KINGTA TECHNOLOGY A1 Bluetooth Speaker User Manual
KINGTA TECHNOLOGY CO., LTD Bluetooth Speaker Users Manual
Users Manual
Waterproof Wireless Speaker
User’s Manual Introduction
Thank you for choosing the TY-WSP100 as your source for
entertainment, you can use this item with iPads,iPhones,
iPods and many types of smart-phone to stream music ,
and enjoy hands-free calling.In order to get the best results
when using the device,please read this manual first before using.
Included:
1.Speaker
2.USB Micro Charging Cable
3.3.5 mm Micro-USB Cable
4.User Manual
Specifications
Supported Profiles:A2DPV1.2 ,AVRCPV1.4,
HFPV1.5,HSP1.2,GAVDP1.2
Bluetooth Range:33ft (10m)
Dimensions: 120.6 *75 *82.9 mm
Battery: Li-Ion 3.7V/2000mAh
Charging: 5V @ 1 A
Feartures
-Volume and song control directly on speaker unit
-Stunning sound clarity
-Ultra portable design
-Great for parties, indoor and outdoor
-Allow you to make and answer phone calls
1.Next/Volume+
2.ON/OFF/Play/Pause/Phone button
3.Previous/Volume –
4.Blue LED(Bluetooth)
5.Red LED(Charging)
6.MIC
7.Micro USB Charging/AUX in Port
2
3
7
6
1
4 5
TY-WSP100
Operation
Powering On
Press and Hold "ON/OFF" button 2 seconds to power ON, the
Blue LED will start to quick flash.
If an AUX cable is connected to the unit, the Blue LED will
becomes slow flash ,notifying you the unit is in Aux-In mode.
Powering Off
Press and Hold "ON/OFF" button 2 seconds to power OFF
Aux-In Mode
Plug in the supplied 3.5 mm cable into the unit. The other end is
connected to your device. The Blue LED will becomes slow flash.
It means in “Aux” mode.
Please note music and volume can be controlled by your device.
Charging
Attach the USB cable to the unit, and plug into any USB charger.
If the unit is completely discharged, it will take approximately 4
hours to fully charge.
The Red LED will illuminate during charging, when it has
completed, the Red LED will turn off.
Note:There will be a beep when the battery is low and needs to
be recharged.
Bluetooth Mode
Pairing
The unit will automatically go into “Pairing Mode” when it is
powered ON.
Go into your Bluetooth device settings menu and look for “TY-
WSP100”After the unit has paired and connected,
it will re-connect automatically when the unit is powered
on and the device is in range.
Note: Bluetooth Timeout :10 minutes
Making and Receiving Phone Calls
When the unit is connected and paired to your device,
Press and hold " " and " " button at the same time.
pairing off the phone that last connected before.
the unit allows you to make or receive phone calls with its
built-in microphone.
Press “ ” to accept a call
To end a call press“ ”
To place a call, simply dial the number or select a contact from
To reject a call, press and hold “ ” for 2 seconds
To press the button “ ” twice to redial the last dialed number
Begin Streaming Music
Press “ ” to start playing music.
Press and Hold “ ” 2 seconds to play the next track.
Press and Hold “ ” 2 seconds to play the previous track.
Press either “ ” or “ ” for volume control.
LED Status
Blue LED solid Bluetooth Mode
Blue LED become slow flash
Red LED
Aux Mode
Charging
Troubleshooting
Unit doesn’t connect
to device
Speaker needs to be connected/
re-paired to device
A tone is heard every few seconds Speaker needs to be charged
Unit will not power on Speaker needs to be charged
Unit doesn’t control
track(s)/volume
Speaker needs to be in Bluetooth
mode for full control
Unit distorts at
high volume
The devices’ volume needs to
be lowered
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
