Jens Electric Co SZJENSMWOC20L1 Microwave Oven User Manual WP700D S20
Shenzhen Jens Electric Co Ltd Microwave Oven WP700D S20
Contents
- 1. WP700D N20 user manual
- 2. WP700D S20 user manual
WP700D S20 user manual
20
Litre
Electronic
Microwave
Owner
s
Instruction
Manual
WP700D-S20
Read
the
Instructions
carefully
and
Keep
for
Future
Reference
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
- WARNING: when the appliance is operated in the combination mode,
children should only use the oven under adult supervision due to
the temperatures generated;
- WARNING: if the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person;
- WARNING: it is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the removal
of a cover which gives protection against exposure to microwave
energy;
- WARNING: liquids and other foods must not be heated in sealed
containers since they are liable to explode
- WARNING: Only allow children to use the oven without supervision
when adequate instructions have been given so that the child is
able to use the oven in a safe way and understands the hazards of
improper use;
- only use utensils that are suitable for use in microwave ovens
- when heating food in plastic or paper containers, keep an eye on the
oven due to the possibility of ignition;
- if smoke is observed, switch of or unplug the appliance and keep the
door closed in order to stifle any flames;
- microwave heating of beverages can result in delayed eruptive boiling,
therefore care must be taken when handling the container;
- the contents of feeding bottles and baby food jars shall be stirred or
shaken and the temperature checked before consumption, in order to
avoid burns;
- eggs in their shell and whole hard-boiled eggs should not be heated in
microwave ovens since they may explode, even after microwave
heating has ended;
- the oven should be cleaned regularly and any food deposits removed;
- failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation;
- if the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a
hazard.
- The temperature of accessible surfaces may be high when the appliance
is operating.
-2-
SPECIFICATIONS
Power consumption:
Output:
Operating Frequency:
Outside Dimensions:
Oven Cavity Dimensions:
Oven Capacity:
Uncrated Weight:
120V~60Hz,1080W
700W
2,450MHz
454mm(W) X 330mm(D) X 262mm(H)
315mm(W) X 296mm(D) X 211mm(H)
20litres
Approx. 10.5kg
BEFORE
YOU
CALL
FOR
SERVICE
If the oven will not perform at all, the display does not appear or the display disappears:
a) Check to ensure that the oven is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds and
plug it in again securely.
b) Check the premises for a blown circuit fuse or a tripped main circuit breaker. If these seem to be operating properly,
test the outlet with another appliance.
2. If the microwave power does not function:
a) Check to see whether the timer is set.
b) Check to make sure that the door is securely closed to engage the safety interlocks. Otherwise, the microwave
energy will not flow into the oven.
IF
NONE
OF
THE
ABOVE
RECTIFIES
THE
SITUATION,
THEN
CONTACT
THE
AUTHORIZED
SERVICE
AGENT.
Note:
The
appliance
is
for
household
use
for
heating
food
and
beverages
using
electromagnetic
energy
and
for
indoor
use
only.
RADIO
FREQUENCY
INTERFERENCE BTATEMENT
Microwave
oven
may
cause
interference
to
your
radio,
TV,
or
similar
equipment.
When
interference
occurs,
it
may
be
eliminated
or
reduced
by
the
following
procedures.
a.
Clean
the
door
and
sealing
surface
of
the
oven.
b.
Place
the
radio,
TV,
etc.
as
far
away
from
your
microwave
oven
as
possible.
c. Use a properly installed antenna for your radio, TV, etc. to get a strong signal reception.
INSTALLATION
1. Make sure all the packing materials are removed from the inside of the door.
2. Inspect the oven after unpacking for any visual damage such as:
Misaligned Door
Damaged Door
Dents or Holes in Door Window and Screen
Dents in Cavity
If any of the above are visible, DO NOT use the oven.
3. This Microwave Oven weights 10.5Kg and must be placed on a horizontal surface strong enough to
support this weight.
4. The oven must be places away from high temperature and steam.
5. DO NOT place anything on top of the oven.
6. DO NOT remove the turn-table drive shaft.
7. As with any appliance, close supervision is necessary when used by children.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape Wire for the electric current. This appliance is equipped with a cord
having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded.
