KYE SYSTEMS GMZJ7 Ring Mouse User Manual GM 090028T
KYE Systems Corp Ring Mouse GM 090028T
User Manual
English
1
Hardware Installation
Note: Supports Windows 7/Vista/XP.
1. Connect the pico receiver to a USB port of a PC or notebook.
2. Make sure that you have turned on the power switch.
Software Installation
1. Put the CD into the CD-ROM.
2. Follow the instructions on the screen to finish the software installation.
3. After installation, you’ll find the ioMedia icon in the taskbar.
ioMedia Software
ioMedia provides a fast setting for six scene modes. In each scene mode, each button has a
different function when you select it. Each feature is described on the next page.
English
2
i.
Device Selection
ii.
Scene Mode: Web Browsing, Music, Movie, Photo, Presentation and eBook
iii.
Product Photo
iv.
Button definition in each scene mode
v.
Set: Save the setting. (※)
Exit: Exit from ioMedia.
OK: Save the setting and exit from ioMedia. (※)
※
※※
※ Note:
(1). After you select each mode, the button function will not change immediately.
You can still move the cursor and execute the left and right button.
(2). Press
and
button together (as shown below) to execute the mode you have
selected. Press them together again to return to Mouse Mode.
(3). Press
,
and
button together to return to Mouse Mode and open the
ioMedia UI.
(4). When you change the mode each time, the taskbar will show in the message bar
to remind you.
Ring Mouse Function
1. Mouse Mode
OptoWheel Touch
Control Area Slide your thumb in the OptoWheel touch control area for
in-air cursor movement.
Left Button
Press OptoWheel touch control area to execute the click
function.
Press Left button for three seconds to turn on Click Lock
function. This lets you drag an object when holding down
the mouse button. To release, click the left button again.
Middle Button Provides traditional middle button function, like
auto-panning when the thumb is on the OptoWheel touch
control area.
Right Button Provides traditional right button functions.
English
3
2. Scene Mode
Web Browsing
OptoWheel Touch
Control Area
(Cursor Mode)
Press OptoWheel touch control area to execute the Click
function. Or slide your thumb in the OptoWheel touch
control area for in-air cursor movement.
Scroll Up & Down
(Scrolling Mode) Scroll up and down by using your thumb after you press the
Function key.
Function Key Press Function key to enter scrolling mode and press again
to return to cursor mode.
Right Button Provides traditional right button functions.
Note: This mode※
※※
※ works in Internet Explorer 6 or above.
Music
Pause/Play Button Press OptoWheel touch control area to Pause/Play when
playing music.
Volume Up & Down Scroll up using your thumb to increase the Volume.
Scroll down using your thumb to decrease the Volume.
Previous Song Press this button to play Previous Song.
Next Song Press this button to play next Song.
※
※※
※ Note: This mode works in Windows Media Player 9 or above.
Movie
Pause/Play Button Press OptoWheel touch control area to Pause/Play when
playing a movie.
Volume Up & Down Scroll up using your thumb to increase the Volume.
Scroll down using your thumb to decrease the Volume.
Rewind Press this button to rewind the movie.
Fast Forward Press this button to fast forward the movie.
※
※※
※ Note: This mode works in Windows Media Player 9 or above..
English
4
Zoon in & out Scroll up using the thumb to enlarge an area of the photo.
Scroll down using the thumb to Zoom out.
Previous Photo Press this button to see the previous photo.
Next Photo Press this button to see the next photo.
※
※※
※ Note: This mode works in Windows Picture and Fax Viewer.
Presentation
Black Screen Press OptoWheel touch control area for Black Screen
during a presentation.
Page Up & Down Scroll up using the thumb for Page Up.
Scroll down using the thumb for Page Down.
ESC Press this button to exit from the presentation.
Play Press this button to play the presentation.
※
※※
※ Note: This mode works in Microsoft Office PowerPoint.
eBook
OptoWheel Touch
Control Area
Press OptoWheel touch control area to execute the Click
function. Or slide your thumb in the OptoWheel touch
control area for in-air cursor movement.
Previous Page Press this button to return to previous page.
Next Page Press this button to go to next page.
※
※※
※ Note: This mode works in Adobe Reader.
Using Ring Mouse in Scene Mode
For example: Movie Mode
1. Open the ioMedia software.
2. Select “Movie” mode.
3. Open the movie clip in Windows Media Player.
4. Press
and
button together to execute the movie mode. If you wan to return to default.
function, press theses buttons together again.
5. In Movie mode, each button will have a new function; refer to “Scene Mode”.
English
5
Note: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment. (15.21)
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired
operation.(15.19(a)(3))
