For Customer Use:

Enter below the Model No. and Serial

No. which are located either on the rear,

bottom or side of the cabinet. Retain this

information for future reference.

Model No.

Serial No.

LVT0901-001A

[J]

INSTRUCTIONS

MX-G500 — Consists of CA-MXG500 and SP-MXG500.

COMPACT COMPONENT SYSTEM

SP-MXG500 SP-MXG500

CA-MXG500

DISC CHANGE

COMPU PLAY CONTROL

STANDBY/ON

STANDBY

CD-R/RW PLAYBACK

CLOCK

/TIMER

DISPLAY

PHONES REPEAT

REC START

/STOP

CD REC

START DUBBING

PROGRAM RANDOM TAPE BTAPE A

AUX TAPE

/AM

SUBWOOFER

LEVEL

SOUND

MODE

MX-G500

EXTENDED SUPER BASS

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

CD 1

CD 2

CD 3

DISC CHANGE

COMPU PLAY CONTROL

STANDBY/ON

STANDBY

CD-R/RW PLAYBACK

TUNING

CLOCK

/TIMER

DISPLAY

PHONES REPEAT

REC START

/STOP

CD REC

START DUBBING

PROGRAM RANDOM TAPE BTAPE A

AUX TAPE

/AM

SUBWOOFER

LEVEL

SOUND

MODE

MX-GT700

EXTENDED SUPER BASS

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

CD 1

CD 2

CD 3

SP-MXGT700 SP-MXGT700

CA-MXGT700

MX-GT700 — Consists of CA-MXGT700 and SP-MXGT700.

DISC

SKIP

VOLUME

–

RM–SMXG500A REMOTE CONTROL

STANDBY/ON

123

456

789

+10

SLEEP

SOUND

MODE

TAPE A/B

FADE

MUTING

FM/AM

AUX

TAPE

SUBWOOFER

LEVEL

FM MODE

DISC

SKIP

VOLUME

–

RM–SMXG500A REMOTE CONTROL

STANDBY/ON

123

456

789

+10

SLEEP

SOUND

MODE

TAPE A/B

FADE

MUTING

FM/AM

AUX

TAPE

SUBWOOFER

LEVEL

FM MODE

GT700&G500COVER[J]_f 02.1.16, 9:03 PM1

– G-1 –

Warnings, Cautions and Others

Mises en garde, précautions et indications diverses

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

ATTENTION

Afin d’éviter tout risque d’électrocution, d’incendie, etc.:

1. Ne pas enlever les vis ni les panneaux et ne pas

ouvrir le coffret de l’appareil.

2. Ne pas exposer l’appareil à la pluie ni à l’humidité.

1. CLASS 1 LASER PRODUCT

2. DANGER: Invisible laser radiation when open and

interlock failed or defeated. Avoid direct exposure to

beam.

3. CAUTION: Do not open the top cover. There are no user

serviceable parts inside the Unit; leave all servicing to

qualified service personnel.

1. PRODUIT LASER CLASSE 1

2. ATTENTION: Radiation laser invisible quand l'appareil

est ouvert ou que le verrouillage est en panne ou

désactivé. Eviter une exposition directe au rayon.

3. ATTENTION: Ne pas ouvrir le couvercle du dessus. Il n'y

a aucune pièce utilisable à l'intérieur. Laisser à un

personnel qualifié le soin de réparer votre appareil.

Caution –– STANDBY/ON switch!

Disconnect the mains plug to shut the power off completely.

The STANDBY/ON switch in any position does not

disconnect the mains line. The power can be remote control-

led.

Attention –– Commutateur STANDBY/ON!

Déconnecter la fiche de secteur pour couper complètement

le courant. Le commutateur STANDBY/ON ne coupe

jamais complètement la ligne de secteur, quelle que soit sa

position. Le courant peut être télécommandé.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol,

within an equilateral triangle is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product's

enclosure that may be of sufficient

magnitude to constitute a risk of electric

shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

CAUTION

For U.S.A.

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

WARNING: TO REDUCE THE RISK OF FIRE

OR ELECTRIC SHOCK, DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR MOISTURE.

GT700&G500Safety[J]_f 02.1.16, 9:03 PM1

– G-2 –

For Canada/pour le Canada

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,

INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS

LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER

JUSQUAU FOND.

For Canada/pour le Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS

B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL

APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING

EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,”

ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.

CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE

BRUITS RADIOELECTRIQUES APPLICABLES AUX

APPAREILS NUMIRIQUES DE CLASSE B PRESCRITES DANS

LA NORME SUR LE MATERIEL BROUILLEUR: “APPAREILS

NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES

COMMUNICATIONS.

GT700&G500Safety[J]_f 02.1.16, 9:03 PM2

– 1 –

Introduction

About This Manual

This manual is organized as follows:

•The manual mainly explains operations using the

buttons and controls on the unit. You can also use the

buttons on the remote control if they have the same or

similar names (or marks) as those on the unit.

If operation using the remote control is different from

that using the unit, it is then explained.

• Basic and common information that is the same for many

functions is grouped in one place, and is not repeated in

each procedure. For instance, we do not repeat the

information about turning on/off the unit, setting the

volume, changing the sound effects, and others, which are

explained in the section “Common Operations” on pages 9

and 10.

• The following marks are used in this manual:

Gives you warnings and cautions to prevent

damage or risk of fire/electric shock.

Also gives you information which is not good

for obtaining the best possible performance

from the unit.

Gives you information and hints you had better

know.

Precautions

Installation

• Install in a place which is level, dry and neither too hot nor

too cold—between 5˚C (41˚F) and 35˚C (95˚F).

• Install the unit in a location with adequate ventilation to

prevent internal heat built-up in the unit.

• Leave sufficient distance between the unit and the TV.

• Keep the speakers away from the TV to avoid interference

with TV.

DO NOT install the unit in a location near heat

sources, or in a place subject to direct sunlight,

excessive dust or vibration.

We would like to thank you for purchasing one of our JVC products.

Before operating this unit, read this manual carefully and thoroughly to

obtain the best possible performance from your unit, and retain this manual

for future reference.

Power sources

• When unplugging from the wall outlet, always pull the

plug, not the AC power cord.

DO NOT handle the AC power cord with wet

hands.

Moisture condensation

Moisture may condense on the lens inside the unit in the

following cases:

• After starting heating in the room

• In a damp room

• If the unit is brought directly from a cold to a warm place

Should this occur, the unit may malfunction. In this case,

leave the unit turned on for a few hours until the moisture

evaporates, unplug the AC power cord, and then plug it in

again.

Others

• Should any metallic object or liquid fall into the unit,

unplug the unit and consult your dealer before operating

any further.

• If you are not going to operate the unit for an extended

period of time, unplug the AC power cord from the wall

outlet.

DO NOT disassemble the unit since there are no

user serviceable parts inside.

If anything goes wrong, unplug the AC power cord and

consult your dealer.

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM1

– 2 –

Contents

Location of the Buttons and Controls ....................... 3

Front Panel ................................................................. 3

Remote Control .......................................................... 5

Getting Started ............................................................ 6

Unpacking .................................................................. 6

Putting the Batteries into the Remote Control ........... 6

Connecting Antennas ................................................. 6

Connecting Speakers .................................................. 7

Connecting Other Equipment ..................................... 8

Canceling the Display Demonstration ....................... 8

Common Operations .................................................. 9

Turning On or Off the Power ....................................... 9

Setting the Clock ........................................................ 9

Selecting the Sources................................................... 9

Adjusting the Volume ............................................... 10

Reinforcing the Bass Sound ..................................... 10

Selecting the Sound Modes ...................................... 10

Listening to the Radio .............................................. 11

Tuning in a Station ................................................... 11

Presetting Stations .................................................... 11

Tuning in a Preset Station ........................................ 11

Playing Back CDs ..................................................... 12

Loading CDs ............................................................ 12

Playing Back CDs—All Disc and One Disc ............ 12

Basic CD Operations ................................................ 13

Programming the Playing Order of the Tracks

—Program Play .................................................. 14

Playing at Random—Random Play ......................... 15

Repeating Tracks or CDs—Repeat Play .................. 15

Prohibiting Disc Ejection—Tray Lock .................... 15

Playing Back Tapes ................................................... 16

Playing Back a Tape ................................................. 16

Recording .................................................................. 17

Recording a Tape on Deck B .................................... 17

Dubbing Tapes .......................................................... 18

CD Synchronized Recording ..................................... 18

Using the Timers ....................................................... 19

Using Daily Timer .................................................... 19

Using Recording Timer ............................................ 20

Using Sleep Timer .................................................... 21

Timer Priority ........................................................... 21

Maintenance .............................................................. 22

Troubleshooting ........................................................ 23

Specifications ............................................................. 24

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM2

– 3 –

Location of the Buttons and Controls

Become familiar with the buttons and controls on your unit.