WARNING – Improper use of the grounding can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if
doubt exists as to whether the appliance is properly grounded, and either:
I ) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding
plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension
cord shall be equal to or greater than the electrical rating of the appliance, or
2) Do not use an extension cord. If the power supply cord is too short, have a qualified electrician or
serviceman install an outlet near the appliance.
a) A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping
over a longer cord.
b) Longer cord sets or extension cords are available and may be used if care is exercised in their use.
c) If a long cord or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical
rating of the appliance;
2) The extension cord must be a grounding-type 3-wire cord; and
3) The longer cord should be arranged so that it will not drape over the counter top or tabletop where it can
be pulled on by children or tripped over unintentionally.
CAUTION: This oven is protected internally by a 125/250V, 20Amp Fuse.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains leads of the appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is
marked with the letter E or by the earth symbol coloured green of green-and-yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or
coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L
or coloured red.
IMPORTANT SAFETY INSTRUCTIONS
-WARNING: When the appliance is operated in the combination mode, children should only use the oven
under adult supervision due to the temperatures generated; (Only for the model with grill function)
-WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired
by a competent person;
-WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair
operation that involves the removal of a cover which gives protection against exposure to microwave energy;
-WARNING: liquids and other foods must not be heated in sealed containers since they are liable to explode.
-WARNING: Only allow children to use the oven without supervision when adequate instructions have been
given so that the child is able to use the oven in a safe way and understands the hazards of improper use;
- The oven must have sufficient air flow.Keep 10 cm space at back;15 cm at both sides and 30cms from top
of the oven.Don't remove oven's feet, do not block air events of the oven.
- Only use utensils that are suitable for use in microwave ovens.
- When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition;
- If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any
flames;
- Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when
handling the container;
- The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns;
- Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may
explode, even after microwave heating has ended;
- When cleaning surfaces of door, door seal, cavity of the oven, use only mild, nonabrasive soaps, or
detergents applied with a sponge or soft cloth.
- The oven should be cleaned regularly and any food deposits removed;
- Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly result in a hazardous situation;
- If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
- The temperature of accessible surfaces may be high when the appliance is operating.
SAFETY INSTRUCTIONS FOR GENERAL USE
Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from
this oven:
1. Always have the glass tray, roller arms, coupling and roller track in place when operating the oven.
2. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any
other nonfood items, or for sterilizing purposes.
3. Do not operate the oven when empty. This could damage the oven.
4. Do not use the oven cavity for any type of storage, such a papers, cookbooks, etc.
5. Do not cook any food surrounded by a membrane, such as egg yolks, potatoes, chicken livers, etc without first
being pierced several times with a fork.
6. Do not insert any object into the openings on the outer case.
7. Do not at any time remove parts from the oven such as the feet, coupling, screws, etc.
8. Do not cook food directly on the glass tray. Place food in/on proper cooking utensil before placing in the oven.
9. IMPORTANT-COOKWARE NOT TO USE IN YOUR MICROWAVE OVEN
Do not use metal pans or dishes with metal handles.
Do not use anything with metal trim.
Do not use paper covered wire twist-ties on plastic bags.
Do not use melamine dishes as they contain a material which will absorb microwave energy. This may cause the
dishes to crack or char and will slow down the cooking speed.
Do not use Centura Tableware. The glaze is not suitable for microwave use. Corelle Livingware closed handle
cups should not be used.
Do not cook in a container with a restricted opening, such as a pop bottle or salad oil bottle, as they may
explode if heated in a microwave oven.
Do not use conventional meat or candy thermometers.
There are the thermometers available specifically for microwave cooking. These may be used.
10. Microwave utensils should be used only in accordance with manufacturer's instructions.
11. Do not attempt to deep-fry foods in this oven.
12. Please remember that a microwave oven only heats the liquid in a container rather than the container itself.
Therefore, even though the lid of a container is not hot to the touch when removed from the oven, please
remember that the food/liquid inside will be releasing the same amount of steam and/or spitting when the lid is
removed as in conventional cooking.
13. Always test the temperature of cooked food yourself especially if you are heating or cooking food/liquid for
babies. It is advisable never to consume food/liquid straight from the oven but allow it to stand for a few minutes
and stir food/liquid to distribute heat evenly.
14. Food containing a mixture of fat and water, e.g. stock, should stand for 30-60 seconds in the oven after it has
been turned off. This is to allow the mixture to settle and to prevent bubbling when a spoon is placed in the
food/liquid or a stock cube is added.
15. When preparing/cooking food/liquid and remember that there are certain foods, e.g. Christmas puddings, jam
and mincemeat, which heat up very quickly. When heating or cooking foods with a high fat or sugar content do
not use plastic containers.
