User Manual
Wireless Stereo Headphone
User’s Manual
Features:
● Automatically reconnects with the last connected Bluetooth device.
● Rechargeable battery provides up to 5 hours of continuous playback.
● Built-in on-ear controls let you control your music,adjust the volume,and answer calls
● Plug the micro USB cable into the micro USB port, and connect the other end of the
cable to either a computer USB port or to a USB - compatible car or wall charger.
● Solid red LED light will appear on the power button to indicate when the headphone
is charging, even while headphone is turned off.
● When charging is complete, the LED light will turn blue.
● Charging time is approximately 1-2 hours.
Charge It
Turn It On/Off
Pair & Connect With New Device
● Press & hold the power button on the right side of the headphone for about 3 seconds.
● The headphone will emit a beep , and a blue/red
LED light will flash to indicate the headphone is turning on.
● To turn the Bluetooth headphone off, press & hold the power button again for 3 seconds,
until the LED light turns off.
● Power on the Bluetooth headphone (refer to the “Turn It On/Off” section)
● The Bluetooth headphone will automatically enter pairing mode when it is
turned on. The LEDlight will start to quickly flash blue to indicate the Bluetooth is
now ready to be paired with your device.
● On your Bluetooth-enabled smartphone, tablet or media player, navigate to the
Bluetooth settings menu, turn on the Bluetooth feature, and search for new devices.
● After a few seconds you will see “Bluetooth Headphones” listed.
● Tap this model to select it. The headphone will emit a beep and the Bluetooth LED
will slowly flash blue while it is paired with the device.
Press & Hold (3 Sec):Power On/Off
When powered on, pairing mode is automatically entered
Click Once:Play/Pause,Answer/End Calls
Double Click: Re-dial Last Dialed Phone Number
Press & Hold (1-2 Sec):Reject Incoming Call
Press & Hold (up to 3 Sec) Bluetooth will power off
Play
Reconnect to Bluetooth
● Connect your device via Bluetooth (refer to the “Pair & Connect” section)
● Open your favorite music app and press play.
● Control the music, track & volume from your device, or control the music & volume
from the on-ear touch controls.
● Press the Power button once to play/pause music & answer calls, press it twice to
redial the last number called on your phone, and press & hold (1-2 sec)
to reject an incoming call.
● The headphone will automatically reconnect to the last Bluetooth device it was
connected to.
● If you have a previously paired device that does not auto-reconnect, navigate to
the Bluetooth settings menu on your device, turn on the Bluetooth feature, and
select “Bluetooth Headphones” from your list of paired Bluetooth devices.
● You can also press and hold the Play button for 3 seconds to turn off the Bluetooth.
Then, follow the directions to turn on the bluetooth and connect your
device again.
Troubleshooting
No power
Make sure your Bluetooth device has A2DP profile.
Check if both devices are paired and connected over
Bluetooth.
Recharge your Headphones using the included micro
USB cable. Try using a different micro USB cable.
Music is not playing
over Bluetooth
Navigate to your Bluetooth settings menu on your
Bluetooth device, tap “Bluetooth Headphones”, and
select “Forget”. Now follow the steps to pair your
device again. Or, press & hold the power button on the
Bluetooth to turn off Bluetooth and turn it on again.
Then follow the steps to reconnect your device.
Bluetooth device will
not reconnect with
the headphone
Headphone Specifications:
Driver Unit Size: 40mm
Frequency Response: 20Hz to 20KHz
Impedence: 32Ω
Sensitivity: 95-/+10%dB
Mic Sensitivity: 58dB±3dB
Built -in Battery: Lithium
Input: DC 5V/300mAH
Battery Capacity : 300mAH
Music playing time: Up to 5 hours*
Charging time: 1-2 Hours
Bluetooth Specification: V3.0
Operating Distance: 10 Meters (Class Ⅱ)
System Requirements: Bluetooth-capable device
Power Source: Built-in rechargeable battery or via USB cable
Battery Information:
*Approximate playback time. Battery life depends
on individual use and may be slightly more or less than the time specified.
Bluetooth Information:
Additional Connection Sources:
Increase Volume/Next Track Decrease Volume/Previous Track
Microphone
*Track, Play and Pause features do not function with Video
LED Status Light
Power ON/OFF / Pause
Changing Song Next Track : press + to go to the next track
Increasing Volume High : press + and hold to increase volume.
Changing Song Previous Track : press - to go to previous track
Decreasing Volume : press - and hold to decrease volume
Pause : Press Pause Button to Pause the Track
USER GUIDE
© Jazwares, LLC. 2016
Jazwares LLC.