Front Panel

DISC CHANGE

STANDBY/ON

STANDBY

CD-R/RW PLAYBACK

CLOCK

/TIMER

DISPLAY

PHONES REPEAT

REC START

/STOP

CD REC

START DUBBING

PROGRAM RANDOM TAPE BTAPE A

AUX TAPE

/AM

SUBWOOFER

LEVEL

SOUND

MODE

CD 1

CD 2

CD 3

EXTENDED SUPER BASS

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

COMPU PLAY CONTROL

;

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM3

– 4 –

See pages in the parentheses for details.

Front Panel

1STANDBY/ON button and STANDBY lamp (9)

2CLOCK/TIMER button (9, 19 – 21)

3DISPLAY button (9)

4PRESET +/– buttons (11)

4 / ¢ (reverse search/forward search) buttons

(9, 13 – 15, 19 – 21)

57 (stop) button (12 – 18)

6TUNING +/– buttons (11)

1 / ¡ (fast forward/fast rewind) buttons (13, 16)

7Display window

8Remote sensor

9TAPE 3 button and lamp (9, 16, 18)

Pressing this button also turns on the unit.

pCD 6 (play/pause) button and lamp (9, 12 – 15)

Pressing this button also turns on the unit.

qFM/AM button and lamp (9, 11)

Pressing this button also turns on the unit.

wAUX button and lamp (9)

Pressing this button also turns on the unit.

ePHONES jack (10)

rREPEAT button (12, 13, 15)

PROGRAM button (14)

RANDOM button (15)

tREC START/STOP button (17)

CD REC START button (18)

DUBBING button (18)

yTAPE A button (16)

TAPE B button (16)

uDeck A cassette holder (16, 18)

Pressing the 0 EJECT portion opens the holder.

iCarrousel

o0 (Carrousel open/close) button (12, 13 – 15)

Pressing this button also turns on the unit.

;DISC CHANGE button (12, 13)

Continued

aDisc number buttons and lamps (CD1, CD2, and CD3)

(13 – 15, 18)

Pressing one of these buttons also turns on the unit.

sSET button (9, 11, 14, 19 – 21)

dCANCEL/DEMO button (8, 9, 14, 20, 21)

fSOUND MODE control (10)

gVOLUME control (10)

hSUBWOOFER LEVEL control (10)

jDeck B cassette holder (16 – 18)

Pressing the EJECT 0 portion opens the holder.

Display window

1Timer indicators

• DAILY (daily timer), REC (recording timer), SLEEP

(sleep timer), and (timer) indicators

2Tape operation indicators

• A/B (operating deck), REC (recording), and 2 3 (tape

running) indicators

3CD play mode indicators

• REPEAT (1, 1 DISC, ALL DISC), PRGM (program),

and RANDOM indicators

4Tuner operation indicators

• MONO and ST (stereo) indicators

5SOUND MODE indicator

6Disc indicators

7Volume level, Subwoofer level and Sound Mode pattern

indicators

8SUBWOOFER LEVEL indicator

9CD track number indicators

pMain display

• Shows the source name, frequency, etc.

Display Window

126

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM4

– 5 –

Remote Control

1STANDBY/ON button (9)

2SLEEP button (21)

3AUX button (9)

Pressing this button also turns on the unit.

4Number buttons (11, 13)

5TAPE 3 button (9, 16)

Pressing this button also turns on the unit.

6FM/AM button (9, 11)

Pressing this button also turns on the unit.

7CD 6 button (9, 12 – 15)

Pressing this button also turns on the unit.

84/1 (fast rewind/reverse search) button

(11, 13, 16)

9VOLUME – button (10)

pSUBWOOFER LEVEL button (10)

qSOUND MODE button (10)

wFM MODE button (11)

eTAPE A/B button (16)

rFADE MUTING button (10)

tDISC SKIP button (12)

yVOLUME + button (10)

u¢/¡ (fast forward/forward search) button

(11, 13, 16)

i7 (stop) button (12 – 18)

When using the remote control, point it at

the remote sensor on the front panel.

DISC

SKIP

VOLUME

–

RM–SMXG500A REMOTE CONTROL

STANDBY/ON

123

456

789

10 +10

SLEEP

SOUND

MODE

TAPE A/B

FADE

MUTING

FM/AM

AUX

TAPE

SUBWOOFER

LEVEL

FM MODE

DISC CHANGE

COMPU PLAY CONTROL

STANDBY/ON

STANDBY

CD-R/RW PLAYBACK

CLOCK

/TIMER

DISPLAY

PHONES REPEAT

REC START

/STOP

CD REC

START DUBBING

PROGRAM RANDOM TAPE BTAPE A

AUX TAPE

/AM

SUBWOOFER

LEVEL

SOUND

MODE

EXTENDED SUPER BASS

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

PLAY

CD 3

CD 1

CD 2

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM5

– 6 –

Getting Started

Unpacking

After unpacking, check to be sure that you have all the

following items.

The number in the parentheses indicates the quantity of the

pieces supplied.

• AM loop antenna (1)

• FM antenna (1)

• Remote control (1)

• Batteries (2)

If any is missing, consult your dealer immediately.

Putting the Batteries into the Remote Control

Insert the batteries—UM-4/AAA/IEC R03—into the remote

control, by matching the polarity (+ and –) on the batteries

with the + and – markings on the battery compartment.

When the remote control can no longer operate the unit,

replace both batteries at the same time.

• DO NOT use an old battery together with a new one.

• DO NOT use different types of batteries together.

• DO NOT expose batteries to heat or flame.

• DO NOT leave the batteries in the battery

compartment when you are not going to use the

remote control for an extended period of time.

Otherwise, it will be damaged from battery leakage.

UM-4/AAA/IEC R03

Continued

Connecting Antennas

FM antenna

1Attach the FM antenna to the FM [75 Ω]

coaxial terminal.

2Extend the FM antenna.

3Fasten it up in the position which gives you

the best reception, then fix it on the wall, etc.

About the supplied FM antenna

The FM antenna supplied with this unit can be used as temporary

measure. If reception is poor, you can connect an outdoor FM

antenna.

To connect an outdoor FM antenna

Before connecting it, disconnect the supplied FM antenna.

FM antenna (supplied)

Outdoor FM antenna

(not supplied)

A 75 Ω antenna with coaxial type connector should be

used.

FM [75 ]

ANTENNA

FM [75 ]

ANTENNA

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM6

– 7 –

Press and hold the clamp of the AM terminal

on the rear of the unit.

Insert the end of the AM loop antenna cord

into the terminal.

• If the AM loop antenna wire is covered

with vinyl, remove the vinyl by twisting it

as shown in the diagram.

Release the finger from the clamp.

Turn the AM loop antenna until you have the

best reception.

To connect an outdoor AM antenna

When reception is poor, connect a single vinyl-covered wire

to the AM terminal and extend it horizontally. (The AM loop

antenna must remain connected.)

For better reception of both FM and AM

• Make sure the antenna conductors do not touch any other

terminals and connecting cords.

• Keep the antennas away from metallic parts of the unit,

connecting cords, and the AC power cord.

Press and hold the clamp of the speaker

terminal on the rear of the unit.

Insert the end of the speaker cord into the

terminal.

Match the polarity (colors): Blue (+) to blue (+) and black

(–) to black (–); red (+) to red (+) and black (–) to black

(–).

• If the wire is covered with vinyl, remove

the vinyl by twisting it as shown in the

diagram.

Release the finger from the clamp.

IMPORTANT: Use only speakers with the same speaker

impedance as indicated by the speaker terminals on the

rear of the unit.

MAIN SPEAKER SUBWOOFER

4-8

[ ]

-16

AM antenna

Vinyl-covered wire

(not supplied)

AM loop antenna

(supplied)

Connecting Speakers

Speaker

cord

(red/black)

From left

main

speaker’s

terminals

Speaker cord

(red/black)

Speaker cord

(blue/black)

From right

main

speaker’s

terminals

From left

subwoofer’s

terminals

From right

subwoofer’s

terminals

Speaker cord

(blue/black)

Blue Red

Black

ANTENNA

FM 75 AM

[ ]

For MX-GT700:

DO NOT carry the speaker by holding the duct

tube (on the top of the speaker).

Black

2, 3

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM7

– 8 –

DIGITAL OUT

OPTICAL

( )

For playing the other equipment through this unit,

connect between the audio output jacks on the other

equipment and AUX IN jacks by using audio cords (not

supplied).

To audio output

AUX IN

Audio/video

equipment

Connecting Other Equipment

You can connect both analog and digital equipment.

•DO NOT connect any equipment while the power

is on.

•DO NOT plug in any equipment until all

connections are complete.

To connect an analog component

Be sure that the plugs of the audio cords are color coded:

White plugs and jacks are for left audio signals, and red ones

for right audio signals.

CANCEL

DEMO

CANCEL

DEMO

To connect audio equipment with an optical digital

input terminal

You can record CD sound onto the connected digital

equipment.

Connect an optical digital cord (not supplied) between the

optical digital input terminal on the other equipment and the

DIGITAL OUT [OPTICAL] terminal.

NOW, you can plug in the unit and other

connected equipment FINALLY!

Cancelling the Display Demonstration

When connecting the AC power cord into a wall outlet, the

unit automatically starts display demonstration.

On the unit ONLY:

To cancel the display demonstration, press

CANCEL/DEMO.

