Junlan Electronic TDV31120 10 inch BLUETOOTH PDVD BUNDLE User Manual 1
Shenzhen Junlan Electronic Ltd 10 inch BLUETOOTH PDVD BUNDLE 1
User manual
PRODUCT GUIDE
BC MODEL:ONA17AV048
10 INCH BLUETOOTH
PORTABLE BUNDLE
2
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CAUTION:
THIS DIGITAL VIDEO DISC PLAYER
EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS
PRODUCT.
PLEASE READ THIS OWNER`S MANUAL
CAREFULLY AND RETAIN FOR FUTURE
REFERENCE. SHOULD THE UNIT
REQUIRE MAINTENANCE, CONT ACT AN
AUTHORIZED SERVICE LOCATION-SEE
SERVICE PROCEDURE.
USE CONTROLS, ADJUSTMENTS OR
THE PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO
LASER BEAM, DO NOT TRY TO OPEN THE
ENCLOSURE. VISIBLE LASER RADIATION
MAY BE PRESENT WHEN THE ENCLOSURE
IS OPENED. DO NOT STARE INTO BEAM.
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
WARNING:
TO REDUCE THE RISK OF FIRE OR
E L E C T R I C S H O C K , A N D A N N O Y I N G
INTERFERENCE, USE THE RECOMMENDED
ACCESSORIES ONLY.
SURGE PROTECTORS:
It is recommended to use a surge protector for
AC connection. Lightning and power surges
ARE NOT covered under warranty for this
product.
FCC NOTICE:
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not Installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
● Reorient or relocate the receiving
antenna. Increase the separation between
the equipment and receiver.
● Connect the equipment into an outlet
on a circuit different from that to which the
receiver is connected.
● Consult the dealer or an experienced
radio/TV technician for help.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Increase the separation between the equi-
pment and receiver.
The lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product`s enclosure that may
be of sufcient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance(servicing) instructions in the
literature accompanying the appliance.
DANGER:
Invisible and hazardous laser
radiation when open and interlock
failed or defeated. Avoid direct
exposure to beam.
Warning:Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.”
3
WARNING
USE UNDER SUPERVISION OF AN ADULT
DUE TO LONG CORD
This unit has a long AC cord or other long
cord that can easily be tripped on or pulled on,
causing injury, Please make sure it is arranged
so it will not drape over a tabletop, etc. Where
it can be pulled on by children or tripped over
accidentally.
EXERCISE CAUTION AS UNIT HAS SHARP
POINTS.
Before using the unit, be sure to read all
operating instructions carefully. Please note
that these are general precautions and may
not pertain to your unit.
1 ) Read these instructions.
All the safety and operating instructions should
be read before the product is operated.
2 ) Keep these instructions.
The safety and operating instructions should
be retained for future reference.
3 ) Heed all warnings.
All warnings on the product and in the
operating instructions should be adhered to.
4 ) Follow all instructions.
All operating and use instructions should be
followed.
5 ) Do not use this apparatus near water.
Do not use this product near water and
moisture, for example: near a bathtub,
washbowl, kitchen sink or laundry tub; in a wet
basement; or near a swimming pool.
6 ) Clean only with dry cloth.
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a dry cloth for cleaning.
7)Do not block any ventilation
openings. Install in accordance with the
manufacturer's instructions.
Slots and openings in the cabinet and in the
back or bottom are provided for ventilation, to
ensure reliable operation of the product and
to protect it from overheating. These openings
must not be blocked or covered. The openings
should never be blocked by placing the product
on a bed, sofa, rug or other similar surface.
This product should never be placed near or
over a radiator or heat source. This product
should not be placed in a built-in installation
such as a bookcase or rack unless proper
ventilation is provided or the manufacturer's
instructions have been adhered to.
8 ) Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus(including amplifiers) that produce
heat.
9 ) Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug
has two blades with one wider than the other. A
grounding type plug has two blades and a
third grounding prong. The wide blade or the
third prong are provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10 ) Protect the power cord from being
walked on or pinched particularly at plugs,
convenience
receptacles, and the point where they exit from
the apparatus.
11 ) Only use attachments/accessories
specied by the manufacturer.
12 ) Use only with the cart, stand, tripod,
bracket, or table specied by the manufacturer,
or sold with the apparatus. When a cart is
used, use caution when
moving the cart/apparatus
combination to avoid injury
from tip-over.
