Kaba Mas Price Book Pricelist21Rev A

Kaba Mas List Price Book #21

November 1, 2013

November 1, 2013 3Table of Contents Kaba Mas List Price Book #21

Table of Contents

LIMITED WARRANTY ��4

TERMS AND CONDITIONS ��5-6

GITCON™ SERIES �� 7

Gitcon G50 - Mechanical Lock Ordering Information ��8

UNICON™ CL SERIES ��9

Unicon™ Models CL10/CL20/DL20 Ordering Information ��10-11

Accessories ��12

AUDITCON® 2 SERIES �� 13

52/T52 Ordering Information �� 14-15

252/552 Ordering Information ��16-17

Accessories ��18

Parts �� 19-20

CENCON® �� 21

Cencon Cash-In-Transit ATM Locking System Ordering Information ��22-23

Software/Accessories/Keys ��24

Parts ��25-26

X-10™ HIGH SECURITY LOCKS/CDX-10™ HIGH SECURITY PEDESTRIAN EXIT DEVICE �� 27

X-10 Ordering Information ��28

CDX-10 ��29

X-10 Parts ��30-31

X-09 Parts ��32-34

CDX-10/CDX-09 Strikes/Mounting Plates��35

TECHNICAL TRAINING �� 36

PRODUCT WEIGHTS & MEASURES ��37

November 1, 20134Kaba Mas List Price Book #21 Product Warranty

Limited Warranty

Kaba Mas LLC (“Kaba Mas”) warrants to the original purchaser that the product(s) shall be free of defects in

material and workmanship for a period of one (1) year from the date of manufacture by Kaba Mas (complete locks),

and sixty (60) days (parts)� This warranty applies provided there is compliance with all installation/operating

instructions supplied by Kaba Mas and, provided further, that the product has been subject to normal use

without any misuse, negligence, modiﬁcation, or the occurrence of any accidental damage�

Kaba Mas MAKES NO OTHER WARRANTY WITH RESPECT TO THE PRODUCT, EX PRESSED OR IMPLIED, INCLUDING

WITHOUT LIMITATION ANY WARRANTY AS TO SUITABILITY OF THE PRODUCT FOR ANY PARTICULAR PURPOSE

OR USE OR THE MER CHANT ABIL I TY THEREOF AND SHALL NOT BE LIABLE FOR ANY LOSS OR DAMAGE

SUSTAINED THROUGH BURGLARY, THEFT, ROBBERY, FIRE OR OTHER HAZARD. THIS LIM IT ED WARRANTY IS IN

LIEU OF ALL OTHER WAR RAN TIES OR CONDITIONS EX PRESSED OR IMPLIED BY LAW AND/OR CUSTOM.

In the event of a defect in materials or workmanship covered by this warranty, the pur chas er shall return, at

purchaser’s expense, the product to Kaba Mas for repair or replacement� Repair or replacement shall be at

the election of Kaba Mas� The pur chas er’s sole remedy shall be the repair or replacement of the product and

under no cir cum stanc es shall Kaba Mas be liable to the purchaser or any other person for any con se quen tial,

incidental, economic, direct, in di rect, general or special damages arising out of any breach of warranty� In no

event shall Kaba Mas’s liability exceed the original cost of the product�

This warranty and remedies set forth above are exclusive and in lieu of all others, oral or written, expressed or

implied� No dealer, distributor, agent or employee is authorized to make any modiﬁcation or addition to

this warranty�

Kaba Mas EXPRESSLY DISCLAIMS ANY WARRANTY OF NON-INFRINGEMENT PROVIDED UNDER KRS 355.2.312,

UCC §2-312, OR SIMILAR LAW. KABA MAS SHALL NOT INDEMNIFY NOR BE RESPONSIBLE FOR ANY DAMAGES

ARISING OUT OF A CLAIM THAT THIS PRODUCT INFRINGES ANY PATENT.

Some states do not allow the exclusion or limitation of implied warranties or limitation of li a bil i ty for

incidental or consequential damages, so the above limitation or exclusion may not apply to you�

NOTICE

Installation of the product with any unapproved accessorial item or product may in val i date the Kaba Mas, LLC Limited

Product Warranty.

November 1, 2013 5Terms & Conditions of Sale Kaba Mas List Price Book #21

Terms & Conditions of Sale

Terms and Conditions

All sales will be subject to the terms and conditions set forth herein, and any terms and conditions contained in any orders

contrary to these terms and conditions will be null and void. Kaba Mas reserves the right to immediately and without further

notice dis con tin ue the selling of products to any customer that does not fully comply with these terms and con di tions. Customer

may not assign any rights or obligations without prior written consent of Kaba Mas.

Products and Prices

All prices of the products are set forth in the List Price Book. Kaba Mas reserves the right to amend such prices from time to

time, and to discontinue the production of any product, or to change the design, func tion and ﬁnish thereof, without prior notice

to the customer.

Credit Issues

Kaba Mas retains a purchase money security interest in all goods and materials which have been or are hereafter acquired

by customer with credit granted by Kaba Mas (“Collateral”). Upon any default by customer, Kaba Mas shall have the rights of

a secured party under the Uniform Commercial Code as adopted by the Commonwealth of Kentucky, as amended upon any

default by customer. Kaba Mas may require customer to assemble the Collateral at a place designated by Kaba Mas. Customer

shall reimburse Kaba Mas for all costs (including reasonable attorney’s fees) incurred in collecting any amounts due to Kaba

Mas or executing its interest hereunder. In addition to any other right or remedy hereunder, Kaba Mas shall have at all times

the right to offset any obligation of customer to Kaba Mas against any obligation of Kaba Mas to customer. If in Kaba Mas’s sole

judgement any doubt arises at any time as to the ability of the customer to pay for the products, or if the customer at any time

is past due in payment of any amount owing to Kaba Mas, Kaba Mas may (without liability and without prej u dice to any remedies,

and regardless of any sched ule of shipment or payment to the contrary), delay production, postpone any shipment or stop any

product in transit until Kaba Mas shall have received payment in full of all amounts, whether or not then due, owing to it by the

customer. In case of any such postponement, the price of the prod ucts affected shall be the price in effect on the date of ﬁnal

shipment. Payment terms are Net 30 days unless oth er wise speciﬁed. Any action or proceeding brought by customer of Kaba

Mas arising out of these terms shall be brought solely in a court of competent jurisdiction located in Fayette County, Kentucky.

Warranty

Customer shall forever indemnify, defend and hold harmless Manufacturer from and against any and all losses, damages, costs

(including, without limitation, attorney fees and court costs), expenses, claims, li a bil i ties, obligations and judgements related to

the product or the sale or use thereof to the extent not covered by Kaba Mas’s warranty, including without limitation, by reason

of any unauthorized war ran ties or rep re sen ta tions with respect thereto. Customers shall promptly notify Kaba Mas of all charg-

es, complaints or claims concerning the product, whether or not covered by Kaba Mas’s warranty, and shall fully co op er ate with

Kaba Mas in investigating and re solv ing the same. The customer shall not repair, replace, modify or tamper with any product for

war ran ty purposes unless the written consent of Kaba Mas is ﬁrst obtained.

Taxe s

Any taxes, duties, levies or other charges now hereafter imposed directly or indirectly on Kaba Mas or required to be collected

directly or indirectly by Kaba Mas by any taxing authority in connection with the sale, delivery, use or consumption of the

products, including, without limitation, any sales, doc u men ta ry, use, excise, purchase, turnover and import taxes, consular fees

and customs duties shall be for the account of the customer, and the customer shall on demand forthwith pay to Kaba Mas any

such tax, levy or charge.

November 1, 20136Kaba Mas List Price Book #21 Terms & Conditions of Sale Continued

Promotion of Products

The customer shall sell and promote the products in a manner which will enhance the image and good will of Kaba Mas, its

customer and the products. The use of Kaba Mas’s trademarks and name is strictly prohibited without prior written consent of

Kaba Mas.

Minimum Orders

Minimum order amount per shipment is $100.00 net.

Order Acknowledgements

All Kaba Mas orders will be acknowledged in writing within three (3) business days after receipt of all information pertinent to

the order. It is the responsibility of the customer to check all acknowledgements in order to ascertain that they conform to their

purchase order. All estimates of dates of delivery are made by Kaba Mas in good faith, and are not guaranteed.

