Jakks Pacific 94977 MASTER A MILLION 2.0 ASSORTMENT User Manual 40957 US IM R2
Jakks Pacific (HK) Ltd. MASTER A MILLION 2.0 ASSORTMENT 40957 US IM R2
User Manual
US A5 148 x 210 mm
5+
HOW TO REGISTER THE BALL WITH THE SMART DEVICE:
1. Pull out the core module from the ball cover and insert the battery. You have to put the core module back into the ball to start the registration process.
2. The RED LED will be quick flashing which indicates that it is ready for the registration process. You have to complete the process within 2 minutes.
3. Please keep the Bluetooth & the MAM 2.0 APP on in your smart-device and follow the step of the MAM 2.0 APP to register the ball.
4. If the registration process is failed within 2 minutes, the ball will be back into the standby mode with LED and Bluetooth off. By bouncing ball, please repeat from step 2
to register the ball again.
5. The built-in LED will flash for 3 times after each bounce and the bouncing counter will be uploaded to the MAM 2.0 APP. Please keep the Bluetooth on and open
the MAM 2.0 APP in your smart-device.
6. When the counter reaches each of the below milestones, the RGB LED display will flash the corresponding color when bouncing:
000000 to 199999 Red
200000 to 399999 Green
400000 to 599999 Orange
600000 to 799999 Blue
800000 to 999999 Purple
After 1,000,000 bounces, the LEDs will flash all the colors above.
HARDWARE SPECIFICATIONS:
- Operating Voltage and battery type: DC 3.0V , CR2032
- Operating Current: below 40mA
- Standby Current: below 15uA.
- Built-in Bluetooth 4.0 for SmartDevice connection
- Built-in RGB LED for bouncing and connection status display.
- Built-in memory to store the counter number and ID from server.
Google Play is a trademark of Google inc.
Apple and the Apple logo are trademarks of Apple Inc,.
registered in the U.S. and other countries.
App Store is a service mark of Apple Inc.
SUPPORTED
OPERATING SYSTEMS:
• iOS 10 & HIGHER
• ANDROID 6 API LEVEL19
“MARSHMELLOW" & HIGHER
BATTERY INSTALLATION INSTRUCTIONS
Batteries included. If performance diminishes after purchase, replace with fresh batteries.
Requires 1 x DC 3.0V, CR2032 battery (included).
ADULT INSTALLATION REQUIRED
1. Locate battery compartment at the back.
2. Use a coin to separate cover and pull out cover.
3. Using a Phillips Head screwdriver (not included) remove the screw and battery cover.
4. Install new battery.
5. Replace the battery cover, the screw, and the outer cover.
* If you experience problems such as the LED is dim, no light, or no connection of Bluetooth, please try to pull out the battery cover and insert again.
If you still face the problem, the battery may need to be changed.
DATA CHARGES MAY APPLY. ASK A PARENT FOR PERMISSION.
MAY NOT BE COMPATIBLE WITH ALL iOS AND ANDROID DEVICES.
* Product not waterproof. Keep away from water.
1
BATTERY INSTALLATION INSTRUCTIONS
Scan here for more information
23
How long will it take you to
bounce to a Million?
Includes:
1 Master A Million
™
2.0 Ball
Requires
1 x 3V (CR2032)
Button Cell Lithium
Battery (Included)
he s
crew and
bat
ter
M
ill
ion
™
es
V
(C
R2032)
Ce
ll
Lit
hiu
m
m
c
lud
ed)
TI
ON
S
DA
TA
C
H
MA
M
Y NOT
BE
C
yo
u
to
o
io
n?
Automatically syncs
to smart device
Contains button or coin cell battery. Hazardous if swallowed - see instructions.
WARNING:
COVER
COIN
+
CR2032
+
CR2032
USE COIN TO
TWIST COVER
2
USE COIN TO
OPEN
PULL OUT COVER
4
5
67
+
-
CR2032
REMOVE THE SCREW
PULL OUT
BATTERY COVER
INSTALL 3V (CR2032)
BATTERY
REPLACE BATTERY
©2018 and manufactured for / fabriqué pour
JAKKS PACIFIC, INC., 2951 28TH ST., SANTA MONICA, CA 90405 USA.
® and/et™ designate U.S. trademarks of / désignent les marques déposées de JAKKS Pacific.
Other trademarks used under license / Autres marques déposées utilisées sous licence.
MADE IN CHINA. FABRIQUÉ EN CHINE.
Imported into / Importé dans EU by JAKKS Pacific (UK) Ltd., 1 Arlington Square, Downshire
Way, Bracknell, Berkshire RG12 1WA, GB and JAKKS Pacific Germany GmbH, Lindenstraße
26a, D-91126 Schwabach, DE.
www.jakks.com www.jakks.com/warranty consumers@jakks.com
North America / Amérique du Nord: 1.877.875.2557 or 1.909.594.7771
United Kingdom / Royaume-Uni: 00.44(0)1344.638909
Colors & decoration may vary. Retain packaging/instructions for reference. / Les couleurs et le
décoration peuvent varier par rapport aux illustrations. Conserver l'emballage/instructions pour
toute référence.
Remove all packaging before giving toy to child. Enlever le jouet de l’emballage avant de le
donner à un enfant.
Contient une pile bouton. Danger en cas d'ingestion (voir consignes).
ATTENTION:
BATTERY SAFETY INFORMATION
• This product contains a Button or Coin Cell Battery.
• A swallowed Button or Coin Cell Battery can cause internal chemical burns in as little as
two hours and lead to death. Due to chemical burns and potential perforation of the
esophagus.
• Dispose of used batteries immediately, Flat/drained batteries can still be dangerous
• Keep new and used batteries away from children.
