Flip Key Application Chart

Kaba Ilco Corp.

P. O. Box 2627 (27802)

400 Jeffreys Rd., Rocky Mount, NC 27804

Tel.: (252) 446-3321 Fax: (252) 446-4702

www.ilco.us

May 2015

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

ACURA

CL 1998-2003 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

CSX (Canada) 2006-2011 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

EL (Canada) 2003-2005 K001-N718 HO01FB HO01-PT N N Y Megamos (13) Fixed

EL (Canada) 2001-2002 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

Integra 2000-2001 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

MDX 2007-2013 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

MDX 2001-2006 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

NSX 1997-2005 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

RDX 2007-2012 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

RL 2005-2009 5001-8442 HD106FB HD111-PT Y Y Y Philips (46) Encrypted

RL 1996-2004 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

RSX 2002-2006 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

TL 2007-2014 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

TL 2004-2006 5001-8442 HD106FB HD111-PT Y Y Y Philips (46) Encrypted

TL 1999-2003 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

TSX 2009-2014 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

TSX 2004-2008 5001-8442 HD106FB HD111-PT Y Y Y Philips (46) Encrypted

ZDX w/ Regular Ignition 2010-2012 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

AUDI

A4 Avant/Cabriolet, 2002-2007 1-6000 HU66FB HU66AT6 N N N Megamos Encrypted (48)

A4, S4, T T, Allroad, Quattro 2002-2005 1-6000 EXT HU66FB HU66AT6 N N N Megamos Encrypted (48)

A6, S6 2001-2005 1-6000 HU66FB HU66AT6 N N N Megamos Encrypted (48)

A8 1997-2000 1-6000 HU66FB HU66AT6 N N N Megamos Encrypted (48)

Allroad Quattro 1999-2005 1-6000 HU66FB HU66AT6 N N N Megamos Encrypted (48)

S4 - Avant, Cabriolet, Sedan 2006-2007 6001-8100 HU66FB HU66AT6 N N N Megamos Encrypted (48)

S6, S8 Sedan 2005-2007 6001-8100 HU66FB HU66AT6 N N N Megamos Encrypted (48)

* Y = Yes, N = Not Compatable

Flip Key Application Chart 2 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

TT Coupe, Roadster 2000-2004 1-6000 HU66FB HU66AT6 N N N Megamos Encrypted (48)

BUICK

Allure (Canada) 2010-2012 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Encore 2014-2015 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

LaCrosse 2010-2015 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Regal 2011-2015 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Verano 2012-2015 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

CADILLAC

SRX 2010-2013 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

CHEVROLET

Camaro 2010-2015 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Cruze 2011-2015 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Impala 2014-2014 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Sonic 2012-2015 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Volt 2011-2015 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

CHEVROLET TRUCKS, VANS, SUVS

City Express 2015-2015 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips (46E) Encrypted

Colorado 2004-2012 70000-75928 TOY43FB OEM# 19267217 N N N Megamos Encrypted (48)

Equinox 2010-2015 Z0001-Z6000 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Silverado - 1500 Crew,

Extended Cabs, Silverado

Hybrid, SSR

2014-2015 V0001-V5573 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Suburban 2015-2015 V0001-V5573 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Tahoe 2015-2015 V0001-V5573 HU100FB B119-PT Y N Y Philips (46E) Encrypted

CHRYSLER

200 2011-2014 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

300, 300C 2005-2007 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

300M 1999-2004 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Aspen 2007-2009 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Cirrus 1999-2000 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Concorde 1998-2004 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

LHS 1999-2001 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

New Yorker 1998-2001 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Pacifica 2004-2008 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

PT Cruiser 2006-2011 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

PT Cruiser 2001-2005 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Sebring Convertible 2007-2011 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Flip Key Application Chart 3 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

Sebring Convertible 1998-2006 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Sebring Sedan (4-Door) 2007-2011 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Sebring Sedan (4-Door) 2001-2006 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Town & Country Van 2004-2007 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Town & Country Van 2001-2003 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Voyager 2001-2003 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

DODGE

Avenger 2008-2014 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Caliber 2007-2012 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Charger, Charger Daytona R/T 2005-2008 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Intrepid 1998-2004 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Magnum 2005-2007 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Neon, SRT 2000-2005 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Nitro - SLT, SXT 2007-2012 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Stratus Sedan 1999-2006 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