When you press other buttons

The display demonstration stops temporarily. It will start

automatically again (if no operation is done for 2 minutes) until you

cancel it by pressing CANCEL/DEMO.

To start the display demonstration manually

Press and hold CANCEL/DEMO again for more

than 2 seconds.

To optical

digital input

Before connecting

the other equipment,

remove the

protective plug from

the terminal.

Audio equipment

with an optical digital

input

Protective

plug

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM8

– 9 –

Common Operations

Turning On or Off the Power

To turn on the unit, press STANDBY/

ON so that the STANDBY lamp goes off.

To turn off the unit (on standby), press

STANDBY/ON again so that the

STANDBY lamp lights up.

A little power is always consumed even while the unit is on

standby.

To switch off the power supply completely, unplug the AC

power cord from the AC outlet.

When you unplug the AC power cord or if a power

failure occurs

The clock is reset to “– – : – –” soon, while the tuner preset stations

(see page 11) will be erased in a few days.

Setting the Clock

Before operating the unit any further, first set the clock built

in this unit. You can set the clock whether the unit is on or

off.

On the unit ONLY:

Press CLOCK/TIMER.

The hour digits start flashing on the display.

Press 4 or ¢ to adjust the hour,

then press SET.

The minute digits start flashing on the display.

• If you want to correct the hour after pressing SET,

press CANCEL/DEMO. The hour digits start

flashing again.

ON TIME

(Daily Timer)

DAILY

Canceled ON TIME

(Recording Timer)

CLOCK

REC

Press 4 or ¢ to adjust the

minute, then press SET.

To check the clock time

Press DISPLAY while playing any source.

• Each time you press the button, the source

indication and the clock time alternate on the

display.

To adjust the clock again

If you have adjusted the clock before, you need to press

CLOCK/TIMER repeatedly until “CLOCK” is selected.

• Each time you press the button, the clock/timer setting

modes change as follows:

If there is a power failure

The clock loses the setting and is reset to “– – : – –.” You need to set

the clock again.

Selecting the Sources

To listen to the radio, press FM/AM. (See page 11.)

To play back CDs, press CD 6. (See pages 12 – 15.)

To play back tapes, press TAPE 3. (See page 16.)

To select the external equipment as the source, press AUX.

When you press the play button for a particular source (AUX,

FM/AM, CD 6, and TAPE 3), the unit turns on (and the

unit starts playing the source if it is ready—COMPU PLAY

CONTROL).

STANDBY/ON

STANDBY

STANDBY/ON

STANDBY

SET

DISPLAY

CLOCK

TIMER

SET

AUX

/AM

TAPE

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM9

– 10 –

Selecting the Sound Modes

This function only affects the playback sound, not your

recording.

You can select one of the 6 preset sound modes (3 surround

modes and 3 SEA—Sound Effect Amplifier—modes).

To select the sound modes, turn the

SOUND MODE control until the sound

mode you want appears on the display.

• As you turn the control, the sound modes change as

follows:

Surround modes*:

D.CLUB : Increases resonance and bass.

HALL : Adds depth and brilliance to the sound.

STADIUM: Adds clarity and spreads the sound, like in an

outdoor stadium.

SEA (Sound Effect Amplifier) modes:

ROCK : Boosts low and high frequency. Good for

acoustic music.

POP : Good for vocal music.

CLASSIC : Good for classical music.

OFF : Cancels the sound mode.

* Surround elements are added to the SEA elements to create

being-there feeling in your room.

When one of these modes is selected, the SOUND MODE

indicator lights up as —

While one of the SEA modes (SEA elements without surround

elements) is selected, the SOUND MODE indicator lights up as

—

When using the remote control, press SOUND MODE to

select the sound mode.

• Each time you press the button, the sound modes change as

follows:

Adjusting the Volume

You can adjust the volume level only while the unit is turned

on.

Turn the VOLUME control

clockwise to increase the volume or

counterclockwise to decrease it.

• The volume level can be adjusted in

32 steps (VOL MIN, VOL 1 —

VOL 30, and VOL MAX).

When using the remote control, press VOLUME + to increase

the volume or press VOLUME – to decrease it.

For private listening

Connect a pair of headphones to the PHONES jack. No sound

comes out of the speakers. Be sure to turn down the volume before

connecting or putting on headphones.

DO NOT turn off (on standby) the unit with the

volume set to an extremely high level; otherwise, a

sudden blast of sound can damage your hearing,

speakers and/or headphones when you turn on the

unit or start playing any source next time.

REMEMBER you cannot adjust the volume level

while the unit is on standby.

To turn down the volume level temporarily

Press FADE MUTING on the remote control.

The volume level gradually decreases to

“VOL MIN.”

To restore the sound, press the button again.

Reinforcing the Bass Sound

This function only affects the playback sound, not your

recording.

Turn the SUBWOOFER LEVEL control

clockwise to increase the subwoofer sound

or counterclockwise to decrease it.

• The subwoofer level can be adjusted

in 4 steps (LEVEL 1 — LEVEL 4.)

If you turn the control clockwise up to the LEVEL 4,

“MAX” flashes on the display for a few seconds.

When using the remote control, press SUBWOOFER LEVEL

to adjust the subwoofer level. Each time you press the button,

the subwoofer level changes as LEVEL 1 =LEVEL 2 =

LEVEL 3 =LEVEL 4 =(back to the beginning).

SUBWOOFER LEVEL indicator always

lights up while the unit is on.

FADE

MUTING

SUBWOOFER

LEVEL

SOUND

MODE

D.CLUB

(Dance CLUB)

OFF

(Canceled)

HALL STADIUM ROCK

POP

CLASSIC

SOUND MODE indicator also

lights up on the display

D.CLUB

(Dance CLUB)

OFF

(Canceled)

HALL STADIUM ROCK

POP

CLASSIC

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM10

– 11 –

Listening to the Radio

On the unit ONLY:

Tune in the station you want to preset (in this

example, of FM 87.50).

• See “Tuning in a Station.”

Press SET.

Press PRESET + or PRESET – to

select a preset number.

Press SET again.

The tuned station in step

is stored in the preset number

selected in step

• Storing a new station on a used number erases the

previously stored one.

When you unplug the AC power cord or if a power

failure occurs

The preset stations will be erased in a few days. If this happens,

preset the stations again.

Tuning in a Preset Station

Press FM/AM.

The unit automatically turns on and tunes

in the previously tuned station (either FM

or AM).

• Each time you press the button, the band

alternates between FM and AM.

Select a preset number.

On the unit:

Press PRESET + or PRESET –.

On the remote control:

Press the number buttons.

Ex.: For preset number 5, press 5.

For preset number 15, press +10

then 5.

For preset number 20, press +10,

then 10.

For preset number 25, press +10,

+10, then 5.

For preset number 30, press +10, +10, then 10.

Tuning in a Station

Press FM/AM.

The unit automatically turns on and tunes

in the previously tuned station (either FM

or AM).

• Each time you press the button, the

band alternates between FM and AM.

Start searching for stations.

On the unit:

Press and hold TUNING + or

TUNING – for more than 1 second.

On the remote control:

Press and hold 4/1 or

¢/¡ for more than 1

second.

The unit starts searching for stations

and stops when a station of sufficient

signal strength is tuned in.

If a program is broadcast in stereo, the ST (stereo)

indicator lights up.

To stop during searching, press TUNING + or TUNING –

(or 4/1 or ¢/¡ on the remote control).

When you press TUNING + or TUNING –

(or 4/1 or ¢/¡ on the remote control) briefly

and repeatedly

The frequency changes step by step.

To change the FM reception mode

When an FM stereo broadcast is hard to receive or

noisy, press FM MODE on the remote control so

that “MONO” appears and MONO indicator also

lights up on the display. Reception improves.

To restore the stereo effect, press FM MODE again so that

“STEREO” appears.

In this stereo mode, you can hear stereo sounds when a

program is broadcast in stereo.

Presetting Stations

You can preset 30 FM and 15 AM stations.

In some cases, test frequencies have been already memorized

for the tuner since the factory examined the tuner preset

function before shipment. This is not a malfunction. You can

preset the stations you want into memory by following the

presetting method.

• There is a time limit in doing the following steps. If the

setting is canceled before you finish, start from step

again.

FM MODE

SET

123

456

789

10 +10

SET

/AM

EN01-11.MX-GT700&G500[J]_f 02.1.16, 9:03 PM11

– 12 –

If you wish to load a third disc, press

DISC CHANGE on the unit or DISC

SKIP on the remote control.

The disc tray rotates by 120˚.

Press 0 again.

The carrousel closes.

About the disc indicators

Each disc indicator corresponds to the disc tray of the same number.

• The disc marker lights up for the disc number you have selected.

• The disc indicator rotates while the corresponding CD is being

played.

• The disc indicator goes off when the unit has detected that there is

no CD on the corresponding disc tray.

Playing Back CDs—All Disc and One Disc

You can play all loaded CDs continuously—All Disc play, or

one selected disc—One Disc play.

All Disc play

Load CDs.

