LCT2518-002C-A

0709TMH-II-IM

LCD Television Users Guide

1080p HDTV

Important Note:

In the spaces below, enter the model and serial number of your television (located at the

rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this

guide. Keep this user’s guide in a convenient place for future reference. Keep the carton

and original packaging for future use.

Model Number:

Serial Number:

POWER

TIMER

MODE TV STB VCR DVD AUDIO

INPUT

123

456

789

0

TUNE TV

RETURN+

iPod MUTING

– CH + – VOL +

RM-C1485

TV

DVR

STATUS

VIDEO GUIDE

TV/VCR SUB T.

SUB CH ML/MTS DISPLAY

SOUND

OK

M

E

N

U

F

A

V

O

R

I

T

E

A

S

P

E

C

T

B

A

C

K

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

PCON

iTV

LT-32P300

LT-42P300

LT-42PM30

LT-46P300

32" class (31.5" Diagonal)

42" class (42" Diagonal)

42" class (42" Diagonal)

46" class (45.9" Diagonal)

As an “ENERGY STAR®” partner, JVC has determined that

this product or product model meets the “ENERGY STAR®”

guidelines for energy efficiency.

Please read the important notice for energy efficiency on page 7.

LCT2518-002C-A.indd 1LCT2518-002C-A.indd 1 6/29/09 3:46:11 PM6/29/09 3:46:11 PM

2

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid improper installation and never position the unit where good ventilation is unattainable.

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair

it yourself or remove the rear cover.

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this TV set for a long period of time, be sure to disconnect both the

power plug from the AC outlet and antenna for your safety.

* To prevent electric shock do not use this polarized plug with an extension cord, receptacle or

other outlet unless the blades can be fully inserted to prevent blade exposure.

Warnings

CAUTION: To reduce the risk of electric shock. Do

not remove cover (or back). No user serviceable

parts inside. Refer servicing to qualified service

personnel.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

The lightning flash with arrowhead

symbol, within an equilateral

triangle is intended to alert the

user to the presence of uninsulated

“dangerous voltage” within the

product’s enclosure that may be of

sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an

equilateral triangle is intended

to alert the user to the presence

of important operating and

maintenance (servicing) instructions

in the literature accompanying the

appliance.

IMPORTANT RECYCLING INFORMATION

This product has a fluorescent lamp that contains mercury. Disposal

of these materials may be regulated in your community due to

environmental considerations. For disposal or recycling information,

please contact your local authorities or for USA, the Electronic Industries

Alliance: http://www.eiae.org

Do not attempt to service the product yourself

Caution

To prevent electrical shock, do not open the cabinet.

There are no user serviceable parts inside.

Please refer to qualifi ed service personnel for repairs.

LCT2518-002C-A.indd 2LCT2518-002C-A.indd 2 6/29/09 3:46:12 PM6/29/09 3:46:12 PM

3

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's

instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug

has two blades with one wider than the other. A grounding type plug has two blades and

a third grounding prong. The wide blade or the third prong are provided for your safety. If

the provided plug does not fit into your outlet, consult an electrician for replacement of the

obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury

from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is damaged,

liquid has been spilled or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

16) Place the television on a stable, flat surface. Failure to do so can result in the television

falling, causing injury.

17) Do not allow young children to play around or on the television. Do not hang from the TV.

Failure to do so can result in the television falling, causing injury.

18) Do not allow young children to play with the plastic bag that came with the television when

you unpacked it. Failure to do so can result in suffocation, causing injury.

19) Avoid improper installation and never position the unit where good ventilation is

impossible. When installing this TV, distance recommendations must be maintained

between the set and the wall, as well as inside a tightly enclosed area or piece of furniture.

Keep to the minimum distance guidelines shown for safe operation.

Important Safety Instructions

150 mm

5 7/8 in

200 mm

7 7/8 in

50 mm

2 in

150 mm

5 7/8 in

200 mm

7 7/8 in

LCT2518-002C-A.indd 3LCT2518-002C-A.indd 3 6/29/09 3:46:12 PM6/29/09 3:46:12 PM

4

20) Cautions for installation

— Do not tilt the TV towards the left or right, or towards the back.

— Install the TV in a corner on the floor so as to keep cords out of the way.

— The TV will generate a slight amount of heat during operation. Ensure that

sufficient space is available around the TV to allow satisfactory cooling.

— Have two people remove the TV from the box with the screen facing away

from you. It's possible your clothing, (such as a belt buckle or button) may

scratch the front of the TV. Do the same when moving the TV to another

location.

21) When attaching to a wall, use the optional JVC wall mounting unit.

For LT-32P300: JVC-XUF-2637 LCD FLAT WALL MOUNT

For LT-42P300 / LT-42PM30: JVC-XUF-2637 LCD FLAT WALL MOUNT

For LT-46P300: JVCPCM-MS2 TILT/FLAT WALL MOUNT

Caution

— Consult qualified installers.

— See the included manual on mounting procedures.

— JVC is not responsible for damages or injuries due to improper mounting.

— Use with other wall mounting unit is capable of resulting in instability or causing possible

injury.

22) Make enough room for inserting and removing the power plug. Place the TV as close

to the outlet as possible. The main power supply for this TV is controlled by inserting or

removing the power plug.

23) Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

24) When this TV is connected to the wall outlet, it is always on standby even when all the LED

lamps are not lit. To shut down the TV, unplug the TV from the wall outlet.

Important Safety Instructions

FCC Notice:

Caution: Changes or modifi cations not expressly approved by party responsible for

compliance could void the user's authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/TV technician for help.

LCT2518-002C-A.indd 4LCT2518-002C-A.indd 4 6/29/09 3:46:12 PM6/29/09 3:46:12 PM

5

Warnings . . . . . . . . . . . . . . . . . . 2

Important Safety Instructions . . . 3

Key Features . . . . . . . . . . . . . . . 6

Logos & Licenses . . . . . . . . . 7

Package Contents . . . . . . . . . 8

TV Basic Controls . . . . . . . . . . . 13

Remote Control . . . . . . . . . . . . . 18

Initial Setup . . . . . . . . . . . . . . . 22

Customizing your TV . . . . . . . 24

Picture . . . . . . . . . . . . . . . . . 26

Video Status . . . . . . . . . . . . . . . . 26

Color Temp . . . . . . . . . . . . . . . . 27

Color Management . . . . . . . . . . . . . 27

Dynamic Gamma . . . . . . . . . . . . . . 27

Smart Picture . . . . . . . . . . . . . . . . 27

Digital VNR . . . . . . . . . . . . . . . . . 27

MPEG NR . . . . . . . . . . . . . . . . . 27

Natural Cinema . . . . . . . . . . . . . . . . . 27

Video Reset . . . . . . . . . . . . . . . . . 27

Display . . . . . . . . . . . . . . . . 28

Video Input Label . . . . . . . . . . . . . . 28

Photo Viewer . . . . . . . . . . . . . . . . 28

Aspect . . . . . . . . . . . . . . . . . . . . 30

TV . . . . . . . . . . . . . . . . . 31

Closed Caption . . . . . . . . . . . . . . . . 31

C.C. Type . . . . . . . . . . . . . . . . . . . 31

C.C. Setting . . . . . . . . . . . . . . . . . . . 31

Tuner Mode . . . . . . . . . . . . . . . . 32

Auto Scan . . . . . . . . . . . . . . . . 32

Add Channel . . . . . . . . . . . . . . . . 32

Edit Channel . . . . . . . . . . . . . . . . 33

V-Chip . . . . . . . . . . . . . . . . 33

Password . . . . . . . . . . . . . . . . 34

MPAA . . . . . . . . . . . . . . . . 35

Can. Eng. . . . . . . . . . . . . . . . . 36

Can. Fre. . . . . . . . . . . . . . . . . 36

Table of Contents

TVPG . . . . . . . . . . . . . . . . . 37

Guide . . . . . . . . . . . . . . . . 37

PC . . . . . . . . . . . . . . . . . 38

Auto Adjustment . . . . . . . . . . . . . 38

Phase Adjustment . . . . . . . . . . . . 38

PC H-Position . . . . . . . . . . . . . . . . 38

PC V-Position . . . . . . . . . . . . . . . . 38

Reset . . . . . . . . . . . . . . . . . . 38

Sound . . . . . . . . . . . . . . . . . 39

MTS . . . . . . . . . . . . . . . . 39

Digital Audio (ML) . . . . . . . . . . . . 39

Surround . . . . . . . . . . . . . . . . 39

Sound Status . . . . . . . . . . . . . . . . 39

Audio Reset . . . . . . . . . . . . . . . . 39

Power . . . . . . . . . . . . . . . . . 40

Power Indicator . . . . . . . . . . . . 40

Illumination . . . . . . . . . . . . . . . . 40

Setting . . . . . . . . . . . . . . . . . 41

Plug-In Menu . . . . . . . . . . . . . . . . 41

Time Zone . . . . . . . . . . . . 41

D.S.T. . . . . . . . . . . . . . . . . 41

Language . . . . . . . . . . . . . . . . 41

Noise Mute . . . . . . . . . . . . 41

Front Panel Lock . . . . . . . . . . . . 41

Transparency . . . . . . . . . . . . 41

Auto Shut Off . . . . . . . . . . . . . . . . 41

Control with HDMI . . . . . . . . . . . . . 42

System Info . . . . . . . . . . . . . . . . 42

Auto Demo . . . . . . . . . . . . 42

Optical Out . . . . . . . . . . . . 43

PC Smart Input . . . . . . . . . . . 43

Sync Mode . . . . . . . . . . . . . . 43

Enjoy Movies/Music from your

iPod . . . . . . . . . . . . . . . . . . 44

Programming Your Remote . . . . 51

Programming Codes . . . . . . . 53

Connecting Your Devices . . . . . 58

Troubleshooting . . . . . . . . . . . . 64

Specifi cations . . . . . . . . . . . . 66

Warranty . . . . . . . . . . . . 67

Getting Started

Basics

Advanced

Etc.

LCT2518-002C-A.indd 5LCT2518-002C-A.indd 5 6/29/09 3:46:12 PM6/29/09 3:46:12 PM

6

Your JVC TV is equipped with many features. Here is some key features

highlighted in detail.

Dock

Dock Adapter

(supplied with iPod or separately purchased)

1 Simple playback of video and music on

TV. You can charge your iPod. You

can watch a program while listening

to the iPod (source of program must

be from TV’s Internal Tuner). You

can view photos from the iPod while

listening to the iPod.

2 Stunning picture quality via 1920x1080 Full HD panel.

Dynamic Gamma and Color Management give further

fi ne tuned picture reproduction. Smart Picture adjusts the

best possible picture quality automatically scene by scene

based on the incoming signal from any source!

3 JVC exclusive oblique cone speakers provide excellent

TV sound quality. OmniSurround sound provides you 4

different settings based on the program you are watching.

The equalizer will fi ne tune your listening preferences.

4 Full connectivity with 3 HDMI, 2 Component, 1 S-video and others. The variety of

connections are explained in pages 58 to 63.

x 3 x 2 x 1

5 Aspect mode will show every pixel you are getting in High Defi nition. The Full Native mode

will show 100% of 1080p. Full – with slight overscan. Panorama, Cinema will fi ll the screen

with various aspect settings.

Full or Widescreen Mode

Key Features

LCT2518-002C-A.indd 6LCT2518-002C-A.indd 6 6/29/09 3:46:12 PM6/29/09 3:46:12 PM

7

Logos & Licenses

As an “ENERGY STAR®” partner, JVC has determined that

this product or product model meets the “ENERGY STAR®”

guidelines for energy efficiency.

iPod is a trademark of Apple Inc.,

registered in the U.S. and other countries.

Manufactured under license from Dolby Laboratories. "Dolby", and

the double-D symbol are trademarks of Dolby Laboratories.

HDMI, the HDMI Logo and High-Defi nition

Multimedia Interface are trademarks or

registered trademarks of HDMI Licensing LLC.

Getting started

Notice:

• The open source software is embedded in this product. For more information, please go to:

http://software.jvc.com/opensource/lnx/DP/08_AtscQam_T/download.html

This JVC Television is factory set to “Home” mode, which is optimized for normal home viewing.

This setting reduces power consumption to help the environment and to comply with ENERGY

STAR® qualifi cation.

Enabling certain features and functionality in this TV (e.g., Video Status) may increase its energy

consumption, possibly beyond the limits required for ENERGY STAR® qualifi cation.

LCT2518-002C-A.indd 7LCT2518-002C-A.indd 7 6/29/09 3:46:13 PM6/29/09 3:46:13 PM

8

Use two “AA” batteries (included).

Place the "–" end in the unit first, making sure the "+" and "–" markings are correct. Place the

"–" end in the unit first.

POWER

TIMER

MODE TV STB VCR DVD AUDIO

INPUT

123

456

789

0

TUNE TV

RETURN+

iPod MUTING

– CH + – VOL +

RM-C1485

TV

DVR

STATUS

VIDEO GUIDE

TV/VCR SUB T.