Cancellations/Changes

Requests for cancellations or changes must be received by Kaba Mas within 5 business days of order acknowledgement date.

Kaba Mas reserves the right to impose a re-stocking fee, as a percentage of the value of the merchandise, should a cancellation

or change be made after production has begun.

Claims

Claims for shortages or errors in packaging must be made to Kaba Mas in writing within ten (10) business days after receipt

of shipment.

Returned Merchandise

Returns will not be accepted without prior written approval by Kaba Mas and without a Returned Goods Authorization Number

issued by Kaba Mas’s Customer Service Department. All returns are subject to a re-stocking charge. Purchaser must provide

invoice number and information regarding original date of shipment with all returned goods. Electronic components sold under

the Parts Program are not returnable under any circumstances.

Shipments

All products shall be shipped F.O.B. factory and shall be deemed the property of the customer when accepted by the carrier.

Unless otherwise agreed in writing, the choice of carrier shall be at Kaba Mas’s sole discretion. A service fee of $25.00 (net) will

be applied to all orders drop shipped at the request of the customer.

Force Majeure

Kaba Mas shall be excused for any delay in performance hereunder and shall not be responsible for any loss or damage caused

by acts of God; accident or casualty; war or warlike activities; insurrection or civil commotion: supply, labor, engineering, or

transportation difﬁculties; acts of any government (with or without valid jurisdiction); strikes; blockades; boycotts, lockouts or

any other causes, whether or not similar in nature to those speciﬁed herein, beyond Kaba Mas’s control. The provision as regards

strikes, blockades, boycotts and lockouts shall apply irrespective of whether Kaba Mas itself is the subject or instigator of such a

measure. Performance by Kaba Mas hereunder shall be suspended during the continuance of any such measure.

Terms & Conditions of Sale

Continued

Gitcon™ Series

Goods-In-Transit Locks

November 1, 20138Kaba Mas List Price Book #21 Gitcon | Model G50 — Mechanical

Model G50 — Mechanical

Model/Power Description LIN (Lock Identiﬁcation Number) List Price

050M Model G50 - Mechanical 050Mxxxxxxxxxxx $416.00

Handle Add to List

X Swing door xxxxXxxxxxxxxxx standard

R Roll-up Door Whiting Premium xxxxRxxxxxxxxxx add $68.00

T Roll-up Door Whiting General Purpose (Todco) xxxxTxxxxxxxxxx add $68.00

Core Kit

ICX Interchangeable Core Cylinder Housing xxxxxICXxxxxxxx standard

Keying

KD Keyed different xxxxxxxxKDxxxxx standard

XC Less Core xxxxxxxxXCxxxxx deduct $5.00

Door Thickness

A 3/4" Door xxxxxxxxxxAxxxx standard

G 1 1/2" Door xxxxxxxxxxGxxxx no add

Country Code

E United States xxxxxxxxxxxExxx standard

Mounting Plate

Z No Selection Required xxxxxxxxxxxxZxx

Install

1 G50 Install Group, English xxxxxxxxxxxxx1x standard

2 G50 Install Group, World Trade xxxxxxxxxxxxx2x no add

Packaging

A Distributor (Individual) xxxxxxxxxxxxxxA standard

EXAMPLE

0 5 0 M

Model

Power Source

X

Handle

K D

Keying

I C X

Cam Kit

(Core Kit)

A

Door

Thickness

E

Country

Code

Z

Mounting

Plate

1

Install

A

Packaging

Unicon™ Series

Multi-Use Cabinet Locks

November 1, 201310 Kaba Mas List Price Book #21 Unicon Series | Models CL10/CL20/DL20

Model Description LIN (Lock Identiﬁcation Number) List Price

CL10 Cabinet Lock Model 10 CL10xxxxxxxxxxx $260.00

CL20 Cabinet Lock Model 20 CL20xxxxxxxxxxx $296.50

DL20 Door Lock Model 20 DL20xxxxxxxxxxx $348.50

Power Source Add to List

S Battery Powered xxxxSxxxxxxxxxx standard

(Supplied less battery)

Keypad

MK Universal Keypad, for all lock orientations xxxxxMKxxxxxxxx standard

Door Thickness

(Material)

1 14-20 Gauge Sheet Metal xxxxxxx1xxxxxxx no add

2 1/8" (4mm) Sheet Metal xxxxxxx2xxxxxxx no add

3 3/16" (5mm) Sheet Metal xxxxxxx3xxxxxxx no add

4 1/4" ( 6mm) Sheet Metal xxxxxxx4xxxxxxx no add

5 1/2" (13mm) to 7/8" (23mm) Wood xxxxxxx5xxxxxxx no add

6 Metal Display Stand xxxxxxx6xxxxxxx no add

7 1 3/8" - 1 3/4" Wood or Metal Door xxxxxxx7xxxxxxx no add

(for Model DL20 only)

Bolt LIN # Add to List

CAM Cam Latch xxxxxxxxCAMxxxx $15.50

for door thickness 1, 2, 3 or 4 (metal)

CAW Cam Latch xxxxxxxxCAWxxxx $15.50

for door thickness 5 (wood)

DEM Dead Bolt, End Throw, xxxxxxxxDEMxxxx no add

for door thickness 1, 2, 3 or 4 (metal)

DEW Dead Bolt, End Throw, xxxxxxxxDEWxxxx no add

for door thickness 5 (wood)

DCM Dead Bolt, Cross Throw, xxxxxxxxDCMxxxx no add

for door thickness 1, 2, 3 or 4 (metal)

DCW Dead Bolt, Cross Throw, xxxxxxxxDCWxxxx no add

for door thickness 5 (wood)

DMM Dead Bolt, End Throw, w/ Cross Throw Parts xxxxxxxxDMMxxxx $8.25

for door thickness 1, 2, 3 or 4 (metal)

EXAMPLE

C L 2 0

Model

S

Power

Source

1 D

Door

Thickness

M K

Keypad

E

Bolt

M

Control Shaft

Length

Country

Code

Install Packaging

Unicon Series

Models CL10/CL20/DL20

November 1, 2013 11Unicon Series | Models CL10/CL20/DL20 Kaba Mas List Price Book #21

Bolt (continued) LIN # Add to List

DMW Dead Bolt, End Throw, w/ Cross Throw Parts xxxxxxxxDMWxxxx $8.25

for door thickness 5 (wood)

SEM Spring Latch Bolt, End Throw xxxxxxxxSEMxxxx no add

for door thickness 1, 2, 3 or 4 (metal)

SEW Spring Latch Bolt, End Throw xxxxxxxxSEWxxxx no add

for door thickness 5 (wood)

SCM Spring Latch Bolt, Cross Throw xxxxxxxxSCMxxxx no add

for door thickness 1, 2, 3 or 4 (metal)

SCW Spring Latch Bolt, Cross Throw xxxxxxxxSCWxxxx no add

for door thickness 5 (wood)

SDI Spring Bolt, Door, Inswing xxxxxxxxSDIxxxx no add

for door thickness 7 (wood or metal)

SDO Spring Bolt, Door, Outswing xxxxxxxxSDOxxxx no add

for door thickness 7 (wood or metal)

Control Shaft Length Add to List

A 1.75" (44.5mm) for Dead Bolts & Cam Latches: xxxxxxxxxxxAxxx no add

DEM, DEW, DCM, DCW, DMM, DMW, CAM, CAW

B 1.75" (44.5mm) for Spring Latch Bolts: xxxxxxxxxxxBxxx no add

SEM, SEW, SCM, SCW

C 1.915" (48.64mm) for Dead Bolts: xxxxxxxxxxxCxxx no add

DEM, DCM, DMM (cart applications)

D 1.25" (31.75mm) for Spring Bolt Door xxxxxxxxxxxDxxx no add

asm No Key Override: SDI, SDO (door applications)

E 1.25" 31.75mm) for Spring Bolt Door xxxxxxxxxxxExxx $130.00

asm w/ Key Override: SDI, SDO (door applications)