An appliance and cart
combination should be
4
moved with care.
Quick stop, excessive force and uneven
surfaces may cause the appliance and cart
combination to overturn.
13 ) Unplug this apparatus during lightning
storms or when unused for long periods of
time.
To protect your product from a lightning storm,
or when it is left unattended and unused for
long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable
system.
This will prevent damage to the product due to
lightning and power-line surges.
14 ) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus
has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture does not operate normally, or
has been dropped.
15 ) Power source.
This product should be operated only from the
type of power source indicated on the marking
label.
If you are not sure of the type of power supply
to your home, consult your appliance dealer or
local power company. For products intended
to operate from battery power, or other source,
refer to the operation instructions.
16 ) Power lines
An outside antenna system should not be
located in the vicinity of overhead power lines
or other electric light or power circuits, or where
it can fall into such power lines or circuits.
When installing an outside antenna system,
extreme care should be taken to keep from
touching such power lines or circuits as contact
with them might be fatal.
17 ) Overloading
Do not overload wall outlets and extension
cords as this can result in a risk of fire or
electric shock.
18 ) Object and liquid entry
Never push objects of any kind into the
product through openings as they may touch
dangerous voltage points or short out parts
that could result in re or electric shock. Never
spill or spray any type of liquid on the product.
19 ) Outdoor antenna grounding
If an outside antenna is connected to the
product, be sure the antenna system is
grounded so as to Provide some protection
against voltage surges and built up static
charges. Section 810 of the National Electric
Code ANSI/NFPA 70 provides information with
respect to proper to grounding of the mast and
supporting structure, grounding of the lead-
in wire to an antenna discharge product, size
of grounding conductors, location of antenna-
discharge product, connection to grounding
electrodes and requirements for the grounding
electrodes.
20 ) Service
Do not attempt to service this product yourself
as opening or removing covers may expose
you to dangerous voltage or other hazards.
Refer all servicing to qualified service
personnel.
21 ) Replacement parts
When replacement parts are required, be sure
the service technician uses replacement parts
specified by the manufacturer or those that
have the same characteristics as the original
parts.
Unauthorized substitutions may result in re or
electric shock or other hazards.
22 ) Safety check
Upon completion of any service or repairs
ANTENNA LEAD
IN WIRE
ANTENNA DISCHARGE UNIT
( NEC SECTION 810-20 )
GROUNDING CONDUCTORS
( NEC SECTION 810-21 )
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
( NEC ART 250, PARTH )
GROUND CLAMPS
5
to this product, ask the service technician to
perform safety checks to determine that the
product is in proper operational condition.
23 ) Wall or ceiling mounting
The product should be mounted to a wall
or ceiling only as recommended by the
manufacturer.
24 ) Damage requiring service
Unplug this product from the wall outlet and
refer service to qualified service personnel
under the
following conditions.
a ) When the power-supply cord or plug is
damaged.
b ) If liquid has been spilled or objects have
fallen into the product.
c ) If the product has been exposed to rain or
water.
d ) If the product does not operate normally
by following the operating instructions. Adjust
only those controls that are covered by the
operating instructions, as an adjustment of
other controls may result in damage and will
and require extensive work by a qualified
technician to restore in the product to its
normal operation.
e ) If the product has been dropped or the
cabinet has been damaged.
in performance-this indicates a need for
service.
25 ) Note to CATV system installer
This reminder is provided to call the CATV
system installer's attention to Article 820-40
of the NEC that provides guidelines for proper
grounding and, in particular, specifies that
the cable ground shall be connected to the
grounding system of the building, as close to
the point of cable entry as practical.
NOTE: Refer all servicing to qualied service
personnel Servicing is required when the unit
has been damaged in any way such as the
has been damaged, liquid has been spilled
into unit, the unit has been exposed to rain or
moisture, the unit has been dropped or the unit
does not operate normally.
NOTES ON HANDLING:
● When shipping the unit, always use the
original shipping carton and packing materials.
For maximum protection, repack the unit as it
was originally packed at the factory.
● Do not use volatile liquids, such as insect
spray,
near the unit. Do not leave rubber or plastic
products in contact with the unit for a long time.
They will leave marks on the nish.
● The top and rear panels of the unit
may become warm after a long period of use.