DODGE TRUCKS, VANS, SUVS

Caravan & Grand Caravan 2004-2007 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Caravan & Grand Caravan 2001-2003 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Dakota 2001-2004 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Dakota Club/Quad Cabs SLT,

ST, Laramie 2005-2012 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Durango 2005-2008 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Durango 2001-2003 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Pickup Trucks, Ram & Dakota

(U.S. Made) 2006-2008 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Ram 1500 2002-2005 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Ram 1500 Sport, TRX4,ST,

Laramie 2006-2008 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Ram 2500 2002-2005 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Ram 2500 ST, Sport, Laramie,

Power Wagon, SLT, TRX4 2006-2010 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Ram 3500 2002-2005 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Ram 3500 Sport, Laramie,

ST, SLT 2006-2010 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Ram/Quad Cab, SRT 10 2006-2008 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

EAGLE

Vision 1998-1998 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

FIAT

Flip Key Application Chart 4 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

500 2012-2014 DE1-DE11210 SIP22FB SIP22MH Y N Y Philips (46) Encrypted

FORD

Cobra 1997-1997 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Contour 2.51 V6 1997-1998 A-B-C-D-E H73FB H73-PT Y Y Y Texas Instruments (4C) Encrypted

Contour V6 LX3 1997-2000 A-B-C-D-E H73FB H73-PT Y Y Y Texas Instruments (4C) Encrypted

Crown Victoria 2003-2012 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Crown Victoria 1998-2002 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Edge w/ Power Liftgate 2011-2015 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

Edge w/ Power Liftgate 2011-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Edge w/o Power Liftgate 2011-2015 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

Edge w/o Power Liftgate 2011-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Edge - SE, SEL, SEL Plus 2007-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Escape 2013-2013 10,001-11,500 HU101FB H94-PT N N N Texas Instruments (80 Bit) Encrypted

Escape 2005-2012 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Escape 2001-2004 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D60) Encrypted

Escape Hybrid 2005-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Fiesta 2011-2012 10,001-11,500 HU101FB H94-PT Y Y Y Texas Instruments (4D63) Encrypted

Five Hundred 2005-2007 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Five Hundred/Taurus 2008-2008 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Flex w/ Power Liftgate 2011-2015 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

Flex w/ Power Liftgate 2011-2012 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Flex w/o Power Liftgate 2011-2015 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

Flex w/o Power Liftgate 2011-2012 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Flex 2009-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Focus 2011-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Focus 2006-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Focus 2000-2005 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D60) Encrypted

Ford GT 2005-2006 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4C) Encrypted

Freestyle 2005-2007 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Fusion 2011-2012 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Fusion 2006-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Mustang 2011-2014 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

Mustang 2005-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Mustang 1996-2004 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Mustang GT 1996-1996 A-B-C-D-E H73FB H73-PT Y Y Y Texas Instruments (4C) Encrypted

Taurus w/ Regular Ignition 2011-2015 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

Flip Key Application Chart 5 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

Taurus 2000-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Taurus LX 1996-1999 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Taurus SHO & LS 1998-1999 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Taurus SHO & LS 1996-1997 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Taurus X, Freestyle 2008-2008 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Thunderbird 2003-2005 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Thunderbird 2002-2002 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4C) Encrypted

FORD TRUCKS, VANS, SUVS

E-Series 2013-2015 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

E-Series 2008-2012 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Excursion 2000-2006 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Expedition 2011-2015 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

Expedition 2003-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Expedition 1997-2002 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Explorer w/ Regular Ignition 2011-2015 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

Explorer mid-2001-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Explorer 1998-mid-2001 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Explorer Sport 1999-mid-2001 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Explorer Sport Trac mid-2001-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

F-150 Heritage 2004-2004 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

F-150 2011-2014 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

F-150, F-250 Series Light Duty 2004-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

F-150, F-250, & F-350 Series 1999-2003 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

F-250, 350, 450 Super Duty

Series 2011-2015 1X-1706X H72FB/H84FB/H92FB H92-PT N N N Texas Instruments (80 Bit) Encrypted