Country Code Add to List

E United States xxxxxxxxxxxxExx standard

Install

1 Standard Screws xxxxxxxxxxxxx1x standard

Packaging

A Distributor (Individual) xxxxxxxxxxxxxxA standard

M Metal Display, mounted xxxxxxxxxxxxxxM $31.25

W Wood Display, mounted xxxxxxxxxxxxxxW $46.75

EXAMPLE

C L 2 0

Model

S

Power

Source

1 D

Door

Thickness

M K

Keypad

E

Bolt

M

Control Shaft

Length

EA

Country

Code

1

Install

A

Packaging

Unicon Series

Models CL10/CL20/DL20

November 1, 201312 Kaba Mas List Price Book #21 Unicon Series | Accessories

Part # Package Qty. Description Package Price

321100 1 Unicon™ Series Software Implementation Package* $831.00

321109 1 Unicon™ Series Software Upgrade Package** $753.00

(for previous Unicon Series software users requiring operating system† upgrade)

327031 1 Reporting Key Fob (red) for downloading data from lock $52.00

327030 1 Programming Key Fob (teal) for uploading data to lock $57.25

203286 1 USB Adapter for Unicon Data Cable $57.25

202124 1 Serial Adapter for Unicon Data Cable $57.25

322007 1 Unicon Data Cable $20.75

321102 1 Key Override Sensor Kit*** (keyed different cylinder) $46.75

321103 1 Key Override Sensor Kit**** (keyed alike cylinder) $46.75

321106 50 Unicon Lock Covers (for front housing & knob) $114.50

321107 8 Duracell CR-2 Batteries $79.00

*Includes Software Install CD, Reporting key fob, Programming key fob, USB adapter and key fob data cable.

**Includes Software Install CD only.

***Includes Cylinder, 2 keys, sensor switch adapter assembly and cam. For use with spring loaded latch bolt only.

****For customer reorders, 4-digit key code must be speciﬁed for keyed alike cylinders. Includes Cylinder, 2 keys, sensor switch adapter assembly and

cam. For use with spring loaded latch bolt only.

†Consult Technical Support for currently supported operating systems.

NOTE: Minimum order amount per shipment is $100.00 net.

Unicon CL Series locks packed (10) per master carton.

Unicon Series

Accessories

Auditcon® 2 Series

Commercial Safe Locks

November 1, 201314 Kaba Mas List Price Book #21 Auditcon 2 Series | Models 52/T52

Model/Power Description LIN (Lock Identiﬁcation Number) List Price

052S* 52 Self-Powered 052Sxxxxxxxxxxx $295.25

05WS* 52 Self-Powered Swing Bolt 05WSxxxxxxxxxxx $295.25

T52S T52 Self-Powered T52Sxxxxxxxxxxx $331.75

T5WS T52 Self-Powered Swing Bolt T5WSxxxxxxxxxxx $331.75

T52A T52 Battery Assist T52Axxxxxxxxxxx $343.25

T5WA T52 Battery Assist Swing Bolt T5WAxxxxxxxxxxx $343.25

* available with “Housing/Display” RN or VN only

Housing/Display Add to List

RN Round xxxxRNxxxxxxxxx standard

RY* Round, Time Delay Display Compatible xxxxRYxxxxxxxxx add $16.75

VN Vertical xxxxVNxxxxxxxxx standard

VY* Vertical, Time Delay Display Compatible xxxxVYxxxxxxxxx add $16.75

* Refer to page 16 for Remote Time Delay Display Unit

Bolt Add to List

10N Dead Bolt, Non-Sensor xxxxxx10Nxxxxxx standard dead bolt

10Y Dead Bolt, Sensor xxxxxx10Yxxxxxx add $28.50

20N Dead Bolt, Non-Sensor, 10-32.5 (2X) Tapped Holes xxxxxx20Nxxxxxx add $7.25

23N Dead Bolt, Non-Sensor, M4-7 x 15mm (2X) Tapped Holes xxxxxx23Nxxxxxx add $7.25

70N* Slide Bolt, Non-Sensor xxxxxx70Nxxxxxx standard slide bolt

75N Swing Bolt, Non-Sensor xxxxxx75Nxxxxxx standard swing bolt

*Not VdS Certiﬁed if manufactured after 12/31/09

Relocker/Case Cover Add to List

1 Slide Bolt, No Relocker Plate xxxxxxxxx1xxxxx standard

2 Slide Bolt, Y Plate xxxxxxxxx2xxxxx no add

3 Slide Bolt, Y Plate and Universal Plate xxxxxxxxx3xxxxx no add

4 Dead Bolt, No Relocker Plate xxxxxxxxx4xxxxx no add

5 Dead Bolt, Universal Relocker Plate xxxxxxxxx5xxxxx no add

8 Swing Bolt, No Relocker Plate xxxxxxxxx8xxxxx no add

9 Swing Bolt, Universal Relocker Plate xxxxxxxxx9xxxxx no add

EXAMPLE

0 5 2 S

Model

Power Source

V

Housing

Display

1N 0

Bolt

N

Door Cable

Measurement

Relocker

Case Cover

4

Dial

Label

Country

Code

Install Packaging

Round

52/T52

Vertical

52/T52

Auditcon 2 Series

Models 52/T52

November 1, 2013 15Auditcon 2 Series | Models 52/T52 Continued Kaba Mas List Price Book #21

Auditcon 2 Series

Models 52/T52 Continued

Door Measurement Add to List

Dead Bolt (Spindled) - Door Thickness

A Up to 1" (25.4 mm) Door xxxxxxxxxxAxxxx no add

B Up to 3.5" (88.9 mm) Door xxxxxxxxxxBxxxx standard

C Up to 9" (228.6 mm) Door xxxxxxxxxxCxxxx no add

D Up to 5" (127 mm) Door xxxxxxxxxxDxxxx no add

E Up to 15" (381 mm) Door xxxxxxxxxxExxxx no add

F Up to 7" (177.8 mm) Door xxxxxxxxxxFxxxx no add

Slide Bolt (Non-Spindled) Cable Length

L 12" (304.8 mm) xxxxxxxxxxLxxxx no add

M 18" (457.2 mm) xxxxxxxxxxMxxxx standard

N 30" (762 mm) xxxxxxxxxxNxxxx add $13.50

P 48" (1219.2 mm) xxxxxxxxxxPxxxx add $15.50

Q 24" (609.6 mm) xxxxxxxxxxQxxxx no add

R 36" (914.4 mm) xxxxxxxxxxRxxxx add $15.50

Country Code Add to List

E †United States (UL/VdS/DNV/EN 1300) xxxxxxxxxxxExxx standard

S* †Spanish (UL/VdS/DNV/EN 1300) xxxxxxxxxxxSxxx no add

I* †Italian (UL/VdS/DNV/EN 1300) xxxxxxxxxxxIxxx no add

G* †German (UL/VdS/DNV/EN 1300) xxxxxxxxxxxGxxx no add

F* †France (UL/VdS/DNV/EN 1300) xxxxxxxxxxxFxxx no add

U* †United Kingdom (UL/VdS/DNV/EN 1300) xxxxxxxxxxxUxxx no add

D* †Sweden (UL/VdS/DNV/EN 1300) xxxxxxxxxxxDxxx no add

* Must select “Dial Label” D

† No VdS certiﬁcation for 70 N Slide Bolt if manufactured after 12/31/09

Dial Label Add to List

A Black xxxxxxxxxxxxAxx standard

B Black, No Logo xxxxxxxxxxxxBxx no add

C No Label xxxxxxxxxxxxCxx no add

D †Tamper Evident xxxxxxxxxxxxDxx add $7.25

† shipped on all Country Codes, except “E” at no additional cost

Install Add to List

1 Standard Screws xxxxxxxxxxxxx

1

x standard

2 Metric Screws xxxxxxxxxxxxx2x no add

Packaging Add to List

A Distributor (Individual) xxxxxxxxxxxxxxA standard

B OEM (Bulk) xxxxxxxxxxxxxxB no add

Auditcon® 2 Series locks packed (10) per master carton.

