USER GUIDE
BH-2050
1. WELCOME
Thank you for purchasing the Kanen Bluetooth Headset.
We hope you will enjoy it !
Box contents
• Kanen over-ear Bluetooth headphone
• USB to micro USB cable
• 3.5 mm ( 1/8”) audio cable with microphone
• User guide
2
2. OVERVIEW
Button functions
Important: Playback, volume, and phone control functionality varies
by media device. When using the audio cable, control the playback,
volume & phone functions by using the media device controls.
Plug the headset into any available USB port on your PC using the
micro-USB cable
3
3. CHARGING
3.1 BATTERY STATUE
4
4. CONNECTING
4.1 CONNECT TO A BLUETOOTH DEVICE
1. Hold the Play / pause / pair button in the pairing position
for 3 secs.
2. Pairing mode will be announced in the headphones, and the
Bluetooth light will flash blue & red.
3. Headset named "BH-2050" shown on your Bluetooth device
4.2 CONNECT TO 3.5MM JACK CONNECTOR
Connect the headset to most smartphones, tablets or any other
3.5mm device using the supplied audio cable
5. SUPPORT
5.2 HOW TO CARE FOR YOUR HEADSET
- Always store the headset with the power off and safely protected
- Avoid storage at extreme temperatures (above 60℃/140°F or
below -40℃/-40°F. This can shorten battery life and may affect
operation. High temperatures may also degrade performance.
- Do not expose the headset to rain or other liquids.
5.1 FAQ
5 6
3.2 LED STATUE
LED battery statue
Microphone
Volume +/Next
Volume -/Previous
Power
Pair
Play / pause
Wired audio input
Micro USB port
Redial last number
/ Reject call
answer / end call
Button Function
Power Push the button to indicator "l"-power on
Push the button to indicator "0" - power off
Play / pause / pair Long press while off (5 seconds) - pairing
Short press (while playing music) - play / pause
Answer / end call Short press (while calling) - answer / end call
Reject call
/ Redial last number
Long press (while calling, 3 seconds) - reject call
Short press twice - redial last number
Volume up (+) / Next Press and hold to increase volume (max level indicated by beep sound)
Press once to go to next track
Volume down (-) / Previous Press and hold to decrease volume (min level indicated by beep sound)
Press once to go to previous track
Charge time About 2 hours
Talk time Up to 20 hours
Music playback time Up to 20 hours
Standby time Up to 100 hours
*Charging the headset before using for the first time is recommended
in order to maximize battery life.
Problem
I hear crackling noises
Solution
-Bluetooth is a radio technology that is sensitive
to objects between the headset and the connected
devices. Ensure the headset and the connected
device are within range (up to 10meters or 30feet)
I cannot hear anything
I am having Bluetooth
connection problems
-Increase the speaker volume
-Check your mobile device's Bluetooth menu and
delete/forget the headset. Re-connect the headset
to your Bluetooth device following the Bluetooth
connection instructions
Will the headset support
other Bluetooth equipment ?
-The headset is designed to work with Bluetooth
mobile devices. It can also support other Bluetooth
devices that can support a headset, hands-free
and / or advance audio distribution profile.
-Ensure that the headset is connected to a device
*Design and specifications are subject to change without notice
7 8
Bluetooth Version: 4.0
Supported Bluetooth profiles: A2DP v1.2, AVRCP v1.4,
HFP v1.6, HSP v1.2, DI v1.3
Frequency range: 2.4GHz - 2.4835GHz
Transmission range: up to 10 m (33’)
Power: lithium-ion polymer battery, 4.5 V / 500 mAh (rechargeable)
Driver size: 40mm
Frequency response: 20 Hz - 20 kHz
Sensitivity: 105±3dB
Specifications
CHARGE
LED Activity
Green (while plugged in) Fully charged
Function
Flashing Red Low battery
Red (when plugged in) Charging
Blue Phone conversation
Quick Blue/Red Flashing Pairing mode
Slow Blue Flashing Connected
jack
3 conductor
jack
4 conductor
Microphone
To explore our full selection of products, visit us at
www.kanen.net.cn or mail to support@kanen.net.cn for
customer support or to obtain specific instructions on
how to obtain warranty service for your product.
© 2015 All Rights reserved. All other trademarks and trade
names are those of their respective owners.
MADE IN CHINA
+
-
ON/OFF
Quick Blue/
Red Flashing
ON OFF
BH-2050
PAIR
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions : (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
