Jetson Electronic Technologies JET-100A WIRED BOOSTER User Manual
Shenzhen Jetson Electronic Technologies Co.,Ltd WIRED BOOSTER
User manual
Jetson Transmission Booster Operating Instructions
Models: JET-100A
1. Function
The Jetson transmission boosters function with two JETTE brand TPMS systems for trucks. Even though the basic systems
have been tested and work well up to 60 ft., there are occasions where a vehicle will emit electronic interference causing the
loss of signal from the transmitters. The chance of lost signals also increases with distance (from receiver to rear tires),
extreme cold and battery deterioration.
2. Operation
Once installed on the tow vehicle or approximate middle of a large Motor coach, no further programming or action is
necessary. The Jetson Booster will automatically pick up the signals from all transmitters and resend the information to the
receiver/monitor.
3. Installation Position
Although fully weather proof, it is recommended to install the booster in a relatively protected area. The illustration below
shows the ideal location for RV, Caravan, trailer and truck use.
PDF 文件使用 "FinePrint pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
4. Installation
The JET100A Jetson booster comes with several “wire ties” which may be used to secure it and its power cord wherever.
Please mount as securely as possible to minimize vibration.
5. Power Supply
Model JET-100A requires external DC power: DC 12V or DC 24V. Red wire is “+” positive, black wire is “-“ negative. If
uncertain, contact a local repair facility to help install the unit.
6. Technical Data:
Working Temperature -40~85℃ (-40°F to 185°F)
Working Voltage DC 12V~DC 24V
Working Frequency 434.2 MHZ
7. Warrantee:
Jetson boosters are guaranteed against manufacturing defects for a period of one year from date of purchase.
PDF 文件使用 "FinePrint pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
FCC Information and Copyright
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