This is normal and not a malfunction.
● When the DVD player is not in use, be sure
to remove the disc and turn off the power.
NOTES ON LOCATING THE DVD PLAYER:
When you place this unit near a TV, radio or
VCR, the playback picture may become poor
and the sound may be distorted. In this case,
move the unit away from the TV, radio or VCR.
NOTES ON CLEANING:
Use a soft, dry cloth for cleaning
● For stubborn dirt, soak the cloth in a weak
detergent solution, wring well and wipe. Use a
dry cloth to wipe it dry. Do not use any type of
solvent, such as thinner and benzene, as they
may damage the surface of the unit.
● If you use a chemical-saturated cloth to clean
the unit, follow that product's instructions.
Warning: Cleaning and adjustment of
lenses and /or other components of playback
mechanism should be performed by a qualied
service technician.
NOTES ON MOISTURE CONDENSATION:
Moisture condensation damages the DVD
player.
Please read the following carefully.
● Moisture condensation occurs, for example,
when you pour a cold drink into a glass on a
warm day. Drops of water form on the outside
f ) When the product exhibits a distinct change
following: the power-supply cord or plug
6
of the glass. In the same way, moisture may condense on the optical pick-up lens inside this unit,
one of the most crucial internal parts of the DVD player.
Moisture condensation occurs during the following cases:
● When you bring the DVD player directly from a cold place to a warm place.
● When you use the DVD player in a room where you just turned on the heater, or a place where the
cold wind from the air conditioner directly hits the unit.
● ln summer, when you use the DVD player in a hot and humid place just after you moved the unit
from an air conditioned room.
● When you use the DVD player in a humid place.
Do not use the DVD player when moisture condensation may occur.
● lf you use the DVD player in such a situation, it may damage discs and internal parts. Remove the
disc, connect the AC/DC Adaptor to the DVD player and the wall outlet, turn on the DVD player and
leave it ON for two or three hours. After two or three hours, the DVD player will have warmed up
and evaporated any moisture.
7
The region number for this DVD Player is: 1
See the following page for information regarding region numbers.
PLAYABLE DISCS:
The following discs can be played back on this DVD player:
DISC TYPES:
DVD
Data on most DVDs is divided into sections called titles
and then into subsections called chapters, each of which
is given a title or chapter number. Some features of this
DVD player will not operate with some DVD discs as they
are preset. If a function you selected does not run as
desired , refer to the manual accompanying the DVD disc.
AUDIO CD
Data on an audio CD is divided into sections called tracks ,
each of which is given a track number.
IMPORTANT:
It is important that you read the manual that accompanies the DVD disc , as there are features that
are on the DVD player that cannot be used with certain DVDs .
There are also extra features on the DVD disc that are different for each DVD disc, so they are not
explained in this owner's manual.
This player conforms to the NTSC and PAL color systems . However , if you are in the USA , Canada
or Mexico,leave this setting on NTSC . If incorrectly set to PAL ,the TV picture may roll vertically. In
this case , set the TV system to NTSC.
Notes on Copyright:
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public and rent
copyrighted material without permission. DVD video discs are copy protected, and any recordings
made from these discs will be distorted. This product incorporates copyright protection technology
that is protected by method claims of certain U.S. Patents and other intellectual property rights
owned by Macrovision
Macrovision Corporation, and is intended for home and other limited viewing uses only, unless
otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Region Management Information:
This DVD Player is designed and manufactured to respond to the Region Management Information
that is recorded on a DVD disc. If the Region number described on the DVD disc does not
correspond to the Region number of this DVD player, this DVD player cannot play that disc. You may
not be able to play back some DVD video discs on this player if they were purchased from outside
your geographic area or made for business purposes. When you try to play back an unauthorized
disc, Wrong Region appears on the TV screen.
1
ABOUT DISCS
8
STOP
BT PAIR
SOURCE
DVD/USB/CARD
1
2
3
4
56
78
910
11
12
13
1. SETUP Button: Press to enter SETUP system, press again to exit.
2. BT PAIR Button: Press to disconnect the connection with headphone.
3. (Previous/Cursor Up)
(Next/Cursor Down)
(Fast backward/Cursor Left)
(Fast forward/Cursor Right)
OK Button: Press to confirm the operation.