EXAMPLE

0 5 2 S

Model

Power Source

V

Housing

Display

1N 0

Bolt

N

Door Cable

Measurement

Relocker

Case Cover

AEA4

Dial

Label

Country

Code

1

Install

A

Packaging

November 1, 201316 Kaba Mas List Price Book #21 Auditcon 2 Series | Models 252/552

Model/Power Description LIN (Lock Identiﬁcation Number) List Price

252S 252 Self-Powered 252Sxxxxxxxxxxx $349.50

25WS 252 Self-Powered Swing Bolt 25WSxxxxxxxxxxx $349.50

252A 252 Battery Assist 252Axxxxxxxxxxx $349.50

25WA 252 Battery Assist Swing Bolt 25WAxxxxxxxxxxx $349.50

552A 552 Battery Assist 552Axxxxxxxxxxx $735.25

55WA 552 Battery Assist Swing Bolt 55WAxxxxxxxxxxx $735.25

Housing/Display Add to List

RN Round xxxxRNxxxxxxxx standard

RY* Round, Time Delay Display Compatible xxxxRYxxxxxxxx add $16.75

VN Vertical xxxxVNxxxxxxxx standard

VY* Vertical, Time Delay Display Compatible xxxxVYxxxxxxxx add $16.75

* Refer to page 16 for Remote Time Delay Display Unit

Bolt Add to List

10N Dead Bolt, Non-Sensor xxxxxx10Nxxxxxx standard dead bolt

10Y Dead Bolt, Sensor xxxxxx10Yxxxxxx add $28.50

20N Dead Bolt, Non-Sensor, 10-32.5 (2X) Tapped Holes xxxxxx20Nxxxxxx add $7.25

23N Dead Bolt, Non-Sensor, M4-7 x 15mm (2X) Tapped Holes xxxxxx23Nxxxxxx add $7.25

70N* Slide Bolt, Non-Sensor xxxxxx70Nxxxxxx standard slide bolt

75N Swing Bolt, Non-Sensor xxxxxx75Nxxxxxx standard swing bolt

*Not VdS Certiﬁed if manufactured after 12/31/09

Relocker/Case Cover Add to List

1 Slide Bolt, No Relocker Plate xxxxxxxxx1xxxxx standard

2 Slide Bolt, Y Plate xxxxxxxxx2xxxxx no add

3 Slide Bolt, Y Plate and Universal Plate xxxxxxxxx3xxxxx no add

4 Dead Bolt, No Relocker Plate xxxxxxxxx4xxxxx no add

5 Dead Bolt, Universal Relocker Plate xxxxxxxxx5xxxxx no add

8 Swing Bolt, No Relocker Plate xxxxxxxxx8xxxxx no add

9 Swing Bolt, Universal Relocker Plate xxxxxxxxx9xxxxx no add

EXAMPLE

2 5 2 S

Model

Power Source

V

Housing

Display

1N 0

Bolt

N

Door Cable

Measurement

Relocker

Case Cover

4

Dial

Label

Country

Code

Install Packaging

Round

252/552

Vertical

252/552

Auditcon 2 Series

Models 252/552

November 1, 2013 17Auditcon 2 Series | Models 252/552 Continued Kaba Mas List Price Book #21

Door Measurement Add to List

Dead Bolt (spindled) - door thickness

A Up to 1" (25.4 mm) Door xxxxxxxxxxAxxxx no add

B Up to 3.5" (88.9 mm) Door xxxxxxxxxxBxxxx no add

C Up to 9" (228.6 mm) Door xxxxxxxxxxCxxxx no add

D Up to 5" (127 mm) Door xxxxxxxxxxDxxxx no add

E Up to 15" (381 mm) Door xxxxxxxxxxExxxx no add

F Up to 7" (177.8 mm) Door xxxxxxxxxxFxxxx no add

Slide or Swing Bolt (non-spindled) cable length

L 12" (304.8 mm) xxxxxxxxxxLxxxx no add

M 18" (457.2 mm) xxxxxxxxxxMxxxx standard

N 30" (762 mm) xxxxxxxxxxNxxxx add $13.50

P 48" (1219.2 mm) xxxxxxxxxxPxxxx add $15.50

Q 24" (609.6 mm) xxxxxxxxxxQxxxx no add

R 36" (914.4 mm) xxxxxxxxxxRxxxx add $15.50

Country Code Add to List

E

†

United States (UL/VdS/DNV/EN 1300) xxxxxxxxxxxExxx standard

S*

†

Spanish (UL/VdS/DNV/EN 1300) xxxxxxxxxxxSxxx no add

I*

†

Italian (UL/VdS/DNV/EN 1300) xxxxxxxxxxxIxxx no add

G*

†

German (UL/VdS/DNV/EN 1300) xxxxxxxxxxxGxxx no add

F*

†

France (UL/VdS/DNV/EN 1300) xxxxxxxxxxxFxxx no add

U*

†

United Kingdom (UL/VdS/DNV/EN 1300) xxxxxxxxxxxUxxx no add

D*

†

Sweden (UL/VdS/DNV/EN 1300) xxxxxxxxxxxDxxx no add

*Must select “Dial Label” D

†No VdS certiﬁcation for 70 N Slide Bolt if manufactured after 12/31/09

Dial Label

A Black xxxxxxxxxxxxAxx standard

B Black, No Logo xxxxxxxxxxxxBxx no add

C No Label xxxxxxxxxxxxCxx no add

D †Tamper Evident xxxxxxxxxxxxDxx add $7.25

†Shipped on all country codes except “E” at no additional cost

Install Add to List

1 Standard Screws xxxxxxxxxxxxx1x standard

2 Metric Screws xxxxxxxxxxxxx2x no add

Packaging

A Distributor (Individual) xxxxxxxxxxxxxxA standard

B OEM (Bulk) xxxxxxxxxxxxxxB no add

Auditcon® 2 Series locks packed (10) per master carton.

EXAMPLE

2 5 2 S

Model

Power Source

V

Housing

Display

1N 0

Bolt

N

Door Cable

Measurement

Relocker

Case Cover

AEA4

Dial

Label

Country

Code

1

Install

A

Packaging

Auditcon 2 Series

Models 252/552 Continued

November 1, 201318 Kaba Mas List Price Book #21 Auditcon 2 Series | Accessories

Part # Package Qty. Description Package Price

307025 1 Remote Time Delay Display Unit $216.75

301040 1 Duress Alarm Interface Kit $103.00

301101 1 Auditcon 2 Series Software Implementation Package* $265.25

301102 1 Auditcon 2 Series Software Upgrade Package** $139.00

(for previous Audit Only software users or operating system† upgrade)

202021 1 SA Key (red) for data upload/download $46.00

302170 1 B Key (green/teal) for uploading date/time into Model 552 $46.00

202124 1 Serial Adapter for 2-port Key Reader $57.25

212009 1 Key Reader, 2-port $78.00

203286 1 USB Adapter for 2-port Key Reader $57.25

305301 20 Universal Relocker Plate $78.00

365037 20 Relocker Adapter for Slide Bolts $78.00

315063 1 Lock Mounting Plate $18.75

104035 1 Auditcon Series Display Stand (Round) $87.25

314006 1 Auditcon Series Display Stand (Vertical) $87.25

* Includes Software Install CD, SA key, key reader, and USB key reader adapter.

**Includes Software Install CD and USB key reader adapter.

†Consult Technical Support for currently supported operating systems.

NOTE: Minimum order amount per shipment is $100.00 net.

Auditcon 2 Series

Accessories

November 1, 2013 19Auditcon 2 Series | Parts Kaba Mas List Price Book #21

Part # Package Qty. Description Package Price

Dial labels

311200 20 Dial Label, Vertical, Kaba Logo $47.75

311201 20 Dial Label, Vertical, Tamper-Evident $71.75

301200 20 Dial Label, Round, Kaba Logo $47.75

301201 20 Dial Label, Round, Tamper-Evident $71.75

Front housing, vertical

311202 1 Mounting Plate/Keypad/Generator Assembly, TDD Compatible $240.75

311207 5 Front Cover, 52/T52 $67.50

311203 5 Front Cover, 252/552 $67.50

311204 10 Dial and Label $85.25

311101 50 Retainer Clip $37.50

Front housing, round

301202 1 Mounting Plate/Dial/Generator Assembly, Label, TDD Compatible $229.25

301203 1 Keypad and Label $85.25

Installation kits, dead bolt

311205 10 Install Kit, Vertical (10 Standard Screws, Tape, Lube, Cable Shields, Clip) $78.00

311206 10 Install Kit, Vertical (10 Metric Screws, Tape, Lube, Cable Shields, Clip) $95.25

301216 10 Install Kit, Round (7 Standard Screws, Tape, Cable Shields) $69.75

301217 10 Install Kit, Round (7 Metric Screws, Tape, Cable Shields) $87.25

Installation kits, slide bolt or swing bolt

361206 10 Install Kit, Vertical (9 Standard Screws, Lube, Spacers, Cable Shields, Spindle) $66.50