• If you think batteries might have been swallowed or placed inside any part of the body,
seek immediate medical attention.
• If you suspect your child has swallowed or inserted a button battery immediately call the
Poisons Control hotline and seek immediate medical attention.
• Examine devices and make sure the battery compartment is correctly secured, e.g. that
the screw or another mechanical fastener is tightened. Do not use if compartment is not
secure.
• Tell others about the risk associated with button batteries and how to keep their children
safe
WARNING: Battery acid leakage can cause personal injury and cause damage to the
product and surrounding property. If battery leakage occurs, thoroughly wash any affected
skin, making sure to keep battery acid away from eyes, ears, nose and mouth. Immediately
wash any clothing or other surface that comes in contact with leaked battery acid. Leaking
batteries may make "popping" sounds. Dispose according to Local, State or Federal Battery
Laws.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
TO AVOID BATTERY PROBLEMS:
NEVER dispose of batteries in fire, as they may leak and explode.
ALWAYS remove exhausted batteries from toy.
ALWAYS have an adult install batteries consistent with installation instructions.
ONLY use batteries specified by manufacturer.
Batteries are to be inserted with the correct Polarity.
The supply terminals are not to be short-circuited.
Non-rechargeable batteries are not to be recharged.
Rechargeable batteries are to be removed from the toy before being charged.
Rechargeable batteries are only to be charged under adult supervision.
WARNING:
CONSIGNES DE SÉCURITÉ CONCERNANT LES PILES
• Ce produit contient une pile bouton.
• Si elle est avalée, une pile bouton peut, en deux heures à peine, causer la perforation de
l’œsophage et des brûlures chimiques internes fatales.
• Jeter les piles usagées immédiatement selon les règlements de collecte en la matière.
Même mortes, les piles peuvent être dangereuses.
• Garder les piles neuves et usagées hors de la portée des enfants.
• Si vous pensez que des piles aient pu être avalées ou pénétrer le corps, consulter un
médecin d’urgence.
• Si vous pensez que votre enfant a avalé une pile bouton ou que celle-ci a pénétré son
corps, appelez immédiatement le centre antipoison et procurez-vous de l'aide médicale
d'urgence.
• Examiner les appareils et vérifier que le compartiment des piles soit correctement fermé,
avec la vis ou tout autre attache mécanique bien serrées. Ne pas utiliser si le
compartiment des piles n’est pas hermétiquement fermé.
• Expliquer à son entourage le risque associé à l’utilisation de piles boutons et les mesures
à suivre pour assurer la sécurité des enfants.
ATTENTION : Une fuite d’acide des piles peut causer des blessures et endommager le
produit et les objets alentour. Si la pile coule, laver soigneusement la peau aux endroits
affectés en veillant à ce que l'acide de la pile ne rentre pas en contact avec les yeux, les
oreilles, le nez ou la bouche. Laver immédiatement tout vêtement ou autre surface
contaminée. Les piles peuvent émettre des petits bruits secs quand elles coulent. Éliminer
les piles selon les règlements en la matière.
Cet appareil est conforme à la section 15 des règlements de la FCC. Son fonctionnement
est sujet aux deux conditions suivantes :
(1) Il ne doit pas causer de brouillage nuisible et
(2) doit accepter tout brouillage reçu, y compris tout brouillage qui pourrait nuire à son
fonctionnement.
ATTENTION : Toute modification ou altération apportée à cet appareil sans autorisation
expresse de la partie responsable de sa conformité peut révoquer le droit à son utilisation.
REMARQUE : Cet appareil a fait l’objet de tests et a été jugé conforme aux limites
d'appareils numériques de classe B, selon la section 15 des règlements de la FCC. Ces
limites ont été établies afin de fournir une protection raisonnable contre les brouillages
préjudiciables dans le cadre d’une configuration à usage privatif. Cet appareil génère,
utilise et peut irradier de l’énergie de fréquences radioélectriques. S'il n'est pas utilisé selon
les directives d'emploi, il peut causer un brouillage nuisible aux communications
radioélectriques. Néanmoins, il n’est fait aucune garantie que ces perturbations ne
surviendront pas dans une situation particulière. Si cet appareil cause des perturbations
radioélectriques nuisibles dans la réception de la télévision ou de la radio, ce qui peut être
déterminé en allumant et éteignant l’appareil, il est recommandé que l'utilisateur essaye de
corriger le brouillage en suivant une ou plusieurs de ces mesures :
- Réorienter ou déplacer l’antenne de réception.
- Accroître la distance entre l’appareil et le récepteur.
- Brancher l’appareil dans une prise de circuit différent de celui sur lequel le récepteur est
branché.
- Consulter le revendeur ou un technicien agréé radio/télévision.
CAN ICES-3(B) / NMB-3(B)
POUR ÉVITER TOUT PROBLÈME AVEC LES PILES :
NE JAMAIS incinérer les piles ; elles pourraient couler et exploser.
TOUJOURS retirer les piles mortes du jouet.
TOUJOURS confier l’installation des piles à un adulte et suivre les consignes d’installation.
UNIQUEMENT utiliser les piles indiquées par le fabricant.
Installer les piles selon les indications de polarité.
Ne pas court-circuiter les bornes.
Ne pas recharger des piles non rechargeables.
Les piles rechargeables doivent être retirées du jouet avant d’être rechargées.
La recharge des piles rechargeables ne doit se faire que sous la surveillance d’un adulte.
ATTENTION :
PATENT PENDING
TRACK YOUR BOUNCES
AND SEE WHERE YOU RANK IN THE WORLD
This device complies with FCC’s radiation exposure limits set forth for an
uncontrolled environment.
REVERSE
COVER