4. MENU Button: Press to enter root menu playing(it depens on the disc recording).
5. SOURCE Button: Press to enter AV IN mode, press again to resume normal mode.
6. STOP Button: Press once to pre-stop, press again to fully stop.
7. PLAY/PAUSE Button: Press to start playing or pause.
8. VOL+ Button: Press to increase volume.
9. VOL- Button: Press to decrease volume.
10. DVD/USB/CARD Button: Press to display the sources(DVD, CARD, USB), using the direction
11. AUDIO Button: Press repeatedly to switch the audio mode.
12. MUTE Button: Press to turn off the sound, press again to resume.
13. OPEN Button: Press to open the disc cover.
button to select the desired source, and press OK button to confirm.
LOCATION OF CONTROLS
9
Right Side View:
Front Side View:
14 15 16 17 18 19 20
212223
14. USB Port
15. SD/MMC CARD Slot
16. Headphone Jack
17. AV OUT Jack
18. AV IN Jack
19. Power ON/OFF Switch
20. DC IN Jack
21. Charge Indicator 22. Remote Sensor 23. Bluetooth/Power Indicator
LOCATION OF CONTROLS
10
1
2
3
4
5
6
7
89
10
11 12
13
14
15
SOURCE
16
17
18
19
20
21
22
23
24
25
26
27
28
1. SOURCE Button
2. VOLUME +/– Buttons
4. MENU Button
ŻŻ
7.
ǿŻŻ
6. Button
12.
15. SLOW Button
Button
16. LCD ON/OFF Button
17. Numeric Buttons
18. SETUP Button
19. Button
ǿŻŻ
20. Button
ŻŻ
21. OSD (On Screen Display Button
22. SUBTITLE Button
23. ANGLE Button
24. PROG (Program Button
26. STEP Button
27. ZOOM Button
28. A-B Repeat Button
9.
TITLE Button
8.
USB/CARD Button
10.
AUDIO Button
REPEAT Button
13.
11. (
14.
GOTO Button
OK
25. Button
3. MUTE Button
5. Direction Buttons
( Play/Pause Button
6723 %XWWRQ
Ŷ
MENU
TITLE
OK
REMOTE CONTROL
11
BATTERY INSTALLATION (REMOTE CONTROL)
Remote Control Sensor
Remarks:
1. When there is an obstacle between the unit and the transmitter, the transmitter may not operate.
2. When direct sunlight, an incandescent lamp, fluorescent lamp or any other strong light shines on the
remote control of the unit, the remote operation may be unstable.
POWER
Battery installation:
1. Press the tab on the battery door and lift it off.
2. Install two (2) x AAA size batteries (not included) into the battery
compartment as the figure on right and the polarity
markings inside battery compartment.
3. Replace the battery door.
Battery Precautions:
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Besure to follow the correct polarity when installing the battery as indicated in
the battery compartment. A reversed battery may cause damage to the device.
batteries to prevent damage or injury from possible battery leakage.
manufacturer's directions).
6. Do not dispose of battery in fire. Battery may explode or leak.
7. Clean the battery contacts and also those of the device prior to battery installation.
3. Do not mix different types of batteries together (e.g. Alkazline and Carbon-zinc)
or old batteries with fresh ones.
4. If the batteries in the device are consumed or the device is not to be used for a long period
of time, remove the
5. Do not try to recharge the battery not intended to be recharged; it can overheat and rupture.
(Follow battery
12
The unit has a built-in DC 7.4V Lithium-ion rechargeable battery.
Connect the small plug from the supplied AC/DC Adaptor to the DC IN Jack on the right of unit.
Connect the AC/DC Adaptor to the wall outlet having
During charging, the
1%7KH$&'&$GDSWRULVLQWHQGHGWREHFRUUHFWO\RULHQWDWHGLQD
Your battery will last longer if you follow these simple guidelines for caring for and storing it.
Recharge and store the device within the temperature range of 5°C~35°C (40°F~95°F).
Do not overcharge (longer than 24 hours). Excessive charging or
Battery life naturally shortens slowly over time.
2. This is a special negative grounded
Car Adapter. Using this Car Adapter
with a plus grounded car can cause
malfunction.
3. Do NOT plug in the Car Adapter until
the car ignition is turned on.
4. Disconnect the Car Adapter from the
cigarette lighter and the unit after use.