361207 10 Install Kit, Vertical (9 Metric Screws, Lube, Spacers, Cable Shields, Spindle) $82.75

361204 10 Install Kit, Round (5 Standard Screws, Cable Shields) $54.00

361205 10 Install Kit, Round (5 Metric Screws, Cable Shields) $74.25

Lock case, dead bolt, standard (10N)

301204* 1 52 $168.50

301205* 1 T52 $205.50

301206* 1 252 $385.75

301207** 1 552 $481.50

*Non-battery assist

**Battery assist

Auditcon 2 Series

Parts

November 1, 201320 Kaba Mas List Price Book #21 Auditcon 2 Series | Parts Continued

Lock case, dead bolt, metric tapped holes (23N) Package Price

301208* 1 52 $174.75

301209* 1 T52 $211.00

301210* 1 252 $391.00

301211** 1 552 $486.75

*Non-battery assist

**Battery assist

Lock case, slide bolt, standard (70N) (Not VdS Certiﬁed if manufactured after 12/31/09)

361200* 1 52 $168.50

361201* 1 T52 $200.25

361202* 1 252 $385.75

361203** 1 552 $481.50

*Non-battery assist

**Battery assist

Lock case, swing bolt, standard (75N)

351100* 1 52 $168.50

351101* 1 T52 $200.25

351102* 1 252 $385.75

351103** 1 552 $481.50

*Non-battery assist

**Battery assist

Cable

301214 10 Dead Bolt Cable, 3.5" (88.9 mm) Door $85.25

301215 10 Dead Bolt Cable, 9.0" (228.6 mm) Door $96.25

301218 10 Dead Bolt Cable, 15.0" (381 mm) Door $109.25

361208 10 Slide Bolt Cable, 18.0" (457.2 mm) Door $96.25

361209 10 Slide Bolt Cable, 30.0" (762 mm) Door $126.25

Spindle/Tube, dead bolt

301212 10 Dead Bolt Spindle, 9.0" (228.6 mm) Door $109.25

301213 10 Dead Bolt Tube, 9.0" (228.6 mm) Door $24.00

301219 10 Dead Bolt Spindle, 15.0" (381 mm) Door $144.50

301220 10 Dead Bolt Tube, 15.0" (381 mm) Door $37.50

Auditcon 2 Series

Parts Continued

Cencon®

Cash-In-Transit/ATM Locking System

November 1, 201322 Kaba Mas List Price Book #21 Cencon | Cash-In-Transit/ATM Locking System

Model/Power Description LIN (Lock Identiﬁcation Number) List Price

CSD2 Non-Shunt, Gen2 Self-Powered CSD2xxxxxxxxxxx $935.00

CSS2 Alarm Shunt, Gen2 Self-Powered CSS2xxxxxxxxxxx $1035.00

SWING BOLT

*CSLW Cencon Standard Lock, Swing Bolt CSLWxxxxxxxxxxx $835.00

*Interconnect Box REQUIRED. See Following Page for Options.

Housing/Display Add to List

KU Keypad Up xxxxKUxxxxxxxxx standard

KI Keypad Inverted xxxxKIxxxxxxxxx add $49.00

KD Keypad Down xxxxKDxxxxxxxxx no add

SWING BOLT

VY Vertical Display xxxxVYxxxxxxxxx no add

Bolt Add to List

005 M4-.7 x 15mm (2X) Tapped Dead Bolt xxxxxx005xxxxxx no add

006 10/32 x .563 (2X) Tapped Dead Bolt xxxxxx006xxxxxx standard

007 10/32 x .500 (2X) Tapped Dead Bolt xxxxxx007xxxxxx add $29.00

SWING BOLT

75Y Swing Bolt, Standard xxxxxx75Yxxxxxx no add

Relocker/Case Cover Add to List

7 No Relocker Plate (Gen2) xxxxxxxxx7xxxxx standard

SWING BOLT

2 No Relocker Plate (SWB) xxxxxxxxx2xxxxx standard

Door Measurement Add to List

C 1.04" (26.3 mm) Door xxxxxxxxxxCxxxx $5.00

D 1.13" (28.6 mm) Door xxxxxxxxxxDxxxx $5.00

E 1.276” (32.4 mm) Door xxxxxxxxxxExxxx $5.00

G 1.74" (44.3 mm) Door xxxxxxxxxxGxxxx standard

H 2.17" (55 mm) Door xxxxxxxxxxHxxxx standard

J 3.70" (94 mm) Door xxxxxxxxxxJxxxx $5.00

L 4.45" (113 mm) Door xxxxxxxxxxLxxxx $30.00d

M 5.12" (130 mm) Door xxxxxxxxxxMxxxx $50.00

N 9.84" (250 mm) Door xxxxxxxxxxNxxxx add $100.00

P 15.75" (400 mm) Door xxxxxxxxxxPxxxx add $270.00

SWING BOLT

A Up to 5.88" (149 mm) Door xxxxxxxxxxAxxxx no add

C S D 2

Model

Power Source

K

Housing

Display

0U 0

Bolt

6

Door Cable

Measurement

Relocker

Case Cover

G7

Dial

Label

Country

Code

Install Packaging

Cencon

Cash-In-Transit/

ATM Locking System

Keypad Down - KD Swing BoltKeypad Up - KU

Keypad Inverted - KI

EXAMPLE

November 1, 2013 23Cencon | Cash-In-Transit/ATM Locking System Continued Kaba Mas List Price Book #21

Country Code Add to List

E United States (UL/ULC) xxxxxxxxxxxExxx standard

U Universal (UL/ULC/VdS/DNV/EN 1300/CE) xxxxxxxxxxxUxxx add $12.00

SWING BOLT

U Universal (UL/ULC/VdS/DNV/EN1300/CE xxxxxxxxxxxUxxx standard

Dial Label

B Silver (Gen2) xxxxxxxxxxxxBxx standard

SWING BOLT

A Tamper Evident xxxxxxxxxxxxAxx standard

Install

1 Standard & Metric Screws xxxxxxxxxxxxx1x add $6.75

2 Standard Screws xxxxxxxxxxxxx2x standard

3 Metric Screws xxxxxxxxxxxxx3x no add

4 Standard, KI for Factory xxxxxxxxxxxxx4x no add

5 Standard, KI for Field, Saw xxxxxxxxxxxxx5x add $13.50

SWING BOLT

1 Metric Screws xxxxxxxxxxxxx1x no add

2 Standard Screws xxxxxxxxxxxxx2x no add

Packaging

A Distributor (Individual) xxxxxxxxxxxxxxA standard

SWING BOLT

A Distributor xxxxxxxxxxxxxxA standard

Cencon locks packed (10) per master carton.

Cencon

Cash-In-Transit/

ATM Locking System Continued

Swing Bolt Interconnect Box Options (must be ordered with Swing Bolt Lock) Add to List

Non-Shunt Interconnect Box, No USB Connection, Duress,

Bolt Switch, Door Contact, 12" Cables

237029 $100.00

Non-Shunt Interconnect Box, USB Connection, Duress,

Bolt Switch, Door Contact, 12" Cables

237013 $335.00

Shunt Interconnect Box, No USB Connection, Duress, Alarm Shunt,

Bolt Switch, Door Contact, 12" Cables

237014 $200.00

Shunt Interconnect Box, USB Connection, Duress, Alarm Shunt,

Bolt Switch, Door Contact, 12" Cables

237012 $435.00

USB is for Connection to ATM PC

EXAMPLE

C S D 2

Model

Power Source

K

Housing

Display

0U 0

Bolt

6

Door Cable

Measurement

Relocker

Case Cover

BEG7

Dial

Label

Country

Code

1

Install

A

Packaging

Cencon O2

November 1, 201324 Kaba Mas List Price Book #21 Cencon | Software/Accessories/Keys

Cencon

Software/Accessories/Keys

Software Components (See Note)

Part # Description NET Price

Cencon Single Server Software and License (Choose one or more of the modes below) $595.00

• Bank Mode License with Two Green/Teal B Keys $295.00

• FLM Mode License with Two Blue F Keys $995.00

• Route Mode License with Two Yellow R Keys $1595.00

Install Key, Orange Hourglass (Flat) Shape, Customer-Coded (ships separately) $45.00

