AirMaster 4000D is a high performance 4G LTE outdoor CPE product designed

to enable quick LTE fixed data service deployment to the remote customers. It

provides high data throughput and networking features to end users who need

both bandwidth and quality service in the remote area.

RELIABLEPERFORMANCE

AirMaster 4000D is a cost effective outdoor data CPE based on the standard implementation of LTE release 9

specifications. It is able to meet the most demanding requirements from large service providers with high

throughput and availability. With high gain directional patch antenna, AirMaster 4000D enables a longer

reception range from the base station. This yields more efficient use of the network with a larger cell reach,

guaranteed carrier class service, and customer service probability.

The device has one PoE enabled data port and a simple software firewall for security, providing an effective

all-in-one solution to remote enterprise or home networking needs. Factors such as integrated design, low

power consumption, high antenna gainand improved heat dissipation designs further improve the

operational life span of this device.

EASYUSAGE&MANAGEMENT

AirMaster 4000D is a user-friendly LTE CPE, and very easy to install and maintain. Easy and simple

installation for non-professional user delivers instant broadband anywhere. Subscribers can just connect the

device to their computer or home switch/router and the device is ready to offer an experience of surfing over

Internet. The LEDs on the AirMaster 4000D have also been designed for user convenience, and offer a clear

sign of what the device is doing. The compact design is well suited for enterprise and residential home use in

the outdoor environment.The IP addresses can be statically allocated or dynamically obtained via DHCP.

AirMaster 4000D offers rich management features which facilitate the task of service provider. It supports

local management access, Telnet, WEB, and centralized remote OTA configuration, upgrades management

and device monitoring via standard TR-069 ACS systems.

TECHNICALFEATURES

AirMaster 4000D is fully compliant to the LTE Release 9 specification. It offers standard support for 4G

features such as MIMO andAMC to maximize the system capacity and bandwidth throughput. The use of

OFDM modulation enhances performance in non-line-of-sight (NLOS) conditions to ensure immunity to

interference and multi-path conflicts typical of deployments in densely populated urban areas. Sophisticated

QoS capabilities ensure true end-to-end QoS and support for high quality data services.

AirMaster 4000D has built-in router function and VPN client support to provide greater service flexibility and

reliability. The standard PoE support, easy-to-read signal strength and data activity indicators in the back

panel make it intuitive for users to install and check the status of the device.

The product is designed to operate in stringent outdoor environment and meets IP67, lighting and input

power surge protection requirements. The supported product frequency band is LTE B43 (3.65-3.675GHz).



KZ TECHLTE

ODUProduct Series

AirMaster 4000D LTE Outdoor CPE



Shenzhen, China 518057 Tel: +86 (755) 33639088 Fax: +86 (755) 33631919

www.kztech.cn





Physical

Dimensions 198mm x 194mm x 48mm

Weight < 1.5Kg

Power Consumption < 12 W

Power Supply 48V/0.32A DC (PoE optional)

Environmental

Operating Temperature -40°C--55°C

Storage Temperature -30°C--85°C

Humidity 90% max Non-condensing

Wireless Interface

Radio Access 3GPP E-UTLA

Release 9, CAT4

Frequency Band B43（3.65-3.675GHz）

Operation Mode TDD, 2Rx, 1TxD, DL

Antenna Gain 15 dBi

User Interfaces

Data Interface: 1 RJ45 10/100M ETH Port

LED Indicators: Power, System, LAN, SIM,RF(5)

SIM Support SIM card slot

Networking Configuration

DHCP or Static IP address Assignment

Bridge and Router Operation Support

Built-in DHCP Server for LAN Devices

IPv4, IPv6 DS-Lite Support

Multiple PDN interface support

NTP Service Support

Data Networking Features

VPN Pass-through support (PPTP, L2TP & IPsec)

Built-in L2TP & GRE Client Support

Firewall & Access Control

DMZ and Virtual Server Support

IP and Port Filtering Support

Local and Remote Management Restriction

Application Firewall Support

LAN Device Access Control

Device Management

CLI, Telnet and WEB Management Interfaces

Standard TR-069 Management

Device Factory Default Setting

Virtual SIM Support

Industry Standards

ITU

3GPP 3GPP E-UTLA Release 9

IEEE

IEEE 802.3 10Base Ethernet

IEEE 802.3u Fast Ethernet

OTHERS

Water Resistance IP67

Safety FCC or CE



M4000DLTE Outdoor CPE Specifications



Shenzhen, China 518057 Tel: +86 (755) 33639088 Fax: +86 (755) 33631919

www.kztech.cn



InformationtoUsers



AccordingtotheFCCPart15.19,15.21,and15.105

rules,forthisEUT,theinstructionsoroperation

manualfurnishedtheusershallincludethe

followingorsimilarstatement,placedina

prominentlocationinthetextofthemanual:



FCCWarning



ThisdevicecomplieswithPart15oftheFCCRules.

Operationissubjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference,

and(2)thisdevicemustacceptanyinterference

received,includinginterferencethatmay

causeundesiredoperation.



NOTE1:Thisequipmenthasbeentestedandfound

tocomplywiththelimitsforaClassBdigitaldevice,

pursuanttopart15oftheFCCRules.Theselimits

aredesignedtoprovidereasonableprotection

againstharmfulinterferenceinaresidential

installation.Thisequipmentgenerates,usesandcan

radiateradiofrequencyenergyand,ifnotinstalled

andusedinaccordancewiththeinstructions,may

causeharmfulinterferencetoradio

communications.However,thereisnoguarantee

thatinterferencewillnotoccurinaparticular

installation.Ifthisequipmentdoescauseharmful

interferencetoradioortelevisionreception,which

canbedeterminedbyturningtheequipmentoffand

on,theuserisencouragedtotrytocorrect

theinterferencebyoneormoreofthefollowing

measures:

‐Reorientorrelocatethereceivingantenna.

‐ Increasetheseparationbetweentheequipment

andreceiver.

‐Connecttheequipmentintoanoutletonacircuit

differentfromthattowhichthereceiver

isconnected.

‐Consultthedealeroranexperiencedradio/TV

technicianforhelp.



NOTE2:Anychangesormodificationstothisunit

notexpresslyapprovedbythepartyresponsiblefor

compliancecouldvoidtheuser'sauthorityto

operatetheequipment.


