user manual
USER GUIDE
PH-SPHERE
HD BLUETOOTH WIRELESS SPEAKER
Thank you for purchasing the Photive Sphere and welcome to the
Photive family!
This product is designed to provide you with portable wireless high quality sound for
your iPad, iPhone, iPod, computer or other Bluetooth audio devices. This instruction
booklet explains the basic operations, specifications and care of the unit. Please read
them carefully and keep for future reference.
WELCOME
PACKAGE
FUNCTION
CHARGING
PAIRING
LINE-IN
HANDS-FREE SPEAKERPHONE
OPERATION INSTRUCTION
TROUBLESHOOTING
SPECIFICATION
SAFETY INFORMATION
FCC INFORMATION
WARRANTY INFORMATION
4
5
6
7
8
8
9
10
11
12
14
14
TABLE OF CONTENTS
PACKAGE
PH-Sphere speaker
USB charging cable
3.5mm audio cable
1
2
3
2
1
3
FUNCTIONS
Power
Volume down
Previous track
Next track
Volume up
Play/Pause
AUX-IN
LED light indication
USB charging port
1
2
3
4
5
6
7
8
9
1 2 3 4 5 6
7 98
Before using your PH-Sphere, please charge it using the micro USB charging cable
included in the package.
Please note: Most USB chargers are compatible with PH-Sphere. For optimal AC
charging, please use a 1.0A USB charger.
Plug the small micro USB pin into the charging port on the side of the speaker, and the
other end of the cable (the standard USB 2.0 plug) into any standard USB port (such as
a computer or USB charger).
The LED light on the rear side will turn red when it is being charged. When it is fully
charged, the LED indicator light will turn o. The speaker can be charged while playing
music.
CHARGING
PAIRING
Press and hold to turn your speaker on.
The Bluetooth LED indicator will flash blue.
Enable your Bluetooth device such as cell phones, tablets or other Bluetooth media
and make sure it is in searching mode.
Select “Photive Sphere speaker” in the list shown in the Bluetooth device.
IMPORTANT! If the Sphere speaker has lost connection with your device longer than 10
mins, the speaker will turn o automatically in order to conserve the battery.
Note
1 If it prompts, please enter password “0000” for a connection.
2 The speaker will automatically reconnect to the last connected Bluetooth enabled audio device.
3 IMPORTANT When you need to connect your speaker with another Bluetooth enabled audio device,
hold the PAIRING button about 4-5 seconds until the Bluetooth LED indicator flashes quickly. This
will put the speaker into pairing mode.
1
2
3
4
LINE-IN
HANDS-FREE SPEAKERPHONE
If your device is not Bluetooth enabled you can still enjoy your music simply by using
the Line-In Audio Jack. Connect the speaker with the audio cable that is included in the
package to any device with a 3.5mm standard audio jack. Once connected the speaker
can be used as a wired speaker.
Please note: the changing track buttons, and only work when connected wirelessly via
Bluetooth. Volume function will work in Aux-in mode.
You can use PH-Sphere as a portable speakerphone for incoming calls when
connected wirelessly and outgoing calls via Bluetooth.
Take your call by pressing the “ “. Press once again when ending the call. Music will
resume automatically.
To make a call, simply dial your cell phone and talk to the speaker. Once your call is
connected, choose PH-Sphere in the headset options.
1
2
3
OPERATION INSTRUCTION
VOLUME ADJUSTMENT
At any time while playing music, the volume can be changed with the ” ” or “ “
button. To raise the volume, press the “ “ button. To lower volume, press the “ “
button. There will be a tone from the speaker to indicate that the level has reached
maximum or minimum volume.
CHANGING TRACKS
Press the “ “ or “ “ button on the PH-Sphere to change tracks.
PLAY AND PAUSE
Press the “ “ on the speaker to play/pause the music.
Please note: If listing to music via the Aux line in the track controls on the speaker will not function. Control the track from the
device playing audio “ie: Smartphone, Tablet.”
No power
Ensure the speaker is charged and with enough power for operation. The speaker can be used when
it is in charging mode.
No sound
Ensure the speaker is on. Ensure your Bluetooth device is on. If the volume of the speaker is too
low, adjust the volume to an appropriate level.
Unable to connect
Press the pairing button until the LED indicator flashes quickly. The Bluetooth speaker will go into
pairing mode. Select PH-Sphere on your Bluetooth enable device.