• If the current playing source is not the CD player, press

CD 6, then 7 before going to the next step.

Press REPEAT repeatedly so that the

ALL DISC indicator lights up on the

display.

• Each time you press the button, the indication on the

display changes as follows:

* See page 15.

Playing Back CDs Continued

CORRECT INCORRECT

Disc number

Disc indicator

DISC

SKIP

Disc marker

DISC CHANGE

This unit has been designed to playback the following CDs:

Audio CD, CD-R, and CD-RW.

When playing a CD-R or CD-RW

User-edited CD-Rs (CD-Recordable) and CD-RWs

(CD-ReWritable) can be played back when they are already

“finalized.”

• You can play back your original CD-Rs or CD-RWs

recorded in music CD format ONLY. (If CD-RWs have

been recorded in different format, erase all the data on CD-

RWs completely before re-recording on the discs.)

DO NOT play back CD-Rs or CD-RWs

recorded the sound files such as MP3.

• Before playing back CD-Rs or CD-RWs, read their

instructions or cautions carefully.

• Some CD-Rs or CD-RWs may not be played back on this

unit because of their disc characteristics, damage or stain

on them, or if the player’s lens is dirty.

Important notices:

• In general, you will have the best performance by keeping

your CDs and the mechanism clean.

- Store CDs in their cases, and keep them in cabinets or on

shelves.

- Keep the unit’s carrousel closed when not in use.

• Continuous use of irregular shaped discs (heart-shape,

octagonal, etc.) can damage the disc rotating mechanism.

• CD-RWs may require a longer readout time since the

reflectance of CD-RWs is lower than for regular CDs.

Loading CDs

Press 0.

The unit automatically turns on and the

carrousel comes out.

Place one or two discs correctly on the front

recesses of the disc tray, with its label side up.

• When using a CD single (8 cm), place it on the inner

circle of the disc tray.

REPEAT ALL DISC*REPEAT 1 DISC*

REPEAT 1*

1 DISC

ALL DISC

(initial setting)

REPEAT PRO

Track number Elapsed playing time

Track number of the currently playing disc

(Track numbers exceeding 16 are not displayed.)

EN12-16.MX-GT700&G500[J]_f 02.1.16, 9:03 PM12

– 13 –

Press one of the disc number

buttons (CD1, CD2 or CD3)

for the disc you want to start

to play from.

CD play starts from the first track of the

selected disc.

• Pressing CD 6 instead of the disc number buttons

starts playing back if a CD is on the trays.

To stop during play, press 7.

To remove the disc, press 0.

CD playback sequence

When 3 CDs are loaded on the disc trays, they are played in one of

the following sequences.

• When CD1 is pressed : CD1 ] CD2 ] CD3 (then stops)

• When CD2 is pressed : CD2 ] CD3 ] CD1 (then stops)

• When CD3 is pressed : CD3 ] CD1 ] CD2 (then stops)

* When only 2 CDs are loaded, they are played in the same order,

but the disc tray without a CD is skipped.

One Disc play

When more than 2 CDs are loaded on the disc trays, you can

select one particular disc to be played back.

Load CDs.

• If the current playing source is not the CD

player, press CD 6, then 7 before going to

the next step.

Press REPEAT repeatedly so that the 1 DISC

indicator lights up on the display.

• Each time you press the button, the indication on the

display changes as follows:

* See page 15.

Press one of the disc number

buttons (CD1, CD2 or CD3) you

want to listen.

Playback stops when all tracks of the

selected disc are played once and resumes

to All Disc play.

To stop during play, press 7.

To remove the disc, press 0.

To exit from One Disc Play, press REPEAT repeatedly so

that ALL DISC indicator lights up on the display.

The following operations will also cancel the One Disc

play and restore All Disc play when—

• Turning off the power,

• Ejecting the carrousel, or

• Changing the source to play.

REPEAT PROG

CD 1

CD 2

CD 3

REPEAT ALL DISC*REPEAT 1 DISC*

REPEAT 1*

1 DISC

ALL DISC

(initial setting)

Basic CD Operations

While playing a CD, you can do the following operations.

To exchange CDs during playback of another

Press DISC CHANGE to change the CD and the

carrousel comes out.

If you change CDs during play, the current play

will not stop until all CDs you have changed are

played.

To close the carrousel, press DISC CHANGE or 0.

To skip to the another CD in the carrousel

Press DISC SKIP on the remote control.

To stop play for a moment

Press CD 6.

While pausing, “PAUSE” appears on the

display.

To resume play, press CD 6 again.

To locate a particular point in a track

During play, press and hold 1 or ¡.

•1: Fast reverses the disc.

•¡: Fast forwards the disc.

When using the remote control, press and hold

4/1 or ¢/¡.

To go to another track

Press 4 or ¢ repeatedly before or during

playback.

•4: Goes back to the beginning of the current

or previous tracks.

•¢: Skips to the beginning of the next or succeeding

tracks.

If you press and hold 4 or ¢ on the unit before

playing

The track number keeps changing until you release it.

To go to another track directly using the number

buttons

Pressing the number button(s) before or during play allows

you to start playing the track number you want.

Ex.: For track number 5, press 5.

For track number 15, press +10,

then 5.

For track number 20, press +10,

then 10.

For track number 32, press

+10, +10, +10, then 2.

123

456

789

+10

DISC CHANGE

DISC

SKIP

CD 1

CD 2

CD 3

EN12-16.MX-GT700&G500[J]_f 02.1.16, 9:03 PM13

– 14 –

Programing the Playing Order of the Tracks

—–Program Play

You can arrange the order in which the tracks play before you

start playing. You can program up to 32 tracks.

• To use Repeat play (see page 15) for Program play, press

REPEAT after starting Program play.

On the unit ONLY:

Load CDs.

• If the current playing source is not the CD player, press

CD 6, then 7 before going to the next step.

Press PROGRAM so that

“PROGRAM” appears on the

display.

The PRGM (program) indicator also lights up on the

display.

• All Disc play mode is selected automatically. You

cannot select One Disc play mode for Program play.

• If a program has been stored in memory, the program is

called up.

Press one of the disc number

buttons (CD1, CD2, and CD3) to

select the disc number you want

to play.

Press 4 or ¢ to select the track number,

then press SET.

Each time you select a track and press SET, the selected

track number is added to the track number indicator.

Track number

Disc number Program step number

SET

CD 1

CD 2

CD 3

PROGRAM RA

CANCEL

DEMO

Program other tracks you want.

• To program tracks from the same disc, repeat step

• To program tracks from a different disc, repeat steps

and

Press CD 6.

The tracks are played in the order you

have programed.

To stop during play, press 7.

To exit from Program play mode, press PROGRAM again

before or after play so that the unit enters All Disc play mode.

(The program you have made is stored in memory until you

turn off the unit, eject the carrousel, or erase the program.)

• Program play mode is also canceled when you press 0.

To modify the program

Before playing, you can erase the last programed

track shown on the display by pressing CANCEL/

DEMO.

• Each time you press the button, the last

programed track is erased from the program.

To check the program during play, press ¢ (or 4) so

that the playing track will change according to the program

(or reverse) order.

To add tracks in the program before play, simply select the

disc numbers and/or track numbers you want to add by

following steps

and

of the programing procedure.

To erase the entire program before or during play, press 7

twice.

• Turning the power off or ejecting the carrousel will also

erase the stored memory.

If you try to program a 33rd track

“FULL” will appear on the display.

If your entry is ignored

You have tried to program a track from an empty tray, or a track

number that does not exist on the CD. Such entries are ignored.

Continued

EN12-16.MX-GT700&G500[J]_f 02.1.16, 9:03 PM14

– 15 –

Playing at Random—–Random Play

The tracks of the selected CD will play at random.

• To use Random play mode, you have to cancel the Program

play mode.

Load a CD.

Press one of the disc number

buttons (CD1, CD2, and CD3)

for the disc you want to play,

then press 7.

Press RANDOM so that “RANDOM”

appears on the display.

The RANDOM indicator also lights up on the

display.

• Activating Random play cancels Repeat play or All Disc

play. (One Disc is automatically selected.)

• The tracks are played automatically at random. Random

play ends when all tracks are played once.

To stop during play, press 7.

To exit from Random play mode, press RANDOM again

during play so that the unit enters All Disc play mode.

• Random play is also canceled when you press 0.

If you press 4 or ¢

Skips to the next track selected randomly.

Repeating Tracks or CDs—–Repeat Play

You can have all the CDs, the program or the individual track

currently playing repeat as many times as you like.

To repeat play, press REPEAT during or before

playing.

• Each time you press the button, Repeat play

mode changes as follows, and the following

indicator lights up on the display:

REPEAT 1 : Repeats one track on one CD.

REPEAT 1 DISC** : Repeats all the tracks on one CD.

REPEAT ALL DISC: Repeats all the tracks on all the CDs.

*See page 12.

** REPEAT 1 DISC is not used for Program play.

To cancel Repeat play, press REPEAT repeatedly until the

REPEAT indicator (REPEAT 1, REPEAT 1 DISC or

REPEAT ALL DISC) goes off from the display.

