KINGTA TECHNOLOGY T2 Bluetooth speaker User Manual 1
KINGTA TECHNOLOGY CO., LTD Bluetooth speaker 1
User manual
User’s Manual
Introduction:
you can use this item with tablet,notebook and many types of
Troubleshooting
Smart phone to stream music,and enjoy hands free calling.In order to get
the best results when using the device,please read this manual first before
using.
Feartures
-Volume and song control directly on speaker unit
-Stunning sound clarity
-Ultra portable design
-Great for parties, indoor and outdoor
-Allow you to make and answer phone calls
-TF card can use
Specifications
Loudspeaker: 4Ω 3W*2
Package Contents
Built-in Power:3.7V/2000mA
Dimensions: L166*W62*H68.2MM
SNR:≥80DB
Wireless Working Frequency: 2.402-2.480GHZ
Wireless Transmission Distance: up to 32 ft
Charging Time: 3-4 hours
Weight: 350.3g
Speaker Dimension:40mm
Charging: DC5V±0.5/500MA
1. Bluetooth
Speaker 2.
Bluetooth speaker
3. Bike Buddy
1. Keep this product and its charging cable away from excessive heat.
User’s Manual
T2
Important Safety Precautions
2. Do not operate this device with a damaged cable or after it has
malfunctioned or has been damaged in any manner.
3. Do not disassemble your device.
When using your Bluetooth Mobile Speaker, basic safety precautions
A Quick Look at Your Device
should always be followed, including the following:
1. Previous : Press to access the last track in
playlist.Press and hold to lower the volume
2. Phone : Press this button to activate the
the speaker phone function. When music is
playing, press to play or pause a track.
3. Next : press to access the next track in a
a playlist.Long press and hold to increase the volume.
4. Charging Port
You can plug one end of the included USB Charging
Cable into this jack, while plugging the other end into
a USB port on your computer in order to charge your
speaker’s built in lithium battery.
5. ON/OFF Switch
Press and hold the“ ”to power on
Charging Your Speaker
1. Connect one end of the included USB Charging Cable to the
Press and hold the“ ”again to power off
Charging Port on your speaker. Then plug the other end of the USB
Charging Cable into a suitable USB port on your computer to recharge
your speaker’s internal rechargeable battery.
NOTE: The internal battery of your speaker takes approximately four hours
to charge when completely drained.
2. When charging, a red LED light will illuminate to indicate that the unit is
charging. The red light will turn off when your unit is fully charged.
Understanding the LED Status Lights
When Charging Your Speaker
Solid red LED = Charging
No red LED = Charge Complete
When Pairing Your Speaker to a Bluetooth Audio Source
Rapid blinking blue LED: Bluetooth not connected. (Ready to pair.)
Pairing Bluetooth Devices to Your Speaker
In order to pair your Bluetooth audio device to your Bluetooth Speaker for
Solid blue LED: Bluetooth connected.l
the first time, follow the steps below:
1). Make sure your Bluetooth audio source is held within three meters of
your speaker.
2). Press and hold the “ ” switch on your speaker to power on
The LED light will blink blue to indicate that you have entered pairing
status.
3). Go to the Bluetooth Manager of your Bluetooth audio source. Please
refer to the User’s Manual of your Bluetooth audio source for more
information.
4). Search Bluetooth devices and select “T2”.
5). Once paired, the blue LED light will be solid and you can use your
speaker to listen to audio from you Bluetooth sound source.
Using the Hands-Free Function
When an iPhone or other smartphone is connected to your speaker follow
the steps below to take calls hands-free.
1. Press“ ”to pick up the call.
2. Press and hold“ ”for 2 sec to reject the call.
3. During a call: Press“ ”again to hang up the call.
Troubleshooting
The speaker doesn’t connect
to device Speaker needs to be connected/paired again
to device
A tone is heard every few
seconds
Speaker needs to be charged
The speaker will not power on Speaker needs to be charged
The speaker doesn’t control
track(s)/volume
Speaker needs to be in Bluetooth mode for
full control
The speaker sound is distorted
at high volume
The devices’ volume needs to be lowered
Bluetooth connection distance
cannot reach to 32ft.
Avoid operating the Bluetooth speaker in areas
of strong electromagnetic interference,such as
near indution cookers,large power fans,motors
etc.
Move the speaker closer to Bluetooth
device.Fully charge the speaker and try again.
Problem Solution
1
4
2
5
3
Audio Cable
USB Charging cable
T2, BDY-9087, EXTREME
KINGTA TECHNOLOGY CO.,LTD
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
