KIDZTECH TOYS MANUFACTURING LTD 1/24 R/C Jet Panther

User Manual

1:24
SCALE
PRO. SYSTEM
Battery Installation
NO.: 84061 / 84063 / 84064 /
84065 / 84521 / 84522
age
6
For Transmitter (Fig. 3 and Fig. 4)
1. Unscrew the screw on the battery cover
2. Open the battery cover
3. Install 2 new 1.5V “AAA” batteries with correct polarities (+/-)
as shown inside the battery compartment
4. Close the battery cover
5. Tighten the screw on the battery cover
For Vehicle (Fig. 1 and Fig. 2)
1. Switch OFF the power
2. Unscrew the screw on the battery cover
3. Open the battery cover
4. Install 3 new 1.5V “AAA” batteries with correct polarities (+/-)
as shown inside the battery compartment
5. Close the battery cover
6. Tighten the screw on the battery cover
Vehicle - Battery Installation
Fig. 1 Fig. 3
Vehicle Fig. 2 Transmitter
Steering
Wheel
Turbe Boost
/ Bind key
Accelerator
Trigger
Transmitter - Battery Installation
Fig. 4
Direction
Adjustment
Battery
Compartment
ON/OFF
-RC Vehicle (Vehicle) x 1
-RC Transmitter (Transmitter) x 1
-Instruction Manual x 1
2 x AAA
For Transmitter
(Not Included)
Contents
RC Vehicle x 1RC Transmitter x 1
25
3 x AAA
For Vehicle
(Not Included)
by adult
Vehicle
2. Use the Steering Wheel to control the Vehicle turning left or right
Turn Left Turn Right
4. If the vehicle does not run in straight line, adjust the
Direction Adjustment on the Vehicle chassis (Fig.1)
5. Play on smooth surface to have the optimum performance
6. Remember to switch OFF the power of the Vehicle after playing
7. The optimum control range is up to 25m outdoor
Braking Action
Keep driving forward rapidly then switch to backward for the braking action. When the trigger
of the Transmitter returns to the center position, push it again for the backward action.
How To Bind
84063
1. Turn on the Vehicle.
2. Hold the Signal Match Button for 4 second then the Transmitter signal light will flash for 6-7 second. When the Transmitter signal light keep on will show the matching.
3. After the wheels of the Vehicle turn left and right and the LED light of the Transmitter stops flashing, the binding process completed for playing.
4. If it cannot complete within 8 seconds, please turn off both Vehicle and Transmitter and re-start the binding process.
5. When the binding process is done, whenever switching the Vehicle and Transmitter on and off, it searches for the code that it memorized, and will only lock on to the
Transmitter signal containing that code.
6. Please turn off both Vehicle and Transmitter and re-start all binding process if changing to another 2.4GHz Transmitter for playing.
Performance Tips
1. Do not drive on grass, dirt, sand, dusts, carpet or go through water
2. Do not drive in windy or rainy weather
3. Avoid direct impact the Vehicle with obstacles
4. Switch OFF the power when not in use to prevent damage of Vehicle and Transmitter
due to leakage of electrolyte from batteries
5. Remove all batteries from the Vehicle and Transmitter when not in use for long period
6. Keep fingers, hair and loose clothing away from wheels
7. The operating range can be affected by a variety of factors
a) Low Voltage of batteries in Transmitter or Vehicle
b) Interference from other items that emit radio frequency signals
8. Outdoor usage is recommended in order to get optimum control range
9. Recommend to play the vehicle on a clean and smooth surface
10. Clean the battery compartment to make sure it is free from dust to prevent poor
contact of batteries
FCC label compliance statement:
Cautions
1. Do not attempt to disassemble the Vehicle or Transmitter
2. Make sure the batteries are installed with correct polarities (+/-) as shown inside the
battery compartment
3. Remove the package and take out all accessories before giving the Vehicle and
Transmitter to child to play
The packaging and instruction manual contain important information. Please keep them
for future reference.
Warning! Choking Hazard. Not suitable for children under the age of 3 years due to
small parts.
We reserve the right to improve/amend specifications and colors without notice.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
RSS-210 Compliance Statement:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada,. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more
than that necessary for successful communication.
Declaration of Conformity
The product is in conformity with the requirement of EU Directive 2014/53/EU.
Environmental notes:
The whole product also does not belong to household waste at the end of the product life.
You can return it at collection points for the recycling of electronic and electronical instruments
The symbol on the item, instruction manual, hangtag or packing is showing this clearly.
Materials should be recycled according to their respective markings.
Recycling of old devices or other re-use of materials contained therein represents an important
contribution to environmental protection.
Please ask at your local community for the correct collection point.
Disposal of batteries
Batteries should not be disposed of in the household waste. As the consumer you are legally obliged to
return batteries containing harmful substances and all other used batteries. You can hand in your old
batteries at public collection points in your area or wherever batteries are sold.
Frequency band: 2410 - 2475 MHz
Maximum radio frequency
power transmitted: <0 dBm
Conforms to the safety requirements of ASTM F963
You will find these chemical abbreviations along with a crossed-out refuse bin on batteries containing
harmful substances:
Pb=Battery contains lead
Cd=Battery contains cadmium
Hg=Battery contains mercury
KIDZTECH TOYS MANUFACTURING LTD.
Room 1201,12/F, Inter-Continental Plaza,
94 Granville Road, TST East, Hong Kong.
Tel: (852) 27218868 info@kidztech.net
Made in China http://www.kidztech.net
Stop
Forward
3. Use the Accelerator Trigger to drive the Vehicle Forward, Stop and Backward
How To Play
1. Switch ON the Vehicle.
