Junlan Electronic CAW12150 CONCIERGE WIRELESS SPEAKER User Manual 1
Shenzhen Junlan Electronic Ltd CONCIERGE WIRELESS SPEAKER 1
User manual
MODEL: CAW-12150
PLEASE READ CAREFULLY BEFORE OPERATING THIS EQUIPMENT
KEEP IT IN A SAFE PLACE FOR FUTURE REFERENCE
Bluetooth & Wi-Fi Speaker With
Amazon Linkplay Alexa Voice Control
2
DANGEROUS VOLTAGE:The lighting flash with arrowhead symbol within
an equilateral triangle is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
ATTENTION:The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING:TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
WARNING: USE UNDER SUPERVISION OF AN ADULT DUE TO LONG
CORD This unit has a long cord that can be easily tripped on or pulled on,
causing injury. Please make sure it is arranged so that it will not drape over a
tabletop, etc. Where it can be pulled on by children or tripped over accidentally.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference
that may cause undesired operation.
CAUTION: TO REDUCE THE ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE PART INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING:
To assure continued operation, follow the attached installation instructions and
use only shield cables when connecting to other devices. Changes or
modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Before using the unit, be sure to read all operating instruction carefully, please
note that these are general precautions and may not pertain to your unit. For
example, this unit may not have the capability to be connected to an outdoor
antenna.
1. Read these instructions
All the safety and operating instructions should be read before the appliance is
operated.
2. Keep these instructions
The safety and operating instructions should be kept for future reference.
3. Heed all warnings
All warnings on the appliance and in the operating instructions should be
adhered to.
4. Follow all instructions
All operation and use instructions should be followed.
FCC NOTICE:
5. Do not use this apparatus near water
The appliance should not be used near water; for example, near a bath tub,
3
4
washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming
pool.
6. Clean only with dry cloth
The appliance should be cleaned only as recommended by the manufacturer.
7. Do not block any ventilation openings.Install in accordance with the
manufacturer’s instructions.
Slots and openings in the cabinet and in the back or bottom are provided for
ventilation, to ensure reliable operation of the product and to protect it from
overheating. These openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed, sofa, rug, or similar
surface. This product should never be placed near or over a radiator or heat
source. This product should not be placed in a built-in installation, such as a
bookcase or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide or the third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments / accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
An appliance and cart combination should be moved with care. Quick stop,
excessive fore and uneven surfaces may cause the appliance and cart
combination to overturn.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
To protect your product from a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage to the product due to
lightning and power-line surges.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. Power source
This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your appliance dealer or local power company. For products
intended to operate from battery power, or other source, refer to the operation
instructions.
16. Power lines
An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
17. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of
fire or electric shock.
18. Object and liquid entry
Never push objects of any kind into the product through openings as they may
touch dangerous voltage points or short out parts that could result in fire or
electric shock. Never spill or spray any type of liquid on the product.
19. Outdoor antenna grounding
If an outside antenna is connected to the product, be sure the antenna system
is grounded so as to provide some protection against voltage surges and built
up static charges. Section 810 of the National Electric Code ANSI/ NFPA 70
provides information with respect to proper grounding of the mast and
supporting structure, grounding of the lead- in wire to an antenna discharge
product, size of grounding conductors, location of antenna- discharge product,
connection to grounding electrodes and requirements for the grounding
electrodes.
5
2
20. Service
Do not attempt to service this product yourself as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
b)If liquid has been spilled or objects have fallen into the product.
c)If the product has been exposed to rain or water.
d)If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions, as an adjustment of other controls may result in damage and will
require extensive work by a qualified technician to restore the product to its
normal operation.
e)If the product has been dropped or the cabinet has been damaged.
f)When the product exhibits a distinct change in performance- this indicates a
need for service.
25. Note to CATV system installer
This reminder is provided to call the CATV system installer' s attention to
Article 820- 40 of the NEC that provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical.
NOTE: Refer all servicing to qualified service personnel. Servicing is
required when the unit has been damaged in any way such as the
following: the power-supply cord or plug has been damaged, liquid has
been spilled into unit, the unit has been exposed to rain or moisture, the
unit has been dropped or the unit does not operate normally.
21. Replacement parts
When replacement parts are required, be sure the service technician uses
replacement parts specified by the manufacturer or those that have the same
characteristics as the original parts. Unauthorized substitutions may result in
fire or electric shock or other hazards.
22. Safety check
Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper
operating condition.
23. Wall or ceiling mounting
The product should be mounted to a wall or ceiling only as recommended by
the manufacturer.
24. Damage requiring service
Unplug this product from the wall outlet and refer service to qualified service
personnel under the following conditions.
a)When the power- supply cord or plug is damaged.
6
PROdUCT OvERvIEW
7
TOP VIEW
12. LED Light Ring
5. Play/Pause,PAIR Button
4. Volume Down Button
3. Volume Up Button
6. Power on/off, Mode Button
10. Mode Indicator
9. Built-in Microphone
11. Charge Indicator
8. AUX IN Jack
7. DC IN Jack
REAR VIEW
1
2
3
4
5
6
7
8
910 11 912
2. Microphone Control Button
Alexa Communication Button
1.