To DC IN Jack on the unit
as follows:
Charging Indicator will light up red. When finished, it will turn green.
discharging may shorten the
battery’s life.
1. Connect to the cigarette lighter socket of a vehicle that has a 12V battery as the figure below.
AC 100-240V~; 50/60Hz.
POWER SOURCE
Recharge it
YHUWLFDORUÀRRUPRXQWSRVLWLRQ
To the cigarette
lighter socket
NOTES:
Charging by the car adaptor:
Charging by the AC/DC adaptor:
1.
2.
3.
A.
B.
C.
It is NOT compatible w ith a vehicle that has a 24V battery.
13
Audio/Video cable
Connected to the TV Connected to the Video Player
AUDIO OUT
LR
120V ~ 60Hz
VIDEO OUT
VIDEO
Video Player
DIGI TAL
Video input jack ( Yellow )
Audio left channel input jack ( White )
Audio right channel input jack ( Red )
NOTE:
CONNECTIONS
Connecting to a TV or Video Player such like DVD; VCR; DVR Players ... (AV connection cable not included)
The default setting of the unit is AV Out, if connect to external Video
to turn back to AV Out mode.
Player (such like DVD;
VCR; DVR Players ... ), press the SOURCE Button to set to AV IN mode ("AV IN" will appear
on the screen). Press again
The unit itself may not display when connecting through AV OUT jack.
Using the supplied Headphone to listen privately.
-Switch on the unit, the Bluetooth Indicator will blink.
-Switch on the Headphone, it will connect with the unit automatically after a few seconds.
-The Bluetooth Indicator will stay lit when pairing is successful.
The unit itself may not display when connecting through AV OUT jack.
Using the supplied Headphone to listen privately.Using the supplied Headphone to listen privately.
14
a
d
c
b
180°
The viewing angle of the swivel panel can be adjusted as follows:
SWIVEL PANEL
15
3. During playback:
~ Press the or Buttons repeatedly to fast search for a specific section forward/backward.
Press Button to resume normal playback.
~ Press the or Buttons repeatedly to skip to specific track.
~ Press Button to pause, press Button again to resume normal playback.
Repeat Playback:
Press the REPEAT button twice to Repeat Title, then the current Title will playback repeatedly.
Press the REPEAT button the third time to Repeat All then all files will playback repeatedly.
~ Press the VOL (Volume) +/- Buttons to adjust volume level.
(CD)
Repeat Playback:
During playback, press the REPEAT Button once to Repeat Track, then the current track will playback repeatedly.
the Power ON/OFF switch to "ON" position to power on the unit.
2. Press the OPEN button to open the disc cover. Place the disc on the center spindle with the label side facing up.
Close the disc door and the player will start playback automatically.
1. Lift up the panel and turn to desired angle. Slide
~ Press the STOP Button to stop playback. The player will remember the point where disc was stopped.
Press the STOP Button again to fully stop, press the Button to start playback from beginning.
Press the REPEAT button repeated until the repeat mode cancelled to turn off repeat mode.
During playback, press the REPEAT button once to Repeat Chapter, then the current chapter will playback repeatedly.
OPERATIONS
(DVD)
352*press the
1. During CD or DVD playback, ( Program )
4. Using the Direction Button to select and highlight the "PLAY" or Button on the screen then press the OK
Button to start program playback.
(CD/DVD)Program:
2. Using the Direction and Numeric Buttons to select and set the desired TT (Title), CH (Chapters), tracks (for CD)
of the movie /music you wants. The Program menu will appear as follows.
button.
DVD CD
When press the Button again, playback will start from this point.
Press the REPEAT button twice to Repeat All then all files will playback repeatedly.
Press the REPEAT button repeated until the repeat mode cancelled to turn off repeat mode.
T C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
T C T C T C
01:03
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
PLAY CLEAR
TRACK01
TRACK02
TRACK03
TRACK04
TRACK05
TRACK06
2/16
TRACK03
TRACK04
there is wrong programming.
clear all the programmed items when
3. Using the Direction Button to select and highlight the "CLEAR" or Button on the screen then press the
OK Button to
16
SOURCE
VOL/Volume +/–
Press to increase or decrease volume.
MUTE
Press to turn to "AV IN" mode. Press again to resume.
LCD ON/OFF
Press to turn on or off the LCD display.
SUBTITLE
Press to turn off the sound, press again to resume.
