User Manual
KYE SYSTEMS CORP.
English
1
Hardware Installation
For Mouse use:
Energy Mouse
Model:GM-120031/S
1. Connect the receiver to a USB port of a PC.
2. Make sure that you have switched on the power switch underneath the mouse.
For Mouse with power bank function charging:
1. How to start charge Energy Mouse
a. Plug the Micro USB cable into the Energy Mouse Micro USB port, and then
insert the other end of the cable into USB port of your power supply (e.g. wall
charger, or computer USB port). The power level LED indicators will be
flashing in sequence.
b. When the charge is completed, the four LEDs will stay on for 10 minutes, and
then turn off for power saving.
2. How to start charging mobile devices
a. Connect your device to the Energy Mouse USB output port.
b. Press and hold the button for two seconds to turn it on. The power level
LED indicators will flash three times and the charging will start.
c. To stop charging, press the button for two seconds again. Or just
disconnect the cable; Energy Mouse will automatically turn off in 30 seconds.
3. How to check power capacity of Energy Mouse
a. Press and hold button for two seconds for the power level. The four LEDs
will flash three times first then show the power capacity.
4. How to turn off Energy Mouse when charging is finished
a. Just remove the charger cable. Energy Mouse will
automatically turn off automatic off in 30 seconds.
Mouse Button Assignments
1. Left Button: Provides traditional mouse functions like click,
KYE SYSTEMS CORP.
English
2
double click and drag.
2. Magic-Roller: Press the “Magic-Roller” to surf the Internet
and Windows documents.
3. Right Button: Provides traditional mouse click functions.
4. Button: Press and hold this button for two seconds to turn it on. The power
level LED indicators will flash three times and the display battery’s capacity.
5. Power Level LED indicators: When the charge is completed, the four LEDs will
stay on for 10 minutes, and then turn off for power saving.
● LED On ○ LED Off ⊙ LED Blinking
Remark: Power level low indication
If the LED is flashing five times, then the power level is low, and you need to
recharge the mouse immediately.
Note: Download the programmable driver from our website: www.geniusnet.com
Warning: (Troubleshooting)
1. Make sure the Energy Mouse is completely charged before first usage.
2. Use the standard cable or it could cause damage to Energy Mouse.
3. Confirm the voltage of the mobile device is 5V before you use Energy Mouse to
charge it.
4. To maintain the life span and quality of Energy Mouse battery, we recommend
you unplug the power cable promptly after Energy Mouse is fully charged and
fully charge it every four months.
5. Do not drop, knock, disassemble or attempt to repair Energy Mouse by yourself or
you will void the warranty. If there is any problem, you can contact a service
center for assistance.
6. Do not leave Energy Mouse in a vehicle, expose it to sunlight or put it near any
heat source for a long time as strong light and high temperature will lead to
battery damage.
7. Store Energy Mouse in a cool, dry place, and keep it away from fire and moisture.
8. Do not put any object (except the USB cable) into any of the Energy Mouse micro
USB input or USB output ports to avoid short circuit damage.
9. Keep Energy Mouse away from children and pets. Do not use the wireless
optical/laser mouse on a desk which is made of glass or mirror.
10. The connection of the wireless device is factory preset, so when you plug the
USB receiver into any USB port, the connection between the micro receiver and
the mouse will be established automatically.
11. In case your PC did not install the hardware successfully, remove the micro
receiver from the USB port and go Human Interface Devices under Device
LED
Indicators ●●●● ●●●○ ●●○○ ⊙○○○
Blinking
Power Level 100-75% 75-50% 50-25% 25-5%
KYE SYSTEMS CORP.
English
3
Manager to remove the mouse, then plug in the micro receiver to a USB port
again.
12. Energy Mouse can be use as a wire Mouse connect to PC directly.
FCC
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
KYE SYSTEMS CORP.
English
4
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
13.
Safety Caution:
KYE SYSTEMS CORP.
English
5
Correct Disposal of this product. This marking indicates that this
product should not be disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