POWER SOURCE:
There is a built in Li-ion rechargeable battery, recharge it if the battery is low.
1. Connect the Micro USB Plug from the supplied USB Connection Cable to the Micro
USB Port on the rear of unit.
2. Connect the full sized USB Plug from the supplied USB Connection Cable to the
USB Port on the USB Charger (During
When finished, it will turn off).
AUX IN:
To listen from an external Audio Player such as a MP3 Player, Discman …etc.
charging, the charge indicator on the top of
unit will turn RED,
1. Connect one end of the Audio Connection Cable to the AUX Out/Line Out/Phone
Jack on the external Audio Player.
2. Connect the other end of the cable to the AUX IN Jack on the rear of the unit.
3. Play the music on the connected Player as usual.
through the microphone on
8
NOTES:
Your battery will last longer if you're following these simple guidelines for charging
and storing:
A.
Before first time use, charge it approximately
hours until the unit is fully
charged.
B.
Recharge and store the unit within the temperature range of 5°C~35°C
(40°F~95°F).
C.
Do not charge longer than 24 hours. Excessive charging or running the
unit until battery fully drains will damage battery. Battery life will be extended
if you keep the battery fully charged.
D.
Battery life naturally shortens slowly over time.
E.
The rechargeable battery incorporated in this product is not user
replaceable.
4
Press and hold the button to power on the unit, wait the mode indicator blinks
WHITE only, press the button repeatedly until the Mode Indicator turns
GREEN.
BLUETOOTH OPERATION:
4. Play a track on your paired audio player or phone as normal.
bluetooth device list, select it and make connection.
3. After successful connection, the unit will send a tone and the indicator stays lit.
device and speaker are activated and
the pairing name
try to search the speaker, "ISWFV387B" will appear on
with the device
connected before when the bluetooth of the
NOTE:
After first time pairing, the unit will be automatically paired
2. Activate the bluetooth menu on the device you wish to connect to the speaker,
During playing:
in range.
9
1. Press and hold the button to power on the unit, wait the mode indicator blinks
WHITE only, press the button repeatedly until the Mode Indicator will turn
BLUE and blinks.
Press the Button to switch between playing and pause.
Press and hold the or button to adjust volume.
5. Press the button to disconnect the current connection if you want to pair
with another device.
The App icon will appear as the figure on right after successful installation.
APP dOWNLOAd ANd INSTALLATION
MUzO Player
Download the MUZO Player from Apple App store for iOS devies.
Download MUZO Player from Google Play store for Android devices.
SETUP
The following operation base on iOS system. The operation of Android is similar.
NOTE:
CONNECTION
desired WiFi network (router).
Connect your iOS or Android device to the
2. Turn on the WiFi on your iOS or Android device(smart phone or tablet with WiFi function),
Read the screen instructions and press the to continue.
Searching for MUZO Wireless
Hi-Fi System.....
Please make sure your device is
powered up
Your phone is connected to XXX,
same network
"MUZO Cobblestone" isn't setup yet?
Wi-Fi Setup Wizard
please make sure your device is
connected to the
Wi-Fi Setup Wizard
3. Click the MUZO Player icon on your iOS or Android device.
It will start to scan and search the available speaker automatically.
10
1. Press and hold the button to power on the unit, wait the mode indicator blinks
WHITE only, now it is WiFi mode.
to continue.
WIFI INFO
1Please enter Wi-Fi password:
Next
Wi-Fi: XXX
<
Next
Password: Please enter Wi-Fi password
Press the
4. Inputing the WiFi password to make the speaker to connect to WiFi network(router),
Press the Next
<
Press the WPS key on device
WPS
PRESS TO ENTER SETUP M...
to put the device into network
setup mode.
Then click the "Next" button to
Next
2
5. on top of the speaker.
button on your MUZO Player to continue.
11
Press and hold the button
during the connecting process.
6. There will be voice instructing like " searching for WiFi connection", " waiting for WiFi
connection"
PLEASE WAIT
3Wait for device to be
<
Cancel
connected to Wi-Fi...
Don't operate device during Wi-Fi setup.
Please wait for compltion of setup
patiently. It's usually finished in 60
seconds.
If you hear voice prompt for erro message.
please go back and retry
CONNECTED
Device is connected to XXX
successfully
Current Wi-Fi strength of device:100%
Next
If connection fails, please try again and repeat the above connecting steps.
7. When the speaker is connected to the Wi-Fi (router) successfully, and the voice
sounds "Wi-Fi connected", the Indicator on top of the speaker will stay lit.
12
<
NAME DEVICE Finish
Custom...
Room One
Guest Room
Media Room
8. After successful connection, the screen below will appear for you to name the speaker
(set the location name). Click "Custom..." column to set desired name.
Click "Finish" to complete setting.
13
<
DEVICE LIST
LR
LR
...............................................