F-250, 350, 450 Super Duty

Series 2004-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Freestar 2004-2007 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Ranger Pickup 2011-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Ranger Pickup 2006-2010 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Ranger Pickup 2001-2004 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Ranger Pickup 1999-2000 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Transfer Heavy Trucks 6000,

9000, CF7000 2000-2004 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

Transit 2013-2015 10,001-11,500 HU101FB H94-PT N N N Texas Instruments (80 Bit) Encrypted

Transit Connect 2014-2015 10,001-11,500 HU101FB H94-PT N N N Texas Instruments (80 Bit) Encrypted

Transit Connect 2010-2013 T111111-T444444 FO21FB FO21T17 Y Y Y Texas Instruments (4D63) Encrypted

Flip Key Application Chart 6 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

Windstar 2001-2003 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Windstar 1998-2000 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

GMC TRUCKs, VANS, SUVS

Canyon 2004-2012 70000-75928 TOY43FB OEM# 19267217 N N N Megamos Encrypted (48)

Sierra 2014-2015 V0001-V5573 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Terrain 2010-2015 V0001-V5573 HU100FB B119-PT Y N Y Philips (46E) Encrypted

Yukon, Denali 2015-2015 V0001-V5573 HU100FB B119-PT Y N Y Philips (46E) Encrypted

HONDA

Accord Sedan, Coupe 2003-2012 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

Accord Sedan, Coupe 1998-2002 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

Civic 2001-2002 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

Civic / Hybrid 2006-2013 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

Civic / Hybrid 2003-2005 K001-N718 HO01FB HO01-PT N N Y Megamos (13) Fixed

Crosstour 2010-2012 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

CR-V 2007-2013 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

CR-V 2002-2006 K001-N718 HO01FB HO01-PT N N Y Megamos (13) Fixed

CR-Z 2011-2014 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

Element 2006-2011 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

Element 2003-2005 K001-N718 HO01FB HO01-PT N N Y Megamos (13) Fixed

Fit 2009-2013 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

Insight 2010-2014 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

Insight 2000-2004 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

Insight Hybrid 2005-2006 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

Odyssey 2005-2015 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

Odyssey 2003-2004 K001-N718 HO01FB HO01-PT N N Y Megamos (13) Fixed

Odyssey 1998-2002 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

Pilot 2006-2015 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

Pilot 2003-2005 K001-N718 HO01FB HO01-PT N N Y Megamos (13) Fixed

Prelude 1997-2002 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

Ridgeline 2006-2014 K001-N718 HO01FB HO03-PT Y Y Y Philips (46) Encrypted

S2000 2004-2005 K001-N718 HO01FB HO01-PT N N Y Megamos (13) Fixed

S2000 2000-2003 5001-8442 HD106FB HD106-PT N N Y Megamos (13) Fixed

HYUNDAI

Accent (Canada) 1999-2010 T1-T1000 or V1-

V1200 HYN6FB HYN6T14 Y Y Y Philips (46) Encrypted

Azera (replaces the ‘05

XG350) 2006-2011 G0001-G2500 TOY48FB HY20-PT Y Y Y Philips (46) Encrypted

Flip Key Application Chart 7 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

Elantra (Canada) 2007-2010 T1-T2500 HYN14RFB HYN14RT14 Y Y Y Philips (46) Encrypted

Elantra (Canada) 2000-2006 T1-T1000 HYN6FB HYN6T14 Y Y Y Philips (46) Encrypted

Elantra Touring (Canada) 2009-2012 K1-K2500 TOY48FB HY20-PT Y Y Y Philips (46) Encrypted

Genesis Coupe w/o Prox 2010-2014 M0001-M2500 HYN14RFB HYN14RT14 Y Y Y Philips (46) Encrypted

Genesis w/o Prox (4 Dr.) 2009-2010 J1-2500 TOY48FB HY20-PT Y Y Y Philips (46) Encrypted

Sante Fe (Canada) 2007-2010 M0001-M2500 HYN14RFB HYN14RT14 Y Y Y Philips (46) Encrypted