SUB CH ML/MTS DISPLAY

SOUND

OK

M

E

N

U

F

A

V

O

R

I

T

E

A

S

P

E

C

T

B

A

C

K

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

PCON

iTV

+

AA Alkaline

–

+

AA Alkaline

–

AA Batteries x 2

Television x 1 Remote Control x 1

Bottom Cover x 1 Screw x 1

Insert the batteries

If this symbol is shown, it is only

valid in the European Union

Package Contents

LCT2518-002C-A.indd 8LCT2518-002C-A.indd 8 6/29/09 3:46:13 PM6/29/09 3:46:13 PM

9

Caring for the frame and stand

Caring for the Screen

Your TV has a glossy frame and stand which have protection sheets attached to them. Peel

them off before use, but only after the TV has been properly placed. Take care with handling

the glossy frame and stand because these surfaces are delicate.

Normally, light dusting with a soft, non-scratching duster will keep your TV clean.

If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly

moistened with water. You can add a few drops of mild liquid detergent to the water to help

remove spots of oily dirt.

• DO NOT allow liquid to enter the TV through the ventilation slots.

• DO NOT use strong or abrasive cleaners on the TV.

• DO NOT spray liquids or cleaners directly on the TV’s surface.

• DO NOT rub or scrub the TV harshly. Wipe the set gently with a soft cloth.

The screen is treated with an electrostatic-proof coating. When it gets dirty, wipe it gently with a

soft cloth. If the screen is very dirty, wipe it down with a cloth dipped in a diluted kitchen cleaner

and thoroughly wrung-out. Then wipe immediately after with a clean, dry cloth.

• DO NOT apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the

screen. These will remove the coating layer and cause discolorations.

• DO NOT push or hit the screen. This could cause scratches on the screen surface and image

distortions.

Frame

Stand

Getting started

LCT2518-002C-A.indd 9LCT2518-002C-A.indd 9 6/29/09 3:46:14 PM6/29/09 3:46:14 PM

10

Displaying fi xed images for extended periods of time can leave a subtle but temporary burn-in

image on your screen. To avoid this, mix your viewing pattern.

Examples include, but are not limited to the following:

Avoiding Temporary Burn-in

XYZ XYZ

TV on TV off

For example...

• Stock-market report bars

• Shopping channel logos and pricing

displays

• Video game patterns or scoreboards

• Bright station logos

• Internet web sites or other computer-style

images

• DVD discs, video tapes, laser discs

• Broadcast, cable, satellite channels or

digital television tuners/converters

Package Contents

The LT-46P300 has one screw on the back panel hole for safety use. Please remove the screw

when you are attaching a wall mounting unit and placing the TV onto a wall.

Disconnecting the back panel screw

LCT2518-002C-A.indd 10LCT2518-002C-A.indd 10 6/29/09 3:46:14 PM6/29/09 3:46:14 PM

11

Install your TV

To prevent the TV from falling, thread the belt through the hole on the back of the stand and

secure it to the TV rack.

Belt and screw (not included)

Hole

Connect the stand

The LT-32P300 TV stand is not attached to the TV when you purchased it. Please follow the

steps below on how to connect the stand to the TV.

1) Insert the TV stand onto the TV. 2) Tighten the 5 screws to the back of the TV.

Tidying the cables

A cable holder which keeps your connection cables tidy is attached to the back of the stand.

Getting started

LCT2518-002C-A.indd 11LCT2518-002C-A.indd 11 6/29/09 3:46:15 PM6/29/09 3:46:15 PM

12

Disconnecting the stand

If you disconnect the stand, attach the bottom cover and the screw (supplied) into the hole.

1) Place the TV face down on a soft cloth on a table.

2) Remove the screws from the back of the TV.

3) Pull out the stand from the TV.

4) Cover the hole with the supplied bottom cover and tighten the screw.

Notes:

• To re-install the stand, reverse the procedure from 4) to 1).

• If you fi nd it diffi cult to remove the screws from inset screw wells, use a magnetized

screwdriver.

Package Contents

LCT2518-002C-A.indd 12LCT2518-002C-A.indd 12 6/29/09 3:46:16 PM6/29/09 3:46:16 PM

13

Notes:

• Do not use unreasonable force to the

Dock.

• When not using the Dock, close the

cover.

• Do not touch the connector pins of the

Dock or the iPod terminal pins.

• Do not put different devices on the

Dock. It may cause a connection

failure.

Front Panel

Side Panel

INPUT

MENU

CHANNEL

VOLUME

OK

BACK

POWER

PHOTO VIEWER

TV Basic Controls

Dock

Diffuser Illumination

Remote Control Sensor

Input

Change the input

MENU

Used to access the TV’s onscreen

menus.

+CHANNEL–

Move sequentially through the

channels.

+VOLUME–

Raises or lowers the volume.

POWER

Turn the TV on or off.

Photo Viewer Connector

3

1

6

4

3

2

1

2

5

3

1

6

4

2

5

Basics

32

1

4

Power Lamp

4

Note:

• Do not use Photo Viewer connector

to connect the iPod

LCT2518-002C-A.indd 13LCT2518-002C-A.indd 13 6/29/09 3:46:16 PM6/29/09 3:46:16 PM

14

TV Basic Controls

Rear Panel

3

8

4

2

5

7

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

* This is used when you are using

DVI analog audio

6

1

1HDMI™ Connector

9

10

LCT2518-002C-A.indd 14LCT2518-002C-A.indd 14 6/29/09 3:46:17 PM6/29/09 3:46:17 PM

15

Before you connect your television to another device, please refer to the proper diagrams for

your specific TV and remote. These will help assist you in understanding how to connect your

television to another device, as well as use the remote to set up your television. Some of the

connection terminals are color coded for easy connection with the proper cables.

To find the best possible connection that your device can use, see pages 16 - 17.

For more detailed information about connecting external devices, see pages 58 - 63.

Game Console

Video Camera

STB (Digital Cable,

satellite) Tuner Box

DVD Player

HDMI

(INPUT 1, 2, or 3)

DVI ANALOG AUDIO

Composite / Component

(INPUT 4 or 5)

S-Video

3

1

6

4

2

5

DIGITAL AUDIO

OPTICAL OUT

AUDIO OUT

Antenna / Cable

7

8Audio System

PC

D-SUB

USB type B (for PC)

See page 50.

9

10

PC (with HDMI)

Basics

LCT2518-002C-A.indd 15LCT2518-002C-A.indd 15 6/29/09 3:46:17 PM6/29/09 3:46:17 PM

16

Best

Good

Video Connection Connection Cable TV Connection

HDMI HDMI Cable INPUT 1, 2 or 3

DVI + Audio

DVI – HDMI Cable,

Audio Cable

Input 1 +

DVI ANALOG AUDIO

Component

Video + Audio

Component

Video + Audio INPUT 4 or 5

S-Video + Audio

S-Video Cable,

Audio Cable

INPUT 4 +

AUDIO Input

Composite

Video + Audio

Composite

Video + Audio INPUT 4 or 5

TV Basic Controls

Best

Good

Audio Connection Connection Cable TV Connection

OPTICAL INPUT

OPTICAL AUDIO

Cable

DIGITAL AUDIO

OPTICAL OUT

AUDIO INPUT

(L / R) Audio Cable AUDIO OUT

(L / R)

Audio

Video

LCT2518-002C-A.indd 16LCT2518-002C-A.indd 16 6/29/09 3:46:18 PM6/29/09 3:46:18 PM

17

Compatible Signal Notes

Input

• HDMI (Digital)

SD: 480i, 480p

HD : 720p, 1080i, 1080p/24Hz,

1080p/30Hz, 1080p/60Hz

Audio L/R

HDMI™ (v.1.3, HDMI™ CEC Support)

Please usa a High Speed HDMI™ Cable.

High Speed HDMI™ Cable are tested to

carry an HD signal up to 1080p and higher.

See pages 62, 63.

Input

• DVI (Digital)

SD: 480i, 480p

HD : 720p, 1080i, 1080p/24Hz,

1080p/30Hz, 1080p/60Hz

• Audio L/R (Analog)

See page 61, 63.

Input

• Component (Analog)

SD: 480i, 480p

HD: 720p, 1080i

• Audio L/R (Analog)

See page 59.

Input

• S-Video (Analog)

• Audio L/R (Analog)

See pages 59, 61.

Input

• Composite (Analog)

• Audio L/R (Analog)

See page 59.

Compatible Signal Notes

Output

• Audio L/R (Digital)

(PCM or Dolby Digital)

See page 60.

Output

• Audio L/R (Analog)

(Fixed)

See page 60.

Basics

LCT2518-002C-A.indd 17LCT2518-002C-A.indd 17 6/29/09 3:46:19 PM6/29/09 3:46:19 PM

18

The following pages gives you a brief description of each button’s function.

This remote can also control up to four other devices. See pages 51 - 52.

Remote Control

TIMER

Allows you to set the TV to turn on and set the TV to turn off

automatically after a set amount of time and channel of your choice.

On Timer / Input / Sleep Timer

Notes:

• If you set the interval of On Timer by pressing the

¥



buttons,

select channel at Input and press OK.

• After you set On Timer and turn off the TV, power lamp lights.

• You can check the remaining time of On Timer by displaying

this menu again.

• You can set the interval of Sleep Timer by pressing the

¥



buttons.

• 60 seconds before the TV turns off, a message will appear and it

will count the remaining time.

• See page 50, “On Timer using iPod”.

POWER

Turns the TV on or off.

MODE TV STB VCR DVD AUDIO

Switch between “TV / STB / VCR / DVD / AUDIO devices.

See page 51.

V1 V2 V3 V4 V5

Switch between devices connected to Video-1, 2, 3, 4 and 5. For

V4 (Video-4) and V5 (Video-5) you must select the signal input type

fi rst (ie. composite, S-Video, or component). To do so, you need

to press the V4 or V5 button until the correct type is highlighted.

Select “Composite 1” for composite video signal input, “S-Video”

for S-video signal input, or “Component 1” for component video

signal input. Select “Composite 2” for composite video signal input

or “Component 2” for component video signal input. Select PC for

PC signal input.

123

456

789

0

TUNE TV

RETURN

+

Change channels. Input remote codes. See page 51.

TUNE

Lets you decide the input channel and select it. After pressing the

remote 0 - 9 buttons, press TUNE.

0 h 0 m

0 - 0

0 min

Timer

On Timer

Input

Sleep Timer

LCT2518-002C-A.indd 18LCT2518-002C-A.indd 18 6/29/09 3:46:19 PM6/29/09 3:46:19 PM

19

POWER

TIMER

MODE TV STB VCR DVD AUDIO

INPUT

123

456

789

0

TUNE TV

RETURN +

iPod MUTING

– CH + – VOL +

RM-C1485

TV

OK

M

E

N

U

B

A

C

K

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

TV

RETURN +

Has three functions.

Return – Returns to the channel viewed

just before the channel

currently onscreen.

Return+ – Lets you program a specific

channel to return to while

scanning through the

channels using the – CH +

button as you memorize the

channel.

TV – Returns to the TV mode as you are

watching a video, DVD, etc.

Note:

• Press TUNE and RETURN+ TV

buttons. This will memorize the

current channel to return to while you

scan through the other channels. To

cancel, press TUNE and RETURN+

TV buttons again.

– CH + Move sequentially through the channels.

– VOL + Raise or lower the volume.

iPod Control your iPod connected to the TV.

See page 46.

MUTING Turns the TV volume to 0. Press again

to restore the volume.

M

E

N

U

Used to access the TV’s onscreen

menus. See page 24.

OK

F

Used to navigate through the TV’s

onscreen menus.

B

A

C

K

Go back to a previous onscreen menu or

to correct a mistake.

Basics

LCT2518-002C-A.indd 19LCT2518-002C-A.indd 19 6/29/09 3:46:20 PM6/29/09 3:46:20 PM

20

Remote Control

DVR

F

A

V

O

R

I

T

E

Allows you to save channels you like so you can view them easily. First you

must register the channels you like.

Notes:

• Go to the channel you want to register and press the FAVORITE. A list will

appear. Press the FAVORITE button again to register your channel.

• To view your favorite channels, press FAVORITE. Move to select your

channel and press OK.

• To erase your favorite channels, press FAVORITE. Move to select your

channel and press

¥



.

• Both analog and digital channels can be registered.

• The channels you registered will appear in numerical order at the top of the

list.

A

S

P

E

C

T

Allows you to adjust the way the image appears on your TV based on the format

that is being received.

Full / Regular / Slim / Panorama / Cinema / Full Native

See page 30.

SOUND

You can choose several types of sound modes.

Speech / Jazz / Classic / Rock / User

See page 39.

VIDEO

Allows you to choose different picture settings according to personal

preferences. You can access this feature for each input (TV, V1, V2, V3, V4,

V5).

Standard / Dynamic / Theater / Game

See page 26.

GUIDE

You can view program information for Digital Channels.

Note:

• The GUIDE will not show the correct time and date depending on the Time

Zone and D.S.T. settings. See page 41.

Favorite

1

2

4

5

6

7

9

11

13

:Remove:Add

FAVOR ITE

LCT2518-002C-A.indd 20LCT2518-002C-A.indd 20 6/29/09 3:46:21 PM6/29/09 3:46:21 PM

21

* See page 52 for buttons that control your external devices.