16. Cooking utensil may become hot because of heat transferred from the heated food. This is especially true if
plastic wrap has been covering the top and handles of the utensil. Potholders may be needed to handle the
utensil.
17. To reduce the risk of fire in the oven cavity:
(a)Do not overcook food. Carefully attend microwave oven if paper, plastic, or other combustible materials are
placed inside the oven to facilitate cooking.
(b)Remove wire twist-ties from bags before placing bag in oven.
(c)If materials inside the oven should ignite, keep oven door closed, turn the oven off at the wall switch, or shut
off power at the fuse or circuit breaker panel.
18. This appliance is not intend for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
19. Children should be supervised to ensure that they do not play with the appliance.
20. Save these instructions.
FEATURE
DIAGRAM
5
3
6
(1)
Door
Safety
Lock
System
(2)
Oven
Window
(3)
Oven
Air
Vent
(4)
Roller
Ring
4
(5)
Glass
Tray
1
1
2
(6)
Control
Panel
CONTROL PANEL
OPERATION INSTRUCTION
1.SIMPLE COOKING
You only need press "START/RESET
"
to start cooking for 1 min with 100% microwave power. Each press
means increasing one minute cooking time, the maximum time is 30 min. After cooking finished you will sound
five beeps for remind.
Press and hold the "Start/Reset" for 2 seconds to stop.
2.MICROWAVE COOKING
(A) Fast cooking method
(For example: Select 100% power to cook foods for 5 minutes.)
a) Set the time "5:00"
b) Press "START/RESET" button
(B) Control by hand
(For example: Select 70% power to cook foods for 10 minutes)
a) Press "MICRO/GRILL" button to select 70% power.
b) Press time button to set cooking time "10:00"
c) Press "START/RESET" button.
You can press "MICRO/GRILL" button to select power.
Step
Display
Micro
power
1
P10
100%
2
P7
3
P5
4
P3
5
P1
70%
50%
30%
10%
3.AUTO DEFROST FUNCTION
You need to press "1Min" (1.0kg) and "10Sec" (0.1kg) according to the weight of the food.The oven can
select defrosting program and auto start defrosting.
For example: defrost 0.4kg frozen foods
1) Press "MICRO/GRILL" to choose defrost function, display "DEF".
2) Set weight "0.4kg" by pressing "1Min" and "10Sec" buttons.
3).Press "START/RESET" button.
Remark: the maximum weight is 2kgs.
4.START AND RESET
1) Open door status
Press "START/RESET" button to cancel setting or cooking program.
2) Close door status
Press "START/RESET" button to start cooking after setting cooking program.
Press "START/RESET" button to continue cooking when the cooking is in pause status.
Press "START/RESET" button to stop working when the microwave oven is operating.
5.CHILDREN SAFETY LOCK
To activate the Child Lock, press "1Min" and "10Sec" buttons at the same time for 2 seconds.After that press
any button is useless. If press "1Min" and "10Sec" button at the same time for 2 seconds again it will unlock
this function.
CARE OF YOUR MICROWAVE OVEN
1.Turn the oven off and remove the power plug from the wall socket before cleaning.
2.Keep the inside of the oven clean.When food splatters or spilled liquids adhere to oven walls,wipe with a
damp cloth.The use of harsh detergent or abrasives is not recommended.
3.The outside oven surface should be cleaned with a damp cloth.To prevent damage to the operating parts
inside the oven,water should not be allowed to seep into the ventilation openings.
4.Do not allow the Control Panel to become wet. Clean with a soft, damp cloth, Do not use detergents,
abrasives or spray-on cleaners on the control Panel.
5.If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth.This may occur
when the microwave oven is operated under high humidity conditions and in no way indicates malfunction
of the unit.
6.It is occasionally necessary to remove the glass tray for cleaning.Wash the tray in warm sudsy water or in
a dishwasher.
7.The roller ring and oven cavity floor should be cleaned regularly to avoid excessive noise.Simply wipe the
bottom surface of the oven with mild detergent,water or window cleaner and dry.The roller ring may be
washed in mild sudsy water or dish washer.Cooking vapour collect during repeated use but in no way
affect the bottom surface or roller ring wheels.
When removing the roller ring from cavity floor for cleaning,be sure to replace it in the proper position.
8.Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in a
deep microwaveable bowl. Microwave for 5 minutes,wipe thoroughly and dry with a soft cloth.
9.When it becomes necessary to replace the oven light,please consult a dealer to have it replaced.