Dispatch Pack (USB Key Box & USB Cable), Customer-Coded $595.00

Dispatch Pack for Servers (USB Card with Bracket & USB Cable), Customer-Coded $595.00

CenTran 5, Single Server Software License $3995.00

Keys

Part # Description Category Color Shape List Price

202020 F Key First Line Maintenance Personnel Lock User (blue) Teardrop (Bent) $46.00

202022 R Key Route Mode Personnel Lock User (yellow) Teardrop (Bent) $46.00

202270 B Key Bank Mode Personnel Lock User (green/teal) Teardrop (Bent) $46.00

202024 L Key Logon to Cencon (Ex: D, S, SS) Software User (black) Teardrop (Bent) $46.00

212030 A Key Additional Logon to KMU Software User (orange) Teardrop (Bent) $46.00

202021 SA Key Supervisor Audit Data Transfer (red) Teardrop (Bent) $46.00

202226 CS Key Clock Set (Gen2 Lock + Cencon 4) Data Transfer (white) Hourglass (Flat) $75.00

202224 RS Key Re-Sync (Gen2 Lock + Cencon 4) Data Transfer (dark grey) Hourglass (Flat) $46.00

Software Accessories

Part # Description List Price

205475 Cable Lock for Physically Securing USB Key Box $58.25

203325 Replacement USB Cable, 2 Meter Length $52.00

201186 Interface Kit for Programming/Auditing Gen2 Lock from Cencon 4 Software $291.00

Cencon O2

For Use with CenTran 5 & Cencon Interconnect Box. Enables Remote Connectivity. To Be Installed on the ATM PC.

CenTran Agent (.Net 3.5 Software), compatible with XP Service Pack 2 $595.00

OR

CenTran Agent (.Net 4.0 Software), compatible with XP Service Pack 3, Windows 7, 32/64 bit $595.00

PLUS

Cencon Keybox Agent Software, use with USB Keybox* (For Remote Key Management) $295.00

* Requires CenTran, CenTran Agent

NOTE: The parts listed above can only be ordered via the online Cencon Software Order Form due to special

programming and security requirements during shipping.

November 1, 2013 25Cencon | Parts Kaba Mas List Price Book #21

Cencon Gen2

Part # Package Qty. Description Package List Price

201183 1 Installed Gen2 Lock (CSD2KU0067QEB2A) on Light Grey Display Stand $970.00

205518 1 Thin Plastic Stand with Light Grey Sticker for Displaying Lock $42.00

104035 1 Heavy Black Plastic Stand for Displaying Lock $87.25

201175 1 Back Cover, Gen2, w/ Electronics Card, Non-Shunted, Screws $562.00

201176 1 Back Cover, Gen2, w/ Electronics Card, Shunt Alarm, Screws $661.00

105061 1 Dial Nameplate Decal for Gen1 (Black) $2.75

205498 1 Dial Nameplate Decal for Gen2 (Silver) $2.75

201180 1 Gen2 Cables, 4-wire, for Door Contact & Remote Disable Signals $12.00

201185 1 Handheld Test Device for Gen2 Lock's Multiple Connectors $26.00

Items Used for Both Gen1 and Gen2 Cencon Lock

Part # Package Qty. Description Package List Price

204210 1 Dial Replacement Kit with Spindle for 130mm (5.12") Door Thickness $39.00

201290 1 Dial Replacement Kit with No Spindle $25.00

201160 10 Spindle w/Screw, 44.3 mm (1.74") Door Thickness $75.00

201161 10 Spindle w/Screw, 55 mm (2.17") Door Thickness $85.00

201162 10 Spindle w/Screw, 113 mm (4.45") Door Thickness $105.00

201163 10 Spindle w/Screw, 130 mm (5.12") Door Thickness $125.00

201164 10 Spindle w/Screw, 250 mm (9.84") Door Thickness $155.00

201139 1 Front Housing Assembly, with Keypad Up (KU) Standard $322.00

201140 1 Front Housing Assembly, with Keypad Inverted (KI) $371.00

201136 1 Front Housing Assembly, with Keypad Down (KD) $322.00

201152 1 Cable Replacement Kit, 55 mm (2.17") Door Thickness $45.00

201153 1 Cable Replacement Kit, 130 mm (5.12") Door Thickness $60.00

201154 1 Cable Replacement Kit, 250 mm (9.84") Door Thickness $110.00

201155 1 Mounting Plate $44.00

NOTE: Minimum order amount per shipment is $100.00 net.

Cencon

Parts

November 1, 201326 Kaba Mas List Price Book #21 Cencon | Parts Continued

Items Used for Both Gen1 and Gen2 Cencon Lock (continued)

Part # Package Qty. Description Package List Price

201165 10 Cable-Protecting Tube, 55 mm (2.17") Door $1800

201166 10 Cable-Protecting Tube, 130 mm (5.12") Door $28.00

201167 10 Cable-Protecting Tube, 250 mm (9.84") Door $68.00

201173 1 Cable, Spindle & Tube Kit for up to 400mm (15.75") Door Thickness $360.00

201174 1 Tube & Spindle for up to 55 mm (2.17") Door Thickness $18.00

201143 1 Lock Case w/ Cable, 55 mm Door (No Back Cover) 006 Bolt $323.00

201144 1 Lock Case w/ Cable, 55 mm Door (No Back Cover) 005 Bolt (Metric) $323.00

201145 1 Lock Case w/ Cable, 130 mm Door (No Back Cover) 007 Bolt $368.00

201146 1 Lock Case w/ Cable, 130 mm Door (No Back Cover) 006 Bolt $368.00

201147 1 Lock Case w/ Cable, 130 mm Door (No Back Cover) 005 Bolt (Metric) $368.00

201148 1 Lock Case w/ Cable, 250 mm Door (No Back Cover) 006 Bolt $448.00

201149 1 Lock Case w/ Cable, 250 mm Door (No Back Cover) 005 Bolt (Metric) $448.00

201150 1 Lock Case, (No Back Cover and No Cable) 006 Bolt $288.00

201151 1 Lock Case, (No Back Cover and No Cable) 005 bolt (Metric) $288.00

201156 10 Drive Cam $115.00

204004 1 Install Kit (24 Standard/Metric Screws, etc., Dial Clip/Washer) $15.00

204247 1 Install Kit (16 Standard Screws, etc., Dial Clip/Washer) $12.00

204248 1 Install Kit (12 Metric Screws, etc., Dial Clip/Washer) $12.00

201158 50 Dial Clip, Triangular $73.00

201159 50 Dial Spacer/Washer $109.00

201157 50 Zebra Connector + Housing $325.00

204016 1 Spare Parts Kit w/Keypad Up (55 mm Spindle, Cam, Dial Parts) $363.00

107061 1 Change Key $12.50

201168 1 Alarm Cable, Rainbow-colored, w/ 9-pin Connector, 48.5" long $18.00

NOTE: Minimum order amount per shipment is $100.00 net.

Cencon

Parts Continued

X-10™

High Security Government Locks

November 1, 201328 Kaba Mas List Price Book #21 X-10

X-10

EXAMPLE

X 1 0 X

Model

Power Source

R

Housing

Display

XD X

Bolt

T

Door Cable

Measurement

Relocker

Case Cover

ZEAZ

Dial

Label

Country

Code

1

Install

A

Packaging

X-10™

Model/Power Description LIN (Lock Identiﬁcation Number) List Price

X10X Standard OEM, Distributor, Self-Powered X10Xxxxxxxxxxxx $1,753.00

Housing/Display Add to List

RD Round xxxxRDxxxxxxxxx no add

Bolt

XXT Dead Bolt, 10-32.5 (2X) Tapped Holes xxxxxxXXTxxxxxx standard

Relocker/Case Cover

Z Standard xxxxxxxxZxxxxx no add

Door Measurement

A .92" (23.37 mm) Door xxxxxxxxxxAxxxx no add

B 1.06" (26.92 mm) Door xxxxxxxxxxBxxxx no add

C 1.13" (28.7 mm) Door xxxxxxxxxxCxxxx no add

D 1.17" (29.72 mm) Door xxxxxxxxxxDxxxx no add

E 1.25" (31.75 mm) Door xxxxxxxxxxExxxx no add

F 1.38" (35.05 mm) Door xxxxxxxxxxFxxxx no add

G 1.61" (40.89 mm) Door xxxxxxxxxxGxxxx no add

H 2.06" (52.32 mm) Door xxxxxxxxxxHxxxx no add

J 2.16" (54.86 mm) Door xxxxxxxxxxJxxxx no add

K 2.25" (57.15 mm) Door xxxxxxxxxxKxxxx no add

L 2.81" (71.45 mm) Door xxxxxxxxxxLxxxx no add

M 4.50" (114.3 mm) Door xxxxxxxxxxMxxxx standard

N 10.0" (254 mm) Door xxxxxxxxxxNxxxx no add

Country Code Add to List

E United States xxxxxxxxxxxExxx no add

Dial Label

Z Standard xxxxxxxxxxxxZxx no add

Install

1 Distributor/Government (Individual) xxxxxxxxxxxxx1x no add

Packaging

A Distributor/Government (Individual) xxxxxxxxxxxxxxA no add

X-10 locks packed (10) per master carton

November 1, 2013 29CDX-10 Kaba Mas List Price Book #21

CDX-10

CDX-10™

CDX-10

NOTE: to order the CDX-10 please specify a hard plate and strike using the information below

