1. General Description
K-LCS [Node] is a specification for a suite of high level communication protocols using small, low-power digital
radios based on an IEEE 802 standard for personal area networks. K-LCS [Node] is often used in mesh
network form to transmit data over longer distances, passing data through intermediate devices to reach more
distant ones. This allows K-LCS [Node] networks to be formed ad-hoc, with no centralized control or high-
power transmitter/receiver able to reach all of the devices. Any K-LCS [Node] can be tasked with running the
network.
K-LCS [Node] is targeted at applications that require a low data rate, long battery life, and secure networking.
K-LCS [Node] has a defined rate of 250 kbit/s, best suited for periodic or intermittent data or a single signal
transmission from a sensor or input device. Applications include wireless light switches, electrical meters with
in-home-displays, traffic management systems, and other consumer and industrial equipment that requires
short-range wireless transfer of data at relatively low rates. The technology defined by the K-LCS [Node]
specification is intended to be simpler and less expensive than other WPANs, such as Bluetooth.
1.1 Features
IEEE 802.15.4 Standard Compatible Wireless Networking
Dimming (1 – 10 V), dimming range (10% ~ 100)
Power on/off
Power consumption, Current detection, Voltage detection
Data report (voltage/Current)
Power Consumption : < 2.5W
Independent RTC IC
Remote program update / Hardware Reset
Compact design 30mm × 40mm × 4.8mm
Distance Outdoor: approx. 100m
1.2 Applications
BEMS Applications
Street Lamp Applications
High-bay Lamp Applications
Parking Lamp Application
Document NO. Revision NO. 0.1 Page 3 / 4
Project Code Revised Date 2013-09-30
Prepared by S.J Byun
Project Name K-LCS [NODE ] Checked by
Subject Manual Approved by S.Seok
1.3 Notice
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
A label must be affixed to the outside of the host product with the following statements:
This device contains FCCID: ORI-ZBNODE
1.4 Caution Statement for Modifications
CAUTION : Any Changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate the equipment.
1.5 Mobile Device RF Exposure Statement
RF Exposure - This device is only authorized for use in a mobile application. At least 20 cm of separation distance
between the transmitting antenna device and the user's body must be maintained at all times.
1.6 Mobile Device RF Exposure Statement
The module is limited to OEM installation only.
OEM integrators must ensure that the end-user has no manual instructions to remove or install the
module.. OEM's must comply with FCC marking regulation part 15 declaration of conformity (Section
2.925(e)).
This module is to be installed only in mobile or fixed applications (Please refer to FCC CFR 47 Part
2.1091(b) for a definition of mobile and fixed devices).
The separate approval is required for all operating configurations, including portable configurations with respect to
FCC CFR 47 Part 2.1093 and different antenna configurations.
The K-LCS [Node] module has been designed to operate with the following antenna and gains. Use with
other antenna types or with these antenna types at higher gains is strictly prohibited.
Type of Antenna
Gain (dB) Type of
Connector
Planar Inverted
F antenna
2.59 dBi MCX(F) type
Document NO. Revision NO. 0.1 Page 4 / 4
Project Code Revised Date 2013-09-30
Prepared by S.J Byun
Project Name K-LCS [NODE ] Checked by
Subject Manual Approved by S.Seok
2. Specification
2-1. Electrical Specification
Type No. Description
Zigbee chip
RP-S2450, embedded 8051 with 96kB flash memory
(Tx:43mA, Rx:36mA, Sleep: 25uA)
Memory 128kB Serial Flash
Clock
16MHz Crystal for System Clock
32.768kHz Crystal for Sleep Timer
RF Tx Power +8dBm
RF Rx sensitivity -96dBm
Data rate 250kbps
Dimmer Level PWM, 0 ~ 100%
ADC 입력Level 0 ~ 3V
Power consumption < 2.5W (5V, 500mA)
Interface UART0(DMX512), UART1(Debug & Download)
Dimensions (W x L) 76.2 x 51.4 mm
2-2. Environmental Specification
Storage Temperature –40 ℃~ +85 ℃
Operating Temperature –30 ℃~ +70 ℃
Humidity (Operating) 5% ~ 95% (No dew condensation)
2-3. EMS Specification
PORT PROTECT MODE
ANT Port Common ( 0 – 1 kV / 8/20 s)
2-4. ESD Specification
EN55024 (Transient / BURST)
Contact discharging ±4KV
Air discharging ±8KV
2-5. EMI Specification
EN 55022 (Emission) Class B