During DVD playback, press repeatedly to select the
desired subtitle (Function depends on the recording
of disc).
OPERATIONS
TITLE
depends on the recording of the disc).
Press to return to disc's title page (Function
MENU
depends on the recording of the disc).
Press to return to disc's menu page (Function
OSD (On Screen Display)
During playback, press the OSD button repeatedly to
read the information of playback status.
STEP
During movie playback, press STEP Button repeatedly
to play the movie frame by frame.
Press the Play/Pause Button to resume normal
playback.
SLOW
A-B Repeat
During Playback, press the A-B Button to define where
you want the section to start. Press the A-B Button again
to define where you would like the section to end, the
unit will then plays the selected section repeatedly
and continuously. Press the A-B Button again to resume
normal playback.
(This function is not available on all discs).
During playback, press the SLOW Button repeatedly
to set the slow motion speed. Press Play/Pause
Button to resume normal playback.
GOTO
AUDIO
During DVD playback, press repeatedly to select the
audio mode. (Function depends on the recording
of disc).
Press the GOTO Button, set the desired Title and
Chapter and Time, press the OK button to confirm.
ANGLE
(Function depends on the recording of
During DVD playback, press repeatedly to select the
viewing angle
disc).
ZOOM
During movies playback, press the ZOOM Button
repeatedly to zoom in/out the picture.
17
1. Insert the USB Device or SD/MMC memory card into the USB port /card slot as the gure below.
NB: The unit supported to playback:
~ MP3; WMA (Music le)
~ JPG (Pictures)
Make sure correct les were saved in the USB device or memory cards.
USB or CARD PLAYBACK
3. During playback:
~ Press the or Button repeatedly to skip tracks.
~ Press the Button to pause. Press again to resume.
ǿŻŻ
ǿŻŻ
2. Switch on the unit, press the USB/CARD Button on remote control or press the DVD/USB/CARD
Button on the unit, the "DVD, CARD, USB" selection window will pop up on the screen.
Using the Direction Buttons to select and highlight the desired source then press the OK Button
to confirm to start playback.
18
◄,►,▲,▼need to set or reset. Press the OK
Button to enter or confirm the selection. After setting, press the SETUP Button to save the settings and exit.
Press the SETUP Button, the setting menu will appear on the screen as below. During setting, using the
Direction Buttons to select and highlight the function you
4. If TV type is selected, set the aspect ratio to match the connected TV.
SETUP
Tv System
POWER RESUME
Screen Saver
TV Type
Password
Rating
Default
SYSTEM SETUP
1. If Tv System is selected, it can only be set to NTSC, PAL or AUTO to match the connected TV.
2. If POWER RESUME is selected, if set it On,the unit will start playback from the position where the disc was
stopped last time.
3. If Screen Saver is selected, if set to On, the screen saver will come on when the unit idles or the image is
paused for several minutes.
5. If Password is selected, input the default password "0000" to unlock the rating.
SY ST E M SE T U P:
(R):Under17yearsold,ParentalGuidancestrongly
(PG): Parental Guidance
(PG13): Parental Guidance less than 13 years old
(PG-R): Under 17 years old, Parental Guidance suggested
(NC-17): 17 years old or above
6. If Rating is selected, the rating level will appear as below, set to the desired level as need.
(ADULT): Adult only
(KID SAFE): Kid Safe
(G): All ages
7. If Default is selected and set it to restore, all settings will be restored to factory setting.
LANGUAGE SETUP
Osd Language
Audio Lang
Subtitle Lang
Menu Lang
SE T U P:L AN GU AGE
Select Osd language(on screen display), Audio Lang, Subtitle Lang or Menu Lang separately to set to disired language.
19
SYSTEM SETUP
AUDIO SETUP
Key
SE T U P:AU DIO
Select the audio setup to set the audio key level.
VIDEO SETUP
Brightness
Contrast
Hue
Saturation
SE T U P:
Select the video setup to set the panel quality such as brightness, contrast, hue and saturation.
DIGITAL SETUP
Dual Mono
DIGIT AL
In digital setup menu, you can set to Stereo, Mono L, Mono R or Mix Mono.
#
+4
+2
0
-2
-4
b
Stereo
Mono L
Mono R
Mix Mono
20
Treat the disc carefully. Handle the disc only by its edges.