• Repeat play and Random play cannot be used at the same

time.

• Repeat play is also canceled when you press 0.

Prohibiting Disc Ejection—–Tray Lock

You can prohibit CD ejection from the unit and can lock the

carrousel.

• This operation is possible only while the unit is on with CD

selected as the source.

On the unit ONLY:

To prohibit disc ejection, press 0 for the carrousel while

holding 7.

“LOCKED” appears for a while, and the carrousel is locked.

To cancel the prohibition and unlock the carrousel, press

0 for the carrousel while holding 7.

“UNLOCKED” appears for a while, and the carrousel is

unlocked.

If you try to eject CDs

“LOCKED” appears to inform you that the Tray Lock is in use.

MRANDOM

REPEAT ALL DISC REPEAT 1 DISC

REPEAT 1

1 DISC*

ALL DISC*

CD 1

CD 2

CD 3

REPEAT PRO

EN12-16.MX-GT700&G500[J]_f 02.1.16, 9:03 PM15

– 16 –

Playing Back Tapes

Playing Back a Tape

Press EJECT (0) for the deck you want to

use.

Put a cassette in, with the exposed part of the

tape down and the side you want to play

facing front.

• You can play back only type I tapes.

Close the cassette holder gently.

If you put cassettes in both decks A and B, the last deck

which you have put a cassette into is selected.

To operate the other deck, press TAPE A or TAPE B

(or TAPE A/B on the remote control).

Press TAPE 33

The tape play starts and the tape running

indicator (3) starts flashing slowly.

When the tape plays to the end, the deck

automatically stops.

The use of the C-120 or thinner tape is not

recommended, since characteristic deterioration

may occur and this tape easily jams in the pinch-

rollers and the capstans.

To stop during play, press 7.

To operate the other deck, press TAPE A or TAPE B (or

TAPE A/B on the remote control), then TAPE 3.

To fast-forward the tape, press ¡ (or ¢/¡ on the

remote control). The tape running indicator (3) starts

flashing quickly.

To rewind the tape, press 1 (or 4/1 on the remote

control). The tape running indicator (2) starts flashing

quickly.

To remove the cassette, press 0 EJECT for deck A or

EJECT 0 for deck B.

TAPE

For Deck A

For Deck B

EN12-16.MX-GT700&G500[J]_f 02.1.16, 9:03 PM16

– 17 –

Recording a Tape on Deck B

On the unit ONLY:

Press EJECT 0 for deck B.

Put in a recordable cassette, with the exposed

part of the tape down and the side you want

to record facing front.

Close the cassette holder gently.

Start playing the source—FM, AM, CD

player or auxiliary equipment connected to

AUX IN jacks.

• For duplicating tapes, see “Dubbing Tapes” on page 18.

• For recording from CD, see “CD Synchronized

Recording” on page 18.

Press REC START/STOP.

The REC (recording) indicator lights up on the

display and recording starts.

To stop during recording, press REC START/STOP again

or 7.

To remove the cassette, press EJECT 0 for deck B.

Recording

IMPORTANT:

•It should be noted that it may be unlawful to re-

record pre-recorded tapes, records, or discs without

the consent of the owner of copyright in the sound or

video recording, broadcast or cable program and in

any literary, dramatic, musical, or artistic embodied

therein.

• The recording level is automatically set correctly, so it

is not affected by the VOLUME control and the

SUBWOOFER LEVEL control. Thus, during recording

you can adjust the sound you are actually listening to

without affecting the recording level.

• While recording, you can hear sound modes through the

speakers or headphones. However, the sound is

recorded without these effects (see page 10).

• If recordings you have made have excessive noise or

static, the unit may be too close to a TV. Place the unit

away from the TV.

• You can use type I tape for recording.

To protect your recording

Cassettes have two small tabs

on the back to protect

unexpected erasure or re-

recording.

To protect your recording,

remove these tabs.

To re-record on a protected tape, cover the holes with

adhesive tape.

To keep the best recording and playback sound

quality

If the heads, capstans, and pinch rollers of the cassette

decks become dirty, the following will occur:

• Impaired sound quality

• Discontinuous sound

• Fading

• Incomplete erasure

• Difficulty in recording

To clean the head, capstan, and pinch roller

Use a cotton swab moistened with alcohol.

To demagnetize the head

Turn off the unit, and use a head demagnetizer (available

at electronics and audio shops).

Head

Capstan

Pinch roller

Erase head

REC START

/STOP

EN17-24.MX-GT700&G500[J]_f 02.1.16, 9:03 PM17

– 18 –

CD Synchronized Recording

You can easily record a CD onto a tape.

• You can also record the tracks in order you have made the

program.

On the unit ONLY:

Put a recordable cassette into deck B.

Place a disc correctly on the circle of the disc

tray, with its label side up.

Press one of the disc number buttons (CD1,

CD2, and CD3) to select the disc, then 7.

Press CD REC START.

“CD REC” appears, and the REC (recording)

indicator lights up on the display.

Deck B starts recording and the CD player starts playing.

When the recording is done, the CD player and deck B

stop.

To stop during CD Synchronized Recording, press REC

START/STOP or 7 .

To remove the cassette, press EJECT 0 for deck B.

Dubbing Tapes

On the unit ONLY:

Press TAPE 3, then 7.

Put the source cassette in deck A, and a

recordable cassette into deck B.

Press DUBBING.

Dubbing starts.

“DUBBING” appears, and the REC

(recording) indicator lights up on the display.

To stop during dubbing, press REC START/STOP or 7 .

To remove the cassette, press 0 EJECT for deck A and

EJECT 0 for deck B.

TAPE

ART

CD REC

START DUB

REC

ART DUBBING

CD 1

CD 2

CD 3

EN17-24.MX-GT700&G500[J]_f 02.1.16, 9:03 PM18

– 19 –

Press CLOCK/TIMER again.

“ON TIME” appears for 2 seconds, then the

unit enters on-time setting mode.

Set the on-time you want the unit to

turn on.

1) Press 4 or ¢ to set the hour, then

press SET.

2) Press 4 or ¢ to set the minute, then

press SET.

“OFF TIME” appears for 2 seconds, then

the unit enters off-time setting mode.

Set the off-time you want the unit

to turn off (on standby).

1) Press 4 or ¢ to set the hour, then

press SET.

2) Press 4 or ¢ to set the minute, then

press SET.

The unit enters source selecting mode.

Press 4 or ¢ to select the

source to play, then press SET.

• Each time you press 4 or ¢, the source

changes as follows:

TUNER FM : tunes in to a specified preset FM station.

= go to step

TUNER AM : tunes in to a specified preset AM station.

= go to step

CD : plays a disc from the first track.

= go to step

TAPE : plays a tape in deck A or B.

= go to step

AUX : plays an external source.

= go to step

Using the Timers

There are three timers available—Daily Timer, Recording

Timer, and Sleep Timer.

Before using the timers, you need to set the clock built in the

unit. (See “Setting the Clock” on page 9.)

Using Daily Timer

With Daily Timer, you can wake to your favorite music or

radio program. You can set the timer whether the unit is on or

off.

How Daily Timer actually works

The unit automatically turns on, set the volume level to the

preset level, and starts playing the specified source when the

on-time comes (the indicator flashes while the timer is

operating). Then, when the off-time comes, the unit

automatically turns off (stands by).

Daily Timer works every day unless you cancel it.

• There is a time limit in doing the following steps. If the

setting is canceled before you finish, start from step

again.

• If you have made a mistake while setting timer, press

CANCEL/DEMO. (However, this does not always work. If

CANCEL/DEMO does not work, press CLOCK/TIMER

repeatedly and start from step

again.)

Before you start...

•When using a CD as the source to play:

—Make sure there is a CD on the currently selected

disc number tray.

•When using a tape as the source to play:

—Make sure that a tape is in the deck whose deck

indicator (A or B) is lit on the display.

•When using the external component as the source to

play:

—Set the timer equipped with the external component

at the same time.

On the unit ONLY:

Press CLOCK/TIMER repeatedly

until “DAILY” appears on the display.

indicator lights up and the DAILY (daily

timer) indicator starts flashing on the display.

• Each time you press the button, the timer setting modes

change as follows:

DAILY

Canceled ON TIME

(Recording Timer)

CLOCK

(See page 9.)

RECON TIME

(Daily Timer)

TUNER FM TUNER AM

TAPE

AUX

CLOCK

TIMER

CLOCK

TIMER

SET

EN17-24.MX-GT700&G500[J]_f 02.1.16, 9:03 PM19

– 20 –

Select the preset station

number.

Press 4 or ¢ to select the preset

station number, then press SET.

The unit enters volume setting mode.

Press 4 or ¢ to set the volume

level.

• You can select the volume level from VOL

MIN, VOL 1 — VOL 30, and VOL MAX.

Press SET to complete the Daily

Timer setting.

The DAILY (daily timer) indicator stops

flashing and remains lit. The settings you have

done are shown on the display in sequence for your

confirmation.

Press STANDBY/ON to

turn off the unit (on standby)

if you have set the Daily Timer

with the unit turned on.

If the unit is turned on when the timer-on time comes

Daily Timer does not work.

