USER GUIDE
BLUEBUDS X PREMIUM BLUETOOTH EARBUDS (BBX1)
IN THE BOX
BlueBuds X Bluetooth Headphones
JayBird Carry Case
3 pairs eartips (S,M,L)
3 pairs ear cushions (S,M,L)
2 cord management clips
USB Cable
User Manual
CHARGING
Charging the battery before use is recommended
but not required. BlueBuds X ships pre-charged
however initial charge will vary.
Look for this Bluetooth headset battery status
icon top right corner of your iPhone screen to
see status of BlueBuds X battery.
PAIRING (SETTING UP) HEADPHONES WITH YOUR PHONE / MUSIC DEVICE
1. With headphones turned off, & within 1 meter (3 feet) of music device, press & hold
center key for more than 4 seconds until you see alternating red/green flashing
of the status indicator and a voice prompt saying “Searching for your music device”.
2. On your phone/music device, turn Bluetooth on & have it search for Bluetooth devices
(see instructions in the phone/music device manual for details).
3. Check for “BlueBuds X” and select (enter passcode 0000 if prompted).
4. BlueBuds X voice prompt will say “headphones connected”.
5. If the pairing is not successful, switch off headphones by pushing the center key for
more than 4 seconds and repeat the steps outlined above.
PAIRING WITH A BLUETOOTH ADAPTER
1. Place headphones and mobile phone within 1 meter (3 feet) of each other.
2. Put the headphones into pair mode as outlined on prior page.
3. If using BAU Universal Bluetooth Adapter put into pair mode also (see BAU manual).
4. Plug the Bluetooth adapter into the music device and play a song.
5. The headphones and adapter will pair automatically
(passcode of adapter must be 0000).
6. After successful pairing and connecting, the headphones will say
“Headphones connected”.
PAIRING WITH SEVERAL BLUETOOTH DEVICES
Paired devices will remember each other unless pairing information is deleted,
so there is no need to pair again. BlueBuds X can pair and remember 8 phone/music
devices. Repeat the steps outlined on prior pages to set-up your headphones with
another phone/music device. Note that if a 9th phone/music devices is paired the
oldest pairing information is deleted. BlueBuds X will connect with the latest connected
device. If you want to use another paired phone/music device, switch off the Bluetooth
function of the current Bluetooth device, and then connect it with the other
phone/music device by selecting “BlueBuds X” in the Bluetooth device list and
press connect. Turn the originally paired device back on to reconnect and switch
between either of the devices.
Bluetooth Version V2.1 + EDR (newer versions offer no benefits for headphones)
SBC codec Customised SBC codec offers high fidelity without needing APT-X
Profile Handsfree v1.6, Headset v1.1, A2DP v1.2 and AVRCP v1.4
Effective Range 10 meters (30 feet)
Working time Music & calls up to 8 hours
Standy time Up to 250 hours
Input voltage DC 5V 100mA
Charging time Approximately 2 hours
Dimensions 23 x 13 mm earbud size, 540 mm cord length
Weight Approx 13 g
WARRANTY, CARE & MAINTANCE
Full warranty, care and maintenance details at jaybirdgear.com/warranty
+1.866.244.3399
WARNING: Due to the isolating characteristics of these headphones do not use while driving, riding a bike or where vehicular traffic
is present, or in any other activity where failure to hear surrounding sounds could be dangerous. Use of these headphones at
excessive volumes may cause permanent hearing damage. Always turn the volume down before use. Take caution in regards to
inserting objects into ear canal, use at own risk.
Copyright 2012 JayBird, LLC. All rights reserved. JayBird, and the JayBird logo are trademarks of JayBird, LLC.
Bluetooth is a trademark owned by Bluetooth SIG, Inc. USA, and licensed to JayBird, LLC. iPhone is a trademark of Apple, Inc., registered
in the U.S. and other countries. Manufactured under European patent no EP1410607B1 & corresponding foreign patents
.
Assembled in China.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications to device will void the user’s authority to operate the device. The battery is recycled.
Do not dispose of the battery in fire, as it may cause explosion.
SPECIFICATIONS
LED STATUS
Red: Charging
Green (with USB cable connected): Charged
Red+Green Alternating: Pair Mode
No Light: Standby / Play Mode / Powered Off
VOICE PROMPT
“BATTERY LOW”
Repeated regularly
15 mins prior to empty
MICRO USB CHARGING
Locate fingernail recess
and remove back cover to
expose micro USB charge
point. 2+ hrs for full charge
gives 8 hours of playtime.
30 mins charging gives
90 minutes of play time.
ARE HEADPHONES ON? IS BATTERY LOW?
In Standby* mode, push + or -, watch LED:
Green = Powered on and well charged
Red = Low battery
No Light = Powered off
* Standby Mode:
Powered on but not connected to any device
PAIR MODE: LED ALTERNATES RED/GREEN
LISTEN RESPONSIBLY
Avoid excessive volume levels
and prolonged periods of listening.
Do not use around road traffic.
HAVE FUN
HOLD
4 SEC
TO
PAIR
VOICE PROMPT:
When you hear “Power on” continue pushing until you hear
“SEARCHING FOR YOUR MUSIC DEVICE ...”
TAKE A MOMENT TO REGISTER YOUR
LIFETIME WARRANTY AGAINST SWEAT
jaybirdgear.com/intheclubnow
COMMANDS
Add’l Center Button Call Commands
PUSH 1 SEC PUSH 4 SEC PUSH
ON
OFF
Answer 2nd call, end call
Reject 1st/2nd call, switch
between 2 calls, voice dial
Redial
Mute & unmute call: push + & -
Switch active call to BlueBuds X: push -
FCC ID:XX8BBX1
