Jazwares JAZWARES15295 Star Wars - Mouse User Manual JAZ Mouse A4 Front V4 1

Jazwares Inc Star Wars - Mouse JAZ Mouse A4 Front V4 1

User Manual

Congratulations on your purchase of the Wireless Mouse!
We hope you enjoy all the great features of the clock. To get the
most out of your Wireless Mouse please read this manual as it
provides tips and information about its various features.
Warning:
Replacement of batteries must be done by an adult.
Do not mix old and new batteries.
Do not mix the alkaline, standard (carbon-zinc) and
rechargeable (nickel-cadmium) batteries.
The supply terminals are not to be short-circuited.
Non-rechargeable batteries are not to be recharged.
Exhausted batteries are to be removed.
Only batteries of the equivalent type are to be used.
Batteries are to be inserted with the correct polarity.
Dispose of batteries properly.
Do not dispose of batteries in fire ; batteries may explode or leak.
Only use the adapter provided by the manufacturer.
The mouse takes 2 X AAA Batteries.
• Use this only as intended.
• To prevent fire or shock hazard, do not expose this unit
to rain or moisture.
• Do not submerge the unit in any liquid
• Do not disassemble
SAFETY TIPS:
Power Supply:
Battery Information:
Battery Compartment
Nano Receiver
On/Off
Button
• Nano receiver, plug-and-play
• Wireless carrier frequency: 2402MHz-2480MHz
• Perfect ergonomic design
• Zero delay 2.4GHz & 16 channel transmitted at the same time, to
provide a linear 10 meters effective operating distance.
• Super 5 class intelligent power-saving mode, a battery can up to
more than 6 months life
• GFSK / DSSS FM automatic function, anti-interference ability is
improved more than 8 times
• 1000 dpi high precision, optical tracking engine
• USB charging function, energy saving and environmental
protection
Technical Specifications:
• Available USB Port
• Windows® XP, Vista or Higher
• Macintosh OS 10.1 or Higher
System Requirements:
• Hold the mouse on both sides of the button, the battery cover can be
opened automatically.
• Put into two AAA alkaline batteries (enclosed in the package)
• Insert the mini receiver into the computer spare USB interface,
(suggested to insert on the front of the USB interface of computer,
if need to use the back of computer USB interface, suggest to use the
extended wire connection)
• Turn the On/Off Switch to On.
The mouse is all installed, please enjoy wireless fun!
Installation Steps:
USER GUIDE
2.4 GHz Wireless Mouse
© Jazwares, Inc. 2011
2.4 GHz Wireless Mouse with Nano Receiver
2 AAA Batteries
Instruction Manual
PACKAGE CONTENTS
* NOTE : After periods of inactivity, the mouse goes into sleep mode to conserve
battery life. To wake the mouse simply move it in any direction and it should
respond on the screen.
If the mouse is not working, please follow the next steps.
• Unplug receiver from computer terminal .
Put the receiver into the distance of the mouse within 30 cm.
While holding down the mouse left & right key and the wheel button 10 seconds.
At the same time, let go, quickly insert receiver into the computer terminal.
• Check the batteries, they may need to be replaced.
• If you are still having problems, restart your PC and allow it
to load up then check the mouse.
Trouble Shooting:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by switching the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experience radio/TV technician for help.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules.
NOTES:
FCC ID: YNIJAZWARES15295
FCC ID: YNIJAZWARES13595
WARRANTY COVERAGE
Jazwares, Inc.’s warranty obligation is limited to the terms set forth below.
WHO IS COVERED
Jazwares, Inc. warrants the product to the original purchaser or the person receiving
the product as a gift against defects in material & workmanship as based on the date
of the original purchase from an authorized dealer or retailer. The original sales receipt
showing the product name & the purchase date from an authorized retailer is considered
such proof.
Jazwares, Inc. warrants replacement products or parts provided under this warranty
against defects in materials & workmanship from the date of the replacement or repair
for ninety (90) days or for the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product or part is exchanged,
any replacement item becomes your property and the replaced item becomes
Jazwares, Inc. property.
Replacement product can only be sent if all warranty requirements are met.
Failure to follow all requirements can result in delay.
WHO IS COVERED
Jazwares, Inc. warranty covers new products if a mechanical defect arises & a
valid claim is received within the Ninety (90) Day Warranty Period. At its option,
Jazwares, Inc. will either (1) repair the product at no charge,using new or refurbished
replacement parts, or (2) exchange the product with a product that is new or which has
been manufactured from new, or serviceable used parts & is at least functionally
equivalent or most comparable to the original product in Jazwares, Inc.’s inventory.
WHAT IS NOT COVERED - EXCLUSIONS & LIMITATIONS
The limited warranty applies only to the products manufactured by or for Jazwares, Inc.
that can be identified by the trademark, trade name, or logo affixed to it. This limited
warranty does not apply to any non Jazwares, Inc. hardware product or any software,
even if packaged or sold with the product. Non Jazwares, Inc. manufacturers, suppliers,
or publishers may provide a separate warranty for their own products packaged with the
bundled product. Jazwares, Inc. is not liable for any damage to or loss of any programs,
data or other information stored on any media contained within the product, or any
non - Jazwares, Inc. product or part not covered by this warranty.
Limited Ninety (90) Day Warranty:
WHAT IS NOT COVERED - EXCLUSIONS & LIMITATIONS
This warranty does not apply
(a) to damage caused by accident, abuse, misuse,
misapplication, or non - Jazwares, Inc. product,
(b) to damage caused by service performed by anyone other than Jazwares, Inc.
(c) to a product or a part that has been modified without the written permission
of Jazwares, Inc.
LIMITED WARRANTY DOES NOT COVER
• Shipping charges to return defective product to Jazwares, Inc.
• Product repair and/or part replacement because of improper installation, connections
to improper voltage supply, abuse, neglect, accident, unauthorized repair or other
cause not within the control of Jazwares, Inc.
• Damage or claims for products not being available for use, or for lost data or
lost software.
• Damage occurring to product during shipping.
• A product that requires modification or adaptation to enable it to operate in any country
other then the country for which it was designed, manufactured approved and/or authorized,
or repair of products damaged by these modifications.
• Product lost in shipment and no signature verification receipt can be provided.
• Failure to operate per Owner’s Manual.
BEFORE RETURNING ANY PRODUCT, CONTACT JAZWARES, INC. CUSTOMER SERVICE.
Customer service is available 9-6 EST at 1-800-370-1877.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY FOR THE CONSUMER. JAZWARES, INC. SHALL NOT BE LIABLE FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY
ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
Some states do not allow exclusions or limitation of incidental or consequential damages, or allow
limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you
This warranty gives you specific legal rights. You may have other rights which vary from state to state.
This warranty is only valid in the Unites States of America.
© Jazwares, Inc.
Need More Help?
Do Not Return Item to Store.
Call 1-800-370-1827 and speak to a customer service representative.
USER GUIDE
2.4 GHz Wireless Mouse
Jazwares Inc.
1067 Shotgun Road
Sunrise, Fl. 33326 © Jazwares, Inc. 2011
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following
two conditions: (1) this device may not cause harmful interference,
and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
Dongle’s FCC ID: YNIJAZWARES13595A
Warning: Change or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority operate the equipment.