To turn on or off Daily Timer after its setting is done

Press CLOCK/TIMER repeatedly until

“DAILY” appears on the display.

To turn off the Daily Timer, press

CANCEL/DEMO.

The DAILY (daily timer) indicator goes off

from the display (“OFF” appears for a while).

The Daily Timer is canceled, but the setting

for the Daily Timer remains in memory until

you change it.

To turn on the Daily Timer, press SET.

The DAILY (daily timer) indicator lights up

on the display. The settings you have done are

shown on the display in sequence for your

confirmation.

Using Recording Timer

With Recording Timer, you can make a tape of a radio

broadcast automatically. You can set the timer whether the

unit is on or off.

How Recording Timer actually works

The unit automatically turns on, tunes into the specified

station, sets the volume level to “VOL MIN,” and starts

recording when the on-time comes (the indicator flashes

while the timer is operating). Then, when the off-time comes,

the unit automatically turns off (stands by).

Recording Timer works only once, but the timer setting

remains in memory until you change it.

• There is a time limit in doing the following steps. If the

setting is canceled before you finish, start from step

again.

• If you have made a mistake while setting the timer, press

CANCEL/DEMO. (However, this does not always work. If

CANCEL/DEMO does not work, press CLOCK/TIMER

repeatedly and start from step

again.)

On the unit ONLY:

Put a recordable cassette into deck B.

Press CLOCK/TIMER repeatedly

until “REC” appears on the display.

indicator lights up and the REC (recording

timer) indicator also starts flashing on the

display.

• Each time you press the button, the timer setting modes

change as follows:

Press CLOCK/TIMER again.

“ON TIME” appears for 2 seconds, then the unit

enters on-time setting mode.

DAILY

Canceled ON TIME

(Recording Timer)

CLOCK

(See page 9.)

RECON TIME

(Daily Timer)

SET

CLOCK

TIMER

CANCEL

DEMO

SET

CLOCK

TIMER

CLOCK

TIMER

STANDBY/ON

STANDBY

Continued

EN17-24.MX-GT700&G500[J]_f 02.1.16, 9:04 PM20

– 21 –

Set the on-time you want the unit to

turn on.

1) Press 4 or ¢ to set the hour, then

press SET.

2) Press 4 or ¢ to set the minute,

then press SET.

“OFF TIME” appears for 2 seconds, then

the unit enters off-time setting mode.

Set the off-time you want the unit to

turn off (on standby).

1) Press 4 or ¢ to set the hour, then

press SET.

2) Press 4 or ¢ to set the minute, then

press SET.

The unit enters preset station selecting

mode.

Select the preset station.

1) Press 4 or ¢ to select the band

(“TUNER FM” or “TUNER AM”), then

press SET.

2) Press 4 or ¢ to select a preset channel

number, then press SET.

The REC (recording timer) indicator stops

flashing and remains lit. The settings you

have done are shown on the display in

sequence for your confirmation.

Press STANDBY/ON to

turn off the unit (on standby) if

necessary.

About the recording source

If you change the source while recording, the recording source also

changes.

To turn on or off Recording Timer after its setting is

done

1 Press CLOCK/TIMER repeatedly until

“REC” appears on the display.

2 To turn off the Recording Timer, press

CANCEL/DEMO.

The REC (recording timer) indicator goes off

from the display (“OFF” appears for a while).

The Recording Timer is canceled, but the

setting for the Recording Timer remains in

memory until you change it.

To turn on the Recording Timer, press SET.

The REC (recording timer) indicator lights up

on the display. The settings you have done are

shown on the display in sequence for your

confirmation.

Using Sleep Timer

With Sleep Timer, you can fall asleep to music.

You can set Sleep Timer when the unit is turned on.

How Sleep Timer actually works

The unit automatically turns off after the specified time

length passes.

On the remote control ONLY:

Press SLEEP.

The time length until the shut-off time appears

and the SLEEP indicator starts flashing on the

display.

• Each time you press the button, the time length changes

as follows:

Wait for about 5 seconds after specifying the

time length.

The SLEEP indicator stops flashing and remains lit.

To check the remaining time until the shut-off time, press

SLEEP once so that the remaining time until the shut-off time

appears for about 5 seconds.

To change the shut-off time, press SLEEP repeatedly until

the desired time length appears on the display.

To cancel the setting, press SLEEP repeatedly until “OFF”

appears on the display so that the SLEEP indicator goes off

from the display.

• Sleep Timer is also canceled when you turn off the unit.

Timer Priority

Since each timer can be set separately, you may wonder what

happens if the setting for these timers overlaps.

Here are some examples.

•Recording Timer has priority over Daily Timer.

If Recording Timer is set to come on while Daily Timer is

operating, Daily Timer is canceled and Recording Timer

start working.

•If Sleep Timer overlaps with another timer (either Daily

Timer or Recording Timer), a timer with the earlier shut-off

time has priority.

When using the Recording Timer and Sleep Timer at the

same time, pay special attention to the shut-off time.

Recording Timer

7:006:30

Sleep Timer

7:30

AM 6:00

SET

CLOCK

TIMER

CANCEL

DEMO

SET

SLEEP

STANDBY/ON

STANDBY

SLEEP10

OFF

(Canceled)

SLEEP20 SLEEP30 SLEEP60

SLEEP90SLEEP120

Daily Timer

7:006:30

Recording Timer

7:30

AM 6:00

canceled.

EN17-24.MX-GT700&G500[J]_f 02.1.16, 9:04 PM21

– 22 –

Maintenance

To get the best performance of the unit, keep your discs, tapes, and mechanism clean.

Handling cassette tapes

• If the tape is loose in its cassette, take up

the slack by inserting a pencil in one of

the reels and rotating.

• If the tape is loose, it may get stretched,

cut, or caught in the cassette.

• Be careful not to touch the tape surface.

• Avoid the following places to store the

tape:

— In dusty places

— In direct sunlight or heat

— In moist areas

— Near a magnet

Handling discs

• Remove the disc from its case by

holding it at the edge while pressing the

center hole lightly.

• Do not touch the shiny surface of the

disc, or bend the disc.

• Put the disc back in its case after use to

prevent warping.

• Be careful not to scratch the surface of

the disc when placing it back in its case.

• Avoid exposure to direct sunlight,

temperature extremes, and moisture.

To clean the disc

Wipe the disc with a soft cloth in a straight

line from center to edge.

DO NOT use any solvent—such as

conventional record cleaner, spray, thinner, or

benzine—to clean the disc.

Cleaning the unit

•Stains on the unit

Should be wiped off with a soft cloth. If the unit is heavily

stained, wipe it with a cloth soaked in water-diluted neutral

detergent and wrung well, then wipe clean with a dry cloth.

•Avoid the following since they may cause damage to the

unit.

- DO NOT wipe it with a hard cloth.

- DO NOT wipe it strong.

- DO NOT wipe it with thinner or benzine.

- DO NOT apply any volatile substance such as

insecticides to it.

- DO NOT allow any rubber or plastic to remain in

contact with it for a long time.

EN17-24.MX-GT700&G500[J]_f 02.1.16, 9:04 PM22

– 23 –

Symptom

Unable to cancel the display demonstration.

No sound is heard.

Hard to listen to broadcasts because of

noise.

The disc sound is discontinuous.

The disc tray does not open or close.

The disc does not play.

The cassette holders cannot be opened.

Impossible to record.

Operations are disabled.

Unable to operate the unit from the remote

control.

If you are having a problem with your unit, check this list for a possible solution before calling for service.

If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person,

such as your dealer, for service.

Troubleshooting

Cause

Other buttons are pressed to cancel the

display demonstration.

Connections are incorrect or loose.

• Antennas are disconnected.

• The AM loop antenna is too close to the

unit.

• The FM antenna is not properly extended

and positioned.

The disc is scratched or dirty.

• The AC power cord is not plugged in.

• Trays are locked.

The disc is placed upside down.

Power supply from the AC power cord has

been cut off while the tape was running.

Small tabs on the back of the cassette are

removed.

The built-in microprocessor may

malfunction due to external electrical

interference.

• The path between the remote control and

the remote sensor on the unit is blocked.

• The batteries are exhausted.

Action

Press DEMO on the unit. (See page 8.)

Check all connections and make

corrections. (See pages 6 to 8.)

• Reconnect the antennas correctly and

securely.

• Change the position and direction of the

AM loop antenna.

• Extend the FM antenna at the best

position.

Clean or replace the disc. (See page 22.)

• Plug the AC power cord.

• Unlock the trays. (See page 15.)

Place the disc with the label side up.

Turn on the unit.

Cover the holes with adhesive tape.

Unplug the AC power cord and then plug it

back in.

• Remove the obstruction.

• Replace the batteries.

EN17-24.MX-GT700&G500[J]_f 02.1.16, 9:04 PM23

– 24 –

Specifications

Amplifier section—CA-MXG500

Output Power

SUBWOOFERS : 80 W per channel, min. RMS, driven into

6 Ω at 63 Hz with no more than 10% total

harmonic distortion.