Sante Fe (Canada) 2002-2006 A1-A1000 HYN6FB HYN6T14 Y Y Y Philips (46) Encrypted

Sonata (Canada) 2011-2015 K1-K2500 TOY48FB HY20-PT Y Y Y Philips (46) Encrypted

Tiburon (Canada) 2001-2010 T1-T1000 HYN6FB HYN6T14 Y Y Y Philips (46) Encrypted

Tucson (Canada) 2010-2012 M0001-M2500 HYN14RFB HYN14RT14 Y Y Y Philips (46) Encrypted

Tucson (Canada) 2005-2009 V1-V1200 HYN6FB HYN6T14 Y Y Y Philips (46) Encrypted

Veracruz (Canada) 2007-2010 M0001-M2500 HYN6FB HYN6T14 Y Y Y Philips (46) Encrypted

INFINITI

FX35/FX45 w/ Regular Ignition 2003-2008 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips (46) Encrypted

G20 2000-2002 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

G35 2003-2004 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips (46) Encrypted

G35 w/ Regular Ignition 2005-2008 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips (46) Encrypted

I30, I35 2000-2004 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

M45 2003-2006 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips (46) Encrypted

Q45 2002-2005 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips (46) Encrypted

Q45 1997-2001 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4C) Fixed

QX4 1999-2003 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

QX56 2004-2007 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips (46) Encrypted

JAGUAR

S-Type 2000-2008 T111111-T444444 FO21FB FO21T7 Y Y Y Texas Instruments (4D60) Encrypted

XJ8, XJR 2004-2008 T111111-T444444 FO21FB FO21T7 Y Y Y Texas Instruments (4D60) Encrypted

X-Type 2002-2008 T111111-T444444 FO21FB FO21T7 Y Y Y Texas Instruments (4D60) Encrypted

JEEP

Cherokee 2015-2015 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Cherokee 1998-2001 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Commander 2006-2007 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Compass 2007-2015 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Grand Cherokee 2005-2008 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Grand Cherokee 1998-2004 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Liberty 2005-2013 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Liberty 2002-2004 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Flip Key Application Chart 8 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

Patriot 2007-2015 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Wrangler 2007-2015 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips (46) Encrypted

Wrangler 1998-2006 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

KIA

Amanti 2007-2009 L001-L1000 TOY40FB KK9-PT Y Y Y Philips (46) Encrypted

Amanti 2004-2006 L001-L1000 TOY40FB KK7-PT Y Y Y Texas Instruments (4D60) Encrypted

Borrego w/ Regular Ignition 2009-2011 G0001-G2500 TOY48FB HY20-PT Y Y Y Philips (46) Encrypted

Forte (Canada) 2010-2012 M0001-M2500 HYN14RFB HYN14RT14 Y Y Y Philips (46) Encrypted

Magentis (Canada) 2009-2011 G0001-G2500 TOY48FB HY20-PT Y Y Y Philips (46) Encrypted

Magentis (Canada) 2001-2006 S1-S1000 KIA3RFB KIA3RT14 Y Y Y Philips (46) Encrypted

Optima (Canada) 2001-2006 S1-S1000 KIA3RFB KIA3RT14 Y Y Y Philips (46) Encrypted

Optima (Canada) 2010-2011 K1-K2500 TOY40FB KK9-PT Y Y Y Philips (46) Encrypted

Rio (Canada) 2010-2011 G0001-G2500 TOY48FB HY20-PT Y Y Y Philips (46) Encrypted

Rio (Canada) 2006-2009 V1-V1200 HYN15FB HYN15T14 Y Y Y Philips (46) Encrypted

Rondo (Canada) 2011-2012 K1-K2500 TOY48FB HY20-PT Y Y Y Philips (46) Encrypted

Sedona (Canada) 2006-2009 H0001-H2500 or

V1-V1200 HYN14RFB HYN14RT14 Y Y Y Philips (46) Encrypted

Sedona (Canada) 2002-2005 Y2001-Y3000 KIA3RFB KIA3RT14 Y Y Y Philips (46) Encrypted

Sephia (Canada) 2004-2004 Y2001-Y3000 KIA3RFB KIA3RT14 Y Y Y Philips (46) Encrypted

Sorento (Canada) 2010-2011 G0001-G2500 TOY40FB KK9-PT Y Y Y Philips (46) Encrypted

