INTRODUCTION
We are grateful you decided to purchase this 2.4GHz Color LCD A/V
Wireless Monitor, which incorporate the latest in advanced technology. We
feel strongly that you will be pleased with the quality and features of this
product.
This 2.4GHz Color LCD A/V Wireless Monitor enables you to transmit
picture and sound signals cordlessly, which most ideal for applications such
as baby monitoring, household security, office or warehouse surveillance
system, etc.
PACKAGE CONTENT
Please note that the package should include the follows:
a) 1 x Camera Unit
b) 1 x Monitor Unit
c) 1 x Charging Base Unit (JY-238R only)
d) 2 x AC/DC adaptors
e) 2 x Audio/Video Cord (1 for JY-229TC)
f) This instruction manual
Optional Accessories --- Rechargeable Batteries
If you find any of the above missing, please contact your retailer.
3
PICTURE OF MONITOR UNIT
1. TFT LCD Display
2. Speaker
3. Power On/Off Indicator
4. Channel Selection Switch
5. Channel indicating LEDs
6. Automatic Channel Scan Indicator
7. Brightness Control (+)(-)
8. Volume and power O/Off switch
9. LCD On/Off Switch
10. DC Jack
11. Audio/Video output
12. Belt Clip
13. Battery Cover (JY-238R)
14. Recharging Base (optional for JY-238R)
PICTURE of Monitor Unit
4
PICTURE OF CAMERA UNIT
15. Camera Lens
16. Channel Indicators LEDs
17. Channel Selection Switch
18. Voice Activation Action Selection Switch
19. Analog Audio/Video Input Jack
20. Light Sensor for Automatic Night Vision
21. Power On/Off Switch
22. Power On/Off Indicator
23. DC Jack
24. Microphone
Picture of Camera Unit
5
SAFETY INSTRUCTION
Please observe the following precautions to prevent fire, personal injury, and
product damage:
Read Instructions:
All the safety and operating instructions should be read before the 2.4GHz
Color LCD A/V Wireless Monitor is operated.
Retain Instructions:
The safety and operating instructions should be retained for future reference.
Heed Warnings:
All warnings on the 2.4GHz Color LCD A/V Wireless Monitor and
operating instructions should be adhered to.
Follow Instructions:
All operating instructions should be followed.
Water and Moisture:
This product is designed for the indoor use only. The unit should not be
exposed to dripping or splashing and that no objects filled with liquids, such
as vases, shall be placed on the unit. The item should not be used near water;
for example, near a bath tub, wash bowl, kitchen sink, laundry tub in a wet
basement, of near a swimming pool, etc.
Ventilation:
The 2.4GHz Color LCD A/V Wireless Monitor should not be situated on a
bed, sofa, rug, or similar surface that may block the ventilation openings, or
placed in an enclosed installation, such as a bookcase or cabinet that may
impede the flow of air through the ventilation openings.
Heat:
The 2.4GHz Color LCD A/V Monitor should be situated away from heat
sources such as radiators, heat registers, stoves, or other appliances that
produce heat. No naked flames sources, such as lighted candles, should be
placed on the apparatus.
6
Power Source:
Besides batteries operated, the 2.4GHz Color LCD A/V Monitor should be
connected to a power supply only of the type described in this operating
instruction (AC/DC adaptors: 9V 500mA Centre Positive).
Cleaning:
Use a dry cotton cloth to keep the 2.4GHz Color LCD A/V Monitor free of
dust. Do not use water!
Non-Use Periods:
Always remove the batteries from the Camera and the Monitor battery packs
or unplug the AC adaptors from wall outlets during long periods of non-use.
Object and Liquid Entry:
Care should be taken so that objects do not fall into, and liquids are not
spilled into the enclosure through the openings.
Damage Requiring Services:
The 2.4GHz Color LCD A/V Monitor should be serviced by qualified
service personnel when:
a. Objects have fallen or liquid has been spilled into the products; or
b. The units have been exposed to rain; or
c. The units do not appear to operate normally or exhibits a marked
change in its performance; or
d. The units have been dropped or the enclosure damaged.
Caution:
a. This product cannot replace responsible adult supervision of a child.
You should personally check your child’s activity at regular intervals.
b. Never use this 2.4GHz Color LCD A/V Wireless Monitor to a degree
where your life or health or the life or health of others or integrity of
property depends on its function! Manufacturer will not accept any
responsibility or claim for death and injury of any person or lost and
damage of any property due to malfunction or misuse of the product.