MAIN SPEAKERS: 40 W per channel, min. RMS, driven into

4 Ω at 1 kHz with no more than 10% total

harmonic distortion.

Audio input sensitivity/Impedance

(at 1 kHz, measured at MAIN SPEAKERS)

AUX : 400 mV/50 kΩ

Digital output: DIGITAL OUT (OPTICAL)

Signal wave length : 660 nm

Output level : –21 dBm to –15 dBm

Speakers/Impedance : Subwoofers : 6 Ω – 16 Ω

Main speakers : 4 Ω – 8 Ω

Tuner

FM tuning range : 87.50 MHz – 108.00 MHz

AM tuning range: 530 kHz – 1 710 kHz

CD player

CD Capacity : 3 CDs

Dynamic range : 85 dB

Signal-to-noise ratio : 85 dB

Cassette deck

Frequency response

Normal (type I): 50 Hz — 14 000 Hz

Wow and flutter : 0.15% (WRMS)

General

Power requirement : AC 120 V , 60 Hz

Power consumption : 130 W / 200 VA (at operation)

17 W (on standby)

Dimensions (approx.): 270 mm x 317 mm x 449 mm (W/H/D)

(10 11/16 in. x 12 1/2 in. x 17 11/16 in.)

Mass (approx.) : 8.8 kg (19.4 lbs)

Supplied accessories

See page 6.

Speaker section—SP-MXG500

Type : 3-way bass-reflex type

Speaker units : Subwoofer : 13.5 cm (5 3/8 in.)

cone x1

Main Woofer : 13.5 cm (5 3/8 in.)

cone x1

Tweeter : 5 cm (2 in.) cone x1

Power handling capacity : Subwoofer : 80 W

Main speaker : 40 W

Impedance : Subwoofer : 6 Ω

Main speaker: 4 Ω

Frequency range : Subwoofer : 26 Hz — 92 Hz

Main speaker : 92 Hz — 20 000 Hz

Sound pressure level : Subwoofer : 75 dB/W•m

Main speaker : 88 dB/W•m

Dimensions (approx.) : 282 mm x 318 mm x 322 mm (W/H/D)

(11 1/8 in. x 12 9/16 in. x 12 11/16 in.)

Mass (approx.) : 5.0 kg (11.1 lbs) each

Amplifier section—CA-MXGT700

Output Power

SUBWOOFERS : 110 W per channel, min. RMS, driven into

6 Ω at 63 Hz with no more than 10% total

harmonic distortion.

MAIN SPEAKERS: 55 W per channel, min. RMS, driven into

4 Ω at 1 kHz with no more than 10% total

harmonic distortion.

Audio input sensitivity/Impedance

(at 1 kHz, measured at MAIN SPEAKERS)

AUX : 400 mV/50 kΩ

Digital output: DIGITAL OUT (OPTICAL)

Signal wave length : 660 nm

Output level : –21 dBm to –15 dBm

Speakers/Impedance : Subwoofers : 6 Ω – 16 Ω

Main speakers : 4 Ω – 8 Ω

Tuner

FM tuning range : 87.50 MHz – 108.00 MHz

AM tuning range: 530 kHz – 1 710 kHz

CD player

CD Capacity : 3 CDs

Dynamic range : 85 dB

Signal-to-noise ratio : 85 dB

Cassette deck

Frequency response

Normal (type I): 50 Hz — 14 000 Hz

Wow and flutter : 0.15% (WRMS)

General

Power requirement : AC 120 V , 60 Hz

Power consumption : 145 W / 200 VA (at operation)

19 W (on standby)

Dimensions (approx.): 270 mm x 317 mm x 449 mm (W/H/D)

(10 11/16 in. x 12 1/2 in. x 17 11/16 in.)

Mass (approx.) : 9.1 kg (20.1 lbs)

Supplied accessories

See page 6.

Speaker section—SP-MXGT700

Type : 3-way bass-reflex type

Speaker units : Subwoofer : 20 cm (7 7/8 in.)

cone x1

Main Woofer : 9 cm (3 8/16 in.) cone x1

Tweeter : 5 cm (2 in.) cone x1

Power handling capacity : Subwoofer : 110 W

Main speaker : 55 W

Impedance : Subwoofer : 6 Ω

Main speaker : 4 Ω

Frequency range : Subwoofer : 26 Hz — 92 Hz

Main speaker : 92 Hz — 20 000 Hz

Sound pressure level : Subwoofer : 75 dB/W•m

Main speaker : 88 dB/W•m

Dimensions (approx.) : 240 mm x 425 mm x 333 mm (W/H/D)

(91/2 in. x 16 3/4 in. x 13 1/8 in.)

Mass (approx.) : 5.4 kg (12.0 lbs) each

Design and specifications are

subject to change without notice.

EN17-24.MX-GT700&G500[J]_f 02.1.16, 9:04 PM24

BT-51002-5

(0301)

QUALITY SERVICE

HOW TO LOCATE YOUR JVC SERVICE CENTER

Dear Customer,

In order to receive the most satisfaction from your purchase,please read the instruction booklet before

operating the unit.In the event that repairs are necessary, please call 1 (800)537-5722 for your nearest

authorized servicer or visit our website at www.JVC.com

Remember to retain your Bill of Sale for Warranty Service.

Do not service the television yourself

Caution

To prevent electrical shock,do not open the cabinet.There are no user serviceable

parts inside.Please refer to qualified service personnel for repairs.

Accessories

To purchase accessories for your JVC product,please call toll free:1 (800)882-2345 or

on the web at www.JVC.com

TOLL FREE: 1 (800) 537-5722

http://www.jvc.com

Authorized Service Centers

GT700&G500Warranty[J]_f 02.1.16, 9:04 PM2

THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND

IN COMMONWEALTH OF PUERTO RICO.

WHAT WE WILL DO:

If this product is found to be defective, JVC will repair or replace defective parts at no charge to the original owner.

Such repair and replacement services shall be rendered by JVC during normal business hours at JVC authorized service

centers. Parts used for replacement are warranted only for the remainder of the Warranty Period. All products and parts

thereof may be brought to a JVC authorized service center on a carry-in basis except for Television sets having a screen

size 25 inches and above which are covered on an in-home basis.

WHAT YOU MUST DO FOR WARRANTY SERVICE:

Return your product to a JVC authorized service center with a copy of your bill of sale. For your nearest JVC authorized

service center, please call toll free: (800) 537-5722.

If service is not available locally, box the product carefully, preferably in the original carton, and ship, insured, with

a copy of your bill of sale plus a letter of explanation of the problem to the nearest JVC Factory Service Center, the

name and location of which will be given to you by the toll-free number.

If you have any questions concerning your JVC Product, please contact our Customer Relations Department.

WHAT IS NOT COVERED:

This limited warranty provided by JVC does not cover:

1. Products which have been subject to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty

installation, lack of reasonable care, or if repaired or serviced by anyone other than a service facility authorized by

JVC to render such service, or if affixed to any attachment not provided with the products, or if the model number

or serial number has been altered, tampered with, defaced or removed;

2. Initial installation and installation and removal for repair;

3. Operational adjustments covered in the Owner's Manual, normal maintenance, video and audio head cleaning;

4. Damage that occurs in shipment, due to act of God, and cosmetic damage;

5. Signal reception problems and failures due to line power surge;

6. Video Pick-up Tubes/CCD Image Sensor, Cartridge, Stylus (Needle) are covered for 90 days from the date of purchase;

7. Accessories

8. Batteries (except that Rechargeable Batteries are covered for 90 days from the date of purchase);

There are no express warranties except as listed above.

THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS

LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN.

JVC SHALL NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER

DAMAGES, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, WITHOUT LIMITATION, DAMAGE

TO TAPES, RECORDS OR DISCS) RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH

OF THIS WARRANTY. ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANT-

ABILITY AND FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE WARRANTY PERIOD SET FORTH ABOVE.

Some states do not allow the exclusion of incidental or consequential damages or limitations on how long an

implied warranty lasts, so these limitations or exclusions may not apply to you. This warranty gives you specific

legal rights and you may also have other rights which vary from state to state.

LIMITED WARRANTY

JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth below ONLY TO THE

ORIGINAL PURCHASER AT RETAIL to be FREE FROM DEFECTIVE MATERIALS AND WORKMANSHIP from the date

of original retail purchase for the period as shown below. ("The Warranty Period")

PARTS LABOR

JVC COMPANY OF AMERICA

DIVISION OF JVC AMERICAS CORP.

1700 Valley Road

Wayne, NJ 07470

REFURBISHED PRODUCTS CARRY A SEPARATE WARRANTY, THIS WARRANTY DOES NOT APPLY. FOR DETAILS OF

REFURBISHED PRODUCT WARRANTY, PLEASE REFER TO THE REFURBISHED PRODUCT WARRANTY INFORMATION

PACKAGED WITH EACH REFURBISHED PRODUCT.

For customer use:

Enter below the Model No. which is located either on the rear, bottom or side of the cabinet. Retain this information

for future reference.

