Jakks Pacific 97036RX MXS RC Pro Stunt Bike User Manual 97036 Instruction Test
Jakks Pacific (HK) Ltd. MXS RC Pro Stunt Bike 97036 Instruction Test
User Manual.pdf
ADDITIONAL INFORMATION
ON OFF
ON OFF
ON OFF ON OFF
INSTRUCTIONS
CONTENTS
USING YOUR MXS REMOTE CONTROL SUPER STUNT BIKE
1. Turn the Transmitter power switch to the “ON” position.
2. Turn the power switch located on the right front side of the Stunt Bike to the “ON” position.
3. When the Stunt Bike and Transmitter are turned on, the power light on the Transmitter will flash to sync with the Stunt Bike. When the power
light stops flashing and turn off, the sync is complete.
4. When you push buttons, the power light will turn on.
HOW TO DRIVE
DRIVING FORWARD STARTING FROM A LEANING POSITION
1. Hold the seat of the Stunt Bike and give the Transmitter
forward throttle.
2. As the rear wheel speeds up, place the Stunt Bike on the
ground and give it a gentle push forward.
Note: Works on the rough surface. When performance
diminishes, replace with fresh batteries.
1. If the Stunt Bike stalls or slows down enough to lean on one of the stabilizer
wheels, increase the throttle, and it will drive toward the direction it is leaning.
2. As it drives in circles, steer the Stunt Bike in the opposite direction of the
circle to go straight again.
Forward Left
Stabilizer Wheel
Right
TRANSMITTER
· NEVER drive near traffic, buildings, trees, people, animals or other obstructions.
· NEVER operate during weather storms of other adverse weather conditions.
· NEVER touch the rear wheel or pick up Stunt Bike while it is in motion.
· ALWAYS point away from face, eyes, people, animals and property while driving.
· ALWAYS keep fingers, hair and eyes away from Stunt Bike's wheels while it is in the "ON" position.
· ALWAYS use alkaline batteries only.
Requires 4 AA (LR6) alkaline batteries
(not included).
1. Locate Battery Compartment
on the underside of the Stunt
Bike. Using a Phillips Head
screwdriver, remove the screw
and lift away the Battery Cover.
3. Holding onto the center wall,
remove the Battery Hub.
1. Locate Battery
Compartment on the
bottom of the
Transmitter.
2. Using a Phillips Head
screwdriver, remove
the screw and lift away
the Battery Cover.
Requires 2 AA (LR6) alkaline
battery (not included) 3. Install the battery,
as shown.
4. Replace the Battery
Cover and the
screw.
4. Install fresh
batteries into
the Battery
Hub, making
sure they are
aligned as
shown.
5. Replace the Battery Hub with its
contacts facing the front wheel of
the Stunt Bike. Replace the Battery
Cover and the screw.
Battery Hub Contacts
2. If replacing batteries,
remove old batteries
before pulling out the
Battery Hub.
Power Switch
Power Light
Power Switch
Battery
Compartment
Throttle
Steering
Battery Compartment
(1) TRANSMITTER (97036TX)
BATTERY INSTALLATION Adult Installation Required
STUNT BIKE
Important Safety Information
Item No.:
Description:
Color(s):
Dimension (Width x Height x Depth):
Primary Display Panel (PDP) Size:
Product Line:
Studio:
Customer: Vendor:
Road Champs_MXS
HK - In House
Kid Toys
MXS_RC Stunt Bike - Instruction Sheet
210mm(W) x 297mm(H)
480mm(W) x 380mm(H)
97036
Version: US Revision: 01
Minimum Packaging Spec.:-
Coating:
Black only
210mm
297mm
210mm
297mm
TM & © 2016 MANUFACTURED BY JAKKS PACIFIC, INC., 2951 28TH STREET, SANTA MONICA, CA 90405 U.S.A. MADE IN CHINA.
Contents may vary in style, color, shape and decoration from images shown on package or in advertising. Questions or comments? www.jakks.com,
consumers@jakks.com, or 1-877-875-2557 in North America. Retain packaging since it contains important information. ATTENTION! Remove and
discard packaging ties and fasteners before giving toy to child.
97036 R-1
Doubled Sided Printing
10 Mar. 2017
MXS REMOTE CONTROL SUPER STUNT BIKE
®
(1) MXS RC STUNT BIKE AND RIDER (97036RX)
®
CAUTION:
ADULT SUPERVISION REQUIRED
ALWAYS PLAY IN SAFE SURROUNDINGS,
AWAY FROM STREETS OR MOVING VEHICLES.
®
REQUIRED BATTERIES:
- RC Stunt Bike: 4 “AA (LR6)” Alkaline batteries
- Transmitter: 2 “AA (LR6)” Alkaline battery
To steer left, push left
on the steering.
To steer right, push
right on the steering.