Battery:
a. Replace only with the same or equivalent type.
b. Please dispose of old, defective batteries in an environmentally friendly
manner in accordance with the relevant legislation.
7
STATEMENT ON REGULATION
This product is designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generate, uses and
can radiate radio frequency energy and if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and
receiver.
z Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
z Consult the dealer or an experienced radio/TV technician
for help.
Operation with non-approved equipment or unshielded cables is likely to
result in interference to radio or TV reception. The user is cautioned that
changes and modifications made to the equipment without the approval of
manufacturer could void the user’s authority to operate this equipment.
8
INSTALLATION
INSTALLING BATTERIES (EXCEPT JY-229TC)
Camera:
1. Remove the battery cover at the bottom or back of the unit.
2. Insert AA size batteries according to marking in the battery
compartment.
3. Align the battery cover tabs with the camera tab holes and replace the
cover.
Monitor:
1. Remove the battery cover at the back of the unit.
2. Insert AA size batteries according to the marking of the battery
compartment.
3. Align the battery cover tabs with the monitor tab holes and replace the
cover.
PLEASE NOTE:
1. Do not mix old and new batteries.
2. Do not mix alkaline, standard or rechargeable batteries
3. Remove the batteries during long period of non-use.
4. (European Version only) Due to specially designed circuitry for safety.
Only specially designed rechargeable battery can be recharged. Some of
the package may have this special battery included. Please contact your
dealer if you have any queries.
INSTALLING AC/DC ADAPTOR:
1. Install the plug of AC adaptor to the DC jack of the unit.
2. Plug the AC adaptor into a standard wall AC power outlet.
3. Switch on the unit with the power ON/OFF switch.
4. The power indicator will be illuminated.
Warning: Improper use of adaptor may cause malfunction of the units.
Please consult your dealer for any queries.
Please note that the service life of batteries is limited. Therefore, when
monitoring over long periods and, in particular, overnight, it’s recommended
to use AC adaptors for both camera and monitor unit.
9
Use only the AC adaptors supplied with the package.
Before plug in AC adaptors, please make sure only rechargeable NiMH
batteries [or no battery] are inside the battery compartment.
Special Note for JY-229TC
Switch the Channel Selection switch at the bottom of the unit to any one of
the 4 channels to turn on the unit.
MOUNTING THE CAMERA
The Camera unit JY-229TC is designed for mounting on the ceiling, or on to
the wall, or simply placed on table.
To mount the Camera unit:
1. Take the Camera Mounting Plate off from the bottom of the
Camera unit.
2. Secure the Mounting Plate at your decided position by using the 3
mounting screws supplied with the product. The word FRONT
faces the front view of the Camera unit.
3. Insert the DC plug through the Wire Through Hole of the
Mounting Plate.
4. Sandwich the wire between the Wire Positioning Clips.
5. Insert the DC plug into the DC jack at the bottom of the Camera
unit.
6. Line-up the Wire Positioning Clip with the Wire Through Hole of
the Mounting Plate.
7. Turn the Camera unit clockwise to lock the Camera unit securely
into position.
8. If the Camera unit is mounted on the ceiling, turn the Lens
Compartment approximately 60 degrees vertically to receive a
right side up image at the Monitor unit.
10
RECHARGING THE UNIT
( NOT APPLICABLE FOR JY-229TC & JY-238T)
Camera and monitor of your 2.4GHz Color LCD A/V Wireless Monitor
have built-in battery recharging circuit. Make sure only rechargeable NiMH
batteries are inside the battery compartment before plug in AC/DC adaptors.
The unit will be in recharging mode with the AC/DC adaptor plug in.
JY-238R Monitor unit, can be recharged by either plug in the AC/DC
adaptor or place on the Recharging Base (optional), which has the AC/DC
adaptor connected.
The Recharging Base will have the green indicator on while the AC/DC
adaptor is connected. The indicator will turn to orange color while
recharging or the monitor is switched on.
11
CAMERA OPERTATION
Power ON/OFF
Use the Power ON/OFF sliding switch to turn ON/OFF the unit.
For JY-229TC, switch the Channel Selection switch at the bottom of the unit
to any one of the 4 channels to turn on the unit.
Channel Selection
There are 4 channels for selection in order to avoid interference from other
signal sources.
