USER’S GUIDE
V:801-01
Bluetooth Mono Speaker
For the most up-to-date version of this User’s Guide,
go to www.iLiveElectronics.com
ISB33S
Pairing a Bluetooth Device
1. Turn on the unit using the Power switch. The Pairing/Line In
Indicator will ash blue slowly and will enter pairing mode.
When pairing, remain within 3 feet of the unit.
2. Using the native controls on your Bluetooth device,
select the “ISB33” in your Bluetooth settings to pair.
If your device requests a password, enter the default password “ 0 0 0 0 ”. Refer to the user’s
manual for your specic device for instructions on pairing and connecting Bluetooth devices.
3. When successfully paired and connected, the Pairing Indicator
will display a solid blue light and a beep will sound from the unit.
After initial pairing, the unit will stay paired unless unpaired manually by the user.
If problems arise with pairing, press the Pair button to begin pairing again.
Playing Audio Wirelessly
1. Follow the instructions for Pairing a Bluetooth Device.
2. Use the native controls on the connected
Bluetooth device to select a track.
3. To play, pause or skip the selected track, use the native
controls on the connected Bluetooth device.
4. Audio played through the connected Bluetooth
device will now be heard through the speakers.
Using the 3.5mm Audio Input
1. Plug one end of a 3.5 mm audio input cable (not
included) into the 3.5 mm Audio Input on the unit.
The Pairing/Line In Indicator will display a green light.
2. Plug the other end of the cable into the audio output/
headphone output on an MP3 Player or other audio source.
3. Turn on the unit using the Power switch.
4. Audio played through the connected device
will now be heard through the speakers.
Note: Any audio being played through a connected Bluetooth Device
will cease once the 3.5mm Audio source is connected.
Warnings and Precautions
• WARNING: To prevent re or shock hazards, do not expose this unit to rain or moisture.
• WARNING:Do not place this unit directly onto furniture surfaces with any
type of soft, porous, or sensitive nish. As with any rubber compound made
with oils, the feet could cause marks or staining where the feet reside. We
recommend using a protective barrier such as a cloth or a piece of glass between
the unit and the surface to reduce the risk of damage and/or staining.
• WARNING : Where the mains plug or appliance coupler is used as the
disconnect device, such disconnect device shall remain readily operable.
• Note : This device uses an internal rechargeable lithium-ion battery that should
last the lifetime of the device. If you suspect your battery may be dead after
several attempts to charge, please contact 1-888-999-4215 for support.
• Never disassemble the unit or attempt to remove the battery as
that could cause leakage of an electrolytic substance.
Warranty
Contact Information
For Warranty Information and the most up-to-date version of this
User’s Guide, go to: www.iLiveElectronics.com
EmailSupport:prodinfo@dpiinc.com
EmailParts:partsinfo@dpiinc.com
PhoneSupport: 1-888-999-4215
Website:www.iLiveElectronics.com
ISB33B-801-01-IB.indd 1-6 4/18/2013 11:36:36 AM
Features
• Supports Bluetooth v2.0
• Supports prole A2DP (Advanced Audio Distribution Prole)
• LED pairing indicator
• Micro-USB port for battery recharge
• 3.5mm audio input
• Pairing button
• On/o switch
• Wireless range: 33 feet
• DC battery power: built-in rechargeable lithium ion battery
• Battery life: ~2.5 hours
Micro USB Charging Port
Charging Indicator
Pairing/Line In Indicator
Charging Indicator
LINE IN POWER
ON OFF
PAIR
DC IN
Pair
Press to begin connecting
a Bluetooth device.
Power
Adjust the switch to turn
the unit on or o.
Always be sure to switch to the
OFF position when not in use.
Line Input
Introduction
Power
USB Power
Requires a Micro USB to USB cable (included).
Note: PC must not be in sleep mode.
LINE IN POWER
ON OFF
PAIR
DC IN
Included
• Micro USB to USB charging cable
Status Indicator
Power O No light
Charging Red light
Fully Charged Green light
Low battery Flashing red light
To download this User’s Guide in English, Spanish, or French, or to get answers to
frequently asked questions, visit the support section at www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para
obtener respuestas a preguntas frecuentes, visite la sección de apoyo en www.
iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour
obtenir des réponses à des questions fréquemment posées, consultez la rubrique
d’assistance sur www.iLiveElectronics.com
International Support
ISB33B-801-01-IB.indd 8-12 4/18/2013 11:36:37 AM
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