1067 Shotgun Road
Sunrise, Fl. 33326
USER GUIDE
© Jazwares, LLC. 2016
Included in box:
• Wireless Headphone
• Micro USB Cable
• User Guide
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by SHENZEN LISAIER TRONICS CO.,LTD
is under license. Other trademarks and
trade names are those of their respective owners.
Compatible with most Apple iOS and Android devices
© 2016 Mattel. All Rights Reserved.
Congratulations on your purchase of the Bluetooth Headphones!
To get the most out of your Bluetooth Headphones please read this manual
as it will help explain proper usage.
IMPORTANT:
Please save this instruction sheet.
It contains valuable product information.
ITEM # 10029 - Bluetooth Headphones
Jazwares, 16A Crane Grove, London, N7 8LE, United Kingdom
www.jazwares.com
WHAT IS NOT COVERED - EXCLUSIONS & LIMITATIONS
This warranty does not apply
(a) to damage caused by accident, abuse, misuse,
misapplication, or non - Jazwares, Inc. product,
(b) to damage caused by service performed by anyone other than Jazwares, LLC.
(c) to a product or a part that has been modified without the written permission
of Jazwares, Inc.
LIMITED WARRANTY DOES NOT COVER
• Shipping charges to return defective product to Jazwares, LLC.
• Product repair and/or part replacement because of improper installation, connections
to improper voltage supply, abuse, neglect, accident, unauthorized repair or other
cause not within the control of Jazwares, LLC.
• Damage or claims for products not being available for use, or for lost data or
lost software.
• Damage occurring to product during shipping.
• A product that requires modification or adaptation to enable it to operate in any country
other then the country for which it was designed, manufactured approved and/or authorized,
or repair of products damaged by these modifications.
• Product lost in shipment and no signature verification receipt can be provided.
• Failure to operate per Owner’s Manual.
BEFORE RETURNING ANY PRODUCT, CONTACT JAZWARES, LLC. CUSTOMER SERVICE.
Customer service is available 9-6 EST at 1-800-370-1877.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY FOR THE CONSUMER. JAZWARES, LLC. SHALL NOT BE LIABLE FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY
ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
Some states do not allow exclusions or limitation of incidental or consequential damages, or allow
limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you
This warranty gives you specific legal rights. You may have other rights which vary from state to state.
This warranty is only valid in the Unites States of America.
© Jazwares, LLC.
WARRANTY COVERAGE
Jazwares, LLC.’s warranty obligation is limited to the terms set forth below.
WHO IS COVERED
Jazwares, LLC. warrants the product to the original purchaser or the person receiving
the product as a gift against defects in material & workmanship as based on the date
of the original purchase from an authorized dealer or retailer. The original sales receipt
showing the product name & the purchase date from an authorized retailer is considered
such proof.
Jazwares, LLC. warrants replacement products or parts provided under this warranty
against defects in materials & workmanship from the date of the replacement or repair
for ninety (90) days or for the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product or part is exchanged,
any replacement item becomes your property and the replaced item becomes
Jazwares, LLC. property. If a refund is granted, your product becomes
Jazwares, LLC. property.
Replacement product can only be sent if all warranty requirements are met.
Failure to follow all requirements can result in delay.
WHO IS COVERED
Jazwares, LLC. warranty covers new products if a mechanical defect arises & a
valid claim is received within the Ninety (90) Day Warranty Period. At its option,
Jazwares, Inc. will either (1) repair the product at no charge,using new or refurbished
replacement parts, or (2) exchange the product with a product that is new or which has
been manufactured from new, or serviceable used parts & is at least functionally
equivalent or most comparable to the original product in Jazwares, Inc.’s inventory.
WHAT IS NOT COVERED - EXCLUSIONS & LIMITATIONS
The limited warranty applies only to the products manufactured by or for Jazwares, LLC.
that can be identified by the trademark, trade name, or logo affixed to it. This limited
warranty does not apply to any non Jazwares, LLC. hardware product or any software,
even if packaged or sold with the product. Non Jazwares, LLC. manufacturers, suppliers,
or publishers may provide a separate warranty for their own products packaged with the
bundled product. Jazwares, LLC. is not liable for any damage to or loss of any programs,
data or other information stored on any media contained within the product, or any
non - Jazwares, LLC. product or part not covered by this warranty.
Limited Ninety (90) Day Warranty:
Warning! Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experience radio/TV technician for help.
NOTES:
FCC Warning:
IMPORTANT:
Please save this instruction sheet.
It contains valuable product information.
Frequency : 2.4GHz
FCC ID : YNIJAZWARES10029