Press the channel switching button at the front of the camera (JY-238T &
JY278T) or use the channel selection switch at the bottom of JY-229TC to
select a channel.
A/V Input
This feature allow user to have an optionally Analog A/V (Audio-Video)
input to the Camera unit and transmit this A/V signal to the Monitor unit per
the Voice Activation option selected by the user.
The A/V Input jack locates on the left side (JY-238T) and back (JY-278T) of
the unit. Use the AV cord to connect the source of an AV signal (e.g. DVD)
to the unit.
Voice Activation
To Activate: Select the AUTO option by the Voice Activation switch on the
left side (JY-238T) and right side (JY-278T) of the Camera unit.
On JY-278T, sensitivity of this feature can be adjusted. The Higher the
sensitivity the Lower is the sound level required to trigger the signal
transmission.
When the sound level of the unit’s surrounding area reaches the preset level,
the Camera will transmit the image captured to the Monitor.
When the surrounding sound level is below the preset level, A/V signal
input to the Camera will be transmitted. No signal will be transmitted if AV
12
signal input is not used.
NOTE: LCD on the Monitor unit will be automatically switched off if no
signal is received from the Camera
To Deactivate: Select the CAMERA or AV option by the Voice Activation
switch.
The Camera will only transmit CAMERA signal continuously when the
CAMERA option is selected.
The Camera will only transmit the AV input signal continuously when the
AV option is selected.
Automatic Infra-Red Night Vision
The infra-red night vision of the camera is designed to allow the camera
pick up pictures during darkness or periods of very low levels of light. The
function will switch on automatically when the level of light is low.
Only objects placed within 6ft/2m will be monitored.
MONITOR OPERTATION
Power ON/OFF
Use the volume and ON/OFF switch on the side of the unit to turn on the
unit.
Channel Selection
Press the Channel Switching Button at the front of the monitor to a channel
with optimized clear image and sound. Channels are indicated by LED lights
labeled with letters A, B, C or D.
Automatic Channel Scan
This option allows the Monitor unit to scan through all 4 channels
automatically and stops at each channel for about 5 seconds. Press the
Channel Switching Button until the LED light labeled with AUTO is turned
on and starts blinking. Images from different Camera units on different
13
channels can then be seen on the Monitor unit.
LCD On/Off
This power saving feature is located on the side of the monitor. When the
monitor is switched to LCD “off” position and the camera is remained
power on, there will be no picture on the monitor screen. The unit is using
smaller amount of power and is still operational. You can still hear the sound
signal that captured from the monitoring area. The monitor will resume
working with a clear picture when the LCD is switched back to “on”.
Brightness Control
The brightness of the LCD can be adjusted by the 2 Brightness Control
buttons on the side of the Monitor unit. (+) to increase and (-) to decrease
the brightness of the LCD.
Audio/Visual Output Link
An additional security feature of this 2.4GHz Color LCD Wireless Monitor
is you can link the monitor to a VCR recorder for recording what ever the
camera captures. Also, you can link to a television set that has a
“Picture-In-Picture” feature that allows you to take a glance to the
monitoring area all the while watching your favorite TV program.
The A/V Output jack locates at the left side of the monitor. This needs to be
connected to the Audio and Video input jacks of your VCR or TV sets with
the AV cord.
14
TROUBLESHOTTING
Problem Possible Cause – things to do/check
No reception z Unit has not been switched on.
z AC/DC adaptor has not been connected.
z Out of Battery (check Led indicator:
Full Power - Green; Low Power -
Orange)
z The camera may not be transmitting.
(power is not on or is in voice activation
mode)
z Wrong Channel (Please note the
monitor will return to Channel A
automatically after power off)
No picture display but can
hear sound
z Check if the LCD on/off switch is
turned to on.
z Low Power (Check LED indicator: Full
Power - Green; Low Power - Orange)
Battery cannot be
recharged
z AC/DC adaptor has not been connected.
z Non-rechargeable battery has been
used.
z (European Version only) Normal
Rechargeable battery cannot be charged
due to special designed circuitry. Only
special designed rechargeable battery
can be recharged. Some of the package
may have this special battery included.
Please contact your dealer if you have
any queries.
No transmission z Unit has not been switched on.
z AC/DC adaptor has not been connected.
z Out of Battery (check Led indicator:
Full Power - Green; Low Power -
Orange)
z Check if the voice activation mode is
switched on.