How to switch between solo and multi mode?
No song
ROOM 1
ROOM 2
Play All
Press the "
"
to add new Speaker (s) to the network, repeating
the
procedure for each additional speaker.
Press the " " button to set the Speaker audio to L (Left Channel), R (Right Channel)
LR (Stereo).
LR
ting
connec
ro
9. There will be one speaker (ROOM 1) appearing on device list after connection.
" "
Press the setting icon to rename the speaker, check the speaker information
( such as the speaker SSID, restore to factory setting, etc), and so on.
14
R
You Belong with me
Bedroom
....................................................
R
Bathroom
R
Bathroom
Because of you
......................................................
R
You Belong with me
Bedroom
Multi Mode: Press and hold device icon and
drag towards another device to pair devices.
Solo Mode: Press and hold device icon and
drag down past dotted line.
How to switch between solo and multi mode?
Touch
to solo or multi modes as the onscreen instructions.
on the DEVICE LIST page to learn
and set the speakers
15
D
D
Search
Favorites
My music
TuneIn
iHeartRadio
Line In
Settings
Touch to search
Touch to listen the
collected favorite songs
Touch to listen native
songs
Touch to listen radio,
talks, sports, etc.
Touch to log on
Touch to switch to line
in mode
professional music
platform
Touch to log on
professional online
radio platform
online
songs
Touch to check version and feedback
TIDAL
Sportify
Touch to listen from
online songs platform
Bluetooth
Touch to switch to
Bluetooth mode
HOME PAGE INTERFACE
Click the " MUZO " on screen to enter homepage, operate as below instructions and the
screen instructions. Some platforms may need registration.
Touch to log in Amazon
Touch to add more
service
Amazon
16
1. Tap "Spotify" on MUZO homepage.
2. Input your account and password to log in.
3. Open the Spotify on your phone, tablet or PC, and play any song.
4. Tap the connect icon .
5. Pick your device from the list.
Before use, you have to create an spotify premium account for log in.
Before use, you have to create an iHeartradio account for log in.
Before use, you have to create a TIDAL account for log in.
1. Tap "iHeartradio" on MUZO homepage.
2. Input your account and password to log in.
3. Select the desired song and play.
1. Tap "TIDAL" on MUZO homepage.
2. Input your account and password to log in.
3. Select the desired song and play.
17
Licenses
The Spotify Software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses.
SPOTIFY OPERATION
IHEARTRADIO OPERATION
TIDAL OPERATION
1. Touch on homepage, the log in window will pop up, input your account
AMAZON LINK PLAY ALEXA VOICE CONTROL
Before using Amazon linkplay Alexa voice control function, you must get an Amazon prime
account, creat an account on Amazon website.
and password to log in.
2. If you have logged in before, the figures below will appear and operate as the tips.
Amazon login successful
Next
18
3. Press the button once to activate the speaker to communicate before asking the
Example 1:
Press the button first, then ask the speaker, what's the weather like today?
The speaker will reply: the weather is not so cold.
The speaker will reply: it is 8 o'clock now.
Continute to ask the speaker to do other things, such as "Play Music!".
The speaker will reply: here is the station we found, the music will be played.
speaker, (or you must say "ALEXA" to activate the speaker's communication system
without pressing any button).
Example 2:
Just say "ALEXA" to the speaker, then you can ask the speaker, what's the time now?
4. If you want to stop asking or inquiring the speaker, or avoiding external voice interference,
press and hold the button to turn off voice input, the LED ring will turn ,
REd
press and
hold this button again to turn on.
No, thanks Continue
To remove access, visit Your Account at Amazon.
Linkplay Alexa Speaker
Click "Continue" to sign in to Linkplay Alexa
Speaker.
Amazon
Idle
Listening Blue LED ON
Thinking Blue LED ON
Talking Blue LED blinks
SPEAKER STATUS
COMMUNICATION STATUS
LED RING STATUS
LED ON
White
Red LED ON
Microphone Off
LED RING
LED RING
19
20
TROUBLESHOOTING
Check the following before requesting service:
SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION
Can’t power on Built in battery drained Recharge the battery
Volume level of paired/connected device
is in low level
Rise the volume level of the
paired/connected device
Volume level of the connected/paired
device too high
Reduce the volume level of the
connected/paired device
BT not
unctioning
The external BT device had NOT paired to
the unit
Pair the external BT device to the
unit
The external BT device too far from the
unit
Place the external BT device
close to the unit
SPECIFICATTIONS
Power source:Built-in DC 3.7V, 2200mAh (7.4WH) rechargeable Li-ion Battery,
Recharge by DC 5V through Micro USB Port
BT Version: 4.1
BT Operation Distance: 32 Feet in open area
PACKAGE INCLUDES
1 x Us ’s Manual
1 x USB Connection Cable (For Charging Only)
1 x Audio Connection Cables with 3.5mm Plugs
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE
WITHOUT NOTICE
er
f
No sound or
sound weak
Sound
distortion
Wifi Operation Distance: Feet in open area96about
about