Part # Description List Price

For mounting with non drill-resistant mounting plate specify (includes plate and strike):

521025/521030 Strike Type 1 $2,270.00

521025/521031 Strike Type 2 $2,270.00

521025/521032 Strike Type 3 $2,270.00

521025/521033 Strike Type 9 $2,270.00

For mounting with drill-resistant hard plate (includes plate and strike):

521025/521020 Strike Type 1 $2,815.00

521025/521021 Strike Type 2 $2,815.00

521025/521022 Strike Type 3 $2,815.00

521025/521023 Strike Type 9 $2,815.00

NOTE: Refer to page 34 when ordering strikes or plates only.

Replacement CDX-10 for use with CDX Assembly (Long Bolt)

Part # Description List Price

521025 Lock and Dial (X-10 for CD Applications) $1,783.00

521035 Replacement Lock with Cable (X-10 for CD Applications) $1,338.00

X-10™

November 1, 201330 Kaba Mas List Price Book #21 X-10 | Parts

Accessories Display Stand List $ Per

104035 Display Stand for X-10 $89.00

527075 X-10 Mounted on Display Stand $1892.00

Part # X-10 LCD Assembly (IC) List $ Per

507081 Contents: LCD Endcap Assembly, Type 2 (1) $162.00

Part # X-10 Cable Assembly for up to 4.5" Door (UA) List $ Per

527100 Contents: Cable Assembly, Flex Wall thk. 4.5 (1) $98.00

Ground Contact (1)

Tube Retainer (1)

Screw - FH 2 - 56 X .188, TORX, UC (1)

Part # X-10 Cable Assembly for up to 2.25" Door (UA) List $ Per

521011 Contents: Cable Assembly, Flex Wall thk. 2.813 (1) $94.00

Ground Contact (1)

Tube Retainer (1)

Screw - FH 2 - 56 X.188, TORX, UC (1)

Part # X-10 Instruction Pack List $ Per

527002 Contents: Change Key (1) $32.50

Mounting Template (1)

X-10 Operating Instructions (1)

X-10 Installation Instructions (1)

X-10 Quick Reference Guide (1)

Part # X-10 Change Key List $ Per

107061 $12.50

Part # X-10 Lock Mounting Kit List $ Per

524002 Contents: $51.00

Saw Blade 52 teeth/inch (1)

Saw Handle (1)

Hexkey, 5/64 Long (1)

Tube Deburr Stone (1)

Vise Clamp (1)

Hub Gauge (1)

Lubricant, Tube Lubriplate Grease (1)

Screw - PH 8/32 X 5/16 (4)

Screw - Case 1/4 - 20 X .38 (4)

Screw - Case 1/4 - 20 X .31 (4)

Insulator, Tape M85-89 (1)

Zebra Connector Housing (1)

Zebra Connector, SPL (1)

Cable Retainer (3)

Spindle Screw - PH 6.32 X .395 (1)

X-10

Parts

November 1, 2013 31X-10 | Parts Continued Kaba Mas List Price Book #21

Part # X-10 Hub Assembly (GC) List $ Per

504067 Contents: Hub Assembly (1) $13.50

Part # X-10 Dial-Retaining Rings (C-Clips) List $ Per

504085 Replacement Clips used w/ Hub (50) $99.00

Part # X-10 Dial (HC) List $ Per

504068 Contents: X-10 Dial (1) $25.00

Part # X-10 4.5" Spindle Assembly with Mounting Screw (EC) List $ Per

524004 Contents: Spindle Assembly, W-THK 4.5 (1) $27.50

Part # Lubricant List $ Per

9810004 Contents: Lubricant (1) $1.60

Part # X-10 Tube Kit (MA) List $ Per

104017 Contents: Inner Tube 4.5 (1) $57.00

Outer Tube 4.5 (1)

Part # X-10 Sealed Lock Case Assembly, Bolt, Tapped (AC) List $ Per

521017 Contents: Lock Case Assembly (1) $1,308.00

Part # X-10 Generator List $ Per

507084 Contents: Generator (1) $108.50

Part # X-10 Dial Ring Assembly (no LCD) (DC) List $ Per

504075 Contents: Dial Ring (1) $45.50

Spindle Tube Retainer (1)

Spindle Tube Holder (1)

Screw - BH, 4-40 X .156, Comb. Drive (2)

Washer, SPL. ﬂat, .185 ID X .360 OD (2)

Part # X-10 Dial Ring Cover Assembly (CC) List $ Per

507085 Contents: Generator Clutch Assembly, PCB (1) $168.00

Dial Ring Cover Assembly (1)

Screw - PH 8/32 X 5/16 (2)

Gear Plate Assembly (1)

Screw - SEMS, 6/32 X .313, Plain (3)

Gear Drive, 94ET/48P, 15IT/30P (1)

Gear, Comb, 14/53T, 48P (1)

Screw - PH 4/40 X 5/32 (2)

Screw - PH, 4/40 X .375, CRBH, Type 1 (2)

NOTE: Minimum order amount per shipment is $100.00 net.

X-10

Parts Continued

November 1, 2013 32X-09 | Parts Kaba Mas List Price Book #21

Accessories Display Stand List $ Per

104035 Display Stand for X-09 $89.00

Part # X-09 LCD Assembly (IC) List $ Per

507081 Contents: LCD Endcap Assembly, Type 2 (1) $162.00

Part # X-09 Cable Assembly for up to 4.5" Door (UA) List $ Per

507071 Contents: Cable Assembly, Flex Wall thk. 4.5 (1) $98.00

Ground Contact (1)

Tube Retainer (1)

Screw - FH 2 - 56 X .188, TORX, UC (1)

Part # X-09 Cable Assembly for up to 2.25" Door (UA) List $ Per

501100 Contents: Cable Assembly, Flex Wall thk. 2.25 (1) $94.00

Ground Contact (1)

Tube Retainer (1)

Screw - FH 2 - 56 X.188, TORX, UC (1)

Part # X-09 Instruction Pack List $ Per

504054 Contents: Change Key (1) $32.50

Mounting Template (1)

X-09 Operating Instructions (1)

X-09 Installation Instructions (1)

X-09 Quick Reference Guide (1)

X-09 Small Spindle Hole Installation Procedure (1)

X-09 Attention Sheet (1)

Part # X-09 Change Key List $ Per

107061 $12.50

Part # X-09 Lock Mounting Kit List $ Per

504063 Contents: $51.00

Saw Blade 52 teeth/inch (1)

Saw Handle (1)

Hexkey, 5/64 Long (1)

Tube Deburr Stone (1)

Vise Clamp (1)

Hub Gauge (1)

Cover Lock Pin (1)

Retaining Ring, E-Type, 5/32 dia. Shaft (1)

Special Compression Spring (1)

Lubricant, Tube Lubriplate Grease (1)

Screw - PH 8/32 X 5/16 (4)

Screw - Case 1/4 - 20 X .38 (4)

Screw - Case 1/4 - 20 X .31 (4)

Insulator, Tape M85-89 (1)

Zebra Connector Housing (1)

Zebra Connector, SPL (1)

Cable Retainer (3)