RM-C1485

TV

DVR

STATUS

VIDEO GUIDE

TV/VCR SUB T.

SUB CH ML/MTS DISPLAY

SOUND

F

A

V

O

R

I

T

E

A

S

P

E

C

T

PCON

TV/VCR

SUB CH

Digital broadcast sometimes offers sub channels.

By using the SUB CH button, you can select a

sub channel easily.

For example, to move to sub channel 123-45:

1) Press 1, 2 and 3 in order

2) Press the SUB CH button

3) Press 4 and 5 in order

4) Press the TUNE button

SUB T.

ML/MTS

Allows you to listen to a program in Stereo,

Mono sound or another language (Sap) if

available. First you must set the MODE to TV on

your remote.

Notes:

• When you are receiving a digital broadcast, if

there are other languages, you can change the

language by pressing the ML/MTS button.

• Keep the TV in stereo mode to get the best

sound quality. The sound will work in stereo

mode even if a certain broadcast is in mono

sound only.

• Choose the mono setting to reduce excessive

noise on a certain channel or broadcast.

• MTS is unavailable if your television’s Input

source is (V1, V2, V3, V4, V5).

• ML/MTS will not work when you are using

HDMI.

DISPLAY View current channel information.

Basics

LCT2518-002C-A.indd 21LCT2518-002C-A.indd 21 6/29/09 3:46:22 PM6/29/09 3:46:22 PM

22

When you turn on your TV for the first time, the Initial Setup menu appears automatically.

These menus will help you setup your TV with basic information for Language, Time and

Tuner Setup. You can also set this setting in the Plug In Menu. See page 41.

Initial Setup

POWER

1) Turn on the TV

1 Select a language

Time Zone Choose the time zone you live in.

D.S.T. Changes the clock automatically for daylight

saving time. On / Off

1 Change settings

4) Set time attribute

Set Time Attribute

Atlantic

On

Next

Time Zone

D.S.T.

2 Select an item 4 Move to next menu

3 Select “Next”

OK OK

2) Set the language

Set Language/Langue/Idioma

English

Next

OK OK

2 Select “Next”

3 Move to next menu

3) Set the mode

Select Home for use at home.

Retail is used in the TV store.

Set Mode

Home

Next

1 Select a mode

OK OK

2 Select “Next”

3 Move to next menu

LCT2518-002C-A.indd 22LCT2518-002C-A.indd 22 6/29/09 3:46:23 PM6/29/09 3:46:23 PM

23

“Thank you! Setup is now complete”

1 Change settings

5) Set TV attribute

Start Scan Exit

Set TV Attribute

Tuner Mode Air

2 Select an item

4 Start scanning

channels

3 Select “Start Scan”

OK OK

Tuner Mode Choose Air (antenna) or Cable

Cable Users: After your auto tuner setup is complete, you may, (depending on the type of

hookup), have only 1 channel, usually 2, 3 or 4 in the auto tuner memory. This

is normal.

Notes:

• If you use a set top box (satellite or cable box), press Exit to skip this step.

• If you want to turn off the Auto Demo, press the MENU button.

We have an important note for customers who subscribe to basic cable services (do not have

a separate cable box) and plan to use their JVC TV remote control to select channels.

Once you run the Auto Tuner Setup (which detects and programs all the channels your TV is

receiving through the RF input), every channel number available from your cable company

will appear in your television’s Channel Summary and they will all be marked as available for

scanning. Even though every channel is detected and appears as available, you will only be

able to view those that you specifi cally subscribe to from your cable company. This will likely

mean there are blank channels between those channels you wish to scan or “surf”.

We apologize for any inconvenience this may cause but it is important to note that this is

not a malfunction of your television. If you want to sequentially scan those channels you

subscribe to without blank ones in between, you can contact your cable company for their

cable box and remote, or manually deselect them using the edit / skip feature on page 33.

Basics

LCT2518-002C-A.indd 23LCT2518-002C-A.indd 23 6/29/09 3:46:24 PM6/29/09 3:46:24 PM

24

Customizing Your TV

You can customize your TV by operating the menus on the TV screen. The TV screen displays

the Menu Bar, Menu Item and available items are highlighted.

Picture Display TV Sound Power Setting

Video Status

Tint

Color

Contrast

Bright

Detail

Backlight

Color Temp

Color Management

Dynamic Gamma

Smart Picture

Digital VNR

MPEG NR

Natural Cinema

Video Reset

Standard

50

25

50

43

94

50

Cool

Off

On

On

High

On

On

0 –

0 –

0 –

0 –

0 –

0 –

– 100

– 100

– 100

– 100

– 100

– 100

:Selec t :Operate

OK :Back

BACK :Exit

MENU

Choose from several preset Video modes.

Menu Bar

Menu Item

Explanation of function displays

Guide

Using the menus

1) Display the menu bar

M

E

N

U

2) Display the desired menu

Picture Display TV Sound Power Setting


(P. 26)

Display

(P. 28)

TV

(P. 31)

Sound

(P. 39)

Power

(P. 40)

Setting

(P. 41)

OK

1 Press ¥ to select a menu

2 Press  to select a menu item

LCT2518-002C-A.indd 24LCT2518-002C-A.indd 24 6/29/09 3:46:24 PM6/29/09 3:46:24 PM

25

3) Change or adjust the setting

Video Status

Tint

Color

Contrast

Bright

Detail

Backlight

Color Temp

Color Management

Dynamic Gamma

Smart Picture

Digital VNR

MPEG NR

Natural Cinema

Video Reset

Standard

50

25

50

43

94

50

Cool

Off

On

On

High

On

On

0 –

0 –

0 –

0 –

0 –

0 –

– 100

– 100

– 100

– 100

– 100

– 100

■ To enter an item’s sub menu

Select

OKOK

Enter

4) Close the menu

Note:

• Depending on the situation (analog channels, digital channels, video signal format, external

inputs, etc.), some items will be displayed in gray and can not be selected.

OK

1 Press  to select

a menu item

2 Press ¥ to change the setting

■ To the previous screen

Advanced

M

E

N

U

B

A

C

K

Video Input Label

Photo Viewer

Aspect

AIR TV

Full

Thumbnail View

Interval 10

(Example: Photo Viewer)

LCT2518-002C-A.indd 25LCT2518-002C-A.indd 25 6/29/09 3:46:25 PM6/29/09 3:46:25 PM

26

Customizing your TV


Video Status

Choose different display settings according to personal preferences. You can use this feature

with TV, V1, V2, V3, V4 and V5.

Standard

Resets the picture display to the factory settings.

Dynamic

Gives a vivid picture with better contrast when viewing in a brightly lit room.

Theater

Gives a rich, film-like look to video when viewing in a dimly lit room.

Game

Used for when you are playing video games connected to your TV.

Notes:

• Each mode is memorized for each analog TV / composite / S-Video, digital TV, HDMI,

component signal input.

• Each video status can be chosen along with your favorite picture settings (Tint, Color,

Contrast, Bright, Detail and Backlight).

■ Allows you to change and adjust the way the picture appears on your television.

Tint

Allows you to adjust the levels of red and green on your TV.

Color

Allows you to make all the colors on your TV appear more vivid or subtle.

Contrast

Allows you to adjust the level of black and white on your TV giving you a darker or brighter

picture overall.

Bright

Allows you to adjust the overall brightness of the TV.

Detail

Allows you to adjust the level of fine detail on your TV.

Backlight

Allows you to adjust the brightness of the internal lamp which effects the overall brightness of

the TV.

LCT2518-002C-A.indd 26LCT2518-002C-A.indd 26 6/29/09 3:46:26 PM6/29/09 3:46:26 PM

27

Dynamic Gamma

Allows you see more detail in very dark or bright areas so these areas don’t appear “muddied”.

Normally, this feature should be left On for optimum picture quality. On / Off

Color Management

Allows you to compensate for dull colors to ensure dull colors are reproduced with natural hues.

On / Off

Color Temp

Allows you to adjust colors to look as accurate as possible. Cool / Natural / Warm

Video Reset

Resets all picture adjustments at once to the default settings, except for Natural Cinema.

Natural Cinema

Allows you to compensate for image blurring when the original video you are watching was shot

at 24 frames/sec, and is broadcast at 30 frames/sec. This conversion process is known as

“TELECINE”. On / Off

Notes:

• When you are receiving a 480p, 720p or 1080p signal, Natural Cinema cannot be selected.

• Natural Cinema is only applied for NTSC, SD 480i and HD 1080i signals.

MPEG NR

This function effects the block noise removal and mosquito NR (Noise Reduction)

simultaneously.

Note:

• When you are receiving digital channels, block noise removal will have no effect.

Digital VNR

This function can be selected to change the effect of Digital VNR (Video Noise Reduction).

High – Adjusts the effect maximally

Low – Adjusts the effect minimally

Off – Function is turned off.

Smart Picture

Allows the TV to adjust the brightness level automatically to a level suitable for what you are

watching. On / Off

Advanced

LCT2518-002C-A.indd 27LCT2518-002C-A.indd 27 6/29/09 3:46:26 PM6/29/09 3:46:26 PM

28

Customizing your TV

Video Input Label

Allows you to label all the devices you have connected to the TV that use the VIDEO-1, 2, 3, 4

and 5 inputs.

Display

VCR

DVD

PVR

D-VHS

STB

SAT

AMP

GAME

CAM

DISC

Blu-ray DVD

Default

OK

1 Select

2 Set

Photo Viewer

Photo Viewer allows you to enjoy your digital pictures stored on your USB Mass Storage Class

devices. You can view them on the TV in high quality if USB Mass Storage device is connected

to the Photo Viewer terminal on the TV.

When you select Thumbnail view and press OK, a folder or file list will be displayed. Select

your folder by using the ¥ or  buttons. Choose a picture and press the OK button. It

will now be shown on the screen. To move to the next picture, press the  button. To move to

the previous picture, press the ¥ button.

* If there is more than 10 images, those images will be shown in the next page. To go to the

next page, select the last image on the page and press the  or  buttons. To go back to

the previous page, press the ¥ or  buttons.

Slide Show

– In Thumbnail View screen, you can view slide show by pressing the TUNE button.

Photo Viewer with iPod

– In Thumbnail View screen, you can listen to music content stored on your iPod. Start your

iPod to play music, and put it on the TV’s Dock. You cannot operate iPod with TV remote.

OK

1 Select

2 Display

Photo Viewer

Page 1

j1010001 j1010002 j1010003 j1010004

j1010005 j1010006 j1010007 j1010008 j1010009

:Select :Oper ate

OK :Back

BACK :Exit

MENU :Slide show

TUNE

Thumbnail View

LCT2518-002C-A.indd 28LCT2518-002C-A.indd 28 6/29/09 3:46:26 PM6/29/09 3:46:26 PM

29

1

2

4

3

Move to the upper left

Move up

Move to the upper right

Move to the left

Reset

Choose Slide Show Interval of 5, 10 or 20 seconds by pressing the ¥ buttons.

Notes:

• Gently pull out your USB device from the Photo Viewer terminal after fi nishing the Photo

Viewer menu.

• Use the supplied USB cable that came with your device. Do not use HUB or USB extension

cable.

• Photo Viewer cannot be guaranteed to work with all USB Mass Storage Devices. It may take

some time to display or it may not display correctly.

• Please refer to the Customer Support website at www.jvc.com/support for information and

notes regarding your devices you wish to connect.

• Supported fi le formats are “.jpg” or “.JPG”.

• All your stored data should be backed up fi rst as a precaution before connecting to the TV.

• Depending on your stored fi le size, it can take extra time to display “Photo Viewer” page.

• Depending on your stored fi le type, some data may not be able to be displayed in the

thumbnail screen.

• You may only view HDD photos when using HDD equipped Everio Cameras.

Display Continued...

DISPLAY

– VOL +

5

6

7

9

8

M

A

Enlarge Reduce

Display help screen

90º Rotation

Interval

(in Slide Show)

Play/Pause

Move to the right

Move to the lower left

Move down

Move to the lower right

OK

Advanced

* Move functions only work when pictures are zoomed in.

LCT2518-002C-A.indd 29LCT2518-002C-A.indd 29 6/29/09 3:46:27 PM6/29/09 3:46:27 PM

30

Customizing your TV

Aspect

Panorama - When watching a 4:3 aspect

picture it is stretched to fit the

dimensions of the 16:9 aspect

screen.

Cinema - This ratio “zooms in” on

the center part of a 4:3

aspect picture, blowing it up

proportionally to fill the 16:9

screen.

Full - When watching a 4:3 aspect picture,

it is stretched to fit the dimensions of

the TV. When watching a 16:9 aspect

picture, it displays 95% of the ratio.

Full Native - This ratio displays 100%

of the ratio. Normally, all

aspects except for Full Native

display about 95%.

Regular - When watching a 4:3 aspect

picture without modifying

the original picture to fit the

dimensions of your 16:9 screen.

Black bars will appear along the

picture’s sides. The picture will be

centered within the boundaries of

the 16:9 screen.

Allows you to adjust the way the image appears on your TV based on the format that is being

received.