Never allow your ngers to contact with the shiny, unprinted side of the disc.
● Do not attach adhesive tape, stickers, etc. to the disc label.
● Clean the disc periodically with a soft, lint-free,dry cloth, Never use detergents or abrasive cleaners
to clean the disc. If necessary, use a CD cleaning kit.
● If a disc skips or gets stuck on a section of the disc, it is probably dirty or damaged(scratched).
● When cleaning the disc, wipe in straight lines from the center of the disc to the outer edge of the
disc. Never wipe in circular motions.
● Discs should be stored in their cases after each use to avoid damage.
● Do not expose discs to direct sunlight, high temperatures or dust, etc. Prolonged exposure or
extreme temperatures can warp the disc.
● Do not stick or write anything on either side of the disc. Sharp writing Instruments, or the ink, may
damage the surface.
Cleaning the Unit
● To prevent re or shock hazard, disconnect your unit from the AC power source when cleaning.
● The nish on your unit may be cleaned with a dust cloth and cared for as other furniture. Use
caution when cleaning and wiping the plastic parts.
● Mild soap and a damp cloth may be used on the front panel.
CARE AND MAINTENANCE
Caring for Discs
21
ACCESSORIES
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Power Source:
Disc Compatibility:
1 x User's Manual
1 x Remote Control
1 x Headphone
SPECIFICATIONS
1 x AC/DC Adaptor
1 x Car Adaptor
DVD/VCD/CD/CD-R/CD-RW/DVD±R/DVD±RW
Power Source: Built-in DC 7.4V Lithium-ion rechargeable battery, recharge by DC 12V, 1000mA
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
LIMITED PRODUCT WARRANTY
This quality product is warranted to be free from manufacturer’s defects in material and workman-ship,
provided that the unit is used under the normal operating conditions intended by the manufacturer.
Should you have any problem with this product, please and it is highly recommended to visit our website at
www.curtisint.com before you take any other steps as we have additional copies of instruction manuals,
operating manuals and trouble shooting tips on our website which gives you the answer on most of the
questions you could have in operating the unit.
TERMS OF WARRANTY
C.I. Service Dept. warrants this product to be free from defects in materials and workmanship for 90 days on
parts and 90 days on labor. If you originally purchased your product more than 90 days ago, a repair fee
may apply.
Nothing within this warranty shall imply that C.I. will be responsible or liable for any damage to any items
placed in this product, whether due to any defect of the product, or its use, whether proper or improper.
EXCLUSIONS
Save as herein provided, C.I. Service Dept. (Canada) or C.I. Service Dept. (USA), there are no other
warranties, conditions, representations or guarantees, express or implied, made or intended by C.I. or its
authorized distributors and all other warranties, conditions, representations or guarantees, including any
warranties, conditions, representations or guarantees under any Sale of Goods Act or like legislation or
statue is hereby expressly excluded. Save as herein provided, C.I. Service Dept. (Canada) or C.I. Service
Dept. (USA), shall not be responsible for any damages to persons or property, including the unit itself,
howsoever caused or any consequential damages arising from the malfunction of the unit and by the
purchase of the unit, the purchaser does hereby agree to indemnify and save harmless C.I. from any claim
for damages to persons or property caused by the unit.
TO OBTAIN REPAIRS UNDER THE TERMS OF THIS WARRANTY
1. The original purchaser must present a copy of the original bill of sale and the service warranty card.
2. Any alterations, abuse, misuse, battery corrosion or accidental damage voids the warranty.
3. The warranty does not cover cabinets and accessories.
4. No warranty or insurance contained or set out shall apply when damage or repair is caused by power
failure; damage in transit or when moving the unit; improper power supply; use for commercial or
industrial purposes; service calls resulting in customer education, etc.
5. The defective product should be mailed to:
Canada U.S.A
C.I. Service Dept. Curtis International Ltd
315 Attwell Drive
Toronto, ON
M9W 5C1
c/o Lotus International Company
6880CommerceBlvd.
Canton MI 48187
U.S.A.
For service assistance and product information, please call: 1-800-968-9853.
If mailing the product, the freight must be prepaid and a money order for $7.00 should be included
to cover the cost of insurance and the return of the product.
6. C.I. reserves the right to repair or replace the parts which have become defective.
Model No. Date Purchased Serial No.
