Junlan Electronic MMA3640 Portable Speaker with Bluetooth Wireless Technology User Manual 2016 12 01 MMA3629
Shenzhen Junlan Electronic Ltd Portable Speaker with Bluetooth Wireless Technology 2016 12 01 MMA3629
User Manual
SIZE: 115x165mm
NOTE: If the Audio Connection Cable was plugged into the AUX IN Jack, the Bluetooth function will auto cut. Unplug the Cable
from the AUX IN Jack before use Bluetooth function.
TROUBLESHOOTING:
GENERAL SPECIFICATION:
ACCESSORIES:
1 x User's Manual
1 x USB Connection Cable (For charge only)
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE WITHOUT NOTICE.
POWER SOURCE:
The unit has a built in Li-ion rechargeable battery, recharge it before use or when it is drained as follows:
1. Connect the Micro USB Plug from the supplied USB Connection Cable to the Micro USB Port on the rear of unit.
2. Connect the full sized USB Plug from the supplied USB Connection Cable to the USB Port on the supplied USB Charger (During
charging, the indicator on the rear of unit will turn Purple if the unit is switched on. When finished, it will turn Blue again).
（If the power of the battery is low, the unit will send an indicating sound "low battery". Then recharge the unit immediately.)
To supplied USB charger
To the Micro USB Port on the rear of unit
NOTES:
Your battery will last longer if you're following these simple guidelines for charging and storing.
A. Before first time use, charge it approximately 4 hours until the unit is fully charged.
B. Recharge and store the unit within the temperature range of 5°C~35°C (40°F~95°F).
C. Do not charge longer than 24 hours. Excessive charging or running the unit until battery fully drains will damage battery. Battery life
will be extended if you keep the battery fully charged.
D. Battery life naturally shortens slowly over time.
E. The rechargeable battery incorporated in this product is not user replaceable.
LOCATION OF CONTROLS:
OPERATION:
BT (Bluetooth):
Audio Power
BT Effective range Up to 32 feet in open area
3 Watts per channel (Total 6 Watts RMS)
Impedance of speaker 3 Watts ; 3 ohm x 2
Power Source
BT Version 4.1
Built-in DC 3.7V, 2000 mAH (7.4WH) Li-ion rechargeable battery;
Recharge by DC 5V 1A through Micro USB Port
Can’t power on
No sound or sound weak
Sound distortion
BT not functioning
Recharge the battery
Rise the volume level of the paired/connected device
Reduce the volume level of the connected/paired device
Place the external BT device close to the unit
Pair the external BT Device to the unit as page 4
Built in battery consumed
Volume level of paired/connected device is in low level
Volume level of the connected/paired device too high
The external BT device too far from the unit
The external BT Device had NOT paired to the unit
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
OWNER'S MANUAL
PORTABLE SPEAKER
® Wireless Technologywith Bluetooth
MOdEL:MMA3640
DANGEROUS VOLTAGE: The lighting flash with arrowhead symbol
within an equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
ATTENTION:
The exclamation point
within
an equilateral triangle is intended
to alert the
user
to the presence
of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
FCC NOTICE:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
CAUTION: TO REDUCE THE ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE PART INSIDE, REFER
SERVICING TO
Q
UALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
O NOT OPEN
CAUTION
D
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
MIC MIC
1
OF F/ON
AU X IN DC 5 V
3 4 5 6
1. Microphone
2. Speaker
3. OFF/ON Switch
4. Indicator
5. AUX IN Jack
6. DC IN Jack
TOP VIEW
REAR VIEW
2 2
4. Play a track on your paired audio player or phone as normal.
bluetooth device list, select it and make connection.
3. After successful connection, the unit will send a voice"paired" and the indicator stays lit.
1. Switch on the speaker, the indicator will turn Blue and blink, and it will send a voice
device and speaker are activated.
the pairing name
"bluetooth mode".
to the speaker. Try to search the speaker,
2. After a few seconds, the unit will send a sound "pairing", and the indicator will blink fast.
"MMA3640" will appear on your
with the device connected before when the bluetooth of the
NOTE: After first time pairing, the unit will be automatically paired
When the AUX IN Cable inserted, the bluetooth function will be cut off.
Activate the bluetooth menu on the
device you wish to connect
OF F/ON
AU X IN DC 5V
During bluetooth mode, if the connected phone receives an incoming call, you can answer through the microphone on
top of the unit.
AUX IN:
To listen from an external Audio Player such as a MP3 Player, Discman …etc.
1. Connect one end of the Audio Connection Cable (not supplied) to the AUX Out/Line Out/Phone Jack on the external Audio Player.
2. In power on mode, connect the other end of the cable to the AUX IN Jack on the rear of unit as the figure below. The unit will turn to
AUX IN mode automatically. The unit will send a sound "AUX mode".
To AUX Out / Line Out / Phone Jack on
the external Audio Player
To AUX IN Jack on the rear of unit
3. Play the music on the connected Player as usual. (Make sure the volume level of the connected Audio Player is turned to high
level. )
4. When no longer in use, switch off the unit.
OF F/ON
AU X IN DC 5V
Magnavox warrants this product to be free from manufacturing defects in material and
workmanship under normal use for a period of 180 days from date of purchase. If service
is required, please return the product to the store where it was purchased for exchange;
or, pack the unit in the original packing material with all accessories if applicable, a copy
of your sales receipt and a Cashier’s check or Money Order for $7 (to cover shipping
and handling costs) payable to Craig Electronics Inc. For consumers in Canada, please
make sure that the cashier check or money order is redeemable through a U.S. bank.
Ship your product freight pre-paid. Your unit will be repaired, replaced or if the unit can
not be repaired or replaced, a refund will be forwarded to you within four weeks of receipt
of your unit. Please ship your unit to:
Craig Electronics Inc.
1160 NW 163 Drive
Miami, Fl 33169
This warranty is void if the product has been: a) Used in a commercial application or
rental. b) Damaged through misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d) Damaged because it is
improperly connected to any other equipment.
Note: This warranty does not cover: a) Ordinary adjustments as outlined in the Owner’s
Manual which can be performed by the customer. b) Damage to equipment not properly
connected to the product. c) Any cost incurred in shipping the product for repair. d)
Damage to the product not used in the USA.
This warranty is not transferable and only applies to the original purchase. Any implied
warranties, including the warranty of merchantability, are limited in duration to the period
of this expressed warranty and no warranty whether expressed or implied shall apply to
the product thereafter.
Under no circumstance shall Craig be liable for any loss or consequential damage arising
out of the use of this product. This warranty gives specific legal rights. However, you may
have other rights which may vary from state to state. Some states do not allow limitations
on implied warranties or exclusion of consequential damage. Therefore, these
restrictions may not apply to you.
This product has been manufactured by and is sold under the responsibility of Craig
Electronics Inc, and Craig Electronics Inc is the warrantor in relation to this product.
MAGNAVOX and SMART. VERY SMART are registered trademarks of Koninklijke Philips
N.V. and are used under license from Koninklijke Philips N.V.
To Obtain Service on your Product
email:service@craigelectronics.com
Printed in China MMA3640_WC_E0CL1_B0WU
LIMITED WARRANTY
FCC warning
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure requirement. The
device can be used in portable exposure condition without restriction.
