ACCESSORIES:
1. Micro USB Cable ( for charging )
2. 3.5mm Audio cable ( AUX-in cable )
3. User Manual
HIGHLIGHTS :
The speaker QUO BLADE BT is a compact Bluetooth speaker that can be wirelessly
connected to Bluetooth devices such as smart phones, tablets and computers to
playback any music collection stored on them. Thanks to its powerful battery, the
system delivers full stereo sound, separate from any mains supply, for up to 4-6 hours
and is the perfect companion for the park, while camping or on the beach. Process
control, can get rid of complicated connections and wiring distance constraints, the
user can enjoy high quality music .
BLUETOOTH CONNECTION:
Turn the QUO BLADE BT on by switching the power switch for seconds, then blue led
ash quickly. The speaker now has entered the Bluetooth pairing mode.
CONNECT TO MOBILE PHONES/TABLET PCS/COMPUTERS:
1. Activate your phone’s Bluetooth
2. Go to your phone’s Bluetooth settings , scan for new Bluetooth devices
3. Upon device found (BT-SPEAKER o QUO BLADE BT), click the device name and
pair with it
4. If your phone ask for pairing code , please enter ”0000” and conrm
5. After successful pairing, your speaker will sound a prompt tone and the LED
6. lights blue.
7. Note: Pairing time is varied with dierent mobile phones. It only need to pair
at the rst time and it will auto connect the devices which already paired before
(Speaker only can remember the last 8 paried devices name)
3
BLUETOOTH CONNECTION:
The QUO BLADE BT will have the voice instruction for incoming call. Short Press
to answer the call and talk to speaker directly.Short press to end the call and back
to play status. Long press to reject the incoming call. long press to dial back
the last dialed phone no if no phone conversation.
AUX AUDIO-IN CONNECTOR:
The QUO BLADE BT also features 1x AUX audio in port, simply connect the QUO
BLADE BT with your non-bluetooth mobile phone/MP3 player/PC/laptop with the
3.5mm jack audio cable. The green and blue led will be on, then you can play music
via wired connection.
LOW POWER INDICATOR:
The QUO BLADE BT will have voice hint to remind you to charge if battery is low (bat-
tery only left 10%). User need to charge the speaker timely.
CHARGING AND COMPUTER CONNECTION :
Connect the micro USB charging cable to a computer or USB charger, red Led indica-
tion for charging status.
Red LED goes o upon charging nished. (2~3 hours for charging time.)
4User Manual
HANDSFREE , VOLUME, SKIP TRACKS OPERATIONS :
Function Operation
Disconnet current bluetooth Long press “+, -” to disconnect the
current Bluetooth connection and
searching for another new device
and pairing
Answering a call During an incoming call, short press
key to answer the phone, short
press again hand up phone and back
to play music
Ending or refuse a call Short press key to end the call or
long press to refuse the call.
Redial a call Under Bluetooth mode, press
key for 2~3 sec to redial the last call
phone number.
Powering ON Long press to power on
Powering OFF Long press to power o
Volume Long Press + or - key to adjust volume
NOTE :
1. Under Bluetooth mode when the 3.5mm audio plug is inserted in, the speaker will
switch to line in status automatically;
2. Please switch o the speaker if don’t use to prevent power loss
SPECIFICATIONS:
1. QUO BLADE BT Interfaces:
Audio input connector: 3.5mm
AUX cable : support aux external audio input.
Charging interface: Micro USB
5
2. DIMENSIONS AND BASIC PARAMETERS:
LENGHT: 202 MM ± 0.5MM
HEIGHT: 130 MM± 0.2MM
WIDTH: 24 MM ± 0.5MM
Material: ABS plastic
Weight: 420G ± 5G
3. ELECTRICAL SPECIFICATIONS:
Compatibility:
Bluetooth 2.1
Transmission distance: up to 10 m (transmission distance may dierent according to
environmental factors and other device’s functional range)
Maximum output power: 5Wx2
Sound track: dual track
Signal to noise ratio S / N: ≥ 80dB
Frequency Range: 160Hz-20KHz
Distortion THD: ≤ 1%
Speaker unit: outer diameter 50mm, inner magnet, 4 ohms, 5W
Parameters of power:
Rated voltage: 3.7V DC
Battery: built-in lithium battery, 3.7V/2000mA
Charge voltage: 5V ± 0.25V
Charging time: 3 - 4 hours
Working Time: 4 - 6 hours aprox
LED STATUS:
1.Bluetooth status: blue light ashing for pairing. Blue light keep on for connection
status.
2. Line in mode: green light on
3. Charging status: red light on
4. Charging completed: red light o
5Wx2 （Audio）
6User Manual
TROUBLE SHOOTINGS:
1. My mobile phone can’t nd any new Bluetooth device?
a) Make sure the QUO BLADE BT speaker has entered pairing mode;
b) Ensure the QUO BLADE BT is within the eective working range;
2.Bluetooth devices can’t pair up
a) Make sure your mobile phone allows new connection, did not reach the maximum
allowed connection number, please ref to your mobile’s user manual
b) Make sure the pairing password entered is “0000’. If your are using a Bluetooth
transmitter device, please ensure the responding password of your Bluetooth
transmitter supports “0000” code.
3. My QUO BLADE BT does not play music / answer call when it connected to a
Bluetooth mobile phone?
a) Make sure your Bluetooth mobile phone supports A2DP and HSF (handsfree)
prole;
b) Ensure your Bluetooth cell phone is within eective working range.
4. When paired with my computer, windows ask for new driver? Can you supply?
a) We can’t supply. The bluetooth A2DP/HSF drivers may required to play stereo
sound via bluetooth connection. But the driver is actually needed for the bluetooth
module on your PC, instead of the QUO BLADE BT. Dierent bluetooth module may
require dierent drivers. Please contact your PC or bluetooth module’s manufacturer
for driver update.
5. Why can’t I remotely control the pause, play, previous song and skip track
functions with the speaker when playing music?
a) When you are using 3.5mm AUX audio in connection, you can’t pause, change
volume or skip tracks with the buttons on the speaker;
b) This feature needs the Bluetooth devices paired with the speaker to support AVRCP
(Audio/Video Remote Control Prole). Please make sure your cell phone or other
Bluetooth device supports AVRCP.
SAFETY NOTICES:
Read the following recommendations before using the QUO BLADE BT speaker.
a) Keep it dry and don’t take it to damp places to avoid the product’s internal circuit
being aected.
b) Keep the product away from direct sunlight or hot places. High temperatures will
shorten the life of electronic devices, destroy the battery or distort certain plastic
parts.
c) Don’t expose the product to extremely cold area. It may damage the internal
circuit board.
7
d) Don’t try to disassemble the product as it may get damaged if you are not profes-
sional. e) Don’t let it fall down onto the oor or other hard surfaces. The internal circuit
might get damaged.
f) Don’t use intensive chemical products or detergent to clean the product.
g) Don’t scratch the surface with sharp tips.
Please go to website www.quomobility.com for any support requirement
Copyright © 2015 QUO. ALL RIGHTS RESERVED. The info displayed on this user manual
may slightly dier from the actual product info. QUO is a registered trademark.