X-09

Parts

November 1, 201333 Kaba Mas List Price Book #21 X-09 | Parts Continued

Part # X-09 Hub Assembly (GC) List $ Per

504067 Contents: Hub Assembly (1) $13.50

Part # X-09 Dial-Retaining Rings (C-Clips) List $ Per

504085 Replacement Clips used w/ Hub (50) $99.00

Part # X-09 Dial (HC) List $ Per

504068 Contents: X-09 Dial (1) $25.00

Part # X-09 4.5" Spindle Assembly (EC) List $ Per

504069 Contents: Spindle Assembly, W-THK 4.5 (1) $27.50

Part # X-09 Drive Cam Assembly List $ Per

504074 Contents: X-09 Drive Cam Assembly (1) $45.50

Part # Lubricant List $ Per

9810004 Contents: Lubricant (1) $1.60

Part # X-09 Tube Kit (MA) List $ Per

104017 Contents: Inner Tube 4.5 (1) $57.00

Outer Tube 4.5 (1)

Part # X-09 Lock Case Assembly, Std. Bolt no cover List $ Per

507082 Contents: Cam Assembly (1) $484.00

Case Sub Assembly (1)

Rack SPL 3T, 32P (1)

Screw - PH, 1/62 X .188 (1)

Slide Retainer (1)

Gear SPL, 11T (18T), 32P Rack Drive (1)

Gear SPL, 16T , 32P Slide Drive (1)

Roller, .146 OD X .063 ID X .064 (1)

Extension Spring (2)

Slide Assembly (1)

Bolt Detent Ball (2)

Bolt Detent Spring, SPL (1)

Screw - Bolt, FH 8 - 32 X .375 Hex SOC. (1)

Standard Bolt (1)

Flush Bolt, loose (1)

Motor/Gear Plate Assembly (1)

Motor/Gear Fence (1)

Gear Guard Bracket (1)

Screw - PH 2 -56 X .25 (1)

Torsion Spring (1)

Screw - 2 - 56 Shoulder Special (1)

Ground Contact (1)

Tube Retainer (1)

Screw - FH 2-56 X .188 TORX, UC (1)

NOTE: Minimum order amount per shipment is $100.00 net.

X-09

Parts Continued

November 1, 2013 34X-09 | Parts Continued Kaba Mas List Price Book #21

Part # X-09 Back Cover Assembly (BC) List $ Per

501227 Contents: Cover Assembly, X-09 (1) $824.50

Cover Lock Pin (2)

Retainer Ring, E-Type, 5/32 dia. Shaft (1)

Special Compression Spring (1)

Screw - PH 6/32 X 5/16 (1)

Part # X-09 Motor Kit List $ Per

507101 Contents: Gear/Motor Plate Assembly (1) $243.00

Motor/Gear Fence (1)

Gear Guard Bracket (1)

Screw - 2/56 Shoulder, Special (Gear Stop) (1)

Torsion Spring (1)

Screw - PH 2/56 X .25 (1)

Part # X-09 Generator List $ Per

507084 Contents: Generator (1) $108.50

Part # X-09 Dial Ring Assembly (no LCD) (DC) List $ Per

504075 Contents: Dial Ring (1) $45.50

Spindle Tube Retainer (1)

Spindle Tube Holder (1)

Screw - BH, 4-40 X .156, Comb. Drive (2)

Washer, SPL. ﬂat, .185 ID X .360 OD (2)

Part # X-09 Dial Ring Cover Assembly (CC) List $ Per

507085 Contents: Generator Clutch Assembly, PCB (1) $168.00

Dial Ring Cover Assembly (1)

Screw - PH 8/32 X 5/16 (2)

Gear Plate Assembly (1)

Screw - SEMS, 6/32 X .313, Plain (3)

Gear Drive, 94ET/48P, 15IT/30P (1)

Gear, Comb, 14/53T, 48P (1)

Screw - PH 4/40 X 5/32 (2)

Screw - PH, 4/40 X .375, CRBH, Type 1 (2)

Part # X-09 Flush Dead Bolt (KC) List $ Per

505212 Contents: Flush Dead Bolt (1) $25.00

Part # X-09 Standard +35 mm Dead Bolt List $ Per

505213 Contents: X-09 Standard + 35 mm Dead Bolt (1) $107.50

Part # X-09 Extended Dead Bolt (JC) List $ Per

505214 Contents: 4" Extended Dead Bolt (1) $25.00

Part # X-09 Pin, ring, spring (LOBC Kit) List $ Per

501024 Contents: Pin, Ring, Spring (LOBC Kit) (1) $12.50

X-09

Parts Continued

November 1, 201335 Kaba Mas List Price Book #21 CDX-10/CDX-09 | Strikes/Plates

Part # CDX Strike type 1 List $ Per

114003 Contents: Strike Type 1 (1) $21.00

Part # CDX Strike type 2 List $ Per

114004 Contents: Strike Type 2 (1) $45.50

Part # CDX Strike type 3 List $ Per

114005 Contents: Strike Type 3 (1) $40.00

Part # CDX Strike type 9 List $ Per

114006 Contents: Strike Type 9 (1) $67.50

Part # Drill Resistant Plate List $ Per

114014 Contents: Drill-Resistant Hard Plate (1) $579.50

Part # Non Drill-Resistant Mounting Plate List $ Per

114024 Contents: Non drill-Resistant Mounting Plate (1) $104.50

Part # Base Plate List $ Per

115034 Contents: Base Plate (Inside Container Door) (1) $84.50

NOTE: Minimum order amount per shipment is $100.00 net.

CDX-10 AND CDX-09 (FF-L-2890A) APPLICATIONS

CDX-10/CDX-09

Strikes/Plates

November 1, 2013 36Technical Training Kaba Mas List Price Book #21

Technical Training

Part # Course Description Duration Class Fee Minimum Class Size

CEN-0500 Cencon (at Kaba Mas) 2 day $850/day 4

CEN-0501 Cencon (Off-site)* 2 day $850/day 4

X091O-0900 X-10 Installation/Operation (at Kaba Mas) 1 day $275/person 6

X091O-0900 X-10 Installation/Operation (Off-site) 1 day $275/person 6

* Course fee plus expenses

ALL CLASS FEES ARE NET PRICE EITHER PER DAY OR PERSON

X-10 off-site training must be prearranged by Kaba Mas distributor.

Note: Expenses are deﬁned as instructor’s travel (airfare/mileage), lodging, meals, transportation,

and shipping training materials.

Please visit www.kaba-mas.com

for the most current schedule of technical training courses, and an application.

November 1, 201337 Kaba Mas List Price Book #21 Products Weights & Measures

Product Weights & Measures

GITCON

Model G50 8 lbs. (Swing) 13" x 5 1/2" x 3 1/4"

Model G50 15 lbs. (Roll-up) 15" x 12 1/2" x 5"

UNICON

Single box 1.028 lbs. 10" x 7" x 2 1/2"

10-pack box 10.2 lbs. 20" x 13" x 8"

AUDITCON 2 Series

Single box 2.6 lbs. (Round) 10" x 7" x 2 1/2"

2.2 lbs. (Vertical) 10" x 7" x 2 1/2"

10-pack box 26 lbs. (Round) 20" x 13" x 8"

22 lbs. (Vertical) 20" x 13" x 8"

CENCON

Single box 3 lbs. 10" x 7 1/4" x 4 1/4"

10-Pack box 25-27 lbs. 22" x 15" x 11"

X-10

Single box 4 lbs. 10" x 7 1/4" x 4 1/4"

10-Pack box 40 lbs. 22" x 15" x 11"

6-Pack box 24 lbs. 12 1/2" x 12 1/2" x 12 1/2" (OEM)

CDX-10

Single box 9 lbs. 12" x 9 1/4" x 6"

5-Pack box 45 lbs. or 63 lbs. 19" x 16" x 12 1/2" (Gov’t)

The Kaba Safe Lock Division relies on product innovation to meet our markets’ ever-changing needs

for loss prevention and access control solutions�

The Kaba and LA GARD brands are synonymous worldwide with security, control and accountability�

Kaba AG | Kaba Mas | Kaba Mauer GmbH

KMLLPB#21.NOV01/2013.1K

Kaba Mas LLC

749 W. Short St.

Lexington, KY 40508

phone 859-253-4744

toll-free 877-KabaMas (522-2627)

fax 859-255-2655

web www.kaba-mas.com

Kaba Mas Price Book Pricelist21Rev A

Navigation menu

Versions of this User Manual:

Views

Navigation
