KAB Enterprise TR-009-1 Remote control User Manual
Kab Enterprise Co., Ltd. Remote control
Users Manual
Remote Control Outlets
Operating Instructions
- FOR INDOOR OR OUTDOOR USE -
2
IMPORTANT SAFEGUARDS
Signal Word Definitions
NOTE: These are general definitions only; all may not pertain to the actual product
purchased.
DANGER – Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury. Usage of this signal word is limited to the most
extreme situations.
WARNING – Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
CAUTION – Indicates a potentially hazardous situation, which, if not avoided, may
result in minor/moderate injury or product/property damage. It also alerts against
unsafe practices.
When using electrical products, always follow basic safety precautions including
the following:
READ ALL INSTRUCTIONS BEFORE USE.
!! WARNING-- To reduce the risk of fire, electric shock, or serious personal
injury:
• Do not immerse the product in water or other liquids.
• This product is not intended for use by children and contains small parts that may
pose a choking hazard to children under the age of three. Keep the product out of
the reach of children and pets.
• Do not use an electrical device or appliance with this product whose electrical
specifications exceed those specified in the “Electrical Specifications” section of
this manual.
!! CAUTION-- To reduce the risk of personal injury or product/property
damage:
• This product is intended for non-commercial, non-industrial use in the remote
control of two electrical outlets. Do not use this product for any other purpose.
3
WARNING: This product is equipped with a three-prong grounding pin
plug to reduce the risk of electric shock. This plug will fit into a
grounded outlet only one way. This is a safety feature. Never use
the plug with an extension cord unless you can fully insert the plug
into the extension cord. Do not alter the plug. Do not attempt to
defeat the safety purpose of the grounding plug.
IMPORTANT INFORMATION REQUIRED BY THE FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
MODEL : TR-009-1
FCC ID : PAGTR-009-1
IC : 4494A-TR009-1
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
4
Features
• Controls two electrical outlets up to a distance of 50 feet
• Plugs into any grounded three-prong outlet
• Has two three-prong receptacles
To Set Up
1. Mount the Receiver near a three-prong, grounded, standard 120-volt AC electrical
outlet:
a. Choose a location on the wall to insert a nail or wood screw (not included) for
mounting the Receiver. Please note the following when choosing the location:
• When hung from the nail/screw, the Receiver must be close enough to the
outlet for the cord to plug into the outlet.
• The Receiver must be mounted vertically with its outlets facing downward
and not reaching ground level.
b. Insert the nail/screw into the wall in the chosen location. The nail or screw
head must extend at least 3/16” from the wall.
c. Hang the keyhole of the Receiver on the nail or screw.
2. Plug the Receiver into a standard 120-volt AC electrical outlet.
3. Confirm that the electrical specifications of an item you wish to use with this
product do not exceed those specified in the “Electrical Specifications” section.
Plug the item into an outlet of the Receiver.
4. Remove the plastic battery tab from the Battery Compartment in the back of the
Remote Control to activate the DC 12V Type A23 pre-installed battery.
To Use
1. To activate the Receiver, press the ON Button of the Remote Control. The red LED
of the Remote Control will illuminate momentarily and the LED of the Receiver
will remain illuminated.
NOTE: The Remote Control must be within 50 feet of the Receiver.
2. To turn the Receiver off, press the OFF Button of the Remote Control. The LED on
5
the Receiver will shut off.
Battery Handling and Usage
WARNING: Keep batteries away from children and pets.
• Follow the battery manufacturer’s safety and usage instructions.
• Insert the battery observing the proper polarity (+/−) as indicated inside the
Battery Compartment.
CAUTION: Failure to properly align the battery polarity can cause personal injury
and/or property damage.
• Remove a spent or discharged battery from the product. Remove the battery
when not using the product for an extended period.
• Never throw batteries into a fire. Do not expose batteries to fire or other heat
sources.
• Dispose or recycle spent/discharged batteries in compliance with all applicable
laws. For detailed information, contact your local solid waste authority.
Battery Replacement:
1. Remove the Battery Compartment Cover from the back of the Remote Control by
sliding the Cover in the direction that its treads curve.
2. Remove the spent battery and place a new DC 12V Type A23 battery into the
Battery Compartment, correctly observing the polarity indications (+/−) inside the
Battery Compartment.
3. Replace the Battery Compartment Cover.
Electrical Specifications
Voltage Frequency Wattage Amperage
120VAC 60Hz *1000W - 1625W 13A
*Maximum combined wattage for items using a tungsten bulb plugged into the
Receiver is 1000W.
*Maximum combined wattage for appliances plugged into the Receiver is 1625W.
6
