JVM SINGLE-ACRS SINGLE ACRS-III CARTRIDGE(RFID) User Manual
JVM Co., Ltd. SINGLE ACRS-III CARTRIDGE(RFID)
JVM >
User Manual
JV
-
TM10
SINGLE
ACRS
-
III
Cartridge (RFID)
User Manual
ZZ101P120
JVM PROPRIETARY & CONFIDENTIAL USER MANUAL
1. Introduction ---------------------------------------------------------------------------------- 3
2. Target Machine ------------------------------------------------------------------------------ 7
3. System Requirement ------------------------------------------------------------------------ 8
4. How to use --------------------------------------------------------------------------------- 12
목차
목차목차
목차
CONTENTS
JVM PROPRIETARY & CONFIDENTIAL USER MANUAL
1. Introduction.
View
This product supports RFID.
Antenna
RFID
Module
ZZ101P120
JVM PROPRIETARY & CONFIDENTIAL USER MANUAL
2. Target : ATDPS
3. System Requirement
- Frequency : 13.56MHz
- Protocol : ISO15693 (TI Tag-it)
4. How to use
① Connect CAN to USB Converter.
② Select Bit Rate(250kBit/s) what you use, then Press OK.
③ After recognize RFID Tag, related information will be displayed on
Message Windows.
ZZ101P120
JVM PROPRIETARY & CONFIDENTIAL USER MANUAL
JV-RFRM10
Size (WxDmm) 70mm x 110mm
Weight (g) 200g
Power 5V
Communications CAN
Temperature -20 ~ +50
Frequency 13.56MHz
Specifications
ZZ101P120