Notes:

• Depending on the signal format, some aspect modes are unavailable.

• If you change the aspect mode after the television changed it to Full automatically, the

television will change to the aspect mode you choose. It also turns to Full automatically

when the TV receives an HD (1080p, 1080i or 720p) signal.

• In iPod mode, selections of Aspect menu changes to Full / Regular / 16:9 Mini / 4:3 Mini.

Slim - This aspect mode shrinks the

screen of a 16:9 broadcast to 4:3.

There are some programming that

is already stretched by mistake at

broadcasting companies, so this

mode corrects it. Black side bars will

appear.

LCT2518-002C-A.indd 30LCT2518-002C-A.indd 30 6/29/09 3:46:29 PM6/29/09 3:46:29 PM

31

Closed Caption

Allows you to select the mode of the closed caption. First you must set the MODE to either TV,

STB or VCR on your remote. On / Smart / Off

TV

C.C. Setting

You can choose between caption or text in mode to decide how closed captioning will appear.

OK

1 Select

2 Adjust

Analog CC

Digital CC

Font

Font Size

Font Style

Text Color

Text Opacity

BG Color

BG Opacity

Edge Color

CC1

Service1

Default

Standard

Default

Default

Default

Default

Default

Off

Analog CC

Choose the CC feature that you like for analog closed captioning.

Digital CC

Choose the CC feature that you like for digital closed captioning.

Font

Choose the font that you like for closed captioning.

Font Size

Choose how big the text appears in closed captioning.

Font Style

Choose the style of the font in closed captioning.

Text Color

Choose the color of the text in closed captioning.

Text Opacity

Choose how translucent the text appears in closed captioning.

Note:

• Smart caption will appear when you press the MUTING button only on channels where the

broadcast contains closed captioning.

C.C. Type

Allows you to select the type of the closed caption. Basic is for analog channel’s caption, and

Advanced is for digital channel’s caption. Auto / Basic / Advanced

Advanced

LCT2518-002C-A.indd 31LCT2518-002C-A.indd 31 6/29/09 3:46:30 PM6/29/09 3:46:30 PM

32

Note:

• The Font, Font Size, Font Style, Text Color, Text Opacity, BG Color, BG Opacity and BG

Color settings will not apply to closed caption of analog channels. In addition, some of these

settings for closed caption for digital channels may or may not be available, depending on the

closed captioning data being broadcast.

Tuner Mode

Autoscan

Allows you to scan through all available channels your TV can receive, and memorizes them.

Note:

• The Autoscan is finished when the message “Scanning has completed” appears on the

screen.

If you skipped this step in the initial setup or your setup has changed, you can redo your setup

in this menu. Air / Cable

Add Channel

Allows you to add analog channels. Regarding digital channels, the only channels that will

appear are the ones that are being broadcast.

Enter the new channel number

Please insert scan

number or range

to

Start

OK

1 Select

2 Start

123

456

789

0

TUNE TV

RETURN +

BG Color

Choose the background box color for the Closed Captioning text.

BG Opacity

Choose how translucent the background box color for the Closed Captioning text.

Edge Color

Choose the color of the border of the background box color for the Closed Captioning text.

Customizing your TV

LCT2518-002C-A.indd 32LCT2518-002C-A.indd 32 6/29/09 3:46:30 PM6/29/09 3:46:30 PM

33

TV Continued...

123

456

789

0

TUNE TV

RETURN +

Edit Channel

Allows you to skip channels when using the + CH – button. “✔” means don’t skip, “ ” means

to skip. You can still access those skipped channels manually using the number buttons on the

remote.

OK

OK

Main Channel List

3-2

3-3

5-0

6-0

6-0

11-0

14-0

22-1

36-0

63-0

CH-2

CH-3

CH-1





















Select

Select to skip or not to skip.

Also, select the channel.

V-Chip

Allows you to block channels or content that you deem inappropriate for children.

Notes:

• V-CHIP will not work with video signals from VCRs, DVD players, Blu-ray or camcorders

connected to the TV.

• (For Canadian viewers only) V-CHIP is designed specifically for the US and may not work

properly in Canada.

– When entering the password –

When you try and access the V-Chip menu, “Please input password” will appear. Press the

“0” button four times on your remote to access the V-Chip menu for the first time.

Please input password:

Advanced

LCT2518-002C-A.indd 33LCT2518-002C-A.indd 33 6/29/09 3:46:31 PM6/29/09 3:46:31 PM

34

Password

MPAA

Can. Eng.

Can Fre.

TVPG

NR

G

PG

PG13

R

NC-17

X

OK

1 Select

2 Lock / Unlock

– When you lock or unlock channels –

You can lock or unlock ratings as shown below.

Note:

• If you lock a rating, any rating that is higher is automatically blocked.

Password

You can change the four digit password using

the number buttons on your remote.

* If you forget your password, unplug the TV

from the wall and then plug it back in. Your

password will reset to “0000”

1) Set a new password

OK

Next

Enter the four digit number

Enter the four digit number

2) Confi rm and set

OK

Set

OK

Next

123

456

789

0

TUNE TV

RETURN +

123

456

789

0

TUNE TV

RETURN +

Customizing your TV

New Password

Confirm Password

OK Clear

LCT2518-002C-A.indd 34LCT2518-002C-A.indd 34 6/29/09 3:46:32 PM6/29/09 3:46:32 PM

35

TV Continued...

Viewing Guidelines:

At the beginning of a program, the program will display its rating and the content it contains

(Except for unrated programming).

A program can contain any or all of the following:

V/FV – VIOLENCE/FANTASY VIOLENCE

S – SEXUAL Content

L – Strong LANGUAGE

D – Suggestive DIALOG

MPAA

NR

G

PG

PG13

R

NC-17

X

This setting is based on the US Motion Picture

Association of America (MPAA) ratings system.

NR – Not Rated.

Any type of programming that does not contain a rating.

G – General Audience.

Suitable for all ages.

PG – Parental Guidance Suggested.

Suitable for all ages with parental guidance.

PG 13 – Parents Strongly Cautioned.

Intended for viewers 13 years or older.

R – Restricted.

Not recommended for viewers 17 years without parental guidance.

NC-17 – No One Under 17.

Not intended for viewers 17 years or younger.

X – No One Under 18.

Not intended for viewers 18 years or younger.

Advanced

LCT2518-002C-A.indd 35LCT2518-002C-A.indd 35 6/29/09 3:46:33 PM6/29/09 3:46:33 PM

36

Can. Eng.

This setting is based on the Canada ratings

system.

E

C

C8+

G

PG

14+

18+

E – Exempt.

Any type of programming that does not contain a rating.

C – Intended for children.

Suitable for all ages.

C8+ – Intended for children over 8 years old.

Suitable for all ages over 8 years.

G – General Audience.

May contain material not suited for younger viewers.

PG – Parental Guidance.

May contain material not suited for younger viewers. Parents may consider some content not

appropriate for children 8 - 13 years old.

14+ – 14 Years or Older.

Parents strongly urged to use their discretion in allowing viewing by persons under 14.

18+ – Adult.

Intended for viewers 18 years or older.

Can. Fre.

For instructions on Can. Fre., please see page

36 in the French user’s guide.

E

G

8 Ans+

13 Ans+

16 Ans+

18 Ans+

Customizing your TV

LCT2518-002C-A.indd 36LCT2518-002C-A.indd 36 6/29/09 3:46:33 PM6/29/09 3:46:33 PM

37

TVPG

This setting is based on the US ratings system.

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

ALL FV V SLD

TV Y – Appropriate for all children.

Intended for all children 2 - 6 years old.

TV Y7 – Appropriate for older children.

Intended for children 7 years or older.

TV G – General Audience.

Suitable for all ages.

TV PG – Parental Guidance Suggested.

Suitable for all ages with parental guidance.

TV 14 – Parents Strongly Cautioned.

Intended for viewers 14 years or older.

TV MA – Mature Audiences Only.

Intended for viewers 18 years or older.

Viewing Guidelines:

In addition to the above ratings, you can also block or allow more specifi c content (Except for

unrated programming).

A program can contain any or all of the following:

V/FV – VIOLENCE/FANTASY VIOLENCE

S – SEXUAL Content

L – Strong LANGUAGE

D – Suggestive DIALOG

Guide

You can view program information. (Digital channels only)

Note:

• If the programming information is not being broadcast, the guide function has no effect or

may display incorrect information.

Advanced

LCT2518-002C-A.indd 37LCT2518-002C-A.indd 37 6/29/09 3:46:33 PM6/29/09 3:46:33 PM

38

Customizing your TV

Notes:

• This menu will replace the TV menu when you connect a PC to your TV terminal. See page

63.

• There are some menus that PC mode can not use. (In Picture and Sound menu)

• As for Aspect in the Display menu, only Regular and Full are available.

Adjust the screen position automatically.

Note:

• Sometimes Auto Adjustment will not operate properly. Either adjust with the following

functions or change the signal.

Allows you to adjust the screen position horizontally.

Allows you to adjust the screen position vertically.

Adjust it when noise shows up across the screen. Also, use it when letters become blurry.

PC

Phase Adjustment

Auto Adjustment

PC H-Position

PC V-Position

Resets all PC mode adjustments at once to the default setting.

Reset

LCT2518-002C-A.indd 38LCT2518-002C-A.indd 38 6/29/09 3:46:34 PM6/29/09 3:46:34 PM

39

MTS

Allows you to listen to a program in stereo, mono sound or another language (SAP).

(Depending if available in the program) First you must set the MODE to TV on your remote.

Notes:

• When you are receiving a digital broadcast, if there are other languages, you can change the

language by pressing the ML/MTS button.

• Keep the TV in stereo mode to get the best sound quality. The sound will work in stereo

mode even if a certain broadcast is in mono sound only.

• Choose the mono setting to reduce excessive noise on a certain channel or broadcast.

• MTS unavailable if your television’s input source is (V1, V2, V3, V4, V5).

• ML/MTS will not work when you are using the HDMI.

Digital Audio (ML)

You can change the language if there are other languages available. (Digital channels only)

Sound Status

You can choose several types of sound modes. User / Speech / Jazz / Classic / Rock

Note:

• If you select User, you can customize the various sound frequencies.

100Hz / 330Hz / 1KHz / 3.3KHz / 10KHz

Audio Reset

Resets all sound adjustments at once to the default settings.

Sound

Surround

You can select the surround mode you like. Off / Movie / Music / News / Mono

Advanced

LCT2518-002C-A.indd 39LCT2518-002C-A.indd 39 6/29/09 3:46:34 PM6/29/09 3:46:34 PM

40

Customizing your TV

Power Indicator

Allows you adjust the brightness of the blue power indicator light.

High – Light is brightly lit

Low – Light is dimly lit

Off – Light is off

Illumination

Allows you adjust the brightness of the Diffuser Illumination. See page 13.

High – Light is brightly lit

Low – Light is dimly lit

Off – Light is off

Power

LCT2518-002C-A.indd 40LCT2518-002C-A.indd 40 6/29/09 3:46:34 PM6/29/09 3:46:34 PM

41

Plug In Menu

When you turn on your TV for the first time, the Initial Setup menu appears. If you skip it, or

your setup has changed, you can set it up in this menu anytime.

Time Zone

D.S.T.

Language

Noise Mute

Displays a blank gray screen over channels that are too weak to be received clearly.

On / Off

Allows you to change the TV’s onscreen menu languages to English, French or Spanish.

Adjust your TV’s clock for Daylight Savings. On / Off

Choose the time zone you live in and the clock sets automatically.

Atlantic / Eastern / Central / Mountain / Pacific / Alaska / Hawaii

Setting

Setting Continued...

This allows you to lock the buttons on the side of the TV. On / Off

Change the transparency of the menu screens. 1 / 2 / 3 / 4

This function automatically shuts off your TV when there is no signal from the channel while the

TV is on for 10 minutes. On / Off

Front Panel Lock

Transparency

Auto Shut Off

Advanced

LCT2518-002C-A.indd 41LCT2518-002C-A.indd 41 6/29/09 3:46:34 PM6/29/09 3:46:34 PM

42

Customizing your TV

If you use a HDMI CEC compatible device, set this setting to “On”.

HDMI CEC (Consumer Electronics Control) allows the TV to connect and control multiple HDMI

CEC enabled devices with a single remote. CEC (Consumer Electronics Control) is an optional

protocol used in HDMI.

• HDMI CEC on this TV is compliant with “High-Definition Multimedia Interface Specification”.

• The TV does not support HDMI CEC functions that are not listed below.

• The TV does not guarantee to support use of all HDMI CEC enabled devices.

• Devices that are not enabled to HDMI CEC cannot be controlled with this TV.

– Control the TV using the HDMI CEC enabled device –

• Turn the TV on and switch to the video source of the operating device.

• Switch to the video source of the operating device.

• Turn the TV off with the HDMI CEC enabled device you are viewing.

• For operating instructions of the device, refer to the device’s manual.

– Control the HDMI CEC enabled device using the TV –

• Turn off the operating device by turning off the TV.

• Some device may not support this function. For more details refer to the device’s manual.

