Kab Enterprise Co., Ltd. Remote control Users Manual
Users Manual
Thank-you for purchasing our Woods Model TM16+RC Series – 24 HR Outdoor Lighting Timer
with Remote Control.
Before using your timer, please read the following instructions carefully.
FEATURES
• Wirelessly turns lights and appliances on/off up to 50’ or 15m away
• Choice of operating mode – dusk to dawn, 2 –8 Hour settings or manual on
• Dual outlets – can control two devices
• Easy to install – just plug it in.
INSTALLATION
1. Mount the timer onto a wall near a grounded electrical outlet with the photo sensor facing
outwards. (Note:) To ensure proper operation of automatic function. Ensure
photocell sensor is shielded from all night time sources of light i.e. floodlights).
2. Nail or screw head must extend at least 3/16” out from the wall (nails or screws not
included). Hang the receiver from the slot on back of the unit onto the nail or screw. Plug the
power supply cord of the receiver into the outlet.
3. Plug the device cord into any of the two receptacles at the bottom of the receiver.
PROGRAMMING ON/OFF SETTINGS
Rotate the dial on the timer to select one of the following settings
Dial position Function
OFF Power OFF
ON Power ON
DUSK-DAWN Powers ON at dusk, OFF at dawn
2 Hrs ON at dusk – OFF in 2 hours
4 Hrs ON at dusk – OFF in 4 hours
6 Hrs ON at dusk – OFF in 6 hours
8 Hrs ON at dusk – OFF in 8 hours
TIMER AND REMOTE INTERACTION
Your timer includes a remote control with temporary override:
• Temporary override ON: turns the timer ON for desired settings (2, 4, 6 or 8 Hours).
Please note if your timer dial position is preset it will restart from ‘0’ and count until it
reaches the time set on the dial refer.
• Temporary override OFF: turns the timer OFF for 12 hours before switching control back
to the timer.
Timer Dial position Using the Remote
OFF Press the remote and the timer will turn OFF
ON Press the remote the timer will turn ON
DUSK-DAWN
2, 4, 6 or 8 HRS
Press the remote and it will go into a manual
restart mode. The timer will restart from ‘0’ and
count until it reaches the time set on the dial, or
dawn time. Please refer to examples below for
further explanation.
Examples
Timer set to ON or OFF REMOTE ON – OUTPUT ON; REMOTE OFF - OUTPUT
OFF
Timer set to DUSK-DAWN
When DUSK = 6:00 PM and DAWN = 5:00 AM
If at 4 :00 PM REMOTE activated to ON --> OUTPUT ON and stay ON until 5:00 AM.
Next day ON at DUSK , OFF at – DAWN
If at 10 :00 PM REMOTE activated to OFF --> OUTPUT OFF = 10:00 PM, and stays
OFF until DAWN next day. Next day ON at DUSK , OFF at DAWN
If TIMER setting is 2 HOURS (or 4,6,8 HOURS and so on)
DAY OR NIGHT TIME
REMOTE ON --> OUTPUT ON 2 HOURS (4,6.8 HOURS) Then OFF
When DUSK --> OUTPUT ON 2 HOURS (4,6,8 HOURS) Then OFF
If DUSK is at 6:00 PM
(1) If at 5 :00 PM REMOTE set ON , then OUTPUT ON immediately until 8:00 PM
(as time count restarted at dusk time).
(2) TIMER ON = 6:00 PM, TIMER OFF = 8:00 PM. If at 1 :00 PM REMOTE set ON ,
then OUTPUT turns ON until 3:00 PM.
(3) TIMER ON = 6:00 PM. If at 7:00 PM REMOTE set ON OUTPUT ON until 9:00
PM(as time count restarted at time remote activates to ON).
(4) TIMER ON = 6:00 PM. If at 7:00 PM REMOTE set OFF, then OUTPUT turns OFF
immediately until next day.
ELECTRICAL RATINGS
15 AMPS RESISTIVE, 1000 WATTS TUNGSTEN, 125 VAC, 60 Hz
Note: Tungsten rating relates to the total wattage of light bulbs used.
Resistive is the rating for appliance.
If further assistance is required please call:
1-800-561-4321 416-267-4614 (Toronto and surrounding regions)
Monday to Friday from 8:30AM-5:00PM Eastern Standard time
PRODUCT WARRANTY
Woods Industries (Canada) Inc. warrants this timer for two years from the date of purchase
when operated under normal conditions by the original purchaser (not transferable), against
defects caused by Wood’s workmanship or materials. This warranty is limited to the repair or
replacement, at Wood’s sole discretion, of all or part of the timer. The original receipt is
required for warranty purposes.
Woods is not responsible for injury, property damage or other consequential damages or
damages to third parties arising directly from an actual or alleged defect in mater or
workmanship of the product.
There are no representations, warranties, or conditions express or implied, statutory or
otherwise, other than herein contained, this warranty expressly excludes the implied
warranties and conditions contained in the sale of goods act (Ontario) or any other statue.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Industry Canada Statement
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