Poor sound quality from the bluetooth device
Ensure placing the speaker and Bluetooth device within 33-ft. (10m) sensing distance and with no
barriers.
Notes Clean the speaker with a soft, lint-free, dry cloth.
Never use detergents or abrasive cleaners for cleaning.
TROUBLESHOOTING
Speaker parameters
Output power 3.5W x 2
Impedance 4Ω
Power Input: DC 5V 500mA
Bluetooth parameters
Eective distance 33ft (10m)
Bluetooth: 2.1 + EDR
SPECIFICATION
NOTES
Do not expose the built-in battery to excessive heat,
including direct sunlight and fire. In addition, do not
expose it to rain, moisture and any kinds of liquid.
This speaker is in compliance with the specified
Bluetooth version. It does not guarantee compatibility
of all functions on every Bluetooth enabled device.
Please check with your mobile phone’s user manual
for compatibility and functionality.
11
WARNING
Please read these safety warnings and cautions
carefully to ensure your personal safety and prevent
property damage.
Fire and Electric Shock Hazard
• Do not expose your PH-Sphere to liquid, moisture,
humidity, or rain. Do not use the PH-Sphere near a
bathtub, sink, sauna, pool, or steam room. Exposure
of the PH-Sphere to moisture could result in electric
shock.
• Do not drop, disassemble, open, crush, bend, deform,
puncture, shred, microwave, incinerate, paint, or insert
foreign objects in to the PH-Sphere. Such actions
could result in electric shock.
• Clean the PH-Sphere only with a dry cloth.
• Do not expose your PH-Sphere to extremely high or
low temperatures.
• Do not leave your PH-Sphere in direct sunlight for
extended periods of time.
• Do not leave your PH-Sphere near open flames such
as cooking burners, candles, or fireplaces.
• Do not block any ventilation openings.
Battery/Charger Hazard
• Do not dispose of your PH-Sphere in a fire. The
battery could explode causing injury or death.
• Only charge the battery in accordance with the user
instructions supplied with the PH-Sphere.
• Do not attempt to disassemble the PH-Sphere charger
or force open the built-in battery because this may
result in electric shock.
• Do not charge the PH-Sphere in damp areas or in
extremely high or low temperatures because this
could result in electric shock.
SAFETY INFORMATION
• Do not clean the PH-Sphere when it is being charged.
Always unplug the charger first before cleaning the
PH-Sphere.
Automobile Accident Hazard
• Do not leave or store the PH-Sphere or any of its
accessories near or over your automobile’s air bag
because serious injury may result when an air bag
deploys.
• Do not place the PH-Sphere on high surfaces such
as shelves. During music playback the PH-Sphere may
move which could cause the PH-Sphere to shift and
fall o of the edge.
CAUTION
• Do not use abrasive cleaners to clean your PH-Sphere
because this could cause scratches and damage.
• Do not bring your PH-Sphere in to contact with any
sharp objects because this could cause scratches and
damage.
• Do not insert anything into your PH-Sphere unless
otherwise specified in the user instructions. This may
damage the internal components.
• Do not attempt to repair, modify, or disassemble your
PH-Sphere yourself, it does not contain any user-
serviceable components.
• Do not attempt to replace your PH-Sphere battery, it
is built-in and is not changeable.
• Use only the manufacturer supplied charger to charge
your PH-Sphere. Other chargers may look similar, but
using them could result in electric shock and could
damage the PH-Sphere.
• Observe all signs and displays that require an
electrical device or RF radio product to be switched o
in designated areas.
• Turn o your PH-Sphere prior to boarding an aircraft. Do not
use the PH-Sphere inside an aircraft unless allowed by your
airline.
• Dispose of the PH-Sphere and the PH-Sphere’s battery
in accordance with local regulations. Do not dispose of the
battery with regular household waste.
13
This Product (including any accessories included in
the original packaging) as supplied and distributed in
new condition, is warranted by Photive to the original
consumer purchaser against defects in material and
workmanship (“Warranty”) as follows:
1. LABOR : For a period of one (1) year from date of
original consumer purchase, if this Product or any part is
determined by Photive, or a Photive authorized service
provider, to be defective, Photive will repair or replace
the Product with new or refurbished product of similar
or better quality, at Photive’s option, at no charge to
the original consumer, or pay the labor charges to any
Photive authorized service provider.
After the one (1) year Warranty period, you must pay for
all labor charges.
