Overview
The Saflok Quantum lock series offers a unique two-piece
modular design with a choice of inside escutcheon look.
Synonymous with superior performance, the lock series is
renowned for access control, life safety and security. The
Quantum Series locks are easy to use and work with
dormakaba Access Management Software.
Mobile Access
The Quantum RFID Series are Bluetooth Low Energy (BLE)
capable and can operate using the dormakaba Mobile
Access Solutions.
Applications
• Suitable for small to very large scale hotels
• Easily replaces existing mechanical or electronic door
locks throughout a facility
• Access control for guest rooms, common areas as well as
back-of-house
Security Features
• High security and tamperproof design
• 1” solid deadbolt (optional auto deadbolt)
• Staff monitoring - Keycard audits (RFID and smartcard)
• Tracking mortise for door ajar reporting
• Emergency access: emergency key, mechanical key
(QuantumII) and electronic override
Low Maintenance
• Batteries last up to 2 years
• Low battery indicator alerts staff
• Lock programming and audit records are not erased
during battery replacement
• Operates with a completely sealed contactless reader
(RFID only)
Access control management software
The Quantum Series locks are supported by dormakaba’s
robust access management software solution that
features an array of access control workflows for both
guest and staff access. Optionally, choose dormakaba’s
online access management solution for superior control
and monitoring.
Saflok QuantumII™
RFID
Saflok Quantum™
RFID
Saflok
Quantum™ adese
inside escutcheon
MT
inside escutcheon
Saflok Quantum™ Series
kabalodging.com saflokstore.com 1.800.999.6213 1.248.837.3700
Batteries
Alkaline -
Four AA battery pack
Battery life is up to 2 years
Low battery indicator: alerts staff that batteries need to be changed soon
Lock Operation
Date/Time Stamp Real-time; date and hours/minutes
Interrogation Obtain key usage reports from the lock by using a handheld unit at the door, or increase efficiency by performing a remote
Interrogation using Messenger (optional)
Pre-registered Keycards Keys can be made up to ten days in advance without cancelling current or arriving guests
Keycard Expiration
Configurable expiration dates; can be automatically set for check out date or manually applied when making key during check in process.
Passage Mode
Set by authorized keycard or Messenger system. Can also be configured to perform an automated/pre-defined passage mode time.
Lockout Mode Set by authorized keycard or Messenger system
Keycards Accepted Magstripe, smartcard or Mifare Classic (Quantum RFID and QuantumII) keycards (4 byte NUID)
Feedback Light indicators in reader
Diagnostics Light indicators and handheld display
Audit Trail Up to 4,000 events
Disability Feature RCU readers interface with automatic power operated doors for special openings
Privacy Override Emergency keycards
Certifications & Testing
Accessibility Standard ADA compliant levers (Code of Federal Regulations 28 CFR Part 36 – 1994 "ADA Standards for Accessible Design”)
BHMA/ANSI
Certified to be compliant with Grade One performance tests for “ANSI/BHMA A256.25-2013 Standard for Mortise Locks and
Latches,” and “ANSI/BHMA A256.13-2012 Standard for Electrified Locking Devices.” (Only locks tested and approved by non-
biased third-party test lab are allowed in the “BHMA Certified Products Directory” found at www.buildershardware.com)
Fire Rating
Listed for pre-prepared manufactured doors and certified for retrofitting on existing doors by Underwriters Laboratories for use on fire
doors having up to a three-hour rating.
a. U.L. Certification: GWVW.R12071 “Accessories for Single-point Locks and Latches and Fire Exit Hardware.” Evaluated in accordance
with UL 10B and UL 10C.
b. U.L. Listing: GYQS.R11247 “Electrically Controlled Single-point Locks and Latches.” Evaluated in accordance with UL 10B and UL 10C.
c. Also classified in accordance with Uniform Building Code Standard 7-2, “Fire Test of Door Assemblies” (1997)
Electronics FCC Part 15 Class A and CE directive 89/336/EEC compliant
Environmental
Operating Conditions
Indoor side: 32°F to 151°F (0°C to 66°C)
Outdoor side: -31°F to 151°F (-35°C to 66°C)
0% to 85% non-condensing humidity at 86°F (30°C)
Warranty
Standard Warranty Two years
Support Programs dormakaba Service Plans (Platinum, Gold, Silver)
Mechanical Features
Description Electronic mortise lockset with 1" (25.4mm) throw deadbolt and ⁄" (15.9mm) dead-locking latch bolt
Handing Factory-handed mortise (left, right, left reverse, right reverse)
Lever
ADA Compliant
Arc TroyGalaContinental Elevon
Elevon
ADA Compliant
Apogee
Deadbolt 1" (25.4mm) throw deadbolt and ⁄" (15.9mm) dead-locking latch bolt
Door Thickness 1¾" (44.5mm) to 2⅛" (53.98mm) for standard product
Weight Approx. 8.0 lbs with hardware
Housing Construction Escutcheons: Zinc
Levers: Brass, zinc, or stainless steel
Standard Finishes Bright chrome, bright brass, satin chrome, satin brass, dark mahogany
Inside Trim Options Optional äd se or MT inside escutcheon
Standard Backset 2¾" (69.9mm) from door edge to lever
Locking Options
ANSI lock case with 1¼” or 1” lock front mortise
Options: automatic deadbolt, door ajar, MKO
European lock case mortise (20 x 165 mm) with 20 x 233 mm lock front mortise
Online
Configurations
Messenger Ready DAJ mortise (ANSI lock case)
Standard (stand alone) inside escutcheon
Messenger Online Lock controller board with Messenger capability
DAJ mortise (ANSI lock case)
Inside escutcheon equipped with Messenger module
Mobile Access Options (Quantum RFID Series)
BLE compatible
BLE ready
BLE enabled
Standard Lock. Upgradable to BLE by adding BLE connector cable, end cap and BLE module
Upgradable to BLE with BLE module
End cap with BLE module included, no further upgrades needed
M3572_04-17