Sportage (Canada) 2010-2011 G0001-G2500 TOY48FB HY20-PT Y Y Y Philips (46) Encrypted

LAND ROVER

LR3 2005-2009 1-6000 HU101FB HU101MH Y N Y Philips (46) Encrypted

Range Rover 2007-2009 4001-9000 HU101FB HU101MH Y N Y Philips (46) Encrypted

Range Rover Sport 2006-2009 4001-9000 HU101FB HU101MH Y N Y Philips (46) Encrypted

LEXUS

ES300 2002-2003 40000-49999 TOY48FB TOY48BT4 Y Y Y Texas Instruments (4C)

ES300 1998-2001 O0001-O5000 TOY40FB TOY40BT4 Y Y Y Texas Instruments (4C)

ES330 2004-2006 40000-49999 TOY48FB TOY50-PT Y Y Y Texas Instruments (4D-68)

GS300, GS400 1998-2005 O0001-O5000 TOY48FB TOY48BT4 Y Y Y Texas Instruments (4C)

GS430 2001-2005 40000-49999 TOY48FB TOY48BT4 Y Y Y Texas Instruments (4C)

GS470 2002-2007 40000-49999 TOY48FB TOY50-PT Y Y Y Texas Instruments (4D-68)

IS300 2002-2005 40000-49999 TOY48FB TOY48BT4 Y Y Y Texas Instruments (4C)

IS300 2001-2001 40000-49999 TOY48FB TOY48BT4 Y Y Y Texas Instruments (4C)

LS400, LS430 2001-2006 40000-49999 TOY48FB TOY50-PT Y Y Y Texas Instruments (4D-68)

LS400, LS430 1998-2000 O0001-O5000 TOY48FB TOY48BT4 Y Y Y Texas Instruments (4C)

LS400, LS430 1997-1997 O0001-O5000 TOY40FB TOY40BT4 Y Y Y Texas Instruments (4C)

Flip Key Application Chart 9 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

LX450 1998-1998 O0001-O5000 TOY40FB TOY40BT4 Y Y Y Texas Instruments (4C)

LX470 2003-2008 O0001-O5000 TOY48FB TOY50-PT Y Y Y Texas Instruments (4D-68)

LX470 2001-2002 O0001-O5000 TOY48FB TOY48BT4 Y Y Y Texas Instruments (4C)

LX470 1998-2000 O0001-O5000 TOY40FB TOY40BT4 Y Y Y Texas Instruments (4C)

RX300 1997-2003 40000-49999 TOY48FB TOY48BT4 Y Y Y Texas Instruments (4C)

RX330 2004-2009 40000-49999 TOY48FB TOY50-PT Y Y Y Texas Instruments (4D-68)

RX350 2004-2011 40000-49999 TOY48FB TOY50-PT Y Y Y Texas Instruments (4D-68)

RX400h 2004-2009 40000-49999 TOY48FB TOY50-PT Y Y Y Texas Instruments (4D-68)

RX450h 2010-2010 40000-49999 TOY48FB TOY50-PT Y Y Y Texas Instruments (4D-68)

SC300, SC400 2002-2006 40000-49999 TOY48FB TOY48BT4 Y Y Y Texas Instruments (4C)

SC300, SC400, SC430 1998-2001 40000-49999 TOY40FB TOY40BT4 Y Y Y Texas Instruments (4C)

SC430 2002-2011 40000-49999 TOY48FB TOY50-PT Y Y Y Texas Instruments (4D-68)

LINCOLN

Aviator 2003-2007 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Blackwood 2002-2002 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C)

Continental 1998-2002 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C)

LS6, LS8 2000-2006 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Mark LT (Truck) 2006-2008 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

MKX 2007-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

MKZ 2007-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Navigator 2003-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Navigator 1998-2002 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C)

Town Car 2003-2012 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Town Car 1998-2002 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C)

Zephyr (sister model to Ford

Fusion) 2006-2009 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

MAZDA

626ES - V6, 626LX - V6, 626

w/Luxury Pkg 1998-1999 10100-12283 MAZ24RFB MAZ24RT5 N N Y Philips Transponder

CX-5 2013-2014 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

CX-7 2007-2013 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

CX-9 2007-2015 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

Mazda 2 2011-2014 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

Mazda 3 2004-2013 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

Mazda 5 2006-2015 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

Mazda 6 2003-2013 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

Mazda Speed 6 2006-2008 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

Flip Key Application Chart 10 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