2. PARTS : For a period of one (1) year from the date
of original consumer purchase, Photive will supply,
at no charge to the original consumer, new, rebuilt
or refurbished replacement parts in exchange for
defective parts, or will replace the Product with new or
refurbished product of similar or better
quality, at Photive’s option, at no charge to the original
consumer. After the one (1) year Warranty period, you
must pay for the costs of all parts.
3. SHIPPING COSTS : Notwithstanding the foregoing,
the original consumer is responsible for any shipping
charges incurred to ship the Product or part(s) to
Photive or to an Photive authorized customer service
provider, for diagnosis, repair or replacement.
Please have your model number available along with
your date of purchase.
To receive Warranty service, the original consumer
purchaser must contact Photive for problem
determination and service procedures. Proof of
purchase in the form of a bill of sale or receipted invoice,
evidencing that the Product is within the applicable
Warranty period(s), MUST be presented to Photive, or an
WARRANTY INFORMATION
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed or used in accordance with the
instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
1 Reorient or relocate the receiving antenna
2 Increase the separation between the equipment and
the receiver
3 Connect the equipment to an outlet on a circuit
dierent from that to which the receiver is connected
4 Consult the dealer or an experienced radio/TV
technician for additional suggestions.
Any changes or modifications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate the equipment. Where
shielded interface cables have been provided with
the product or specified additional components or
accessories elsewhere defined to be used with the
installation of the product, they must be used in order
to ensure compliance with FCC regulation.
IMPORTANT NOTICE:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may
cause undesired operation.
FCC INFORMATION
authorized customer service provider, in order to obtain
the requested service.
For warranty & support, Please visit us at
www.photive.com
EXCLUSIONS AND LIMITATIONS
This Warranty covers manufacturing defects in
materials and workmanship encountered in the normal,
noncommercial use of the Product, and does not cover
(a) damage or failure caused by or attributable to
abuse, misuse, failure to follow instructions, improper
installation or maintenance, alteration, accident or
excess voltage or current; (b) improper or incorrectly
performed repairs by non-authorized service facilities;
(c) onsite consumer instruction or adjustments;
(d) transportation, shipping, delivery, insurance,
installation or set-up costs; (e) costs of product removal,
transportation or reinstallation costs; (f) ordinary wear
and tear, cosmetic damage or damage due to acts of
nature, accident; (g) commercial use of the Product;
(h) modification of, or to any part of the Product.
This Warranty applies to the original consumer only
and does not cover products sold AS IS or WITH ALL
FAULTS, or consumable (e.g., fuses, batteries, bulbs
etc.). This Warranty is valid only in the United States,
and only applies to products purchased and serviced
in the United States. All replaced parts and products,
and products on which a refund is made, become the
property of the Warrantor.
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, OTHER THAN THOSE
EXPRESSLY DESCRIBED ABOVE, SHALL APPLY. THE
WARRANTOR FURTHER DISCLAIMS ALL WARRANTIES
AFTER THE EXPRESS WARRANTY PERIOD STATED
ABOVE. NO OTHER EXPRESS WARRANTY OR GUARANTY
GIVEN BY ANY PERSON, FIRM OR ENTITY WITH
RESPECT TO THE PRODUCT SHALL BE BINDING ON THE
WARRANTOR.
REPAIR, REPLACEMENT OR REFUND OF THE ORIGINAL
PURCHASE PRICE − AT THE WARRANTOR’S SOLE
DISCRETION − ARE THE EXCLUSIVE REMEDIES OF
THE CONSUMER. THE WARRANTOR SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY
TO USE THE PRODUCT. NOTWITHSTANDING THE
FOREGOING, CONSUMER’S RECOVERY SHALL NOT
EXCEED THE PURCHASE PRICE OF THE PRODUCT SOLD
BY Photive. THIS WARRANTY SHALL NOT EXTEND
TO ANYONE OTHER THAN THE ORIGINAL CONSUMER
WHO PURCHASED THE PRODUCT AND IS NOT
TRANSFERABLE.
Some states do not allow the exclusion or limitation
of incidental or consequential damages, or allow
limitations on warranties, so the above limitations or
exclusions may not apply to you. This Warranty gives
you specific rights, and you may have other rights,
which vary from state to state.
© 2016 Photive Edison, NJ 08837
iPhone is a trademark of Apple Inc., in the U.S. and/or other countries. The Bluetooth word mark and logos are owned by Blue-
tooth SIG, Inc. All other trademarks and trade names are those of their respective owners. The illustrated product and specifica-
tions may dier slightly from those supplied. Made in China
