InSync®

L

Overview

The InSync L is a battery operated electronic lock with a

tubular dead-locking latch bolt. An InSync L lock works

with Windows®-based SAM RF software, an electronic

key-encoding device, handheld utility device, and

electronic RFID keys to create a comprehensive access

control system. The system eliminates key cutting, lock

replacement, and risks associated with unauthorized

mechanical keys. In addition, it provides multiple levels of

access control to provide the highest level of security.

Applications

• Ideal for all types of multihousing applications,

including apartment homes, student housing,

assisted-living facilities, and military family housing

• Suitable for both new and retrofit projects

• Access control for unit, suite, and common areas

Security Features

• Dead-latching bolt operates with closure of the door

• Inhibit key cancels a specific key; for use when a key

is lost or stolen

• Emergency keys open any lock on a property, including

unit, suite, and common access area locks

• Limited Use keys for vendors, staff members, and

potential residents who may need regulated access to

unit or common access areas

Low Maintenance

• Locks indicate low power signal with key insertion

• Designedforextendedbatterylife

• Weatherized to withstand environmental conditions

3⅛"

(79 mm)

3⅛"

(79 mm)

2¼"

(58 mm)

2¼"

(58 mm)

¼"

(7 mm)

8⅜"

(213 mm)

8⅜"

(213 mm)

8⅜"

(213 mm)

8⅜"

(213 mm)

Front Side Back Back Side Latch

2¼"

(58 mm)

4⅞"

(124 mm)

1"

(25 mm)

1¼"

(32 mm)

Strike

Arc TroyGalaContinental Vintage Apogee

Features

Access Control TheInSync"L"unitlockprovidestrueresidentialentrylockfunctionality.Eachtimetheinside

lever is rotated the lock enters an unlocked state, eliminating the possibility of a lockout. Insertion

of the key and rotation of the outside lever provides ingress and always returns the lock into

the unlocked position. Inserting the key into the lock after egress, places the lock back into the

locked position. The inside thumbturn toggles the lock from unlocked to locked. With the Entry

Conguration,theInSync"L"unitlockbehaveslikeahotellock;thelockwillalwaysre-lock

behind a resident and the thumbturn works like a privacy switch.

Suite locks allow access to residents who have individual units behind the suite door. Suite locks

automatically re-lock and do not have a privacy feature (thumbturn); however with the Suite

EgressConguration,aSuitelockactslikeaUnitlockwherethekeyorthumbturnisusedto

manually re-lock the lock.

Unit or Suite locks can recognize up to 256 individual key IDs plus unlimited “Limited Use Key”

IDsatanytime.Commonlocksprovideaccesstocommonuseareas,suchastnesscenter,

parking garage, and pool.

Credential Locks use an RFID

memory

key that

employs special polymer construction

to repel moisture.

The

InSync

RFID key with dual

technologies includes standard HiTag technology along

with

Prox,

MIFARE®

or DESFire

® option.

Locking Device Options Tubular dead-locking latch bolt

Audit Trail

Unit locks store the last 200 entries to the lock and Suite locks store the last 100 entries, including

time,day,andkeyidenticationorusername.Commonlockscanstoreupto2,000entries.

Programming Locks and common readers are programmed and audited using a Utility Device

Key Levels Resident, zone, master, limited use, and emergency

Mechanical Features

Exterior Dimensions 8⅜"hx3⅛"wx2¼"d

Latch ½"tubulardeadlatch

Power Four (4) standard size AA alkaline batteries

Levers ADA Compliant

Note:VerifythatVintage,Gala,andArcleverscomplywithlocalrecoderequirements.

Standard Finishes Bright Chrome (26), Satin Chrome (26D), Bright Brass (U3), Satin Brass (U4)

Optional Finishes Satin Nickel (U15) or Dark Mahogany (10B)

Backset 2⅜"(60mm)or2¾"(70mm)

,adjustable—nospecialtoolsrequired

Weight 8 lbs. (3.62 kg)

Installation

Door Preparation Standard deadbolt

Door Thickness 1⅜"–2"(35mmto51mm)

Fire Rating ULcertiedforuseonre-rateddoorsuptoa20-minuterating

Environmental Indoor/outdoor approval: -31 ºF to 151 ºF (-35 ºC to 66 ºC)

Accessibility Standard ADA compliant levers and thumbturn

Warranty

Standard Warranty One year from the date of installation

Extended Warranty Kaba Service Plans (Platinum, Gold, Silver)

Kaba Access & Data Systems Americas

Winston-Salem NC 27105

1-800-849-8324

www.kaba-adsamericas.com KAA1229 0216

Bright Brass

Bright Chrome Satin Brass Dark MahoganySatin Nickel

Optional FinishesStandard Finishes

Satin Chrome
