E-Plex
®
2000
Features
No Wires
Requires no wiring to or through the door—eliminates risk of damage from
pinched wires that can result in costly callbacks
Locking Device Options
• Cylindrical: Cylindrical latch with 3-hour UL/ULC fire rating
• Rim Exit Device: Compatible with most leading brands of Exit Devices (Exit
Device and mounting hardware not included)
• American Standard Mortise: With 1¼" (32 mm) face plate; with and without
deadbolt, auto deadbolt also available
Number of Codes
Multiple Users—100 Codes
Handing
Non-handed; pre-assembled for left-hand door installations—easily changed in
the field
Audit Trail
The most recent 1,000 Events are recorded in memory, including the use of
mechanical key override. Software is required to view audit Events.
Programming
Lock is easily programmed via keypad without removing lock from the door or
with optional Microsoft® Excel®-based software
Key Override (Optional)
• Optional Key-in-Lever cylinder in Schlage “C” Keyway
with black Kaba cap
• Small format—Best and equivalent (6 or 7-pin length)
Operation Modes
• PIN access
• Passage—can be toggled on/off or can be pre-programmed to re-lock after a
certain number of hours
• Lockout
Authority Levels
Five different levels allow who has access to specific lock functions, including:
Service Codes—programmed for one-time access or “come-and-go” access for 1
to 24 hours
Electronic pushbutton lock eliminates
problems and costs associated with
issuing, controlling and collecting keys
and cards. Verifies exterior access while
allowing free egress.
E-Plex 2000 locks are powered by three
AA batteries that load into a slide-up
battery tray in the outside housing,
which eliminates wires through the door
and allows for continuous operation up
to 100,000 cycles.
Features continued
User Parameters
Code length—adjustable to accept 4 to 8 digits
Anti-tamper lockout—adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds
Re-lock time—adjustable from 2 to 20 seconds
Lock Power Battery Powered - Batteries located in outside housing; offers quick and easy battery replacements (three
AA Alkaline batteries provide up to 100,000 cycles); lock data is maintained if batteries fail.
Mechanical Features
Construction Heavy-duty commercial Grade 1 lockset, solid cast exterior housing, solid cast levers, cylindrical drive wear
tested for extensive use in indoor and outdoor applications
Numeric Keypad Vandal resistant, solid metal pushbuttons
Backset
Cylindrical: 2¾" (70 mm) backset, 2⅜" (60 mm) backset
Mortise: 2¾" (70 mm) backset
Exit Trim Model: Varies by Exit Device
Latches Cylindrical Models: ½" (13 mm) throw latch, ¾" (19 mm) throw latch (optional)
Mortise Models: ¾" (19 mm) latch, 1" (25 mm) deadbolt (optional)
Strikes Cylindrical locks packaged standard with both ANSI A115.3 “T” Strike and A115.2 ASA Strike
Exit Device Not supplied (see list below for compatibility)
Exit Device Latch Supplied with Exit Device
Exit Device Hub Rotation Up to 60º
Minimum Stile Required 5" (127 mm)
Weight Cylindrical and Mortise Models: 8 lbs. (3.63 kg)
Exit Trim Models: 10 lbs. (4.54 kg)
Finishes Satin Chrome 626 (26D) housings and levers. Optional Satin Brass 606 (04) or
Dark Bronze 744 (10B) housings and levers
Exit Device Compatibility
• Arrow Rim # 3800
• Corbin Rim # 5200
• Detex Rim # F1001
• Detex Surface Vertical Rod #s 20/F20
• Dorma Rim # F9300
• Precision Rim #s 21/FL21
• Precision Surface Vertical Rod #s 22/FL22
• Sargent Rim # 8800
• Von Duprin Concealed Vertical Rod #s 9847/9947
• Von Duprin Mortise #s 9875/9975
• Von Duprin Rim #s 89/99
• Von Duprin Surface Vertical Rod #s 9827/9927
• Yale Concealed Vertical Rod # 7160
• Yale Rim # 7100
ATTENTION: Compatibility is subject to change if modifications are made by Exit Device manufacturers without
Kaba's knowledge.
Satin Chrome Satin Brass Dark Bronze
Key Override Options
Key-in-Lever Cylinder Kaba 1539 6-pin cylinder—Schlage “C” Keyway
Interchangeable Core Small format—Best and equivalent (6 or 7-pin length); cylinder not included
Installation
Ease of Installation No wiring to or through the door—no risk of pinched wires
Door Preparation
Cylindrical and Exit Trim—ASA 161 (easily installs on door preparation with three additional through bore
holes; wood or metal doors)
Mortise—ASA 86 door preparation with three additional through bore holes
Door Thickness
Cylindrical Model: 1⅜" (35 mm) to 2½" (64 mm);
pre-assembled to accommodate doors 1⅝" (41 mm) to 2" (50 mm)
Exit Trim and Mortise Models: 1¾" (44 mm) to 2¼" (57 mm);
pre-assembled to accommodate doors 1¾" (44 mm) to 2⅛" (54 mm)
Items Supplied Include
Cylindrical and Mortise—Lock assembly, installation manual, template, quick reference guide, operations
manual, and required hardware
Exit Trim—Lock assembly, installation manual, template, quick reference guide, operations manual, and
required hardware. Exit Device and mounting hardware not included
Additional Items Supplied
with Key-in-Lever Cylinder
Model Only
Includes Universal Kaba 1539 6-pin cylinder, two nickel silver keys, and Schlage “C” Keyway.
Accessibility Standard Americans with Disabilities Act (ADA)
Fire Rating UL 10C fire rated
Durability ANSI/BHMA Grade 1 Certified (A156.25, A156.2, A156.13, A156.3)
Environmental Indoor/Outdoor approved; -31 °F (-35 °C) to 151 °F (66 °C); Windstorm approved/certified
Warranty
Warranty 3-year warranty from date of installation; built-in warranty counter in lock memory
Deadbolt
No Deadbolt
E2000 Mortise Interior
Auto-Deadbolt
PC Software
PC Software
Interior
(Exit device not included)
E2000 Exterior
E2000 Exterior
E2000 Exterior
Interior
PC Software
Cylindrical Optional Feature
Mortise Optional Features
Exit Trim Optional Feature
Kaba Access & Data Systems Americas
Winston-Salem NC 27105
1-800-849-8324
www.kaba-adsamericas.com KAA1297 0815
