Jonter Digital D16 Bluetooth Speaker User Manual 311671 INS Executive 2 Speaker
Shenzhen Jonter Digital Co., Ltd Bluetooth Speaker 311671 INS Executive 2 Speaker
user manual
LITHIUM-ION BATTERY
WARNINGS
This device contains a non-removable
lithium-ion battery. The battery must be
recycled or disposed of properly.
Contact your local waste management
office for information on battery
recycling or disposal.
FCC INFORMATION
This equipment has been tested
and found to comply with the
limits for a Class B Digital Device,
pursuant to Part 15 of the FCC
Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses, and can radiate radio frequency
energy and, if not installed and used
in accordance with the instructions,
may cause harmful interference to
radio communications. However, there
is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
• Reorient or relocate the
receiving antenna.
• Increase the distance between
the equipment and receiver.
• Connect the equipment to an outlet
on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an
experienced radio/TV technician
for help.
This equipment complies with
Part 15 of the FCC Rules.
Operation is subject to the
following two conditions:
1. This equipment may not cause
harmful interference.
2. This equipment must accept any
interference received, including
interference that may cause
undesired operation.
Modifications not authorized by the
manufacturer may void the user’s
authority to operate this device.
FCC ID: 2AB9SD16
Merrimack, New Hampshire, USA 03054
800-846-3000 • Brookstone.com
CHARGING THE SPEAKER
1. Connect the USB Cable (included)
to the Micro USB Port on the
speaker.
2. With the speaker power off, plug
the other end of USB Cable into a
USB Port on your PC or a 5V 1A
adapter (not included).
3. The LED Indicator light will illuminate
red while charging and will turn off
when speaker is fully charged.
Charges in approximately 3 hours
for up to 10 hours of listening
enjoyment.
NOTE: When battery is low, the speaker
will sound a beep tone every minute.
TURNING THE SPEAKER ON/
OFF
1. Press and hold the Power Button for
2 seconds. The speaker is turned on
and will sound ascending tones. The
LED Indicator quick flash blue.
2. Press and hold the Power Button for
4 seconds again. The speaker will
sound tones. The LED Indicator lits
off and the speaker is powered
off.
Mini Bluetooht Speaker
Go with music everywhere
LOCATION OF PORTS AND
CONTROLS
1. Power/Pairing Button
2. Volume Up Button
3. Volume Down Button
4. Micro-USB Charging Port
5. LED Indicator
6. Aux-In Port
7. Micro-USB Charging Cable
(not shown)
8. Nylon Strap (not shown)
1
2
3
4
6
5
320672 • 320673 • 320674 • 321179
SPECIFICATIONS
DC-Input: 5V, 1A
Output: 3W
Range: Class 2, up to 33 ft (10 m)
Li-ion Rechargeable Battery: 1200mAh
Charging Time: Approx. 3 hours
Battery Life: Approx.10 hours
Compatibility: Bluetooth® 2.0 or above
device with A2DP/AVRCP
The Bluetooth® word mark and logos
are registered trademarks owned of
Bluetooth® SIG, Inc. and any use of
such marks by Brookstone is under
license.
@ 2017 Brookstone
CARE AND STORAGE
Store the speaker in a cool, dry place.
PLAYING MUSIC THROUGH A
WIRED CONNECTION
You can connect your audio device to
the speaker with a 3.5mm audio cable
(included).
1. Plug one end of the cable into your
audio device, just like you would a
pair of headphones.
2. Plug the other end of the cable into
the speaker's Aux-In Port. The LED
Indicator will illuminate solid blue.
3. Use your audio device to control
music playback, and adjust volume
through speaker.
PAIRING YOUR DEVICE
1. Prepare your device to pair using
Bluetooth® technology, making sure
you are within 33 feet of the speaker
Refer to your device’s owners
manual for details if necessary.
2. Turn on the speaker.
3. The LED lndicator will slowly flash
blue and the speaker is ready to pair.
4. Once the speaker is in pairing mode
and your device is ready to pair,
select 'Pocketune.' If prompted,
use 0000 as a PIN for the pairing
code. Once the speaker is selected,
the LED Indicator will be in soild blue
and the speaker will sound ‘do’
tone to confirm pairing is complete.
NOTES:
1. Aux-in will take priority over the
Bluetooth® connection. When Aux
cable is unplugged, the speaker
will reconnect to the phone via
Bluetooth®. A tone will sound.
2. You can connect the speaker to
other Bluetooth® enabled devices by
holding the Power Button 2 seconds.
The Power LED Indicator will flash
blue and the speaker is in pairing
mode again.
LISTENING TO YOUR AUDIO
DEVICE
1. Play your audio device as you
normally would.
2. Single press the Volume Up or
Down buttons to adjust the volume.
3. Long press the Volume Down or
Volume Up buttons will go back to
the previous track or advance to the
next track.
4. To pause audio, press the Power
Button on the Speaker. To resume
audio playback, press the same
button again.