Miata 2001-2005 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

MX5 Miata 2006-2015 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

RX8 2004-2011 10100-12283 MAZ24RFB MAZ24R-PT Y Y Y Texas Instruments (4D63) Encrypted

Tribute 2005-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Tribute 2001-2004 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D60) Encrypted

MAZDA TRUCKS,VANS,SUVS

B Series 2001-2009 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

B Series 1999-2000 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C) Encrypted

MERCURY

Cougar 1999-2002 A-B-C-D-E H73FB H73-PT Y Y Y Texas Instruments (4C)

Grand Marquis 2003-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Grand Marquis 1998-2002 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C)

Marauder 2003-2005 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Mariner (sister to Ford Escape) 2005-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Milan (sister model to ‘06 Ford

Fusion) 2006-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Montego 2005-2008 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Mystique LS 1997-2000 A-B-C-D-E H73FB H73-PT Y Y Y Texas Instruments (4C)

Sable (sister to Ford Taurus) 2008-2009 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Sable GS 1999-1999 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C)

Sable GS & LS 2000-2007 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Sable LS, SE, SHO 1998-1999 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C)

Sable LS, SE, SHO 1996-1997 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C)

MERCURY TRUCKS, VANS, SUVS

Monterey 2004-2007 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Mountaineer 2002-2011 1X-1706X H72FB/H84FB/H92FB H92-PT Y Y Y Texas Instruments (4D63) Encrypted

Mountaineer 1998-2001 1X-1706X H72FB/H84FB/H92FB H72-PT Y Y Y Texas Instruments (4C)

MITSUBISHI

Diamante 2000-2000 E5001-E7679 MIT8FB/MIT12FB MIT8-PT Y Y Y Texas Instruments (4D61) Encrypted

Montero Sport 2000-2000 E5001-E7679 MIT8FB/MIT12FB MIT8-PT Y Y Y Texas Instruments (4D61) Encrypted

Raider 2006-2010 M1-M2618 Y160FB/Y164FB Y164-PT Y Y Y Philips Encrypted (46)

NISSAN/DATSUN

350Z Roadster 2003-2009 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Altima 2005-2006 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Altima 2000-2004 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

Armada w/ Regular Ignition 2004-2014 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Cube w/ Regular Ignition 2009-2013 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Flip Key Application Chart 11 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

Frontier 2006-2015 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Frontier 2002-2005 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

Juke w/o Prox 2011-2014 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Maxima 2004-2007 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Maxima, 810 2000-2003 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

Murano w/ Regular Ignition 2003-2008 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

NV 1500/2500/3500 2012-2015 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Pathfinder mid-1999-2004 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

Pathfinder w/ Regular Ignition 2005-2014 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Quest 2004-2010 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Rogue w/ Regular Ignition 2008-2015 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Sentra w/ Regular Ignition 2007-2014 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Sentra, SE-R, 200SX, 240SX 2000-2006 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

Titan 2004-2014 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Versa w/ Regular Ignition 2007-2015 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Xterra 2005-2015 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips Encrypted (46)

Xterra 2002-2004 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

X-Trail (Canada) 2005-2006 1-22185 NI01FB/NI02FB/NI04FB NI01T or NI02T Y Y Y Texas Instruments (4D60) Encrypted

PLYMOUTH

Breeze 1999-2000 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Grand Voyager, Voyager 2001-2003 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

Neon 2000-2001 M1-M2618 Y160FB/Y164FB Y160-PT Y Y Y Texas Instruments (4D64) Encrypted

PORSCHE

968 1999-2005 1-6000 EXT HU66FB HU66T6 N N Y High Security Key. Megamos Encrypted , Ordered

by VIN

Boxster 2005-2011 1-6000 EXT HU66FB HU66MH# Y N Y Philips Encrypted (46)

Boxster 1997-1998 1-6000 HU66FB HU66T5 N N Y Megamos (13)