– Send status of the TV to the HDMI CEC enabled device –

• When switching the TV’s external input or channel.

• When switching the TV’s menu language.

• Information regarding behavior of the device when status is received, refer to the external

device’s manual.

If HDMI CEC does not work correctly:

• When HDMI CEC enabled device is connected to INPUT 1, INPUT 2 or INPUT 3 with an

HDMI cable, you may not be able to control TV’s external input. To solve the problem set this

setting to “Off”.

Control with HDMI

You can confirm the TV’s software version.

Auto Demo explains this TV’s features to you.

Notes:

• The Auto Demo mode will start automatically when you set Retail in Initial Setup.

• If you press any button on the television or remote, with the exception of

POWER or MENU, the Auto Demo mode will stop for 30 seconds. After 30 seconds

have passed with no operation, the Auto Demo mode will start again.

• If you want to turn off the Auto Demo, press the MENU button.

System Info

Auto Demo

LCT2518-002C-A.indd 42LCT2518-002C-A.indd 42 6/29/09 3:46:35 PM6/29/09 3:46:35 PM

43

You can select the optical digital sound output as PCM or DOLBY DIGITAL when your TV is

connected to an amplifier that has a DOLBY DIGITAL decoder. If you select DOLBY DIGITAL,

you can enjoy listening to 5.1ch sound when watching digital broadcasts. This only applies to

digital channels.

Notes:

• Optical Out can be used for both digital and analog channels.

• If your amplifier does not have DOLBY DIGITAL decoder, select PCM. If you don’t

select PCM, it cannot output the sound from the speakers.

• For connecting an amplifier using the optical output, see page 60.

Optical Out

When PC is turned on it will power on TV and put it in PC mode. Any other function is not logical.

Also it is called PC Smart Input in TV menu so it suggest fl ow from PC to TV.

D-Sub / HDMI / Off

Notes:

• When you use PC Smart Input function with HDMI cable, connect your PC with HDMI

terminal (INPUT 1).

• You cannot use PC Smart Input when Control with HDMI is “On”.

PC Smart Input

Sync Mode

Lets iTunes synchronize your iPod when USB is connected with computer. When you start

Sync Mode, within the TV’s Setting menu, the menu displays “Start” and after fi nished, “Exit” is

displayed.

OK

Press OK to start or exit Sync Mode.

Sync Mode Syncronizing

your iPod

Start

Notes:

• You need USB type A - type B cable connector, see page 50.

• Do not detach your iPod when you start Sync Mode.

• When you exit the Sync Mode, make sure your iPod and PC communication has fi nished.

Advanced

LCT2518-002C-A.indd 43LCT2518-002C-A.indd 43 6/29/09 3:46:35 PM6/29/09 3:46:35 PM

44

iPod

4G photo/color 5G classic touch (1G) touch (1G)

(FW:2.0+)

touch 2G

20GB

40GB

20GB

30GB

40GB

60GB

30GB

60GB

80GB

80GB

120GB

160GB

8GB

16GB

32GB

8GB

16GB

32GB

TV Control Mode

Music Play ✔✔✔✔✔✔

Video Play ✔✔ ✔

Setting ✔ (3) ✔ (3) ✔ (3) ✔ (3) ✔ (3) ✔ (3)

Pod Control Mode

Music Play ✔ (1) ✔ (1) ✔ (1) ✔ (1) ✔ (1, 2) ✔ (1, 2)

Video Play ✔✔✔ (2) ✔ (2)

Photo Slide

Show ✔✔✔✔ (4) ✔ (4)

Setting ✔✔✔✔✔ (2) ✔ (2)

Sync Mode

✔✔✔✔✔✔

* If your iPod is not listed in this chart, it is incompatible with this television.

Compatible iPod Types

Enjoy Movies/Music From Your iPod

• Some setups will require the selection by using the iPod. (Especially those that require wheel

control).

• Not available except for Music/Video play, Photo Slide Show (Pod Control Mode).

(1) – The registration of “On-The-Go” can be done by using the iPod.

(2) – Due to the nature if iPod touch, lock/unlock, Main Menu and the selection of music/video

has to be done using the iPod touch.

(3) – “Shuffl e”, “Repeat” and “Audiobook” can be available in TV Control Mode.

(4) – To control iPod touch Photoviewer, it can be done only by using the iPod touch.

LCT2518-002C-A.indd 44LCT2518-002C-A.indd 44 6/29/09 3:46:35 PM6/29/09 3:46:35 PM

45

iPod nano iPod mini

1G 2G 3G 4G

1GB

2GB

4GB

2GB

4GB

8GB

4GB

8GB

8GB

16GB

4GB

6GB

✔✔✔✔✔

✔✔

✔ (3) ✔ (3) ✔ (3) ✔ (3) ✔ (3)

✔ (1) ✔ (1) ✔ (1) ✔ (1) ✔ (1)

✔✔

✔✔

✔✔✔✔✔

✔✔✔✔✔

Advanced

LCT2518-002C-A.indd 45LCT2518-002C-A.indd 45 6/29/09 3:46:36 PM6/29/09 3:46:36 PM

46

1) Insert your iPod into the Dock on the front of the TV.

Notes:

• It is recommended that music, pictures and movies on the iPod be saved on your PC or other

hard drive for backup.

• Please be sure to connect/disconnect the iPod properly from the Dock and use the iPod

without any accessory/case.

• Please do not jiggle the iPod in the Dock to avoid connection failure or damage to the

connector.

2) Press the iPod button on your remote, then the JVC logo will appear

on the screen of the iPod.

Notes:

• You cannot operate the iPod while the Apple logo appears on the screen of the iPod.

• If your iPod doesn’t work correctly, gently pull out and try again.

3) TV screen will change to the iPod start screen.

4) To exit the menu, press the iPod button. The TV will return to the program you were

watching.

5) When you detach your iPod, while gently holding the base, pull the iPod gently straight

upwards.

By inserting your iPod into the Dock, you can display movies or music on your TV from your

iPod. Also, while inserted you can recharge your iPod.

Ready to play

Music Play

Video Play

Music Shuffle Play

Settings

Now Playing

JVC iPod classic(2)

1

OK

1 Select

2 Set

Dock

Dock adapter

iPod

Notes:

• If the iPod does not play correctly, please update your iPod software to the latest version.

For details about updating your iPod, check on the Apple web site, http://www.apple.com.

• Sound distortion may occur when playing back audio sources with high recording levels.

When distortion occurs, it is recommended to turn off the equalizer of the iPod. For

information on operating the iPod, see the iPod instruction manual.

• JVC is not responsible for any loss of or damage to iPod that might result from the use of this

product.

Enjoy Movies/Music From Your iPod

* When you put your iPod on the Dock, please

use the Dock adapter (supplied with iPod or

separately purchased).

* To detach the dock adaptor from the Dock,

push the slot then pull up to remove the

dock adaptor. If you have difficulty detaching

the Dock adaptor, gently use a flat head

screwdriver to remove.

LCT2518-002C-A.indd 46LCT2518-002C-A.indd 46 6/29/09 3:46:36 PM6/29/09 3:46:36 PM

47

TV Control Mode

You can operate the iPod by using the TV’s remote control and onscreen menus.

Music Play

Video Play

Music Shuffle Play

Settings

Now Playing

JVC iPod classic(2)

1

Music Play

Video Play

Music Shuffle Play

Settings

Now Playing (when playing music)

Icons of Music Play screen

NOWHERE

WHY ARE WE HERE

SOME RANDOM BAND

ROCK

JVC iPod classic(2)

1

1 / 334

00:00:43 / 00:06:21

Music Play

Shuffle

Repeat

Songs

Albums

One

All

1

Rewind

Pause/

Stop

Forward

Play

Your iPod name Blinks when communicating with the iPod

Music

Artist

Album

Genre

* Language Support:

English, French and Spanish

OK

OK

OK Skip to the next/last pageSelect

Set

B

A

C

K

Back to previous menu

Note:

• When Music Play is selected, you can then search by the catagories supported on your

iPod, such as Playlist, Albums, Songs, Podcast etc.

• When you search tracks from Artist, Albums, etc., some tracks may not be displayed on the

list. In this case, select a track from Songs or input tag information using iTunes.

Advanced

LCT2518-002C-A.indd 47LCT2518-002C-A.indd 47 6/29/09 3:46:37 PM6/29/09 3:46:37 PM

48

Music Play / Video Play

NOWHERE

WHY ARE WE HERE

SOME RANDOM BAND

ROCK

JVC iPod classic(2)

1

1 / 334

00:00:43 / 00:06:21

Music Play

Skip to the next/last song

iTV

You can view the last program

you were watching while

listening to your iPod (iTV

Mode). Press iTV button when

playing music.

SOUND

– VOL + Volume

Adjust sound status

B

A

C

K

Back to previous menu

M

E

N

U

TV’s onscreen menu

(“Picture” and “Sound”)

MUTING Mute

TIMER Choose Timer

iPod Back to TV

iTV

Rewind

Play

Forward

Back to Previous Menu Pause

iTV (in Music Play mode)

iTV allows you to watch TV and at the same time, listen to the music content on your iPod.

When you are listening to music in Music Play mode, press the iTV button.

– CH + Change channel

Select input

VIDEO

A

S

P

E

C

T

Adjust Aspect Ratio

Adjust Video status

V5

V1

Change between iPod’s sound

and TV’s sound

–

Select a channel.

(See page 18, 21)

9

0–

TUNE TV/VCR

SUB CH TV

RETURN +

iTV Back to Music Play screen

Note:

• Basic operations are the same as the operations when playing in Music Play mode.

Enjoy Movies/Music From Your iPod

file title

OK

VIDEO

A

S

P

E

C

T

Change the aspect ratio

(Video Play)

Adjust Video status

(Video Play)

DISPLAY Display title (Video Play)

SOUND Adjust sound status DISPLAY Display information

LCT2518-002C-A.indd 48LCT2518-002C-A.indd 48 6/29/09 3:46:37 PM6/29/09 3:46:37 PM

49

Music Shuffle Play

This function selects songs randomly.

Note:

• Basic operations are the same as the operations when playing in Music Play mode.

You can adjust the settings below by pressing the  and OK buttons.

Shuffle / Repeat / Audiobook

You can operate the iPod using the TV’s remote control and the onscreen of the iPod. Press

the PCON button to switch between Pod Control Mode and TV Control Mode.

1) Press the PCON button on the remote control. JVC logo will disappear

and the normal screen of your iPod will appear.

2) Operate with TV remote control.

Note:

• TV will display a blank black screen when operating the iPod in Pod Control Mode.

GUIDE

PCON

Pod Control Mode

OK * Operation varies from

iPod type and/or mode. SOUND

– VOL + Volume

Adjust sound status

VIDEO

A

S

P

E

C

T

Adjust Aspect Ratio

Adjust Video status

B

A

C

K

Back to previous menu

M

E

N

U

TV’s onscreen menu

(“Picture” and “Sound”)

MUTING Mute

TIMER Choose Timer

iPod Back to TV

* Operation varies

from iPod type

and/or mode

iTV

Settings

DISPLAY Exit message

Advanced

LCT2518-002C-A.indd 49LCT2518-002C-A.indd 49 6/29/09 3:46:40 PM6/29/09 3:46:40 PM

50

While your iPod is connected to the Dock, you have the ability to recharge your iPod. The time

it takes depends on how low your batteries are.

Note:

• If you insert the iPod into the Dock when the TV is off, a click sound may occur. This is

normal.

Recharge iPod

Error messages

“iPod not found” This appears when you press the iPod button

without inserting an iPod.

“ Communication failed.

Check Connection”

Insert your iPod again. This is a connection error.

“File not found” This appears when your iPod has no files to play.

You can synchronize your iPod and PC using this TV. Please use USB type A - type B cable

(not supplied) when you connect with SYNC (PC) connector.

PC sync.

Notes:

• Make sure you inserted your iPod into the Dock and both PC and TV’s power is on.

• Depending on your PC and USB cable, Sync Mode (page 43) may not operate correctly.

Also, it is not recommended to use a hub between the PC and TV connection.

• For details about syncing with iTunes, refer to your iPod’s manual.

• You can display iTunes screen on TV. See page 63.

• For updating iPod firmware, connect directly with your iPod and PC.

Enjoy Movies/Music From Your iPod

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

PC

Back of the TV

SYNC (PC)

You can set the timer to listen to your iPod music content. After you set On Timer and select

iPod at Input in Timer menu. See page 18. Insert your iPod into the Dock.

Notes:

• If you want to set the timer to listen to your favorite music content, play the music content

operating your iPod and press pause. And put it on the TV Dock. On Timer will start to play

the selected music.

• You cannot play Video content using On Timer function.

On Timer using iPod

LCT2518-002C-A.indd 50LCT2518-002C-A.indd 50 6/29/09 3:46:41 PM6/29/09 3:46:41 PM

51

You can program your remote control to operate your external devices, using the instructions

and codes on pages 51 - 57.

How to set the codes

1) Manually turn on the device.

2) Change the remote control mode according to the device by pressing the MODE button.

Refer to the following list for which mode to use.

