oscillator :
Lights Green when using a reference signal from an
optional OCXO unit (KXK-3).
Lights Orange when using a reference signal from another
repeater.
Lights red when no reference signal is available or when
an error occurs.
Does not light when the reference signal is an internal
VCXO signal.
l CTRL indicator
The CTRL indicator shows the control channel status
while using Digital trunking :
Lights Green when the repeater is used as control channel.
Blinks Green when using a non-dedicated control channel.
jkl
©
2015
Addendum
Terminal Description
MIC (Modular Jack)
Pin
NO. Pin Name Description Specifi cation I/O Notes
1 NC Not used Not used −
2 SB Power Output 13.6 V O
3 GND GND GND −
4 PTT PTT Signal Input Impedance 100 kI
5 MICG MIC GND MIC GND −
6 MIC MIC Input 600
I
7 HOOK Hook Detection Input Impeadance 100 kI
8 NC Not used Not used −
USB (USB Type-B)
Pin
NO. Pin Name Description Specifi cation I/O Notes
1 VBUS USB VBUS Conform to USB specifi cation I
2 D- USB Data minus Conform to USB specifi cation I/O
3 D+ USB Data plus Conform to USB specifi cation I/O
4 GND USB GND USB GND −
TEST/ SPEAKER CONNECTOR
Pin
NO. Pin Name Description Specifi cation I/O Notes
1 SB Power Output 13.6 V O
2 SB Power Output 13.6 V O
3 NC Not used Not used −
4 GND GND GND −
5 GND GND GND −
6 SPG Speaker GND Speaker GND −
7 RD RX Data Output Allowable load MIN 100 kO not De-emphasis
8 RSSI RSSI Signal Output Output Level 0 to 5 V O
9 SPI Internal Speaker Input Short with "SPO" I
10 AO1 Open Collector Terminal Allowable current value MAX 200 mA O
11 AO2 Open Collector Terminal Allowable current value MAX 200 mA O
12 SPO External Speaker Output Output Level 3W (5%Distortion) O
13 AO3 Open Collector Terminal Allowable current value MAX 200 mA O
14 AO4 Open Collector Terminal Allowable current value MAX 200 mA O
15 AO5 Open Collector Terminal Allowable current value MAX 200 mA O
Control I/O (D-SUB 25 Pin) CONNECTOR
Pin
NO. Pin Name Description Specifi cation I/O Notes
1 NC Not used Not used −
2 RXD Asynchronous Receive Data Comform to RS-232C standard I
3 TXD Asynchronous Send Data Comform to RS-232C standard O
4 AI1 Programmable Function Input 1 Input Impedance 47 kI
5 AI2 Programmable Function Input 2 Input Impedance 47 kI
6 AI3 Programmable Function Input 3 Input Impedance 47 kI
7 DG Digital GND Digital GND −
8 TD TX Data Input Input Impedance 600 I not Pre-emphasis
9 TA TX Audio Input Input Impedance 600 I Pre-emphasis
10 RD RX Data Output Load Impedance 4.7 kO not De-emphasis
11 RA RX Audio Output Load Impedance 4.7 kO De-emphasis
12 RXG RX Signal GND RX Signal GND −
13 SPM Speaker Mute Input Impedance 47 kI
14 BER CLK For Bit Error Rate Clock CMOS O
15 EMON External Monitor Switch Input Impedance 47 kI
16 EPTT External PTT Switch Input Impedance 47 kI
17 SC Squelch Control Output level 0 or 5 V O
18 BER DAT For Bit Error Rate Data CMOS O
19 TXG TX Signal GND TX Signal GND −
20 IO1 Programmable Function I/O 1 Input Impedance 47 kI/O Output level 0 or 5 V
21 IO2 Programmable Function I/O 2 Input Impedance 47 kI/O Output level 0 or 5 V
22 IO3 Programmable Function I/O 3 Input Impedance 47 kI/O Output level 0 or 5 V
23 IO4 Programmable Function I/O 4 Input Impedance 47 kI/O Output level 0 or 5 V
24 IO5 Programmable Function I/O 5 Input Impedance 47 kI/O Output level 0 or 5 V
25 IO6 Programmable Function I/O 6 Input Impedance 47 kI/O Output level 0 or 5 V
LAN (Modular Jack)
Pin
NO. Pin Name Description Specifi cation I/O Notes
1 TD+ TX Signal + Comform to IEEE802.3 standard O 100 Mbps
2 TD- TX Signal − Comform to IEEE802.3 standard O 100 Mbps
3 RD+ RX Signal + Use Designated Transformer I 100 Mbps
4 NC Not used Not used −
5 NC Not used Not used −
6 RD- RX Signal − Use Designated Transformer I 100 Mbps
7 NC Not used Not used −
8 NC Not used Not used −
SYNC 1, 2 Connector (There are two connectors)
Pin
NO. Pin Name Description Specifi cation I/O Notes
1 FRMA RS-485 Differential Signal A Conform to RS485 I/O
2 NC Not used Not used −
3 NC Not used Not used −
4 FRMB RS-485 Differential Signal B Conform to RS485 I/O
RX ANT Impedance 50
TX ANT Impedance 50
REF IN External Reference Signal Input (10 MHz). Impedance : more than 1 k
REF OUT Reference Signal Distribution (10 MHz). Load Impedance : more than 50
B5K-0197-00
MANDATORY SAFETY INSTRUCTIONS TO INSTALLERS AND USERS
• Use only manufacturer or dealer supplied antennas.
• Antenna Minimum Safe Distance: 180 cm (6 feet).
• Antenna Gain: 0 dBd referenced to a dipole.
The Federal Communications Commission has adopted a safety standard
for human exposure to RF (Radio Frequency) energy which is below the
OSHA (Occupational Safety and Health Act) limits.
• Antenna Mounting: The antenna supplied by the manufacturer or
radio dealer must not be mounted at a location such that during radio
transmission, any person or persons can come closer than the above
indicated minimum safe distance to the antenna, i.e. 180 cm (6 feet).
• To comply with current FCC RF Exposure limits, the antenna must be
installed at or exceeding the minimum safe distance shown above,
and in accordance with the requirements of the antenna manufacturer
or supplier.
• Vehicle installation: The antenna can be mounted at the center
of a vehicle metal roof or trunk lid, if the minimum safe distance is
observed.
• Base Station Installation: The antenna should be xed-mounted on
an outdoor permanent structure. RF Exposure compliance must be
addressed at the time of installation.
Antenna substitution: Do not substitute any antenna for the one supplied
or recommended by the manufacturer or radio dealer.
You may be exposing person or persons to excess radio frequency
radiation. You may contact your radio dealer or the manufacturer for
further instructions.
Maintain a separation distance from the antenna to person(s) of at
least 180 cm (6 feet).
You, as the qualied end-user of this radio device must control the
exposure conditions of bystanders to ensure the minimum separation
distance (above) is maintained between the antenna and nearby persons
for satisfying RF Exposure compliance. The operation of this transmitter
must satisfy the requirements of Occupational/Controlled Exposure
Environment, for work-related use, transmit only when person(s) are at
least the minimum distance from the properly installed, externally mounted
antenna. Transmit only when people outside the vehicle are at least the
recommended minimum lateral distance away from the antenna/vehicle.
B59-2667-00