Cayenne 2003-2010 1-6000 EXT HU66FB HU66MH# N N Y Philips Encrypted (46)

SCION

FR-S 2013-2015 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

iQ (Canada) 2012-2013 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

tC 2011-2015 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

tC 2005-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

xA 2004-2007 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

xB (Canada) 2011-2012 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

xB 2004-2008 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

xD (Canada) 2011-2012 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Flip Key Application Chart 12 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

xD 2008-2008 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

STERLING TRUCK

Bullet 2008-2009 M1-M2618 TOY43FB Y164-PT Y Y Y Philips (46) Encrypted

SUBARU

B9 Tribeca 2006-2013 30001-37850 TOY43FB SUB4-PT Y Y Y Texas Instruments (4D62) Encrypted

BRZ w/ Regular Ignition 2012-2015 40000-49999 TOY43FB TOY44G-PT N N N Texas Instruments (4D62) Encrypted

Forester 2009-2013 T001-3000 SUB1FB DAT17T13 Y Y Y Texas Instruments (4D62) Encrypted

Forester 2005-2008 30001-37850 SUB4FB SUB4-PT Y Y Y Texas Instruments (4D62) Encrypted

Impreza 2008-2011 T001-3000 SUB1FB DAT17T13 Y Y Y Texas Instruments (4D62) Encrypted

Impreza 2005-2007 30001-37850 SUB4FB SUB4-PT Y Y Y Texas Instruments (4D62) Encrypted

Impreza WRX 2008-2014 T001-3000 SUB1FB DAT17T13 Y Y Y Texas Instruments (4D62) Encrypted

Legacy 2010-2014 T001-3000 SUB1FB DAT17T13 Y Y Y Texas Instruments (4D62) Encrypted

Legacy 2005-2008 30001-37850 SUB4FB SUB4-PT Y Y Y Texas Instruments (4D62) Encrypted

Legacy, Outback 2005-2009 30001-37850 SUB4FB SUB4-PT Y Y Y Texas Instruments (4D62) Encrypted

Outback 2010-2014 T001-3000 SUB1FB DAT17T13 Y Y Y Texas Instruments (4D62) Encrypted

SUZUKI

Equator 2009-2012 1-22185 NI01FB/NI02FB/NI04FB NI04T Y Y Y Philips (46) Encrypted

TOYOTA

Avalon w/ Regular Ignition 2012-2012 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Avalon w/ Regular Ignition 2005-2011 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Avalon XLS, XL 2002-2005 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Avalon XLS, XL 1998-2004 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Camry CE & LE 2003-2009 50000-69999 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Camry w/ Regular Ignition 2015-2015 50000-69999 TOY43FB OEM# 89785-0D170 N N N Texas Instruments (H) Encrypted

Camry w/ Regular Ignition 2012-2014 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Camry w/ Regular Ignition 2007-2011 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Camry XLE 2002-2003 50000-69999 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Camry XLE 1998-2001 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Camry, Camry LE 1998-2002 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Corolla 2014-2015 50000-69999 TOY43FB OEM# 89070-02880 or

89785-0D170 N N N Texas Instruments (H) Encrypted

Corolla mid-2010-2013 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Corolla 2005-mid-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

FJ Crusier 2011-2014 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

FJ Crusier 2006-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Matrix 2011-2013 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Matrix 2005-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Flip Key Application Chart 13 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

Prius 2004-2008 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Prius 2001-2003 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Prius C w/ Regular Ignition 2012-2014 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Solara 2004-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Solara SE 2002-2003 50000-69999 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Solara SLE 2004-2008 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Solara SLE 1999-2003 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Venza w/ Regular Ignition mid-2010-2014 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Venza w/ Regular Ignition 2009-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Yaris 2012-2014 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Yaris 2007-2011 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

TOYOTA TRUCKS, VANS, SUVS

4 Runner 1999-2002 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

4 Runner Ltd. 1999-2002 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

4 Runner w/ Regular Ignition 2011-2015 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 64 Bit Encrypted

4 Runner w/ Regular Ignition 2003-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Highlander 2001-2003 50000-69999 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Highlander w/ Regular Ignition 2014-2014 50000-69999 TOY43FB OEM# 89070-0R120 or