3) Find the remote control code for your device. See pages 53 - 57.

4) Set the remote code.

TUNE

Enter the four digit numberPress and hold

The mode indicator goes

out for a second, then it

lights.

5) Point the remote at the device and press power. If your device did not turn off or respond, try

another code.

Notes:

• If your device doesn’t respond to any of the codes listed or is not listed, see page 52.

• Some codes may have only limited functions. Try other codes that may have more functions.

123

456

789

0

TUNE TV

RETURN +

Programming Your Remote

TV

STB

VCR

DVD

AUDIO

JVC brand only

Cable Set Top Boxes, Cable/PVR Combinations, Satellite Set Top Box

DBS/PVR Combination

VCR, DBS/PVR Combination, PVR, DVD/PVR Combination

DVD Player, DVD Recorder, Home Theater in a Box, Receiver

Amplifier, Home Theater in a Box, Receiver

Device Applied for these devices

Advanced

LCT2518-002C-A.indd 51LCT2518-002C-A.indd 51 6/29/09 3:46:42 PM6/29/09 3:46:42 PM

52

iPod MUTING

OK

M

E

N

U

F

A

T

B

A

C

K

Remote Control Functions

MODE TV STB VCR DVD AUDIO

POWER

Operates menus

Changes the remote control mode

Turns the selected device off

Select

OK

Display

menu

Back to

previous

menu

Playback / Record, etc.

iTV

Rewind

Play

Forward

Record Stop Pause

Displays Subtitles

SUB T.

Channel Up / Down

Volume Up / Down Open / Close

– VOL +

– CH +

Audio Input

Selection

V1 V2 V3 V4 V5

Search Code Function

This function searches for codes one by one if none of the codes listed for your device has

worked.

1) Manually turn on the device.

2) Change the remote control mode according to the device. Press MODE to select the correct

mode.

3) Activate the search code function. Press and hold POWER and RETURN+/TV until the mode

indicator blinks.

4) Point the remote at the device and press POWER. If no response, try the next code by

pressing  and POWER until the device turns off.

5) Press RETURN+/TV to register and set the code. Then the MODE indicator light goes out.

Notes:

• If your remote still doesn’t work with the “Search Code Function”, use the remote that came

with your device. Your TV remote can not be guaranteed to work with all devices, modes or

operations.

Programming Your Remote

LCT2518-002C-A.indd 52LCT2518-002C-A.indd 52 6/29/09 3:46:43 PM6/29/09 3:46:43 PM

53

Programming Codes

ABC

Americast

Bell South

Digeo

Director

General Instrument

GoldStar

Hamlin

Jerrold

Memorex

Motorola

Pace

Panasonic

Paragon

Philips

Pioneer

Pulsar

Quasar

Regal

Runco

Samsung

Scientific Atlanta

Sony

Starcom

Supercable

Torx

Toshiba

Zenith

Americast

Digeo

General Instrument

Jerrold

Motorola

Pace

Pioneer

Scientific Atlanta

Sony

Supercable

Zenith

0003, 0008

0899

0899

1187

0476

0476, 0810, 0276,

0003

0144

0009, 0273

0476, 0810, 0276,

0003

0000

1376, 0476, 0810,

0276, 1187

1877, 0237, 0008

0000, 0008, 0107

0000

1305, 0317, 0025

1877, 0877, 0144,

0533

0000

0000

0279, 0273

0000

0000, 0144

1877, 0877, 0477,

0008

1006

0003

0276

0003

0000

0000, 0525, 0899

0899

1187

0810

0810

1376, 0810, 1187

1877, 0237

1877, 0877

1877, 0877

1006

0276

0899

Cable Set Top Box

AlphaStar

Chaparral

Coolsat

Crossdigital

DirecTV

Dish Network System

Dishpro

Echostar

Expressvu

GE

General Instrument

GOI

Hisense

Hitachi

HTS

Hughes Network Systems

Humax

iLo

JVC

LG

Magnavox

Memorex

Mitsubishi

Motorola

Next Level

Panasonic

Pansat

Paysat

Philips

Proscan

Proton

RadioShack

RCA

0772

0216

1806

1109

1377, 0392, 0566,

0639, 1639, 1142,

0247, 0749, 1749,

0724, 0819, 1856,

1076, 1108, 0099,

1109, 1414, 1442,

1609, 1392, 1640

1505, 1005, 0775,

1170, 1775

1505, 1005, 0775,

1775

1505, 1005, 0775,

1170, 1775

0775, 1775

0566

0869

0775, 1775

1535

0819

0775, 1775

1142, 0749, 1749,

1442

1790

1535

0775, 1170, 1775

1414

0724, 0722

0724

0749

0869

0869

0247, 0701

1807

0724

1142, 0749, 1749,

0724, 1076, 0722,

0099, 1442

0392, 0566

1535

0869

0566, 0855, 0143,

1392

Cable/PVR Combination

Satellite Set Top Box

DBS/PVR Combination

STB mode

Satellite Set Top Box

1377, 1276, 1108,

1109, 1442, 1609

0856

0639, 1639, 1640

0869

1142, 1442

0749, 1749, 0790,

1285

1392, 1640

1806

0724, 0722

1535

1535

0869

0856, 1856

1377, 0392, 0639,

1142, 1076, 0099,

1392, 1442, 1640

1505, 0775

1505, 0775

1505, 0775, 1170

0775

1142, 1442

1170

0869

1142, 0099, 1442

0392

1392

1442

0639, 1640

0869

Samsung

SKY

Sony

Star Choice

Tivo

Toshiba

UltimateTV

Ultrasat

Uniden

US Digital

USDTV

Voom

Zenith

DirecTV

Dish Network System

Dishpro

Echostar

Expressvu

Hughes Network Systems

JVC

Motorola

Philips

Proscan

RCA

Samsung

Sony

Star Choice

Etc.

LCT2518-002C-A.indd 53LCT2518-002C-A.indd 53 6/29/09 3:46:44 PM6/29/09 3:46:44 PM

54

Programming Codes

ABS

Admiral

Adventura

Aiko

Aiwa

Akai

Alienware

America Action

American High

Asha

Audiovox

Beaumark

Bell & Howell

Broksonic

Calix

Canon

Capehart

Carver

CCE

Citizen

Colt

Craig

Curtis Mathes

Cybernex

CyberPower

Daewoo

Daytron

Dell

Denon

DirecTV

Durabrand

Dynatech

Electrohome

Electrophonic

Emerex

Emerson

1972

0048, 0209

0000

0278

0037, 0000, 0307,

0479

0041, 0061, 0106

1972

0278

0035

0240

0037, 0278

0240

0104

0184, 0121, 0209,

0002, 0479, 1479

0037

0035

0020

0081

0072, 0278

0037, 0278, 1278

0072

0037, 0047, 0240,

0072, 0271

0060, 0035, 0162,

0041, 0760, 1035

0240

1972

0045, 0104, 0278,

0020, 0046, 0561,

1278

0020

1972

0042

0739

0039, 0038

0000

0037

0037

0032

0035, 0037, 0184,

0240, 0045, 0000,

0121, 0043, 0209,

0002, 0278, 1593,

1479, 1278, 0593,

0561, 0479, 0208,

0061

VCR

Fisher

Fuji

Funai

Garrard

Gateway

GE

Go Video

GoldStar

Gradiente

Harley Davidson

Harman/Kardon

Harwood

Headquarter

Hewlett Packard

HI-Q

Hitachi

Howard Computers

HP

Hughes Network Systems

Humax

Hush

iBUYPOWER

Jensen

JVC

KEC

Kenwood

KLH

Kodak

LG

Linksys

Lloyd's

Logik

LXI

Magnasonic

Magnavox

Magnin

Marantz

0047, 0104, 0046

0035, 0033

0000, 0593, 1593

0000

1972

0060, 0035, 0240,

0202, 0760, 0761,

0807, 1035, 1060

0432, 0526

0037, 0209, 0038,

0225, 1237

0000

0000

0081, 0038

0072

0046

1972

0047

0037, 0240, 0000,

0042, 0041, 0105,

1037

1972

1972

0042, 0739

0739

1972

1972

0041

0045, 0067, 0041,

0008, 0366, 1707,

1945, 1774, 1775,

1776, 1777

0037, 0278

0067, 0041, 0038

0072

0035, 0037

0037, 0045, 0042,

0209, 0038, 1037

1972

0000, 0208

0240, 0072

0037

0593, 1278

0035, 0039, 0081,

0000, 0149, 0563,

0593, 1593, 1781

0240

0035, 0081

VCR

VCR mode

VCR

0037

0035, 0162, 0227,

1162

1972

0035

0035, 0162, 0037,

0048, 0039, 0047,

0240, 0000, 0104,

0209, 0046, 0307,

0479, 1037, 1048,

1162, 1237, 1262

0240, 0043, 0061

0240

1972

1972

0042, 0105

0081, 0067, 0043,

0041, 0061, 0173,

0807

0035, 0048

0240, 0000

0000, 0072

0035, 0037, 0048,

0104, 0067, 0041,

0038, 0008

0037

1972

0240

1972

0035

1062, 0162, 0037,

0048, 0104, 0432,

0593, 1048, 1162,

1262

0184, 0121, 0209,

0002, 0208, 0479,

1479

1062, 0035, 0162,

0225, 0227, 0616,

1035, 1162, 1262

0035, 0037, 0240,

0042, 0038, 1035,

1237

0042, 0105

0035, 0000, 0038

Marta

Matsushita

Media Center PC

MEI

Memorex

MGA

MGN Technology

Microsoft

Mind

Minolta

Mitsubishi

Motorola

MTC

Multitech

NEC

Nikko

Niveus Media

Noblex

Northgate

Olympus

Optimus

Orion

Panasonic

Penney

Pentax

Philco

Programming Codes

LCT2518-002C-A.indd 54LCT2518-002C-A.indd 54 6/29/09 3:46:44 PM6/29/09 3:46:44 PM

55

VCR VCR

VCR mode

Philips

Pilot

Pioneer

Polk Audio

Portland

Presidian

Profitronic

Proscan

Protec

Pulsar

Quarter

Quartz

Quasar

RadioShack

Radix

Randex

RCA

Realistic

ReplayTV

Ricavision

Runco

Samsung

Sanky

Sansui

Sanyo

Scott

Sears

Sharp

Shintom

Shogun

Singer

Sonic Blue

Sony

Stack 9

STS

Sylvania

0035, 0081, 0000,

0563, 0593, 0618,

0739, 1081, 1181,

1266

0037

0081, 0042, 0067

0081

0020

1593

0240

0060, 0202, 0760,

0761, 1060

0072

0039

0046

0046

0035, 0162, 1035,

1162

0000, 1037

0037

0037

0060, 0035, 0240,

0000, 0042, 0149,

0105, 0106, 0202,

0760, 0761, 0807,

0880, 1035, 1060

0035, 0037, 0048,

0047, 0000, 0104,

0046

0614, 0616

1972

0039

0240, 0045, 0432,

0739, 0760, 1014

0048, 0039

0000, 0067, 0209,

0041, 0271, 0479,

1479

0047, 0240, 0104,

0046

0184, 0045, 0121,

0043

0035, 0037, 0047,

0000, 0042, 0104,

0046, 0057, 0105,

1237

0048, 0209, 0807,

0848, 1048

0104, 0072

0240

0045, 0072

0614, 0616

0035, 0032, 0033,

0000, 0034, 0636,

0639, 0640, 1032,

1232, 1972

1972

0042

0035, 0081, 0000,

0043, 0593, 1593,

1781

Symphonic

Systemax

Tagar Systems

Tatung

Teac

Technics

Teknika

Thomas

Tivo

TMK

Toshiba

Totevision

Touch

Unitech

Vector

Vector Research

Video Concepts

Videomagic

Videosonic

Viewsonic

Villain

Voodoo

Wards

White Westinghouse

XR-1000

Yamaha

Zenith

ZT Group

Echostar

Hughes Network Systems

JVC

Philips

Samsung

ABS

Alienware

CyberPower

Dell

DirecTV

Dish Network System

Echostar

Gateway

Hewlett Packard

0000, 0593, 1593

1972

1972

0081, 0045, 0000,

0067, 0041, 0008,

0366

0000, 0041

0035, 0162

0035, 0037, 0000

0000

0618, 0636, 0739,

1996

0240, 0208

0081, 0045, 0042,

0067, 0043, 0041,

0008, 0057, 0366,

0845, 1008, 1145,

1972, 1996

0037, 0240

1972

0240

0045

0038

0045, 0061

0037

0240

1972

0000

1972

0060, 0035, 0048,

0047, 0081, 0240,

0000, 0042, 0072,

0149, 0760

0209, 0072

0035, 0000, 0072

0041, 0038

0039, 0033, 0000,

0209, 0034, 0479,

1139, 1479

1972

1945

0739

1945

0739

0739

1972

1972

1972

1972

0739

1945

1945

1972

1972

DBS/PVR Combination

PVR

Howard Computers

HP

Hughes Network Systems

Humax

Hush

iBUYPOWER

JVC

Linksys

Media Center PC

Microsoft

Mind

Niveus Media

Northgate

Panasonic

Philips

RCA

ReplayTV

Samsung

Sonic Blue

Sony

Stack 9

Systemax

Tagar Systems

Tivo

Toshiba

Touch

Viewsonic

Voodoo

ZT Group

Emerson

1972

1972

0739

0739

1972

1972

1945

1972

1972

1972

1972

1972

1972

0616, 1777

0618, 0739

0880

0614, 0616

0739

0614, 0616

0636, 1972

1972

1972

1972

0618, 0636, 0739

1008, 1972, 1996

1972

1972

1972

1972

0000

DVD/PVR Combination

PVR

Etc.

