Jcast Network Korea SC-300 VEHICLE DETECTION SYSTEM (ZIGBEE) User Manual USERS MANUAL
Jcast Network Korea, Inc. VEHICLE DETECTION SYSTEM (ZIGBEE) USERS MANUAL
USERS MANUAL
Jcast’sJcast’s VDSVDS
(Vehicle Detection System)(Vehicle Detection System)
Jcast’s Vehicle Detection System(jVDS) is an AMR-based wireless sensor
that detects vehicle presence and movement, and that transmits real-time
data for many traffic management applications such vehicle speed, traffic
ldhillh
j
ill i f b
vo
l
ume, an
d
ve
hi
c
l
e
l
engt
h
.
j
VDS, v
i
rtua
ll
y ma
i
ntenance
f
ree, can
b
e
installed in minutes and deployed in an hour.
M t l tf f t ffi l hi l
Features Applications
•
M
easuremen
t
p
l
a
tf
orm
f
or
t
ra
ffi
c vo
l
ume, ve
hi
c
l
e
speed, occupancy, vehicle length, etc.
•Low-power wireless communications with SC-300
(road-side equipment)
•In-pavement installation in minutes reduces road
closures and worker exposure
•Weathe
r
-
p
roof sensor with 10-
y
ear batter
y
life
•Automatic traffic management for volume,
vehicle speed, occupancy, etc.
•Traffic signal control management
•Speed violation
•Early warning for vehicles approaching to
key sensitive facilities
p
yy
•Superior accuracy, dependability, and extensibility
•Self-calibrating, self-tuning
•Re-usable and remotely upgradeable
key
sensitive
facilities
•Warning for car accidents in tunnels
•Road weather information such as icing.
TWSN
Multi-Sensor
Zigbee
C
/
Btt
uRSE
Sensor controller
Zigbee Wi-Fi
CAM
E/
PE
TWIS
Acquisition / Control
Wi-Fi NMS
DB/WEB/GIS/USN
C
ase
/
B
e
tt
ery
CAM
E
nc
/
P
o
E
DB
/
WEB
/
GIS
/
USN
ISO 9001 2000 CO-2837/08C
ISO 14001 2004 CE-2837/08C
Jcast Networks Korea, Inc
268, Hagui-ro, 605, (Gwanyang-dong, Anyang MegaValley)
Dong-an-gu Anyang-si, Gyeonggi-do, Korea, 431-767
TEL. +82-31-476-6997~8 FAX. +82-31-476-6930 Http://www.jcast.co.kr
Jcast’sJcast’s VDSVDS
(Vehicle Detection System)(Vehicle Detection System)
Product Specification
TWSNTWSN (Traffic(Traffic andand WeatherWeather SensorSensor Node)Node) uRSEuRSE (ubiquitous(ubiquitous RoadRoad SideSide Equipment)Equipment)
Item Specification
Detection Method 1/3-axis magnetic field sensing
Sampling rate 128 Hz
Protocol IEEE 802.15.4
Modulation DSSS OQPSK
Data rate 250 Kbps
Item Specification
CPU ARM11
O/S Embedded Linux 2.6.29
Memory 128MB
Interface
IEEE 802.15.4 / IEEE 801.16e
10/100 Base-T Ethernet
Wi
-
Fi
(
801
11
a/b/g/n)
Frequency Band 2,400 to 2,438.5 MHz
Channel 16
Channel Band 5MHz
Nominal output power 0dBm
Rx sensitivity -95 dBm (PER = 1%)
Power
Supply
More
than
Support(
nominal
capacity)
Wi
-
Fi
(
801
.
11
a/b/g/n)
Option : IP Camera Support(H.264)
Per-vehicle data
processing
Initial vehicle detect time, Gap, Speed,
Length, Vehicle classification
Dection Accuracy 95% or better
Speed Accuracy 95% or better
Occupancy 90% or better
Power
Supply
More
than
Support(
nominal
capacity)
Dimensions / Weight 90mm * 90mm * 8.5 AH / 500g
Ingress Protection IP 68
Operation Temp. -40℃ to 70℃
Input voltage PoE, 36-58 VDC(48 VDC nominal), 12 VDC
Dimensions / Weight 165mm * 220mm * 50mm / 1000g
Ingress Protection Designed for weatherproof, outdoor, operation
Operation Temp. -10℃ to 60℃
TWISTWIS ((TrafficTraffic andand WeatherWeather InformationInformation System)System)
Item Specification
CPU Dual-core Intel or compatible 2.4 GHz,
1MB cache, 800MHz front side bus
Memory / HDD 2.0GB / 750GB, Onboard SATA
Network 10/100/1000 BT-Ethernet
Protocol TCP/IP, SNMP, HTTP, SOAP, SDP, S니,
DDNS, NTP, ARP, RARP, DHCP
Database MYSQL 5
Traffic data Occupancy, Volume, Speed, Len Length, Gap
Media DVD-ROM drive
OS Windows server group
GUI Flex3, Web, PHP5, GoogleMAP
Report types HTML,PNG,Text,CSV,XLS
ISO 9001 2000 CO-2837/08C
ISO 14001 2004 CE-2837/08C
Jcast Networks Korea, Inc
268, Hagui-ro, 605, (Gwanyang-dong, Anyang MegaValley)
Dong-an-gu Anyang-si, Gyeonggi-do, Korea, 431-767
TEL. +82-31-476-6997~8 FAX. +82-31-476-6930 Http://www.jcast.co.kr
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference. and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Caution
Any changes or modifications (including the antenna) made to this device that are not
expressly approved by the manufacturer may void the user’s authority to operate the
equipment.