MOTO XTREME SPORTS
5+
JAKKS Pacific® Battery, Solar or Electrically-Operated Product 90 DAY LIMITED WARRANTY
Thanks for purchasing a great JAKKS Pacific® product! Please immediately register your product online
at www.jakks.com/warranty. Registration is not required for the effectiveness of this limited warranty.
IMPORTANT NOTICE TO CONSUMER:
This 90 DAY LIMITED WARRANTY applies to the original product purchaser, provided the product:
1) was purchased from an authorized JAKKS™ distributor/dealer/retailer, and 2) is returned at your
expense, postage pre-paid and insured, along with the original dated sales receipt to the address noted
below. Please save a copy of your original sales receipt, as the original receipt will not be returned to
you.
If you return the product to us without the original dated sales receipt, this warranty coverage will not
apply. If the product is determined by JAKKS to be defective and returned to JAKKS within the 90 day
warranty period, we will (at our option) repair or replace it. Return shipment to you may take up to 6
weeks, depending upon your location. If your product is repaired or replaced, it will be warranted for the
longer of the original warranty or for 30 days after warranty service.
SCOPE OF LIMITED WARRANTY: The product is warranted to be: a) tested and inspected before
shipment, and b) free of defects in material and workmanship for 90 days from date of purchase. If a
covered defect occurs within the warranty period, then at our sole option, we will repair or replace the
product or provide you with another product of equal value.
WHAT IS NOT COVERED BY LIMITED WARRANTY:
THIS WARRANTY IS VOID IF THE PRODUCT HAS BEEN MODIFIED OR REPAIRED BY USER OR
OTHERS OR IF IT HAS BEEN DAMAGED AS A RESULT OF ACCIDENT, IMMERSION IN WATER,
NEGLECT, ABUSE, MISUSE, BATTERY LEAKAGE, IMPROPER BATTERY INSTALLATION,
UNAUTHORIZED SERVICE, LOSS OF PARTS, WEATHER, ACTS OF GOD, ANY ACTION OR
OMISSION WHICH CONSTITUTES A DEVIATION FROM THE OPERATING INSTRUCTIONS, OR ANY
OTHER CAUSES NOT ARISING OUT OF DEFECTS IN WORKMANSHIP OR MATERIALS.
EXCLUSIONS FROM LIMITED WARRANTY: THIS WARRANTY IS EXCLUSIVE OF AND IN LIEU OF
ALL OTHER EXPRESS OR IMPLIED WARRANTIES RELATED TO THIS PRODUCT, INCLUDING ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
SPECIAL, INCIDENTAL AND CONSEQUENTIAL DAMAGES ARISNG FROM POSSESSION, USE, OR
MALFUNCTION OF THIS PRODUCT ARE EXCLUDED BOTH FOR PROPERTY DAMAGE AND
PERSONAL INJURY TO THE EXTENT LEGALLY PERMITTED.
ADDITIONAL LEGAL RIGHTS: This warranty provides specific legal rights. You may have other or
different rights in your state or country.
QUESTIONS OR COMMENTS: If you experience product difficulties or have questions or comments,
you may contact our Consumer Relations department as follows:
Phone: 877-875-2557 (toll-free, North America only) or 909-594-7771 (Monday-Friday, 7:30AM-4:30PM
Pacific/ GMT -8).
Mail: JAKKS Consumer Relations, 21749 Baker Parkway, Walnut, California USA 91789.
Email: consumers@jakks.com
WHEN WRITING TO US: Please include: 1) product name; 2) item number; 3) purchase date;
4) description of the problem being experienced; and 5) your name, address and phone number.
Additionally, if eligible under the warranty and so advised by JAKKS Consumer Relations, also include the
defective product and the ORIGINAL dated sales receipt evidencing product purchase. Please retain a
copy of your receipt.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter dout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
TO AVOID BATTERY PROBLEMS:
• NEVER mix old and new batteries or different brands of batteries.
• NEVER mix alkaline, standard (carbon-zinc), rechargeable (nickel-cadmium)
batteries with this product.
• NEVER dispose of batteries in fire, as they may leak and explode.
• ALWAYS remove exhausted batteries from toy.
• ALWAYS have an adult install batteries consistent with installation instructions.
• ONLY use batteries specified by manufacturer.
• Batteries are to be inserted with the correct Polarity.
• The supply terminals are not to be short-circuited.
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the toy before being charged.
• Rechargeable batteries are only to be charged under adult supervision.
BATTERY SAFETY INFORMATION
WARNING! Battery acid leakage can cause personal injury and cause
damage to the product and surrounding property. If battery leakage occurs,
thoroughly wash any affected skin, making sure to keep battery acid away from
eyes, ears, nose and mouth. Immediately wash any clothing or other surface that
comes in contact with leaked battery acid. Leaking batteries may make “popping”
sounds. Dispose according to Local, State or Federal Battery Laws.
To increase speed
and move Stunt Bike
forward, push forward
on the throttle.