LCT2518-002C-A.indd 55LCT2518-002C-A.indd 55 6/29/09 3:46:45 PM6/29/09 3:46:45 PM

56

DVD DVD

DVD mode

Accurian

Advent

Aiwa

Akai

Alco

Allegro

Apex Digital

Arrgo

Aspire Digital

Audiovox

Blaupunkt

Blue Parade

Broksonic

Cinea

Cine Vision

Citizen

Coby

Craig

Curtis Mathes

CyberHome

Daewoo

Denon

Disney

Durabrand

DVD2000

Emerson

Enterprise

ESA

Fisher

Funai

Gateway

GE

Go Video

GoldStar

Greenhill

Harman/Kardon

Hitachi

Hiteker

Humax

iLo

Initial

Insignia

Integra

JBL

Jensen

JVC

Kawasaki

Kenwood

KLH

Koss

Lasonic

Lenoxx

LG

LiteOn

1416

1016

0641

0695, 0770, 0899

0790

0869

0672, 0717, 0755,

0830, 1056, 1061

1023

1168

0790

0717

0571

0695

0831

0876, 0833, 0869

1277

0778, 1107

0831

1087

0816, 0874, 1023,

1024, 1117, 1129

0784, 0705, 0770,

0833, 0869, 1169,

1172

0490, 0634

0675, 1270

1127

0521

0591, 0675, 0821,

1268

0591

0821, 1268

0670

0675, 1268, 1334

1158

0522, 0815, 0717

0744, 0715, 0741,

0783, 0833, 0869,

1044, 1075, 1099,

1158, 1304, 1730

0741

0717

0582, 0702

0573, 0664, 1247

0672

1500, 1588

1348

0717

1268

0627

0702

1016

0558, 0623, 0867,

1164, 1602, 1770,

1771, 1772, 1773

0790

0490, 0534

0717, 0790, 1149

0651

0798

1127

0591, 0741, 0869

1058, 1158, 1416,

1440

Magnavox

Marantz

Memorex

Microsoft

Mintek

Mitsubishi

NAD

NEC

Nesa

NexxTech

Norcent

Onkyo

Oritron

Panasonic

Philips

Pioneer

Polaroid

Polk Audio

Portland

Presidian

Prima

Proscan

Pro Vision

Qwestar

RCA

Rio

Rotel

Sampo

Samsung

Sansui

Sanyo

Sensory Science

Sharp

Sharper Image

Sherwood

Shinsonic

Sonic Blue

Sony

Superscan

Sylvania

Symphonic

Teac

Technics

Theta Digital

Tivo

Toshiba

Urban Concepts

US Logic

Venturer

Xbox

Yamaha

Zenith

0503, 0539, 0646,

0675, 0821, 1268

0539

0695, 0831, 1270

0522, 1708

0839, 0717

1521, 0521

0741

0785

0717

1402

1003, 1107

0503, 0627

0651

0490, 0703, 1362,

1462, 1490, 1762

0503, 0539, 0646,

0675, 0854, 1158,

1260, 1267, 1354

0525, 0571, 0631

1061

0539

0770

0675

1016

0522

0778

0651

0522, 0571, 0717,

0790, 0822, 1022,

1132

0869

0623

0752

0490, 0573, 0744,

0820, 0899, 1044,

1075, 1470

0695

0670, 0695, 0873

1158

0630, 0675, 0752,

1256

1117

0770

0533, 0839

0869, 1099

0533, 1533, 0864,

1033, 1431, 1536

0821

0675, 0821, 1268

0675, 0821

0717, 0790

0490, 0703

0571

1503

0503, 0695, 1045,

1154, 1503, 1515,

1588

0503

0839

0790

0522, 1708

0490, 0539, 0545

0503, 0591, 0741,

0869

DVD Recorder

Accurian

Apex Digital

Aspire Digital

CyberHome

Denon

Funai

Gateway

Go Video

iLo

JVC

LG

LiteOn

Magnavox

Panasonic

Philips

Pioneer

RCA

Samsung

Sensory Science

Sharp

Sony

Sylvania

Zenith

Aiwa

Audiovox

JVC

KLH

Koss

Oritron

Polk Audio

RCA

Rio

Sonic Blue

Teac

Venturer

1416

1056

1168

1129

0490

0675, 1334

1158

0741, 1158, 1304,

1730

1348

1164

0741

1158, 1416, 1440

0646, 0675

0490

0646, 1158

0631

0522

0490, 1470

1158

0630, 0675

1033, 1431

0675

0741

0641

0790

1770, 1771, 1772,

1773

0790

0651

0651

0539

0790

0869

0869

0790

0790

Home Theater in Box

Programming Codes

LCT2518-002C-A.indd 56LCT2518-002C-A.indd 56 6/29/09 3:46:45 PM6/29/09 3:46:45 PM

57

Amstrad

Bose

Curtis Mathes

Durabrand

GE

Harman/Kardon

JVC

Left Coast

Lenoxx

Linn

Marantz

NEC

Optimus

Philips

Pioneer

Polk Audio

RCA

Shure

Sony

Soundesign

Victor

Wards

Yamaha

ADC

Aiwa

Akai

Alco

Amphion Media Works

AMW

Anam

Apex Digital

Audiotronic

Audiovox

Bose

Brix

Cambridge Soundworks

Capetronic

Carver

Classic

Coby

Criterion

Daewoo

Delphi

Denon

Garrard

Gateway

Go Video

Harman/Kardon

Initial

Insignia

Integra

JBL

JVC

Kenwood

KLH

0078

0674

0300

1561

0078

0892

0331

0892

1561

0269, 0282, 0829

0892, 0269

0264

0300, 0823

0892, 0269

0013, 0300, 0823

0892, 0269

0300, 0823

0264

0689, 0815, 1126

0078

0331

0078, 0013

0354, 0133

0531

1405, 0121, 1243,

1388, 1641

1512

1390

1563, 1615

1563, 1615

1609, 1074

1257, 1430

1189

1390

1229, 0639, 1841,

1933

1602

1370

0531

1189

1352

1389

1420

1250

1414

1360, 0771, 1142,

1660, 2832

0463

1517

1532

0110, 0891, 1304,

1306

1426

1751

0135, 1298, 1320

0110, 1306

0531, 1374, 1495,

1560, 1676, 1871,

1894

1313, 1570, 1569

1390, 1412

Amplifier

Koss

Lasonic

Lenoxx

LG

Liquid Video

Magnavox

Marantz

Mitsubishi

NexxTech

Norcent

Nova

Onkyo

Optimus

Oritron

Panasonic

Philips

Pioneer

Polaroid

Polk Audio

Proscan

RCA

Regent

Rio

Saba

Samsung

Sansui

Sanyo

Sharp

Sharper Image

Sherwood

Shinsonic

Sirius

Sonic Blue

Sony

Stereophonics

Sunfire

Teac

Technics

Thorens

Toshiba

Venturer

Wards

XM

Yamaha

Zenith

1366, 1497

1798

1437

1293, 1869

1497

1189, 1269, 0531,

1514

1189, 1269, 0891,

1289

1393

1751

1389, 1751

1389

0135, 0842, 1298,

1320, 1531

1023, 0531, 1074

1366, 1497

1308, 1518, 0367,

1288, 1316, 1548,

1633, 1763, 1764

1189, 1269, 0891,

1266, 1289, 1673

1023, 0014, 0150,

0531, 0630, 1123,

1384, 1823

1508

1289, 1414

1254

1023, 1609, 1254,

0531, 1074, 1123,

1390, 1511

1437

1869

0531, 1519

1295, 1500

1764

1251, 1469

0771, 1286

1556

1517, 1653

1426

1602

1532, 1869

1058, 1441, 1258,

1759, 1622, 0474,

1406, 1558, 1658,

1758, 1858, 1958

1023

1313

0463, 1074, 1390,

1528

1308, 1518, 1384

1189

1788

1390

0014

1406, 1414

0176, 1176, 1276,

1331, 1375, 1476

0857, 1293

Receiver

Audio mode

Home Theater in Box

1388, 1641

1563, 1615

1563, 1615

1609

1257, 1430

1390

1229, 1933

1370

1352

1389

1420

1250

2832

1561

1517

1532

1426

1751

1298

1306

1374, 1495, 1676,

1871

1390, 1412

1366, 1497

1798

1561

1293, 1869

1497

1514

1751

1389, 1751

1389

1298, 1531

1366, 1497

1288, 1316, 1548,

1633, 1763, 1764

1266, 1673

1384

1508

1289

1609, 1390, 1511

1437

1869

1519

1295, 1500

1469

1556

1517

1426

1532, 1869

0689, 1622, 1558,

1658, 1758, 1858,

1958

1390, 1528

1788

1390

1331, 1375

1293

Aiwa

Amphion Media Works

AMW

Anam

Apex Digital

Audiovox

Bose

Cambridge Soundworks

Classic

Coby

Criterion

Daewoo

Denon

Durabrand

Gateway

Go Video

Initial

Insignia

Integra

JBL

JVC

KLH

Koss

Lasonic

Lenoxx

LG

Liquid Video

Magnavox

NexxTech

Norcent

Nova

Onkyo

Oritron

Panasonic

Philips

Pioneer

Polaroid

Polk Audio

RCA

Regent

Rio

Saba

Samsung

Sanyo

Sharper Image

Sherwood

Shinsonic

Sonic Blue

Sony

Teac

Toshiba

Venturer

Yamaha

Zenith

Receiver

Etc.

LCT2518-002C-A.indd 57LCT2518-002C-A.indd 57 6/29/09 3:46:45 PM6/29/09 3:46:45 PM

58

Notes:

• The following connection diagrams are examples on connecting some of the most common

devices to your TV. Please refer to your device’s instruction manual on other connection

methods or for devices not shown here in this instruction book.

• When you are finished connecting your devices, turn on your TV and devices.

Connect an Antenna or Basic Cable

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

TV Rear Panel

Cable or Antenna

Output

INPUT 1

INPUT 2

INPUT 3

Connect a Cable Box

Cable or Antenna

Output

IN

CABLE BOX

OUT

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

TV Rear Panel

INPUT 1

INPUT 2

INPUT 3

Note:

• To view channels on your cable box, make sure your TV’s channel is set to 2, 3 or 4

(depending on the area you live in).

Connecting Your Devices

Notes:

• If you are able to receive ATSC (Digital terrestrial) signal, High Definition (HD) broadcasting

can be watched.

• All digital broadcasting is not necessary High Definition. Check by pressing the DISPLAY

button.

• Digital broadcasting is not available in all areas.

LCT2518-002C-A.indd 58LCT2518-002C-A.indd 58 6/29/09 3:46:45 PM6/29/09 3:46:45 PM

59

Notes:

• Green, blue and red are the most common colors for Component Cables. Some models may

vary in color.

• To watch your VCR / DVD player, make sure your TV is displaying INPUT 4 or INPUT 5 by

pressing the V4 or V5 button on your remote control.

Connect a VCR / DVD Player using Component Video

TV Rear Panel

(INPUT 4)

VCR / DVD Player

Green cable is for “Y”

Blue cable is for “PB”

Red cable is for “PR”

Video Out

PR

YPB

Audio Out

LR

Connect a VCR / DVD Player using Composite Video

TV Rear Panel

(INPUT 5)

VCR / DVD Player

Yellow cable is for “Video”

White cable is for “L”

Red cable is for “R”

Video Out

Y

Audio Out

LR

Notes:

• Yellow, white and red are the most common colors for Composite Cables. Some models may

vary in color.

• To watch your VCR / DVD player, make sure your TV is displaying INPUT 4 or INPUT 5 by

pressing the V4 or V5 button on your remote control.

• If your device has S-Video Output, you can use that instead of using Composite Cables.

Connect INPUT 4 (S-VIDEO) and S-video Output with an S-Video Cable.

Etc.

LCT2518-002C-A.indd 59LCT2518-002C-A.indd 59 6/29/09 3:46:45 PM6/29/09 3:46:45 PM

60

Connect an Amplifier using the DIGITAL AUDIO OPTICAL OUT

Notes:

• Refer to your amplifier’s manual for more information.

• This terminal can only output digital audio (PCM or DOLBY DIGITAL).

• In order to use the optical output connection, select PCM or DOLBY DIGITAL. See page 43.

• You can not output sound from your DIGITAL AUDIO OPTICAL OUT connection if the audio

source is from your HDMI device.