Model No. : Serial No. :

Purchase data : Name of dealer :

AUDIO-1

GT700&G500Warranty[J]_f 02.1.16, 9:04 PM3

MEMO

MEMO 02.1.16, 9:04 PM1

MEMO

MEMO 02.1.16, 9:04 PM2

VICTOR COMPANY OF JAPAN, LIMITED

0102KSMMDWSAM

GT700&G500COVER[J]_f 02.1.16, 9:03 PM2

INSTRUCTIONS

MANUEL D’INSTRUCTIONS

For Customer Use:

Enter below the Model No. and Serial

No. which are located either on the rear,

bottom or side of the cabinet. Retain this

information for future reference.

Model No.

Serial No.

LVT0901-002A

[C]

MX-G500

SP-MXG500 SP-MXG500

CA-MXG500

DISC CHANGE

COMPU PLAY CONTROL

STANDBY/ON

STANDBY

CD-R/RW PLAYBACK

CLOCK

/TIMER

DISPLAY

PHONES REPEAT

REC START

/STOP

CD REC

START DUBBING

PROGRAM RANDOM TAPE BTAPE A

AUX TAPE

/AM

SUBWOOFER

LEVEL

SOUND

MODE

MX-G500

EXTENDED SUPER BASS

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

CD 1

CD 2

CD 3

DISC CHANGE

COMPU PLAY CONTROL

STANDBY/ON

STANDBY

CD-R/RW PLAYBACK

TUNING

CLOCK

/TIMER

DISPLAY

PHONES REPEAT

REC START

/STOP

CD REC

START DUBBING

PROGRAM RANDOM TAPE BTAPE A

AUX TAPE

/AM

SUBWOOFER

LEVEL

SOUND

MODE

MX-GT700

EXTENDED SUPER BASS

FULL - LOGIC CONTROL CD SYNCHRO RECORDING

CD 1

CD 2

CD 3

SP-MXGT700 SP-MXGT700

CA-MXGT700

MX-GT700

DISC

SKIP

VOLUME

–

RM–SMXG500A REMOTE CONTROL

STANDBY/ON

123

456

789

+10

SLEEP

SOUND

MODE

TAPE A/B

FADE

MUTING

FM/AM

AUX

TAPE

SUBWOOFER

LEVEL

FM MODE

DISC

SKIP

VOLUME

–

RM–SMXG500A REMOTE CONTROL

STANDBY/ON

123

456

789

+10

SLEEP

SOUND

MODE

TAPE A/B

FADE

MUTING

FM/AM

AUX

TAPE

SUBWOOFER

LEVEL

FM MODE

— Consists of CA-MXGT700 and SP-MXGT700.

— Composé du CA-MXGT700 et SP-MXGT700.

COMPACT COMPONENT SYSTEM

SYSTEME DE COMPOSANTS COMPACT

— Consists of CA-MXG500 and SP-MXG500.

— Composé du CA-MXG500 et SP-MXG500.

GT700&G500COVER[C]f.pm6 02.2.19, 9:32 AM1

– G-1 –

Warnings, Cautions and Others

Mises en garde, précautions et indications diverses

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

ATTENTION

Afin d’éviter tout risque d’électrocution, d’incendie, etc.:

1. Ne pas enlever les vis ni les panneaux et ne pas

ouvrir le coffret de l’appareil.

2. Ne pas exposer l’appareil à la pluie ni à l’humidité.

Caution –– STANDBY/ON switch!

Disconnect the mains plug to shut the power off completely.

The STANDBY/ON switch in any position does not

disconnect the mains line. The power can be remote control-

led.

Attention –– Commutateur STANDBY/ON!

Déconnecter la fiche de secteur pour couper complètement

le courant. Le commutateur STANDBY/ON ne coupe

jamais complètement la ligne de secteur, quelle que soit sa

position. Le courant peut être télécommandé.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol,

within an equilateral triangle is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product's

enclosure that may be of sufficient

magnitude to constitute a risk of electric

shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

CAUTION

For U.S.A.

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

WARNING: TO REDUCE THE RISK OF FIRE

OR ELECTRIC SHOCK, DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR MOISTURE.

1. CLASS 1 LASER PRODUCT

2. CAUTION: Invisible laser radiation when open and

interlock failed or defeated. Avoid direct exposure to

beam.

3. CAUTION: Do not open the top cover. There are no user

serviceable parts inside the Unit; leave all servicing to

qualified service personnel.

1. PRODUIT LASER CLASSE 1

2. ATTENTION: Radiation laser invisible quand l'appareil

est ouvert ou que le verrouillage est en panne ou

désactivé. Eviter une exposition directe au rayon.

3. ATTENTION: Ne pas ouvrir le couvercle du dessus. Il n'y

a aucune pièce utilisable à l'intérieur. Laisser à un

personnel qualifié le soin de réparer votre appareil.

GT700&G500Safety[C]f.pm6 02.2.19, 9:33 AM1

– G-2 –

For Canada/pour le Canada

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,

INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS

LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER

JUSQUAU FOND.

For Canada/pour le Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B

LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL

APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING

EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,”

ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.

CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE

BRUITS RADIOELECTRIQUES APPLICABLES AUX APPAREILS

NUMIRIQUES DE CLASSE B PRESCRITES DANS LA NORME

SUR LE MATERIEL BROUILLEUR: “APPAREILS NUMERIQUES”,

NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.

Front view

Face

Caution: Proper Ventilation

To avoid risk of electric shock and fire, and to prevent

damage, locate the apparatus as follows:

1 Front:

No obstructions and open spacing.

2 Sides/ Top/ Back:

No obstructions should be placed in the areas shown by

the dimensions below.

3 Bottom:

Place on the level surface. Maintain an adequate air path

for ventilation by placing on a stand with a height of 10 cm

or more.

Sideview

Côté

1 cm

(7/16 in.)

1 cm

(7/16 in.)

15 cm

(5 15/16 in.)

15 cm

(5 15/16 in.)

15 cm

(5 15/16 in.)

15 cm

(5 15/16 in.)

15 cm

(5 15/16 in.)

Attention: Aération correcte

Pour prévenir tout risque de décharge électrique ou d’incendie et

éviter toute détérioration, installez l’appareil de la manière suivante:

1 Avant:

Bien dégagé de tout objet.

2 Côtés/dessus/dessous:

Assurez-vous que rien ne bloque les espaces indiqués sur le

schéma ci-dessous.

3 Dessous:

Posez l’appareil sur une surface plane et horizontale. Veillez à

ce que sa ventilation correcte puisse se faire en le plaçant sur

un support d’au moins dix centimètres de hauteur.

10 cm

(3 15/16 in.)

CA-MXGT700 CA-MXGT700

CA-MXG500 CA-MXG500

SP-

MXGT700

SP-MXG500

SP-

MXGT700

SP-MXG500

English

Français

GT700&G500Safety[C]f.pm6 02.2.19, 9:33 AM2

– 1 –

English

Introduction

About This Manual

This manual is organized as follows:

•The manual mainly explains operations using the

buttons and controls on the unit. You can also use the

buttons on the remote control if they have the same or

similar names (or marks) as those on the unit.

If operation using the remote control is different from

that using the unit, it is then explained.

• Basic and common information that is the same for many

functions is grouped in one place, and is not repeated in

each procedure. For instance, we do not repeat the

information about turning on/off the unit, setting the

volume, changing the sound effects, and others, which are

explained in the section “Common Operations” on pages 9

and 10.

• The following marks are used in this manual:

Gives you warnings and cautions to prevent

damage or risk of fire/electric shock.

Also gives you information which is not good

for obtaining the best possible performance

from the unit.

Gives you information and hints you had better

know.

Precautions

Installation

• Install in a place which is level, dry and neither too hot nor

too cold—between 5˚C (41˚F) and 35˚C (95˚F).

• Install the unit in a location with adequate ventilation to

prevent internal heat built-up in the unit.

• Leave sufficient distance between the unit and the TV.

• Keep the speakers away from the TV to avoid interference

with TV.

DO NOT install the unit in a location near heat

sources, or in a place subject to direct sunlight,

excessive dust or vibration.

We would like to thank you for purchasing one of our JVC products.

Before operating this unit, read this manual carefully and thoroughly to

obtain the best possible performance from your unit, and retain this manual

for future reference.

Power sources

• When unplugging from the wall outlet, always pull the

plug, not the AC power cord.

DO NOT handle the AC power cord with wet

hands.

Moisture condensation

Moisture may condense on the lens inside the unit in the

following cases:

• After starting heating in the room

• In a damp room

• If the unit is brought directly from a cold to a warm place

Should this occur, the unit may malfunction. In this case,

leave the unit turned on for a few hours until the moisture

evaporates, unplug the AC power cord, and then plug it in

again.

Others

• Should any metallic object or liquid fall into the unit,

unplug the unit and consult your dealer before operating

any further.

• If you are not going to operate the unit for an extended

period of time, unplug the AC power cord from the wall

outlet.

DO NOT disassemble the unit since there are no

user serviceable parts inside.

If anything goes wrong, unplug the AC power cord and

consult your dealer.

EN01-11.MX-GT700&G500[C]f.pm6 02.2.19, 9:33 AM1