89785-0D170 N N N Texas Instruments (H) Encrypted

Highlander w/ Regular Ignition 2011-2013 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Highlander w/ Regular Ignition 2004-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Land Cruiser 2003-2008 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Land Cruiser 1998-2002 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

RAV 4 w/ Regular Ignition 2013-2015 50000-69999 TOY43FB OEM# 89070-42830 or

89070-48280 (H) N N N Texas Instruments (H) Encrypted

RAV 4 2011-2012 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

RAV 4 2006-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Sequoia 2015-2015 50000-69999 TOY43FB OEM# 89785-0D170 N N N Texas Instruments (H) Encrypted

Sequoia 2011-2014 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Sequoia 2003-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Sequoia 2001-2002 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Sienna w/ Regular Ignition 2015-2015 50000-69999 TOY43FB OEM# 89785-0D170 N N N Texas Instruments (H) Encrypted

Sienna w/ Regular Ignition 2011-2014 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Sienna Van, XLE-LE 1998-2003 10001-15000 TOY43FB TOY43AT4 Y Y Y Texas Instruments (4C) Encrypted

Sienna Van, XLE-LE-Limited 2004-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Tacoma 2011-2015 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Tacoma 2005-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

Flip Key Application Chart 14 of 14

* Y = Yes, N = Not Compatable

Model Years Code Series Flip Blade Transponder Key

Reference

GTI Compatabillity* Clone*

RW4 Plus &

Ilco EZ®-Clone Plus

Transponder Type /ID

Clone Generate

Tundra 2011-2015 50000-69999 TOY43FB TOY44G-PT N N N Texas Instruments 80 Bit Encrypted

Tundra 2007-2010 50000-69999 TOY43FB TOY44D-PT Y Y Y Texas Instruments (4D67) Encrypted

VOLKSWAGEN

Beetle (New) 2006-2014 1-6000 HU66FB HU66T24 N N N High Security Key. Megamos (48 CAN) Encrypted

Beetle (New) 2000-2005 1-6000 EXT. HU66FB HU66T6 (or dealer FOB) N N N High Security Key. Megamos (48) Encrypted

CC 2009-2014 1-6000 HU66FB HU66T24 N N N High Security Key. Megamos (48 CAN) Encrypted

Eos 2007-2015 0001-6000 HU66FB HU66T24 N N N High Security Key. Megamos (48 CAN) Encrypted

Golf 2000-2006 0001-6000 HU66FB HU66T6 (or dealer FOB) N N N High Security Key. Megamos (48) Encrypted

GLI 2008-2010 0001-6000 HU66FB HU66T24 N N N High Security Key. Megamos (48 CAN) Encrypted

GTI 2007-2013 0001-6000 HU66FB HU66T24 N N N High Security Key. Megamos (48 CAN) Encrypted

GTI 2000-2006 0001-6000 HU66FB HU66T6 (or dealer FOB) N N N High Security Key. Megamos (48) Encrypted

Jetta 2007-2015 0001-6000 HU66FB HU66T24 N N N High Security Key. Megamos (48 CAN) Encrypted

Jetta 2006-2006 0001-6000 HU66FB HU66T24 (or dealer FOB) N N N High Security Key. Megamos (48 CAN) Encrypted

Jetta 2000-2005 0001-6000 HU66FB HU66T6 (or dealer FOB) N N N High Security Key. Megamos (48) Encrypted

Passat (Sedan) 2001-2005 0001-6000 HU66FB HU66T6 (or dealer FOB) N N N High Security Key. Megamos (48) Encrypted

Passat (Wagon) 2003-2005 0001-6000 HU66FB HU66T6 (or dealer FOB) N N N High Security Key. Megamos (48) Encrypted

Phaeton 2004-2005 0001-6000 HU66FB HU66T6 (or dealer FOB) N N N High Security Key. Megamos (48) Encrypted

R32 VR6 2004-2007 0001-6000 HU66FB HU66T6 N N N High Security Key. Megamos (48) Encrypted

Tiguan 2009-2015 0001-6000 HU66FB HU66T24 N N N High Security Key. Megamos (48 CAN) Encrypted

Touareg 2004-2006 0001-6000 HU66FB HU66MH# N N Y Philips Encrypted (46)