TV Rear Panel

(DIGITAL AUDIO OPTICAL OUT)

SpeakerSpeaker

Amplifier

(with DIGITAL AUDIO OPTICAL INPUT)

Connect an Amplifier or Home Theater System

TV Rear Panel

(AUDIO OUT)

SpeakerSpeaker

Amplifier

or

Home Theater System

Notes:

• Refer to your amplifier’s or Home Theater System’s manual for more information.

• If you have a device connected to INPUT 1, INPUT 2 or INPUT 3, you will not be able to hear

any audio from the AUDIO OUT on the back of the TV otherwise.

Connecting Your Devices

LCT2518-002C-A.indd 60LCT2518-002C-A.indd 60 6/29/09 3:46:46 PM6/29/09 3:46:46 PM

61

Connect a Digital Source Device

Notes:

• To watch your digital source device, make sure your TV is displaying INPUT 1 by pressing the

V1 button on your remote control.

• This TV can accept 480i, 480p, 720p, 1080i and 1080p signals via HDMI.

• The INPUT 1 DVI ANALOG AUDIO input can only be used with INPUT 1.

TV Rear Panel (INPUT 1)

Digital Source Device

TV Rear Panel

INPUT 1

DVI ANALOG

AUDIO

After the connections have been made,

tighten the screw to secure the cables.

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

DIGITAL OUT

LR

AUDIO OUT

INPUT 2

INPUT 3

75 Ω

(VHF/UHF)

Connect a Camcorder

TV Rear Panel

(INPUT 4)

Camcorder

Notes:

• To watch video from your camcorder, make sure your TV is displaying INPUT 4 or INPUT 5

by pressing the V4 or V5 button on your remote control.

• If your device has S-Video Output, you can use that instead of using Composite Cables.

Connect INPUT 4 (S-VIDEO) and S-video Output with an S-Video Cable.

Etc.

LCT2518-002C-A.indd 61LCT2518-002C-A.indd 61 6/29/09 3:46:47 PM6/29/09 3:46:47 PM

62

Connect a Blu-ray or HDMI Device

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

INPUT 3

INPUT 1

75 Ω

(VHF/UHF)

TV Rear Panel (INPUT 2)

Blu-ray / HDMI Compatible Device

Notes:

• To watch your Blu-ray or HDMI device, make sure your TV is displaying INPUT 1, INPUT 2 or

INPUT 3 by pressing the V1, V2 or V3 button on your remote control.

• Some decoders may not respond depending on the equipment that is connected to the HDMI.

• This TV can accept 480i, 480p, 720p, 1080i and 1080p signals via HDMI.

• This JVC television can accept a variety of HD signals, including 720p, 1080i, 1080p/24Hz,

1080p/30Hz and 1080p/60Hz. Please note that in some cases, a Blu-ray may only offer the

choice of 1080/60i or 1080/24p. In this case, it is necessary to choose the 1080/60i output.

Please refer to your Blu-ray manual for complete details on choosing the correct output.

• Some HDMI Output Devices may fail to detect this TV as a 1080p device. If this occurs,

manually select 1080p on the HDMI Output Device.

Connecting Your Devices

LCT2518-002C-A.indd 62LCT2518-002C-A.indd 62 6/29/09 3:46:48 PM6/29/09 3:46:48 PM

63

TV Rear Panel

PC

Connect a Computer

Notes:

• Make sure your TV is displaying INPUT 1, INPUT 2, INPUT 3 or INPUT 5 by pressing the V1,

V2, V3 or V5 button on your remote control.

• To use PC Smart Input function, see page 43.

• When you connect a PC using HDMI-DVI cable, connect an audio cable to INPUT 1 DVI

ANALOG AUDIO on the TV.

• Use a D-SUB cable with ferrite cores and no longer than 3 meters to avoid electromagnetic

disturbances.

• Refer to your computer’s manual for more information.

Resolution

640 x 480

800 x 600

1024 x 768

V. Frequency

(Hz)

60

60

60

H. Frequency

(kHz)

31.5

37.9

48.4

Format

VGA

SVGA

XGA

D-SUB

Resolution

640 x 480

800 x 600

1024 x 768

1920 x 1080

V. Frequency

(Hz)

60

60

60

60

H. Frequency

(kHz)

31.5

37.9

48.4

67.4

Format

VGA

SVGA

XGA

FHD

HDMI

Notes:

• Depending on signal quality, some pictures may not be displayed correctly.

• Computers that cannot set the refresh rate to 60 Hz, cannot be used with this TV.

• If you are inputting a PC signal that is invalid, “No signal or Signal can not be displayed” will

appear on the TV screen. It appears when the input is PC and it is a single screen.

• When you connect a PC using an HDMI cable, the TV image may not be displayed correctly.

PC

TV Rear Panel (INPUT 1)

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

INPUT 2

INPUT 3

75 Ω

(VHF/UHF)

Or...

Etc.

LCT2518-002C-A.indd 63LCT2518-002C-A.indd 63 6/29/09 3:46:48 PM6/29/09 3:46:48 PM

64

Refer to the table below to check the condition. If you think that there is a problem, contact the

JVC Service Center where you purchased the television.

Troubleshooting

There is no power

• See if the power cord became unplugged.

• Check for a blown fuse or circuit breaker or a power outage.

There is no picture or sound

• The antenna could be disconnected.

• The tuner could be set improperly. See page 58.

• The TV station may be having diffi culties. Check to see if other stations are working.

• Use the HDMI cable with HDMI logo.

• If you have a device connected to INPUT-1, INPUT-2 or INPUT-3, you will not be able to

hear any audio from the AUDIO OUT on the back of the TV.

• You cannot output audio using the DIGITAL AUDIO OPTICAL OUT when you have digital

sound from an HDMI device connected to the INPUT-1, INPUT-2 or INPUT-3 connection on

the back of the TV.

• This TV can accept 480i (Composite / S / HDMI / Component), 480p, 720p, 1080i and

1080p signals. Please check your settings.

Remote control is not operating properly or at all

• Check to see that the batteries are still working and properly installed.

• Make sure the remote has a clear sight path to the TV.

• You may be too far from the TV. You must be within 23 feet (7 meters).

The power turns off by itself

• Make sure the set did not become unplugged.

• Perhaps the Auto Shut Off is set. See page 41.

• Check to see if the Sleep Timer was set. See page 18.

It does not operate correctly

• This television is operated by a microprocessor. It is possible that external noise or

interference is causing the problem. If the television does not function correctly, remove

the electrical plug from the wall outlet and wait a while before inserting it into the wall outlet

again and operating the television.

The color quality is poor

• Tint and Color may be improperly adjusted. See page 26.

• The Video Status mode may be turned to the wrong setting. See page 26.

There are lines across the picture

• There could be interference from another electrical appliance, such as a computer, another

TV or VCR. Move any such appliances further away from the TV.

The picture is spotted

• There could be interference from a high-wattage appliance, like a hairdryer or vacuum,

operating nearby. Move the antenna away from the appliance or change to a coaxial cable

connection which is less prone to interference.

There are double pictures (ghosts)

• A building or passing airplane can refl ect the original signal and produce a second, slightly

delayed one. Adjust your antenna position.

LCT2518-002C-A.indd 64LCT2518-002C-A.indd 64 6/29/09 3:46:49 PM6/29/09 3:46:49 PM

65

The following are not malfunctions.

• The television may make a creaking sound if the temperature of the room or the temperature

of the inside of the television changes. If there is no problem with the screen or sound, then

there is no need to worry.

• The picture may be temporarily disturbed and noise may be seen on the screen if the power

is turned on immediately after it has been turned off. This is not a malfunction.

Picture is snowy (image noise)

• Your antenna may be damaged, disconnected or turned. Check the antenna connection. If

the antenna is damaged, replace it.

Screen is 80% black

• The Closed Caption Text mode is on. Turn it off in the Closed Caption menu, page 31.

Stereo or bilingual programs can’t be heard

• Make sure the MTS settings are correct. See page 39.

Static electricity

• It is normal to feel static electricity if you brush or touch the screen.

You hear occasional crackling sounds

• It is normal for the TV to make crackling sounds when fi rst turned on or off. Unless the

sound or picture become abnormal, this is fi ne.

The picture is slightly cut off when you use 1080p format only

• Change the picture format setting on your external device to 1080i or other resolution.

The screen disappears except for the menu screen

• This occurs when you select a digital menu when your input source is from the HDMI

connection. Press the MENU button.

My HDMI device doesn’t work or doesn’t work properly

• Please usa a High Speed HDMI™ Cable. High Speed HDMI™ Cable are tested to carry

an HD signal up to 1080p and higher.

No signal or signal can not be displayed

• This OSD appears when the digital channel that you have selected is too weak to receive

or no signal is being detected for that channel.

• It appears when that channel is not receiving a signal and you have the Noise Mute

function Off and you have a single screen. It moves automatically every two seconds to

prevent the screen from burn-in.

• Even if “No signal or signal can not be displayed” appears on the screen, your timer

functions and auto shut off functions that you set, are still active.

Etc.

LCT2518-002C-A.indd 65LCT2518-002C-A.indd 65 6/29/09 3:46:49 PM6/29/09 3:46:49 PM

66

LCD Flat TelevisionType

Reception Format

Power Source

Power Consumption

Model

NTSC, BTSC System (Multi-Channel Sound) ATSC Terrestrial, Digital Cable

AC 120V, 60 Hz

Screen Size

Speakers

Audio Output 10W + 10W

Antenna Terminal

(VHF/UHF,

ATSC/DIGITAL

CABLE IN)

75 ohms (VHF/UHF)(F-type connector)

Dimensions (inch/mm)

W X H X D

Weight (lbs / kg)

Optical Output

Digital Audio Digital Out (optical) x 1

Reception Range

VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper and Ultra bands

(191 channel frequency synthesizer system) at Analog

• Reception of channel A-5 ("95" of the TV set's on-screen cable channel numbers)

is not recommended for your TV set.

VHF 2 to 13, UHF 14 to 69 at ATSC,

CATV 135 Sub, Mid, Super, Hyper and Ultra bands at Digital Cable

Audio Output Jacks

(FIX)

FIX : 500mVrms (-4dBs), Low Impedance

Input 4, 5

Terminal

480i

S (Input 4)

Y: 1 Vp-p positive, 75 ohms (negative sync provided)

C: 0.286 Vp-p (burst signal), 75 ohms

Video: 1 Vp-p, 75 ohms

Audio: 500 mVrms (-4dBs) high impedance

Input 4, 5 Terminal

(Component Terminal)

1080i / 720p / 480p / 480i

Y: 1 Vp-p positive, 75 ohms (negative sync provided)

PB/PR: 0.7 Vp-p 75 ohms

Input 1, 2, 3 Terminal

(HDMI Input Terminal)

Video: 1080p / 1080i / 720p / 480p / 480i

Audio: 2ch PCM, 32 / 44.1 / 48 KHz 16 / 20 / 24 bit

4 x 16cm Oblique x 2

iPod Output

Power

5 V, 500 mA

LT-32P300

155W

32 inch / 80.03 cm

measured diagonally,

16:9 ratio

31 1/4 x 23 1/2 x 9 1/8

(with stand)

792 x 595.7 x 230

(with stand)

31 1/4 x 21 1/2 x 4 3/8

(without stand)

792 x 544.6 x 109.6

(without stand)

29.0 / 13.2 (with stand)

27.1 / 12.3 (without stand)

LT-42P300

LT-42PM30

215W

42 inch / 106.73 cm

measured diagonally,

16:9 ratio

39 7/8 x 28 7/8 x 11 5/8

(with stand)

1013.6 x 733.5 x 296

(with stand)

39 7/8 x 26 5/8 x 4 1/2

(without stand)

1013.6 x 677.3 x 114.8

(without stand)

49.5 / 22.5 (with stand)

46.0 / 20.9 (without stand)

PC Input Jacks Analog RGB D-SUB (15 pin) x 1

LT-46P300

215W

45.9 inch / 116.80 cm

measured diagonally,

16:9 ratio

44 3/8 x 31 1/2 x 11 5/8

(with stand)

1127 x 799.7 x 296

(with stand)

44 3/8 x 29 1/4 x 4 1/2

(without stand)

1127 x 743.2 x 114.8

(without stand)

55.9 / 25.4 (with stand)

52.4 / 23.8 (without stand)

Specifications subject to change without notice.

Specifi cations

LCT2518-002C-A.indd 66LCT2518-002C-A.indd 66 6/29/09 3:46:49 PM6/29/09 3:46:49 PM

67

LCT2518-002C-A.indd 67LCT2518-002C-A.indd 67 6/29/09 3:46:49 PM6/29/09 3:46:49 PM

JVC U.S.A.

Division of JVC Americas Corp.

1700 Valley Road

Wayne, New Jersey, 07470

JVC CANADA, INC.

21 Finchdene Square

Scarborough, Ontario

Canada, M1X 1A7

U.S.A.

TOLL FREE: 1 (800) 252-5722

http://www.jvc.com

Canada

TOLL FREE: 1 (800) 964-2650

http://www.jvc.ca

Remember to retain your Bill of Sales for Warranty Service.

LCT2518-002C-A.indd 68LCT2518-002C-A.indd 68 6/29/09 3:46:50 PM6/29/09 3:46:50 PM
